Base class for NURBS-based FEM simulators. More...

#include <SIMbase.h>

Inheritance diagram for SIMbase:

[legend]

Collaboration diagram for SIMbase:

[legend]

Classes
struct	DumpData
	A struct with data for system matrix/vector dumps. More...

Public Member Functions
virtual	~SIMbase ()
	The destructor frees the dynamically allocated objects.

bool	readModel (const char *fileName)
	Reads model data from the specified input file *fileName. More...

virtual bool	createFEMmodel (char resetNumb)=0
	Creates the computational FEM model from the spline patches.

virtual void	clearProperties ()
	Initializes the property containers of the model. More...

virtual void	initForSingleStep ()
	Interface for app-specific single-step simulation initialisation.

virtual void	initForMultiStep ()
	Interface for app-specific multi-step simulation initialisation.

virtual bool	preprocessC (const IntVec &ignored, bool fixDup, double time0)
	Performs some pre-processing tasks on the FE model. More...

virtual bool	merge (SIMbase that, const std::map< int, int > old2new=nullptr, int poff=0)
	Merges the global equation system of that simulator with this. More...

bool	initSystem (LinAlg::MatrixType mType, size_t nMats=1, size_t nVec=1, size_t nScl=0, bool withRF=false)
	Allocates the system matrices of the FE problem to be solved. More...

bool	initSystem (const SIMbase *that)
	Lets this simulator share equation system with that simulator.

void	initLHSbuffers ()
	Initializes left-hand-side element matrix buffers for integrand.

bool	setAssociatedRHS (size_t iMat, size_t iVec)
	Associates a system vector to a system matrix. More...

bool	setMode (int mode, bool needIntegr=true, bool resetSol=false)
	Defines the solution mode before the element assembly is started. More...

void	setIntegrationPrm (unsigned short int i, double prm)
	Initializes an integration parameter for the integrand. More...

void	setQuadratureRule (size_t ng, bool redimBuffers=false, bool printQP=false)
	Defines the spatial numerical integration scheme to use. More...

virtual bool	printProblem () const
	Prints out problem-specific data to the log stream.

const IntegrandBase *	getProblem () const
	Returns a pointer to the problem-specific data object.

virtual ASM::InterfaceChecker *	getInterfaceChecker (size_t) const
	Returns interface checker type for model.

void	clearProblem ()
	Clears the reference to the problem-specific data object. More...

virtual std::string	getName () const
	Returns the name of this simulator. More...

virtual bool	mixedProblem () const
	Returns whether a mixed formulation is used (used by HDF5 output).

const LinSolParams *	getSolParams () const
	Returns the linear equation solver parameters (for PETSc).

virtual unsigned short int	getNoParamDim () const =0
	Returns the number of parameter dimensions in the model.

virtual size_t	getNoSpaceDim () const
	Returns the number of spatial dimensions in the model.

size_t	getNoFields (int basis=0) const
	Returns the number of primary solution fields. More...

size_t	getNoDOFs (bool subSim=false) const
	Returns the model size in terms of number of DOFs.

size_t	getNoNodes (int basis=0) const
	Returns the model size in terms of number of unique nodes. More...

size_t	getNoElms (bool includeXelms=false, bool includeZelms=false) const
	Returns the model size in terms of number of elements. More...

size_t	getNoSolutions (bool allocated=false) const
	Returns the number of solution vectors.

int	getNoPatches () const
	Returns the total number of patches in the model.

size_t	getNoEquations () const
	Returns the number of unknowns in the linear equation system.

size_t	getNoConstraints () const
	Returns the number of constraint equations in the model.

virtual size_t	getNoRHS () const
	Returns the number of right-hand-side vectors.

unsigned char	getNoBasis () const
	Returns the number of bases in the model.

char	getNodeType (int inod) const
	Returns the type (DOF classification) of the specified global node.

Vec4	getNodeCoord (int inod) const
	Returns the spatial coordinates of the specified global node.

bool	isFixed (int inod, int dof=123) const
	Returns true if all DOFs in the specified global node are fixed.

int	getGlobalNode (int node) const
	Returns the global node number from a process-local node number.

int	getLocalNode (int node) const
	Returns the process-local node number from a global node number.

bool	getElmNodes (IntVec &mnpc, int iel) const
	Finds the Matrix of Nodal Point Correspondance for element iel.

virtual std::vector< IntVec >	getElmConnectivities () const =0
	Obtain element-element connectivities.

void	getBoundaryNodes (int pcode, IntVec &glbNodes, std::vector< Vec3 > *XYZ=nullptr) const
	Finds the list of global nodes associated with a boundary. More...

int	findClosestNode (const Vec3 &) const
	Finds the node that is closest to the given point X.

IntVec	getNodeSet (const std::string &setName) const
	Returns a predefined node set. More...

bool	initDirichlet (double time=0.0)
	Initializes time-dependent in-homogeneous Dirichlet coefficients. More...

bool	hasTimeDependentDirichlet () const
	Checks for time-dependent in-homogeneous Dirichlet conditions.

virtual bool	updateDirichlet (double time=0.0, const Vector *prevSol=nullptr)
	Updates the time-dependent in-homogeneous Dirichlet coefficients. More...

virtual bool	updateConfiguration (const Vector &)
	Updates problem-dependent state based on the current solution.

virtual bool	updateRotations (const RealArray &, double=0.0)
	Updates the nodal rotations for problems with rotational DOFs.

bool	updateGrid (const RealArray &displ)
	Updates the grid coordinates. More...

bool	updateGrid (const std::string &field)
	Updates the grid coordinates. More...

void	setRefined (int nref)
	Sets the refinement status (for restart of adaptive simulations). More...

int	getRefined () const
	Returns current refinement status.

bool	hasElementActivator () const
	Returns true if an element activation function is specified.

void	updateForNewElements (Vector &solution, const TimeDomain &time) const
	Modifies the current solution vector when activating elements. More...

virtual bool	assembleSystem (const TimeDomain &time, const Vectors &prevSol, bool newLHSmatrix=true, bool poorConvg=false)
	Administers assembly of the linear equation system. More...

bool	assembleSystem (double t0=0.0, const Vectors &pSol=Vectors())
	Administers assembly of the linear equation system. More...

bool	extractLoadVec (Vector &loadVec, size_t idx=0, const char *hd=nullptr) const
	Extracts the assembled load vector for inspection/visualization. More...

bool	extractScalars (RealArray &values) const
	Extracts the assembled global scalar quantities.

double	extractScalar (size_t idx=0) const
	Extracts an assembled global scalar quantity.

bool	applyDirichlet (Vector &glbVec) const
	Applies the Dirichlet conditions to given vector. More...

bool	solveEqSystem (Vector &solution, size_t idxRHS, double rCond, int printSol=0, bool dumpEqSys=false, const char compName="displacement")
	Solves the assembled linear system of equations for a given load. More...

virtual bool	solveSystem (Vector &solution, int printSol, double rCond, const char compName="displacement", size_t idxRHS=0)
	Solves the assembled linear system of equations for a given load. More...

bool	solveSystem (Vector &solution, int printSol=0, const char *compName="displacement")
	Solves the assembled linear system of equations for a given load. More...

bool	solveSystem (Vectors &solution, int printSol=0, const char *cmpName="displacement")
	Solves a linear system of equations with multiple right-hand-sides. More...

void	getWorstDofs (const Vector &x, const Vector &r, size_t nWorst, double eps, int iteNorm, std::map< std::pair< int, int >, RealArray > &worst) const
	Finds the DOFs showing the worst convergence behavior. More...

virtual void	iterationNorms (const Vector &x, const Vector &r, double &eNorm, double &rNorm, double &dNorm) const
	Evaluates some iteration norms for convergence assessment. More...

double	solutionNorms (const Vector &x, double inf=nullptr, size_t ind=nullptr, size_t nf=0, char type='D') const
	Evaluates some norms of the primary solution vector. More...

bool	solutionNorms (const TimeDomain &time, const Vectors &psol, const Vectors &ssol, Vectors &gNorm, Matrix eNorm=nullptr, const char name=nullptr)
	Integrates some solution norm quantities. More...

bool	solutionNorms (const TimeDomain &time, const Vectors &psol, Vectors &gNorm, Matrix *eNorm=nullptr)
	Integrates some solution norm quantities. More...

bool	solutionNorms (const Vector &psol, const Vectors &ssol, Matrix &eNorm, Vectors &gNorm, const char *name=nullptr)
	Integrates some solution norm quantities. More...

bool	solutionNorms (const Vector &psol, Matrix &eNorm, Vectors &gNorm)
	Integrates some solution norm quantities. More...

bool	solutionNorms (const Vector &psol, const Vectors &ssol, Vectors &gNorm, const char *name=nullptr)
	Integrates some solution norm quantities. More...

virtual void	printStep (int istep, const TimeDomain &time) const
	Prints out load/time step identification. More...

virtual void	printSolutionSummary (const Vector &solution, int printSol=0, const char *compName=nullptr, std::streamsize outPrec=0)
	Prints a summary of the calculated solution to std::cout. More...

bool	getCurrentReactions (RealArray &RF, const Vector &psol, int pcode=0) const
	Computes the total reaction forces in the model. More...

bool	haveReactions (int pcode=0) const
	Checks for total reaction forces associated with a boundary. More...

virtual const RealArray *	getReactionForces () const
	Returns current reaction force container.

bool	systemModes (std::vector< Mode > &solution, int nev, int ncv, int iop, double shift, size_t iA=0, size_t iB=1)
	Performs a generalized eigenvalue analysis of the assembled system. More...

bool	systemModes (std::vector< Mode > &solution, size_t iA=0, size_t iB=1)
	Performs a generalized eigenvalue analysis of the assembled system. More...

virtual bool	haveBoundaryReactions (bool=false) const
	Returns whether reaction forces are to be computed or not.

bool	assembleForces (const Vector &solution, double t0, RealArray R, Vector S=nullptr)
	Assembles reaction and interface forces for specified boundaries. More...

virtual bool	project (Matrix &ssol, const Vector &psol, SIMoptions::ProjectionMethod method=SIMoptions::GLOBAL, const TimeDomain &time=TimeDomain()) const
	Projects the secondary solution associated with a primary solution. More...

bool	project (Vector &ssol, const Vector &psol, SIMoptions::ProjectionMethod method=SIMoptions::GLOBAL, size_t iComp=0) const
	Projects the secondary solution associated with a primary solution. More...

bool	projectAnaSol (Vector &ssol, SIMoptions::ProjectionMethod method) const
	Projects the analytical secondary solution, if any. More...

bool	project (RealArray &values, const FunctionBase *f, int basis=1, int iField=0, int nFields=1, SIMoptions::ProjectionMethod method=SIMoptions::GLOBAL, double time=0.0) const
	Projects a function onto the specified basis. More...

bool	evalSecondarySolution (Matrix &field, int pindx) const
	Evaluates the secondary solution field for specified patch. More...

virtual bool	fieldProjections () const
	Returns whether projections must be handled through fields or not.

virtual bool	haveAnaSol () const
	Returns whether an analytical solution is available or not.

virtual bool	haveDualSol () const
	Returns whether a dual solution is available or not.

NormBase *	getNormIntegrand () const
	Returns a pointer to a norm integrand object for this simulator. More...

ForceBase *	getBoundaryForceIntegrand (const Vec3 *X0=nullptr) const
	Returns a pointer to a force integrand object for this simulator. More...

ForceBase *	getNodalForceIntegrand () const
	Returns a pointer to a force integrand object for this simulator. More...

const SAM *	getSAM () const
	Returns a const pointer to the SAM object of this simulator.

void	registerDependency (const std::string &name, SIMdependency *sim, short int nvc=1, unsigned char basis=1)
	Registers a dependency on a field from another SIM object. More...

bool	extractPatchSolution (const Vectors &sol, size_t pindx) const
	Extracts all local solution vector(s) for a specified patch. More...

size_t	extractPatchSolution (const RealArray &sol, RealArray &vec, const ASMbase *pch, unsigned char nndof=0, unsigned char basis=0) const
	Extracts a local solution vector for a specified patch. More...

bool	injectPatchSolution (RealArray &sol, const RealArray &vec, const ASMbase *pch, unsigned char nndof=0, unsigned char basis=0) const
	Injects a patch-wise solution vector into the global vector. More...

bool	extractPatchElmRes (const Matrix &glbRes, Matrix &elRes, int pindx) const
	Extracts element results for a specified patch. More...

int	getLocalPatchIndex (int patchNo) const
	Returns the local patch index for the given global patch number. More...

const PatchVec &	getFEModel () const
	Returns a const reference to our FEM model.

ASMbase *	getPatch (int idx, bool glbIndex=false) const
	Returns a pointer to a specified patch of our FEM model. More...

bool	setPatchMaterial (size_t patch) const
	Initializes material properties for the given patch.

const std::map< int, int > &	getGlob2LocMap () const
	Returns a const reference to our global-to-local node mapping.

PropertyVec::const_iterator	begin_prop () const
	Returns the beginning of the property array.

PropertyVec::const_iterator	end_prop () const
	Returns the end of the property array.

SystemMatrix *	getRayleighDampingMatrix (size_t iM=1, size_t iK=0) const
	Returns current Rayleigh system damping matrix. More...

SystemMatrix *	getLHSmatrix (size_t idx=0, bool copy=false) const
	Returns current system left-hand-side matrix.

SystemVector *	getRHSvector (size_t idx=0, bool copy=false) const
	Returns current system right-hand-side vector.

void	addToRHSvector (size_t idx, const SystemVector &vec, double scale=1.0)
	Adds a system vector to the given right-hand-side vector.

RealFunc *	getSclFunc (int code) const
	Returns a scalar function associated with code.

void	setMDflag (char flag)
	Sets the multi-dimension simulator sequence flag.

bool	isFirst () const
	Returns true, if this is the equation system owner.

void	dumpEqSys (bool initialBlankLine=false)
	Dumps left-hand-side matrix and right-hand-side vector to file.

void	dumpSolVec (const Vector &x, bool isExpanded=true, bool expOnly=false)
	Dumps a solution vector to file.

virtual int	printNRforces (const IntVec &={}) const
	Prints out nodal reaction forces to the log stream.

virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc, const PatchVec &patches, char diffBasis=0, int component=1)
	Registers a dependency on a field from another SIM object. More...

virtual void	registerDependency (SIMdependency sim, const std::string &name, short int nvc, const PatchVec &patches, const int MADOF)
	Registers a dependency on a field from another SIM object. More...

virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc=1)
	Registers a dependency on a field from another SIM object. More...

Public Member Functions inherited from SIMadmin
virtual	~SIMadmin ()
	Empty destructor.

virtual bool	read (const char *fileName)
	Reads model data from the specified input file *fileName.

virtual bool	parse (char *keyWord, std::istream &is)
	Parses a data section from an input stream.

virtual bool	parse (const tinyxml2::XMLElement *elem)
	Parses a data section from an XML document.

virtual bool	preprocess (const IntVec &ignored={}, bool fixDup=false)
	Performs some pre-processing tasks on the FE model.

const ProcessAdm &	getProcessAdm () const
	Returns the parallel process administrator.

int	getGlobalProcessID () const
	Returns the global process ID. More...

const std::string &	getHeading () const
	Returns the simulator heading.

void	setHeading (const std::string &heading)
	Defines the simulator heading.

void	printHeading (int &supStep) const
	Prints the heading of this simulator, if any, to IFEM::cout.

Public Member Functions inherited from XMLInputBase
bool	readXML (const char *fileName, bool verbose=true)
	Reads an XML input file. More...

bool	loadXML (const char *xml)
	Loads data from an XML-formatted text string. More...

Public Member Functions inherited from SIMdependency
virtual	~SIMdependency ()
	Empty destructor.

virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc, const PatchVec &patches, char diffBasis=0, int component=1)
	Registers a dependency on a field from another SIM object. More...

virtual void	registerDependency (SIMdependency sim, const std::string &name, short int nvc, const PatchVec &patches, const int MADOF)
	Registers a dependency on a field from another SIM object. More...

virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc=1)
	Registers a dependency on a field from another SIM object. More...

bool	fillField (const std::string &name, const std::vector< double > &values)
	Initializes the nodal vector of named field in this SIM.

virtual std::vector< double > *	getField (const std::string &name)
	Returns the nodal vector of named field in this SIM.

virtual const std::vector< double > *	getField (const std::string &name) const
	Returns the nodal vector of named field in this SIM.

const std::vector< double > *	getDependentField (const std::string &name) const
	Returns the nodal vector of named field in a dependent SIM.

ASMbase *	getDependentPatch (const std::string &name, int pindx) const
	Returns a spline patch associated with a dependent field.

void	registerField (const std::string &name, const std::vector< double > &vec)
	Registers a named field with associated nodal vector in this SIM.

virtual bool	hasIC (const std::string &) const
	Checks whether a named initial condition is present.

Static Public Attributes
static bool	ignoreDirichlet = false
	Set to true for free vibration analysis.

static bool	preserveNOrder = false
	Set to true to preserve node ordering.

Static Public Attributes inherited from SIMadmin
static int	msgLevel = 2
	Controls the console output amount during solving.

Protected Types
typedef std::map< int, RealFunc * >	SclFuncMap
	Scalar field container.

typedef std::map< int, VecFunc * >	VecFuncMap
	Vector field container.

typedef std::map< int, TractionFunc * >	TracFuncMap
	Traction field container.

typedef std::multimap< int, IntegrandBase * >	IntegrandMap
	Property code to integrand map.

Protected Types inherited from SIMadmin
using	IntVec = std::vector< int >
	Convenience alias.

Protected Member Functions
	SIMbase (IntegrandBase *itg)
	The constructor initializes the pointers to dynamic data members.

VecFunc *	getVecFunc (size_t patch, Property::Type ptype) const
	Returns a vector function associated with given patch and property. More...

virtual bool	addConstraint (int patch, int lndx, int ldim, int dirs, int code, int &ngnod, char basis=1, bool ovrD=false)
	Preprocesses a user-defined Dirichlet boundary property. More...

virtual void	preprocessA ()
	Preprocessing performed before the FEM model generation.

virtual bool	preprocessBeforeAsmInit (int &)
	Specialized preprocessing performed before assembly initialization.

virtual bool	preprocessB ()
	Preprocessing performed after the system assembly initialization.

virtual void	preprocessResultPoints ()=0
	Preprocesses the result sampling points.

int	renumberNodes (bool renumMNPC=false)
	Renumbers the global node numbers after resolving patch topology. More...

virtual bool	renumberNodes (const std::map< int, int > &)
	Interface for renumbering of app-specific node number tables.

virtual bool	extractPatchSolution (IntegrandBase *problem, const Vectors &sol, size_t pindx) const
	Extracts all local solution vector(s) for a specified patch. More...

char	getMDflag () const
	Returns the multi-dimension simulator sequence flag.

virtual void	shiftGlobalNums (int, int)
	Shifts global node and element numbers by constant offsets.

virtual bool	initMaterial (size_t)
	Initializes material properties for integration of interior terms.

virtual bool	initBodyLoad (size_t)
	Initializes the body load properties for current patch.

virtual bool	initNeumann (size_t)
	Initializes for integration of Neumann terms for a given property.

virtual bool	assembleDiscreteTerms (const IntegrandBase *, const TimeDomain &)
	Assembles problem-dependent discrete terms, if any.

virtual bool	assembleDiscreteItems (const IntegrandBase *itg, const TimeDomain &time, const Vectors &)
	Assembles problem-dependent discrete terms, if any. More...

virtual double	externalEnergy (const Vectors &psol, const TimeDomain &) const
	Computes (possibly problem-dependent) external energy contribution.

virtual bool	postProcessNorms (Vectors &, Matrix *)
	Applies app-specific post-processing on norms.

void	generateThreadGroups (const Property &p, bool silence=false)
	Generates element groups for multi-threading of boundary integrals. More...

void	changeNumThreads ()
	Called if number of threads changes.

bool	addMADOF (unsigned char basis, unsigned char nndof, bool other=true)
	Adds a MADOF with an extraordinary number of DOFs on a given basis. More...

double *	theExtEnerg ()
	Returns a pointer to the external energy path integral value.

const double *	getExtEnerg () const
	Returns a const pointer to the external energy path integral value.

Protected Member Functions inherited from SIMadmin
	SIMadmin (const char *heading=nullptr)
	The default constructor initializes the process administrator.

	SIMadmin (SIMadmin &anotherSIM)
	Copy constructor.

Protected Member Functions inherited from XMLInputBase
const tinyxml2::XMLElement *	loadFile (tinyxml2::XMLDocument &doc, const char *fileName, bool verbose=false)
	Loads an XML input file into a tinyxml2::XMLDocument object. More...

virtual const char **	getPrioritizedTags () const
	Returns a list of prioritized XML-tags.

Protected Member Functions inherited from SIMdependency
	SIMdependency ()
	The constructor is protected to allow sub-class instances only.

bool	extractPatchDependencies (IntegrandBase *problem, const PatchVec &model, size_t pindx) const
	Extracts local solution vector(s) for all dependent fields. More...

Protected Attributes
unsigned char	nsd
	Number of spatial dimensions.

PatchVec	myModel
	The actual NURBS/spline model.

PropertyVec	myProps
	Physical property mapping.

SclFuncMap	myScalars
	Scalar property fields.

VecFuncMap	myVectors
	Vector property fields.

TracFuncMap	myTracs
	Traction property fields.

IntegrandBase *	myProblem
	The main integrand of this simulator.

IntegrandMap	myInts
	Set of all integrands involved.

AnaSol *	mySol
	Analytical/Exact solution.

FunctionBase *	dualField
	Dual solution field (extraction function)

std::vector< FunctionBase * >	extrFunc
	Extraction functions for VCP.

int	nGlbNodes
	Total number of unique nodes in the model. More...

int	isRefined
	Indicates if the model is adaptively refined.

bool	lagMTOK
	Indicates if global multipliers is OK with multithreading.

bool	fixZeros
	If true, constrain zero pivots before solving.

std::vector< DumpData >	lhsDump
	Coefficient matrix dump specifications.

std::vector< DumpData >	rhsDump
	Right-hand-side vector dump specifications.

std::vector< DumpData >	solDump
	Solution vector dump specifications.

int	nGlPatches
	Number of global patches.

IntVec	myPatches
	Global patch numbers for current processor.

IntVec	myLoc2Glb
	Local-to-global node number mapping.

std::map< int, int >	myGlb2Loc
	Global-to-local node number mapping.

const std::map< int, int > *	g2l
	Pointer to global-to-local node mapping.

std::map< int, int >	myDegenElm
	Degenerated elements mapping.

std::set< int >	myDupNodes
	Set of duplicated nodes.

AlgEqSystem *	myEqSys
	The actual linear equation system.

SAM *	mySam
	Auxiliary data for FE assembly management.

LinSolParams *	mySolParams
	Input parameters for PETSc.

LinSolParams *	myGl2Params
	Input parameters for PETSc, for L2 projection.

Protected Attributes inherited from SIMadmin
ProcessAdm	adm
	Parallel administrator.

int	myPid
	Processor ID in parallel simulations.

int	nProc
	Number of processors in parallel simulations.

std::string	myHeading
	Heading written before reading the input file.

Private Member Functions
const IntVec &	getMADOF (unsigned char basis, unsigned char nndof) const
	Returns an extraordinary MADOF array. More...

Private Attributes
size_t	nIntGP
	Number of interior integration points in the whole model.

size_t	nBouGP
	Number of boundary integration points in the whole model.

size_t	nDofS
	Number of degrees of freedom in this sub-simulator.

char	mdFlag
	Sequence flag for multi-dimensional simulators.

std::map< int, IntVec >	extraMADOFs
	Additional MADOF arrays with varying DOF counts per node.

double	extEnergy
	Path integral of external forces.

Vector	prevForces
	Reaction forces of previous time step.

Additional Inherited Members
Public Types inherited from SIMdependency
typedef std::vector< ASMbase * >	PatchVec
	Spline patch container.

Public Attributes inherited from SIMadmin
SIMoptions &	opt
	Simulation control parameters.

Detailed Description

Base class for NURBS-based FEM simulators.

This class incapsulates data and methods need for solving partial differential equations using NURBS-based finite elements. It only contains the problem-independent data and methods. Sub-classes are derived with additional info regarding the problem to solve.

Member Function Documentation

◆ addConstraint()

bool SIMbase::addConstraint	(	int	patch,
		int	lndx,
		int	ldim,
		int	dirs,
		int	code,
		int &	ngnod,
		char	basis = `1`,
		bool	ovrD = `false`
	)

protectedvirtual

Preprocesses a user-defined Dirichlet boundary property.

Parameters

[in]	patch	1-based index of the patch to receive the property
[in]	lndx	Local index of the boundary item to receive the property
[in]	ldim	Dimension of the boundary item to receive the property
[in]	dirs	Which local DOFs to constrain
[in]	code	In-homogeneous Dirichlet condition property code
	ngnod	Total number of global nodes in the model (might be updated)
[in]	basis	Which basis to apply the constraint to (mixed methods)
[in]	ovrD	If true, override conflicting Dirichlet conditions

This method only deals with constraints assigned directly to some (or all) FE nodes of the specified patch. The method needs to be overridden by the dimension-specific sub-classes to handle constraints on other topological entities, such as boundary edges and faces.

Reimplemented in SIM1D, SIM3D, and SIM2D.

References IFEM::cout, getNodeSet(), getNoParamDim(), and myModel.

Referenced by SIM2D::addConstraint(), SIM3D::addConstraint(), SIM1D::addConstraint(), and preprocessC().

◆ addMADOF()

bool SIMbase::addMADOF	(	unsigned char	basis,
		unsigned char	nndof,
		bool	other = `true`
	)

protected

Adds a MADOF with an extraordinary number of DOFs on a given basis.

Parameters

[in]	basis	The basis to specify number of DOFs for
[in]	nndof	Number of nodal DOFs on the given basis
[in]	other	If true, include other bases in MADOF as well

References extraMADOFs, getNoNodes(), and myModel.

◆ applyDirichlet()

bool SIMbase::applyDirichlet ( Vector & glbVec ) const

Applies the Dirichlet conditions to given vector.

Parameters

[out] glbVec Global vector in DOF-order

References SAM::applyDirichlet(), and mySam.

◆ assembleDiscreteItems()

virtual bool SIMbase::assembleDiscreteItems	(	const IntegrandBase *	itg,
		const TimeDomain &	time,
		const Vectors &
	)

inlineprotectedvirtual

Assembles problem-dependent discrete terms, if any.

Override this method if the discrete terms also depend on current solution state. By default it forwards to the state-less method assembleDiscreteTerms() which can be overridden if no state-dependency.

References assembleDiscreteTerms().

Referenced by assembleSystem().

◆ assembleForces()

bool SIMbase::assembleForces	(	const Vector &	solution,
		double	t0,
		RealArray *	R,
		Vector *	S = `nullptr`
	)

Assembles reaction and interface forces for specified boundaries.

Parameters

[in]	solution	Current primary solution vector
[in]	t0	Current time (for time-dependent loads)
[out]	R	Nodal reaction force container
[out]	S	Nodal interface force container

References SIMadmin::adm, assembleSystem(), myEqSys, myProblem, mySam, setMode(), and IntegrandBase::setSecondaryInt().

◆ assembleSystem() [1/2]

bool SIMbase::assembleSystem	(	const TimeDomain &	time,
		const Vectors &	prevSol,
		bool	newLHSmatrix = `true`,
		bool	poorConvg = `false`
	)

virtual

Administers assembly of the linear equation system.

Parameters

[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	prevSol	Previous primary solution vectors in DOF-order
[in]	newLHSmatrix	If false, only integrate the RHS vector
[in]	poorConvg	If true, the nonlinear driver is converging poorly

This method constitutes the main core of the element assembly process, to establish the global linear system of equations to be solved at each time/load step (or iteration if nonlinear problem).

The method loops over all the Integrand objects defining the problem to be solved, and for each Integrand it loops over the ASMbase patches defining the FE model for doing the numerical integration. It also has separate loops for handling the boundary integrals (for Neumann and Robin type boundary conditions).

References assembleDiscreteItems(), utl::vector< T >::clear(), IFEM::cout, dualField, ASMbase::empty(), extractPatchSolution(), AlgEqSystem::finalize(), GlobalIntegral::finalize(), fixZeros, ASMbase::getElementSet(), IntegrandBase::getExtractionField(), getInterfaceChecker(), IntegrandBase::getMode(), ASMbase::getNoParamDim(), getPatch(), ASMbase::idx, initBodyLoad(), AlgEqSystem::initialize(), GlobalIntegral::initialize(), initMaterial(), AnaSol::initPatch(), FunctionBase::initPatch(), ASMbase::integrate(), ASMbase::integrateEdge(), Integrand::INTERFACE_TERMS, mdFlag, SIMadmin::msgLevel, myEqSys, myInts, myModel, myProblem, myProps, mySol, and PROFILE1.

Referenced by AdaptiveSIM::assembleAndSolveSystem(), assembleForces(), TimeIntegration::SIMImplicitLMM< Solver >::LMMNonLinSIM::assembleSystem(), NonLinSIM::assembleSystem(), assembleSystem(), NewmarkSIM::initAcc(), EigenModeSIM::initSol(), NewmarkSIM::solveIteration(), and NewmarkSIM::solveStep().

◆ assembleSystem() [2/2]

bool SIMbase::assembleSystem	(	double	t0 = `0.0`,
		const Vectors &	pSol = `Vectors()`
	)

inline

Administers assembly of the linear equation system.

Parameters

[in]	t0	Time for evaluation of time-dependent property functions
[in]	pSol	Primary solution vectors in DOF-order

Use this version for linear/stationary problems only.

References assembleSystem().

◆ clearProblem()

void SIMbase::clearProblem ( )

inline

Clears the reference to the problem-specific data object.

This method is used when the same IntegrandBase object is shared by several SIMbase objects, to avoid that it is deleted more than once.

References myProblem.

◆ clearProperties()

void SIMbase::clearProperties ( )

virtual

Initializes the property containers of the model.

Use this method to clear the model before re-reading the input file in the refinement step of an adaptive simulation.

Reimplemented in SIMoutput.

References SIMadmin::adm, DomainDecomposition::clear(), ProcessAdm::dd, dualField, extraMADOFs, extrFunc, myGlb2Loc, myInts, myModel, myPatches, myProps, myScalars, myTracs, myVectors, and nGlbNodes.

Referenced by SIMoutput::clearProperties(), and ~SIMbase().

◆ evalSecondarySolution()

bool SIMbase::evalSecondarySolution	(	Matrix &	field,
		int	pindx
	)		const

Evaluates the secondary solution field for specified patch.

Parameters

[out]	field	Control point values of the secondary solution field
[in]	pindx	Local patch index to evaluate solution field for

The secondary solution is derived from the primary solution, which is assumed to be stored within the Integrand object myProblem. The solution is evaluated at the Greville points and then projected onto the spline basis to obtain the control point values.

References ASMbase::evalSolution(), getPatch(), myProblem, and setPatchMaterial().

Referenced by HDF5Writer::writeSIM().

◆ extractLoadVec()

bool SIMbase::extractLoadVec	(	Vector &	loadVec,
		size_t	idx = `0`,
		const char *	hd = `nullptr`
	)		const

Extracts the assembled load vector for inspection/visualization.

Parameters

[out]	loadVec	Global load vector in DOF-order
[in]	idx	Index to the system vector to extract
[in]	hd	Header for outprint of resultant

References IFEM::cout, SAM::expandSolution(), SAM::getNodeDOFs(), SAM::getNoNodes(), AlgEqSystem::getVector(), myEqSys, mySam, and SAM::printVector().

Referenced by NonLinSIM::lineSearch(), NewmarkSIM::solveIteration(), NonLinSIM::solveIteration(), and NewmarkSIM::solveStep().

◆ extractPatchElmRes()

bool SIMbase::extractPatchElmRes	(	const Matrix &	glbRes,
		Matrix &	elRes,
		int	pindx
	)		const

Extracts element results for a specified patch.

Parameters

[in]	glbRes	Global element result array
[out]	elRes	Patch-level element result array
[in]	pindx	Local patch index to extract element results for

References utl::matrixBase< T >::empty(), ASMbase::extractElmRes(), and getPatch().

Referenced by HDF5Writer::writeKnotspan(), and HDF5Writer::writeSIM().

◆ extractPatchSolution() [1/3]

size_t SIMbase::extractPatchSolution	(	const RealArray &	sol,
		RealArray &	vec,
		const ASMbase *	pch,
		unsigned char	nndof = `0`,
		unsigned char	basis = `0`
	)		const

Extracts a local solution vector for a specified patch.

Parameters

[in]	sol	Global primary solution vector in DOF-order
[out]	vec	Local solution vector associated with specified patch
[in]	pch	The patch to extract solution vector for
[in]	nndof	Number of DOFs per node (optional)
[in]	basis	Basis to extract for (optional)

Returns: Total number of DOFs in the patch (first basis only if mixed)

References ASMbase::empty(), ASMbase::extractNodalVec(), ASMbase::extractNodeVec(), extraMADOFs, SAM::getMADOF(), getMADOF(), ASMbase::getNodeID(), ASMbase::getNodeType(), ASMbase::getNoFields(), SAM::getNoNodes(), ASMbase::getNoNodes(), myModel, and mySam.

◆ extractPatchSolution() [2/3]

bool SIMbase::extractPatchSolution	(	const Vectors &	sol,
		size_t	pindx
	)		const

inline

Extracts all local solution vector(s) for a specified patch.

Parameters

[in]	sol	Global primary solution vectors in DOF-order
[in]	pindx	Local patch index to extract solution vectors for

References extractPatchSolution(), and myProblem.

◆ extractPatchSolution() [3/3]

bool SIMbase::extractPatchSolution	(	IntegrandBase *	problem,
		const Vectors &	sol,
		size_t	pindx
	)		const

protectedvirtual

Extracts all local solution vector(s) for a specified patch.

Parameters

[in]	problem	The integrand to receive patch-level solution vectors
[in]	sol	Global primary solution vectors in DOF-order
[in]	pindx	Local patch index to extract solution vectors for

This method is typically invoked before ASMbase::integrate() on the specified patch, in order to extract all patch-level vector quantities needed by the Integrand. This also includes any dependent vectors from other simulator classes that have been registered. All patch-level vectors are stored within the provided integrand.

References utl::vector< T >::clear(), ASMbase::extractNodalVec(), SIMdependency::extractPatchDependencies(), ASMbase::getGlobalNodeNums(), SAM::getMADOF(), IntegrandBase::getNoSolutions(), getPatch(), IntegrandBase::getSolution(), IntegrandBase::initNodeMap(), myModel, and mySam.

Referenced by assembleSystem(), compute(), extractPatchSolution(), SIM::integrate(), project(), SIMinput::refine(), solutionNorms(), updateGrid(), SIMoutput::writeGlvP(), SIMoutput::writeGlvS(), and HDF5Writer::writeSIM().

◆ generateThreadGroups()

void SIMbase::generateThreadGroups	(	const Property &	p,
		bool	silence = `false`
	)

protected

Generates element groups for multi-threading of boundary integrals.

Parameters

[in]	p	Property object identifying a patch boundary
[in]	silence	If true, suppress threading group outprint

References ASMbase::empty(), ASMbase::generateThreadGroups(), ASMbase::getNoParamDim(), getPatch(), lagMTOK, Property::ldim, Property::lindx, and Property::patch.

◆ getBoundaryForceIntegrand()

ForceBase * SIMbase::getBoundaryForceIntegrand ( const Vec3 * X0 = nullptr ) const

Returns a pointer to a force integrand object for this simulator.

Note: The object is allocated dynamically and has therefore to be manually deleted before the variable receiving the pointer value goes out of scope.

References IntegrandBase::getForceIntegrand(), myProblem, and mySol.

Referenced by SIM::getBoundaryForce().

◆ getBoundaryNodes()

void SIMbase::getBoundaryNodes	(	int	pcode,
		IntVec &	glbNodes,
		std::vector< Vec3 > *	XYZ = `nullptr`
	)		const

Finds the list of global nodes associated with a boundary.

Parameters

[in]	pcode	Property code identifying the boundary
[out]	glbNodes	Global node numbers on the boundary
[out]	XYZ	Spatial coordinates of the boundary nodes (optional)

References ASMbase::getBoundary1Nodes(), ASMbase::getBoundaryNodes(), ASMbase::getCoord(), ASMbase::getNodeID(), ASMbase::getNodeIndex(), ASMbase::getNodeSet(), ASMbase::getNoNodes(), ASMbase::getNoParamDim(), getPatch(), and myProps.

Referenced by getCurrentReactions(), SIMgeneric::getInterfaceForces(), haveReactions(), and SIM::initBoundaryNodeMap().

◆ getCurrentReactions()

bool SIMbase::getCurrentReactions	(	RealArray &	RF,
		const Vector &	psol,
		int	pcode = `0`
	)		const

Computes the total reaction forces in the model.

Parameters

[out]	RF	Reaction force in each spatial direction + energy
[in]	psol	Primary solution vector
[in]	pcode	Property code identifying the boundary for which the reaction forces are computed (0 means the entire model, or all boundaries)

The content of the output array RF is as follows:

\[ RF[0] = \sum_{i=n}^{\rm nnod} \sum_{i=1}^{\rm nsd} f_n^i u_n^i \quad\quad\mbox{(energy)}\]

\[ RF[i] = \sum_{n=1}^{\rm nnod} f_n^i \quad\forall\quad i=1,\ldots,{\rm nsd} \]

If psol representing the displacement field u is empty, the first norm is omitted and the size of the output array RF will be nsd.

References IFEM::cout, utl::vector< T >::empty(), getBoundaryNodes(), SAM::getReaction(), getReactionForces(), mySam, SAM::normReact(), nsd, and printNRforces().

◆ getLocalPatchIndex()

int SIMbase::getLocalPatchIndex ( int patchNo ) const

Returns the local patch index for the given global patch number.

For serial applications this is an identity mapping only, whereas for parallel applications the local (1-based) patch index on the current processor is returned. If patchNo is out of range, -1 is returned. If patchNo is not on current processor, 0 is returned.

References myPatches, nGlPatches, and SIMadmin::nProc.

Referenced by DomainDecomposition::calcGlobalEqNumbers(), DomainDecomposition::calcGlobalNodeNumbers(), SIM2D::connectPatches(), SIM3D::connectPatches(), SIM1D::connectPatches(), MultiPatchModelGenerator1D::createTopologySets(), MultiPatchModelGenerator2D::createTopologySets(), MultiPatchModelGenerator3D::createTopologySets(), getPatch(), SIMoutput::initPatchForEvaluation(), SIM2D::parse(), SIM3D::parse(), SIMinput::parse(), SIM1D::parseBCTag(), SIM2D::parseBCTag(), SIM3D::parseBCTag(), SIMinput::parseBCTag(), SIM2D::readNodes(), SIM3D::readNodes(), SIMinput::readPatches(), DomainDecomposition::sanityCheckCorners(), SIMoutput::savePoints(), SIMinput::setInitialCondition(), HDF5Writer::writeKnotspan(), and HDF5Writer::writeSIM().

◆ getMADOF()

const IntVec & SIMbase::getMADOF	(	unsigned char	basis,
		unsigned char	nndof
	)		const

private

Returns an extraordinary MADOF array.

Parameters

[in]	basis	The basis to specify number of DOFs for
[in]	nndof	Number of nodal DOFs on the given basis

References extraMADOFs.

Referenced by extractPatchSolution(), injectPatchSolution(), registerDependency(), and solutionNorms().

◆ getName()

virtual std::string SIMbase::getName ( ) const

inlinevirtual

Returns the name of this simulator.

This method is typically overridden by sub-classes that are parts of a partitioned solution method and are used to identify the basis for the result fields associated with each simulator in the HDF5 output.

Implements SIMdependency.

Reimplemented in SIMsupel.

Referenced by SIMinput::deSerialize(), HHTSIM::deSerialize(), MultiStepSIM::deSerialize(), NewmarkNLSIM::deSerialize(), initSystem(), preprocessC(), SIMinput::restartBasis(), SIMinput::restoreBasis(), SIMinput::saveBasis(), HHTSIM::serialize(), MultiStepSIM::serialize(), NewmarkNLSIM::serialize(), SIMoutput::serialize(), updateGrid(), HDF5Writer::writeBasis(), HDF5Writer::writeKnotspan(), and HDF5Writer::writeSIM().

◆ getNodalForceIntegrand()

ForceBase * SIMbase::getNodalForceIntegrand ( ) const

Returns a pointer to a force integrand object for this simulator.

Note: The object is allocated dynamically and has therefore to be manually deleted before the variable receiving the pointer value goes out of scope.

References IntegrandBase::getForceIntegrand(), and myProblem.

Referenced by SIM::getNodalForces().

◆ getNodeSet()

IntVec SIMbase::getNodeSet ( const std::string & setName ) const

Returns a predefined node set.

This method extracts the global node numbers of the named set. The sets are defined on the patch level, and in case the set is defined on more than one patch, the union of the patch-wise nodal sets is returned.

References myModel.

Referenced by addConstraint().

◆ getNoElms()

size_t SIMbase::getNoElms	(	bool	includeXelms = `false`,
		bool	includeZelms = `false`
	)		const

Returns the model size in terms of number of elements.

Parameters

[in]	includeXelms	If true, include any extra-ordinary elements
[in]	includeZelms	If true, count all regular elements, including zero-volume elements due to multiple knots, etc.

References SAM::getNoElms(), myModel, and mySam.

Referenced by compute(), SIMoutput::dumpMatlabGrid(), SIM::getBoundaryForce(), SIMoutput::getElementSet(), SIMinput::getElmConnectivities(), initLHSbuffers(), initSystem(), and SIMoutput::writeGlvNo().

◆ getNoFields()

size_t SIMbase::getNoFields ( int basis = 0 ) const

Returns the number of primary solution fields.

Parameters

[in] basis Which basis to consider when mixed methods (0 = all)

References myModel.

Referenced by SIMoutput::dumpVector(), NodeVecFunc::evaluate(), NewmarkSIM::initAcc(), SIMinput::parseBCTag(), HHTSIM::predictStep(), NewmarkNLSIM::predictStep(), NewmarkSIM::predictStep(), printSolutionSummary(), NewmarkSIM::saveStep(), SIMinput::setInitialCondition(), SIMinput::setNeumann(), NewmarkSIM::solutionNorms(), NonLinSIM::updateConfiguration(), SIMoutput::writeGlvS1(), and SIMoutput::writeGlvS2().

◆ getNoNodes()

size_t SIMbase::getNoNodes ( int basis = 0 ) const

Returns the model size in terms of number of unique nodes.

Parameters

[in] basis Which basis to return the number of nodes for (0 = all)

References SAM::getNoNodes(), myModel, mySam, and nGlbNodes.

Referenced by addMADOF(), SIMoutput::dumpMatlabGrid(), SIMoutput::dumpVector(), HHTSIM::predictStep(), NewmarkNLSIM::predictStep(), NewmarkSIM::predictStep(), project(), SIMinput::refine(), solutionNorms(), NonLinSIM::updateConfiguration(), SIMoutput::writeGlvNo(), SIMoutput::writeGlvP(), and SIMoutput::writeGlvS().

◆ getNormIntegrand()

NormBase * SIMbase::getNormIntegrand ( ) const

Returns a pointer to a norm integrand object for this simulator.

Note: The object is allocated dynamically and has therefore to be manually deleted before the variable receiving the pointer value goes out of scope.

References IntegrandBase::getNormIntegrand(), myProblem, and mySol.

Referenced by AdaptiveSetup::initPrm(), AdaptiveSetup::printNorms(), SIMgeneric::printNorms(), and HDF5Writer::writeSIM().

◆ getPatch()

ASMbase * SIMbase::getPatch	(	int	idx,
		bool	glbIndex = `false`
	)		const

Returns a pointer to a specified patch of our FEM model.

Parameters

[in]	idx	1-based patch index
[in]	glbIndex	If true, the patch index is assumed to be global for the whole model, otherwise it is assumed local within current process. For serial applications this option has no effect.

References getLocalPatchIndex(), and myModel.

Referenced by assembleSystem(), DomainDecomposition::calcGlobalEqNumbers(), DomainDecomposition::calcGlobalNodeNumbers(), AdaptiveSetup::calcRefinement(), compute(), MultiPatchModelGenerator1D::createTopology(), MultiPatchModelGenerator2D::createTopology(), MultiPatchModelGenerator3D::createTopology(), SIMoutput::dumpMatlabGrid(), SIMgeneric::evalPoint(), evalSecondarySolution(), extractPatchElmRes(), extractPatchSolution(), SIMgeneric::findElementContaining(), generateThreadGroups(), getBoundaryNodes(), NodeVecFunc::getPointIndex(), SIMgeneric::getSolution(), SIMinput::getTopItemNodes(), SIM::integrate(), SIMoutput::merge(), SIM1D::parse(), SIM2D::parse(), SIM3D::parse(), SIMinput::parseBCTag(), SIMinput::parseDualTag(), SIM1D::parseGeometryTag(), SIM2D::parseGeometryTag(), SIM3D::parseGeometryTag(), SIMinput::parsePeriodic(), preprocessC(), SIMoutput::preprocessResPtGroup(), SIMinput::refine(), DomainDecomposition::sanityCheckCorners(), SIMinput::setPropertyType(), DomainDecomposition::setup(), solutionNorms(), and HDF5Writer::writeSIM().

◆ getRayleighDampingMatrix()

SystemMatrix * SIMbase::getRayleighDampingMatrix	(	size_t	iM = `1`,
		size_t	iK = `0`
	)		const

Returns current Rayleigh system damping matrix.

Parameters

[in]	iM	Index of the system mass matrix
[in]	iK	Index of the system stiffness matrix

References SystemMatrix::add(), IntegrandBase::getIntegrationPrm(), getLHSmatrix(), SystemMatrix::mult(), myEqSys, and myProblem.

◆ getVecFunc()

VecFunc * SIMbase::getVecFunc	(	size_t	patch,
		Property::Type	ptype
	)		const

protected

Returns a vector function associated with given patch and property.

Parameters

[in]	patch	1-based index of the patch to retrieve property for
[in]	ptype	The property type associated with the vector function

References myProps, and myVectors.

◆ getWorstDofs()

void SIMbase::getWorstDofs	(	const Vector &	x,
		const Vector &	r,
		size_t	nWorst,
		double	eps,
		int	iteNorm,
		std::map< std::pair< int, int >, RealArray > &	worst
	)		const

Finds the DOFs showing the worst convergence behavior.

Parameters

[in]	x	Global primary solution vector
[in]	r	Global residual vector associated with the solution vector
[in]	nWorst	How many bad DOFs to detect
[in]	eps	Only record values larger than this tolerance
[in]	iteNorm	Which norm to consider (1=res, 2=dis, 3=energy)
[out]	worst	Node and local DOF number and values of the worst DOFs

References SAM::getNodeAndLocalDof(), mySam, and utl::vector< T >::size().

Referenced by NonLinSIM::printWorst().

◆ haveReactions()

bool SIMbase::haveReactions ( int pcode = 0 ) const

Checks for total reaction forces associated with a boundary.

Parameters

[in] pcode Property code identifying the boundary (0 = all)

References getBoundaryNodes(), SAM::haveReaction(), mySam, and nsd.

◆ initDirichlet()

bool SIMbase::initDirichlet ( double time = 0.0 )

Initializes time-dependent in-homogeneous Dirichlet coefficients.

Parameters

[in] time Current time

References updateDirichlet().

Referenced by preprocessC().

◆ initSystem()

bool SIMbase::initSystem	(	LinAlg::MatrixType	mType,
		size_t	nMats = `1`,
		size_t	nVec = `1`,
		size_t	nScl = `0`,
		bool	withRF = `false`
	)

Allocates the system matrices of the FE problem to be solved.

Parameters

[in]	mType	The matrix format to use
[in]	nMats	Number of system matrices
[in]	nVec	Number of system right-hand-side vectors
[in]	nScl	Number of global scalar quantities
[in]	withRF	Whether nodal reaction forces should be computed or not

References SIMadmin::adm, IFEM::cout, LinAlg::DENSE, getName(), getNoElms(), AlgEqSystem::init(), myEqSys, myModel, mySam, mySolParams, SIMoptions::num_threads_SLU, SIMadmin::opt, SAM::print(), and LinAlg::SPARSE.

Referenced by MultiStepSIM::initEqSystem(), EigenModeSIM::initSol(), and AdaptiveSIM::solveStep().

◆ injectPatchSolution()

bool SIMbase::injectPatchSolution	(	RealArray &	sol,
		const RealArray &	vec,
		const ASMbase *	pch,
		unsigned char	nndof = `0`,
		unsigned char	basis = `0`
	)		const

Injects a patch-wise solution vector into the global vector.

Parameters

	sol	Global primary solution vector in DOF-order
[in]	vec	Local solution vector associated with specified patch
[in]	pch	The patch to inject solution vector for
[in]	nndof	Number of DOFs per node (optional)
[in]	basis	Basis to inject for (optional)

References getMADOF(), ASMbase::getNoFields(), ASMbase::injectNodalVec(), and ASMbase::injectNodeVec().

Referenced by project().

◆ iterationNorms()

void SIMbase::iterationNorms	(	const Vector &	x,
		const Vector &	r,
		double &	eNorm,
		double &	rNorm,
		double &	dNorm
	)		const

virtual

Evaluates some iteration norms for convergence assessment.

Parameters

[in]	x	Global primary solution vector
[in]	r	Global residual vector associated with the solution vector
[out]	eNorm	Energy norm of solution increment
[out]	rNorm	Residual norm of solution increment
[out]	dNorm	Displacement norm of solution increment

References SAM::dot(), mySam, and SAM::norm2().

Referenced by NewmarkSIM::checkConvergence().

◆ merge()

bool SIMbase::merge	(	SIMbase *	that,
		const std::map< int, int > *	old2new = `nullptr`,
		int	poff = `0`
	)

virtual

Merges the global equation system of that simulator with this.

Parameters

	that	The simulator whose equation system is to be merged
[in]	old2new	Global node number mapping
[in]	poff	Global patch index offset

Reimplemented in SIMoutput.

References SIMadmin::adm, ProcessAdm::dd, SAM::getNoElms(), SAM::getNoNodes(), ASMbase::idx, mdFlag, SAM::merge(), myModel, mySam, DomainDecomposition::setup(), and shiftGlobalNums().

Referenced by SIMoutput::merge().

◆ preprocessC()

bool SIMbase::preprocessC	(	const IntVec &	ignored,
		bool	fixDup,
		double	time0
	)

virtual

Performs some pre-processing tasks on the FE model.

Parameters

[in]	ignored	Indices of patches to ignore in the analysis
[in]	fixDup	Merge duplicated FE nodes on patch interfaces?
[in]	time0	Initial time for time-dependent dirichlet conditions

Reimplemented from SIMadmin.

References addConstraint(), SIMadmin::adm, ASMbase::clear(), IFEM::cout, createFEMmodel(), ProcessAdm::dd, ASMbase::empty(), g2l, getName(), IntegrandBase::getNodalDofTypes(), SAM::getNoDOFs(), getNoParamDim(), getPatch(), hasTimeDependentDirichlet(), initDirichlet(), isRefined, lagMTOK, mdFlag, ASMbase::mergeAndGetAllMPCs(), SIMadmin::msgLevel, myDupNodes, SIMadmin::myHeading, myModel, myProblem, myProps, mySam, mySol, nDofS, nGlbNodes, SIMadmin::opt, LinAlg::PETSC, preprocessA(), preprocessB(), preprocessBeforeAsmInit(), preprocessResultPoints(), SIMadmin::printHeading(), PROFILE1, renumberNodes(), ASMbase::resetNumbering(), ASMbase::resolveMPCchains(), DomainDecomposition::setup(), AnaSol::setupSecondarySolutions(), SIMoptions::solver, and SIMoptions::validateGroups.

Referenced by AdaptiveSIM::preprocessC().

◆ printSolutionSummary()

void SIMbase::printSolutionSummary	(	const Vector &	solution,
		int	printSol = `0`,
		const char *	compName = `nullptr`,
		std::streamsize	outPrec = `0`
	)

virtual

Prints a summary of the calculated solution to std::cout.

Parameters

[in]	solution	The solution vector
[in]	printSol	Print solution only if size is less than this value
[in]	compName	Solution name to be used in norm output
[in]	outPrec	Number of digits after the decimal point in norm print

References SIMadmin::adm, ProcessAdm::cout, dumpSolVec(), SAM::getNoEquations(), getNoFields(), mySam, nsd, utl::LogStream::precision(), SAM::printVector(), solutionNorms(), and utl::trunc().

Referenced by MultiStepSIM::solutionNorms(), and solveEqSystem().

◆ printStep()

void SIMbase::printStep	(	int	istep,
		const TimeDomain &	time
	)		const

virtual

Prints out load/time step identification.

Parameters

[in]	istep	Load- or time step counter
[in]	time	Parameters for nonlinear/time-dependent simulations

This method is used by multi-step simulators to print out a heading when starting a new load/time increment. Override this method if your simulator have some additional data to be printed.

References SIMadmin::adm, ProcessAdm::cout, and TimeDomain::t.

Referenced by MultiStepSIM::printStep().

◆ project() [1/3]

bool SIMbase::project	(	Matrix &	ssol,
		const Vector &	psol,
		SIMoptions::ProjectionMethod	method = `SIMoptions::GLOBAL`,
		const TimeDomain &	time = `TimeDomain()`
	)		const

virtual

Projects the secondary solution associated with a primary solution.

Parameters

[out]	ssol	Control point values of the secondary solution
[in]	psol	Control point values of the primary solution
[in]	method	Projection method to use
[in]	time	Parameters for nonlinear/time-dependent simulations

The secondary solution, defined through the Integrand object, corresponding to the primary solution psol is projected onto the spline basis to obtain the control point values of the secondary solution.

References SIMadmin::adm, utl::matrixBase< T >::clear(), utl::matrix< T >::cols(), IFEM::cout, utl::vector< T >::empty(), utl::matrixBase< T >::empty(), extractPatchSolution(), fieldProjections(), utl::matrix< T >::fillBlock(), utl::matrix< T >::fillColumn(), utl::matrix< T >::getColumn(), IntegrandBase::getNoFields(), getNoNodes(), IntegrandBase::initIntegration(), IntegrandBase::initResultPoints(), SIMadmin::msgLevel, myGl2Params, myModel, myProblem, SIMoptions::nGauss, SIMadmin::opt, LocalSystem::patch, PROFILE1, utl::matrix< T >::resize(), utl::matrix< T >::rows(), setPatchMaterial(), setQuadratureRule(), utl::vector< T >::size(), GlbL2::SolverParams, and TimeDomain::t.

Referenced by SIM2D::addConstraint(), SIM3D::addConstraint(), project(), projectAnaSol(), SIMinput::setInitialConditions(), and AdaptiveSIM::solveStep().

◆ project() [2/3]

bool SIMbase::project	(	RealArray &	values,
		const FunctionBase *	f,
		int	basis = `1`,
		int	iField = `0`,
		int	nFields = `1`,
		SIMoptions::ProjectionMethod	method = `SIMoptions::GLOBAL`,
		double	time = `0.0`
	)		const

Projects a function onto the specified basis.

Parameters

[out]	values	Resulting control point values
[in]	f	The function to evaluate
[in]	basis	Which basis to consider
[in]	iField	Field component offset in values vector
[in]	nFields	Number of field components in values vector
[in]	method	Projection method to use
[in]	time	Current time

References SIMadmin::adm, FunctionBase::dim(), injectPatchSolution(), myModel, and utl::vector< T >::size().

◆ project() [3/3]

bool SIMbase::project	(	Vector &	ssol,
		const Vector &	psol,
		SIMoptions::ProjectionMethod	method = `SIMoptions::GLOBAL`,
		size_t	iComp = `0`
	)		const

Projects the secondary solution associated with a primary solution.

Parameters

[out]	ssol	Vector of control point values of the secondary solution
[in]	psol	Vector of control point values of the primary solution
[in]	method	Projection method to use
[in]	iComp	One-based index of the component to return (0 = all)

Convenience overload, for stationary problems only.

References utl::matrix< T >::getRow(), and project().

◆ projectAnaSol()

bool SIMbase::projectAnaSol	(	Vector &	ssol,
		SIMoptions::ProjectionMethod	method
	)		const

Projects the analytical secondary solution, if any.

Parameters

[out]	ssol	Vector of control point values of the secondary solution
[in]	method	Projection method to use

References FunctionBase::dim(), AnaSol::getScalarSecSol(), AnaSol::getStressSol(), AnaSol::getVectorSecSol(), mySol, project(), and utl::vector< T >::resize().

◆ readModel()

bool SIMbase::readModel ( const char * fileName )

Reads model data from the specified input file *fileName.

This method adds profiling to the virtual read() method.

References PROFILE1, and SIMadmin::read().

◆ registerDependency() [1/4]

void SIMbase::registerDependency	(	const std::string &	name,
		SIMdependency *	sim,
		short int	nvc = `1`,
		unsigned char	basis = `1`
	)

Registers a dependency on a field from another SIM object.

Parameters

[in]	name	Name of field we depend on
[in]	sim	The SIM object holding the field we depend on
[in]	nvc	Number of components in field
[in]	basis	The basis the dependent field should be defined on

References getMADOF(), myModel, and registerDependency().

◆ registerDependency() [2/4]

void SIMdependency::registerDependency

Registers a dependency on a field from another SIM object.

Parameters

[in]	sim	The SIM object holding the field we depend on
[in]	name	Name of field we depend on
[in]	nvc	Number of components in field
[in]	patches	The geometry the field is defined over
[in]	diffBasis	If non-null, use diffBasis base from patch vector
[in]	component	Component to use from field

Referenced by registerDependency().

◆ registerDependency() [3/4]

void SIMdependency::registerDependency

Registers a dependency on a field from another SIM object.

Parameters

[in]	sim	The SIM object holding the field we depend on
[in]	name	Name of field we depend on
[in]	nvc	Number of components in field
[in]	patches	The geometry the field is defined over
[in]	MADOF	The MADOF array to associate with this field

References SIMdependency::depFields.

◆ registerDependency() [4/4]

void SIMdependency::registerDependency

Registers a dependency on a field from another SIM object.

Parameters

[in]	sim	The SIM object holding the field we depend on
[in]	name	Name of field we depend on
[in]	nvc	Number of components in field

◆ renumberNodes()

int SIMbase::renumberNodes ( bool renumMNPC = false )

protected

Renumbers the global node numbers after resolving patch topology.

Parameters

[in] renumMNPC If true, also update element connectivity tables

Returns: Total number of unique nodes in the model, negative on error

This method renumbers the nodes to account for overlapping nodes for multi-patch models, duplicated nodes, erased patches, etc. In parallel simulations, the resulting mapping myGlb2Loc will map the global node numbers to local node numbers on the current processor. In serial simulations, this mapping will be unity unless the original global node number sequence had "holes" due to duplicated nodes or erased patches.

References IFEM::cout, g2l, myDegenElm, myGlb2Loc, myLoc2Glb, myModel, preserveNOrder, ASMbase::renumberNodes(), and ASMs2DC1::renumberNodes().

Referenced by preprocessC(), and SIMinput::readTopologyOnly().

◆ setAssociatedRHS()

bool SIMbase::setAssociatedRHS	(	size_t	iMat,
		size_t	iVec
	)

Associates a system vector to a system matrix.

See also: AlgEqSystem::setAssociatedVector

Parameters

[in]	iMat	Index of a coefficient matrix
[in]	iVec	Index of the system vector to associate with the matrix

References myEqSys, and AlgEqSystem::setAssociatedVector().

◆ setIntegrationPrm()

void SIMbase::setIntegrationPrm	(	unsigned short int	i,
		double	prm
	)

Initializes an integration parameter for the integrand.

Parameters

[in]	i	Index of the integration parameter to define
[in]	prm	The parameter value to assign

References IFEM::cout, myInts, myProblem, and IntegrandBase::setIntegrationPrm().

Referenced by GenAlphaSIM::initPrm(), HHTSIM::initPrm(), NewmarkNLSIM::initPrm(), NewmarkSIM::initPrm(), and NonLinSIM::initPrm().

◆ setMode()

bool SIMbase::setMode	(	int	mode,
		bool	needIntegr = `true`,
		bool	resetSol = `false`
	)

Defines the solution mode before the element assembly is started.

Parameters

[in]	mode	The solution mode to use
[in]	needIntegr	If false, silently ignore non-existing integrand
[in]	resetSol	If true, the internal solution vectors are cleared

References myInts, and myProblem.

Referenced by AdaptiveSIM::assembleAndSolveSystem(), assembleForces(), NewmarkSIM::initAcc(), EigenModeSIM::initSol(), NonLinSIM::lineSearch(), MultiStepSIM::saveStep(), NewmarkSIM::solveIteration(), NonLinSIM::solveIteration(), AdaptiveSIM::solveStep(), NewmarkSIM::solveStep(), and AdaptiveSIM::writeGlv().

◆ setQuadratureRule()

void SIMbase::setQuadratureRule	(	size_t	ng,
		bool	redimBuffers = `false`,
		bool	printQP = `false`
	)

Defines the spatial numerical integration scheme to use.

Parameters

[in]	ng	Number of Gauss points in each parameter direction
[in]	redimBuffers	Toggle initialization of internal buffer arrays
[in]	printQP	If true, print out total number of quadrature points

References IFEM::cout, IntegrandBase::hasBoundaryTerms(), myInts, myModel, myProblem, myProps, nBouGP, and nIntGP.

Referenced by AdaptiveSIM::assembleAndSolveSystem(), NewmarkSIM::initAcc(), EigenModeSIM::initSol(), project(), AdaptiveSIM::solveStep(), and NewmarkSIM::solveStep().

◆ setRefined()

void SIMbase::setRefined ( int nref )

inline

Sets the refinement status (for restart of adaptive simulations).

Parameters

[in] nref Number of refinement levels so far

References isRefined.

◆ solutionNorms() [1/6]

bool SIMbase::solutionNorms	(	const TimeDomain &	time,
		const Vectors &	psol,
		const Vectors &	ssol,
		Vectors &	gNorm,
		Matrix *	eNorm = `nullptr`,
		const char *	name = `nullptr`
	)

Integrates some solution norm quantities.

Parameters

[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	psol	Primary solution vectors
[in]	ssol	Secondary solution vectors
[out]	gNorm	Global norm quantities
[out]	eNorm	Element-wise norm quantities
[in]	name	Name of solution being the source of calculation

This method has a similar loop structure as the assembleSystem() method, but the resulting integrals are now element norms (and global equivalents) instead of a global equation system.

If an analytical solution is provided, norms of the exact error in the solution are also computed. If projected secondary solutions are provided (i.e., ssol is not empty), norms of the difference between these solutions and the directly evaluated secondary solution are computed as well.

References SIMadmin::adm, ProcessAdm::allReduceAsSum(), GlbNorm::assemble(), utl::vector< T >::begin(), utl::vector< T >::clear(), utl::matrix< T >::cols(), IFEM::cout, ProcessAdm::dd, GlbNorm::delayAssembly(), externalEnergy(), extractPatchSolution(), extrFunc, fieldProjections(), IntegrandBase::getExtractionField(), getInterfaceChecker(), getMADOF(), SAM::getNoElms(), IntegrandBase::getNoFields(), getNoNodes(), IntegrandBase::getNormIntegrand(), getPatch(), IntegrandBase::initIntegration(), initMaterial(), initNeumann(), AnaSol::initPatch(), Integrand::INTERFACE_TERMS, DomainDecomposition::isPartitioned(), SIMadmin::msgLevel, myModel, myProblem, myProps, mySam, mySol, nBouGP, nIntGP, SIMadmin::opt, postProcessNorms(), PROFILE1, SIMoptions::project, utl::matrixBase< T >::ptr(), and utl::matrix< T >::resize().

◆ solutionNorms() [2/6]

bool SIMbase::solutionNorms	(	const TimeDomain &	time,
		const Vectors &	psol,
		Vectors &	gNorm,
		Matrix *	eNorm = `nullptr`
	)

inline

Integrates some solution norm quantities.

Parameters

[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	psol	Primary solution vectors
[out]	gNorm	Global norm quantities
[out]	eNorm	Element-wise norm quantities

Use this version if no projected solutions are needed/available.

References solutionNorms().

◆ solutionNorms() [3/6]

bool SIMbase::solutionNorms	(	const Vector &	psol,
		const Vectors &	ssol,
		Matrix &	eNorm,
		Vectors &	gNorm,
		const char *	name = `nullptr`
	)

inline

Integrates some solution norm quantities.

Parameters

[in]	psol	Primary solution vectors
[in]	ssol	Secondary solution vectors
[out]	eNorm	Element-wise norm quantities
[out]	gNorm	Global norm quantities
[in]	name	Name of solution being the source of calculation

Use this version for linear/stationary problems only.

References solutionNorms().

◆ solutionNorms() [4/6]

bool SIMbase::solutionNorms	(	const Vector &	psol,
		const Vectors &	ssol,
		Vectors &	gNorm,
		const char *	name = `nullptr`
	)

inline

Integrates some solution norm quantities.

Parameters

[in]	psol	Primary solution vectors
[in]	ssol	Secondary solution vectors
[out]	gNorm	Global norm quantities
[in]	name	Name of solution being the source of calculation

Use this version for linear/stationary problems, and when the element-wise norms are not needed.

References solutionNorms().

◆ solutionNorms() [5/6]

bool SIMbase::solutionNorms	(	const Vector &	psol,
		Matrix &	eNorm,
		Vectors &	gNorm
	)

inline

Integrates some solution norm quantities.

Parameters

[in]	psol	Primary solution vectors
[out]	eNorm	Element-wise norm quantities
[out]	gNorm	Global norm quantities

Use this version for linear/stationary problems, and when no projected solutions are needed/available.

References solutionNorms().

◆ solutionNorms() [6/6]

double SIMbase::solutionNorms	(	const Vector &	x,
		double *	inf = `nullptr`,
		size_t *	ind = `nullptr`,
		size_t	nf = `0`,
		char	type = `'D'`
	)		const

Evaluates some norms of the primary solution vector.

Parameters

[in]	x	Global primary solution vector
[out]	inf	Infinity norms in each spatial direction
[out]	ind	Global index of the node corresponding to the inf-value
[in]	nf	Number of components in the primary solution field
[in]	type	Only consider nodes of this DOF type (for mixed methods)

Returns: L2-norm of the solution vector

References mySam, SAM::normInf(), SAM::normL2(), and nsd.

Referenced by NewmarkSIM::initAcc(), printSolutionSummary(), NewmarkSIM::solutionNorms(), solutionNorms(), and AdaptiveSIM::solveStep().

◆ solveEqSystem()

bool SIMbase::solveEqSystem	(	Vector &	solution,
		size_t	idxRHS,
		double *	rCond,
		int	printSol = `0`,
		bool	dumpEqSys = `false`,
		const char *	compName = `"displacement"`
	)

Solves the assembled linear system of equations for a given load.

Parameters

[out]	solution	Global primary solution vector
[in]	idxRHS	Index to the right-hand-side vector to solve for
[out]	rCond	Reciprocal condition number
[in]	compName	Solution name to be used in norm output
[in]	printSol	Print solution if its size is less than printSol
[in]	dumpEqSys	If true, activate dump of equation system to file

References IFEM::cout, dumpEqSys(), dumpSolVec(), SAM::expandSolution(), AlgEqSystem::getMatrix(), AlgEqSystem::getVector(), SystemMatrix::isZero(), SIMadmin::msgLevel, myEqSys, mySam, printSolutionSummary(), utl::profiler, SystemMatrix::solve(), Profiler::start(), and Profiler::stop().

Referenced by NewmarkSIM::initAcc(), NewmarkSIM::solveIteration(), NonLinSIM::solveIteration(), NewmarkSIM::solveStep(), and solveSystem().

◆ solveSystem() [1/3]

virtual bool SIMbase::solveSystem	(	Vector &	solution,
		int	printSol,
		double *	rCond,
		const char *	compName = `"displacement"`,
		size_t	idxRHS = `0`
	)

inlinevirtual

Solves the assembled linear system of equations for a given load.

Parameters

[out]	solution	Global primary solution vector
[in]	printSol	Print solution if its size is less than printSol
[out]	rCond	Reciprocal condition number
[in]	compName	Solution name to be used in norm output
[in]	idxRHS	Index to the right-hand-side vector to solve for

References solveEqSystem().

Referenced by AdaptiveSIM::assembleAndSolveSystem(), NewmarkSIM::solveStep(), and solveSystem().

◆ solveSystem() [2/3]

bool SIMbase::solveSystem	(	Vector &	solution,
		int	printSol = `0`,
		const char *	compName = `"displacement"`
	)

inline

Solves the assembled linear system of equations for a given load.

Parameters

[out]	solution	Global primary solution vector
[in]	printSol	Print solution if its size is less than printSol
[in]	compName	Solution name to be used in norm output

References solveSystem().

◆ solveSystem() [3/3]

bool SIMbase::solveSystem	(	Vectors &	solution,
		int	printSol = `0`,
		const char *	cmpName = `"displacement"`
	)

Solves a linear system of equations with multiple right-hand-sides.

Parameters

[out]	solution	Global primary solution vectors
[in]	printSol	Print solution if its size is less than printSol
[in]	cmpName	Solution name to be used in norm output

References AlgEqSystem::getNoRHS(), myEqSys, and solveSystem().

◆ systemModes() [1/2]

bool SIMbase::systemModes	(	std::vector< Mode > &	solution,
		int	nev,
		int	ncv,
		int	iop,
		double	shift,
		size_t	iA = `0`,
		size_t	iB = `1`
	)

Performs a generalized eigenvalue analysis of the assembled system.

Parameters

[in]	iop	Which eigensolver method to use
[in]	nev	Number of eigenvalues/vector (see ARPack documentation)
[in]	ncv	Number of Arnoldi vectors (see ARPack documentation)
[in]	shift	Eigenvalue shift
[out]	solution	Computed eigenvalues and associated eigenvectors
[in]	iA	Index of system matrix A in myEqSys
[in]	iB	Index of system matrix B in myEqSys

References IFEM::cout, dumpEqSys(), SAM::expandVector(), utl::matrix< T >::getColumn(), AlgEqSystem::getMatrix(), SAM::getNoEquations(), myEqSys, mySam, PROFILE1, eig::solve(), and utl::trunc().

Referenced by EigenModeSIM::initSol(), and systemModes().

◆ systemModes() [2/2]

bool SIMbase::systemModes	(	std::vector< Mode > &	solution,
		size_t	iA = `0`,
		size_t	iB = `1`
	)

inline

Performs a generalized eigenvalue analysis of the assembled system.

Parameters

[out]	solution	Computed eigenvalues and associated eigenvectors
[in]	iA	Index of system matrix A in myEqSys
[in]	iB	Index of system matrix B in myEqSys

References SIMoptions::eig, SIMoptions::ncv, SIMoptions::nev, SIMadmin::opt, SIMoptions::shift, and systemModes().

◆ updateDirichlet()

bool SIMbase::updateDirichlet	(	double	time = `0.0`,
		const Vector *	prevSol = `nullptr`
	)

virtual

Updates the time-dependent in-homogeneous Dirichlet coefficients.

Parameters

[in]	time	Current time
[in]	prevSol	Pointer to previous primary solution in DOF-order

This method needs to be invoked in the beginning of each time/load step if the problem constains time-dependent in-homogeneous Dirchlet conditions.

If prevSol points to an empty vector, the coefficients of the MPC objects representing the in-homogeneous Dirichlet conditions are set to the current (updated) value of the SpatialFunction defining the Dirichlet condition (used for the initial time step), otherwise they are set to the difference between the new values from the function, and the previous value which is stored in the provided prevSol vector.

If prevSol is null, the Dirichlet coefficients are set to zero. This is used when doing equilibrium iterations on a fixed time level.

See also: ASMbase::updateDirichlet() and SAMpatch::updateConstraintEqs().

References myModel, mySam, myScalars, myVectors, and SAMpatch::updateConstraintEqs().

Referenced by initDirichlet(), NewmarkSIM::solveIteration(), NonLinSIM::solveIteration(), and NewmarkSIM::solveStep().

◆ updateForNewElements()

void SIMbase::updateForNewElements	(	Vector &	solution,
		const TimeDomain &	time
	)		const

Modifies the current solution vector when activating elements.

Parameters

	solution	Current primary solution vector
[in]	time	Parameters for nonlinear/time-dependent simulations

References utl::vector< T >::add(), TimeDomain::dt, utl::vector< T >::fill(), SAM::getEquation(), myModel, mySam, utl::vector< T >::ptr(), and TimeDomain::t.

Referenced by NonLinSIM::advanceStep().

◆ updateGrid() [1/2]

bool SIMbase::updateGrid ( const RealArray & displ )

Updates the grid coordinates.

Parameters

[in] displ The displacement increment to update the grid with

References extractPatchSolution(), ASMmxBase::itgBasis, mixedProblem(), and myModel.

Referenced by updateGrid().

◆ updateGrid() [2/2]

bool SIMbase::updateGrid ( const std::string & field )

Updates the grid coordinates.

Parameters

[in] field Name of the displacement increment field to update with

References SIMdependency::getDependentField(), getName(), and updateGrid().

Member Data Documentation

◆ nGlbNodes

int SIMbase::nGlbNodes

protected

Total number of unique nodes in the model.

This variable is only used to carry the number of nodes in the model, in the case that renumberNodes() is called before preprocess() and until the SAMpatch::init() method is invoked. This value will be equal to SAM::getNoNodes('A').

Referenced by clearProperties(), getNoNodes(), preprocessC(), SIMinput::readTopologyOnly(), and SIMbase().

The documentation for this class was generated from the following files:

src/SIM/SIMbase.h
src/SIM/SIMbase.C

Classes

Public Member Functions

Static Public Attributes

Protected Types

Protected Member Functions

Protected Attributes

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ addConstraint()

◆ addMADOF()

◆ applyDirichlet()

◆ assembleDiscreteItems()

◆ assembleForces()

◆ assembleSystem() [1/2]

◆ assembleSystem() [2/2]

◆ clearProblem()

◆ clearProperties()

◆ evalSecondarySolution()

◆ extractLoadVec()

◆ extractPatchElmRes()

◆ extractPatchSolution() [1/3]

◆ extractPatchSolution() [2/3]

◆ extractPatchSolution() [3/3]

◆ generateThreadGroups()

◆ getBoundaryForceIntegrand()

◆ getBoundaryNodes()

◆ getCurrentReactions()

◆ getLocalPatchIndex()

◆ getMADOF()

◆ getName()

◆ getNodalForceIntegrand()

◆ getNodeSet()

◆ getNoElms()

◆ getNoFields()

◆ getNoNodes()

◆ getNormIntegrand()

◆ getPatch()

◆ getRayleighDampingMatrix()

◆ getVecFunc()

◆ getWorstDofs()

◆ haveReactions()

◆ initDirichlet()

◆ initSystem()

◆ injectPatchSolution()

◆ iterationNorms()

◆ merge()

◆ preprocessC()

◆ printSolutionSummary()

◆ printStep()

◆ project() [1/3]

◆ project() [2/3]

◆ project() [3/3]

◆ projectAnaSol()

◆ readModel()

◆ registerDependency() [1/4]

◆ registerDependency() [2/4]

◆ registerDependency() [3/4]

◆ registerDependency() [4/4]

◆ renumberNodes()

◆ setAssociatedRHS()

◆ setIntegrationPrm()

◆ setMode()

◆ setQuadratureRule()

◆ setRefined()

◆ solutionNorms() [1/6]

◆ solutionNorms() [2/6]

◆ solutionNorms() [3/6]

◆ solutionNorms() [4/6]

◆ solutionNorms() [5/6]

◆ solutionNorms() [6/6]

◆ solveEqSystem()

◆ solveSystem() [1/3]

◆ solveSystem() [2/3]

◆ solveSystem() [3/3]

◆ systemModes() [1/2]

◆ systemModes() [2/2]

◆ updateDirichlet()
