SIMdependency Class Reference

Class administering inter-SIM field dependencies. More...

#include <SIMdependency.h>

Inheritance diagram for SIMdependency:

Collaboration diagram for SIMdependency:

Classes
struct	Dependency
	Struct holding information about an inter-SIM dependency. More...

Public Types
typedef std::vector< ASMbase * >	PatchVec
	Spline patch container.

Public Member Functions
virtual	~SIMdependency ()
	Empty destructor.
virtual size_t	getNoSpaceDim () const =0
	Returns the number of spatial dimensions in the model.
virtual std::string	getName () const =0
	Returns the given name of this simulator.
virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc, const PatchVec &patches, char diffBasis=0, int component=1)
	Registers a dependency on a field from another SIM object. More...
virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc, const PatchVec &patches, const int *MADOF)
	Registers a dependency on a field from another SIM object. More...
virtual void	registerDependency (SIMdependency *sim, const std::string &name, short int nvc=1)
	Registers a dependency on a field from another SIM object. More...
bool	fillField (const std::string &name, const std::vector< double > &values)
	Initializes the nodal vector of named field in this SIM.
virtual std::vector< double > *	getField (const std::string &name)
	Returns the nodal vector of named field in this SIM.
virtual const std::vector< double > *	getField (const std::string &name) const
	Returns the nodal vector of named field in this SIM.
const std::vector< double > *	getDependentField (const std::string &name) const
	Returns the nodal vector of named field in a dependent SIM.
ASMbase *	getDependentPatch (const std::string &name, int pindx) const
	Returns a spline patch associated with a dependent field.
void	registerField (const std::string &name, const std::vector< double > &vec)
	Registers a named field with associated nodal vector in this SIM.
virtual bool	hasIC (const std::string &) const
	Checks whether a named initial condition is present.

Protected Member Functions
	SIMdependency ()
	The constructor is protected to allow sub-class instances only.
bool	extractPatchDependencies (IntegrandBase *problem, const PatchVec &model, size_t pindx) const
	Extracts local solution vector(s) for all dependent fields. More...

Private Types
typedef std::vector< Dependency >	DepVector
	SIM dependency container.
typedef std::map< std::string, const std::vector< double > * >	FieldMap
	Field name to nodal values map.

Private Member Functions
DepVector::const_iterator	getDependency (const std::string &name) const
	Returns an iterator pointing to a named dependency.

Private Attributes
FieldMap	myFields
	The named fields of this SIM object.
DepVector	depFields
	Other fields this SIM objecy depends on.

Detailed Description

Class administering inter-SIM field dependencies.

Member Function Documentation

extractPatchDependencies()

bool SIMdependency::extractPatchDependencies ( IntegrandBase *  problem, const PatchVec &  model, size_t  pindx  ) const

protected

Extracts local solution vector(s) for all dependent fields.

Parameters

	problem	Object with problem-specific data and methods
[in]	model	Patch geometry of this SIM object
[in]	pindx	Local patch index to extract solution vectors for

References utl::vector< T >::clear(), Field::create(), Fields::create(), depFields, ASMbase::extractNodalVec(), ASMbase::extractNodeVec(), IntegrandBase::getNamedVector(), ASMbase::getNoFields(), IntegrandBase::setNamedField(), and IntegrandBase::setNamedFields().

Referenced by SIMbase::extractPatchSolution(), and SIMoutput::initPatchForEvaluation().

registerDependency() [1/3]

void SIMdependency::registerDependency ( SIMdependency *  sim, const std::string &  name, short int  nvc, const PatchVec &  patches, char  diffBasis = 0, int  component = 1  )

virtual

Registers a dependency on a field from another SIM object.

Parameters

[in]	sim	The SIM object holding the field we depend on
[in]	name	Name of field we depend on
[in]	nvc	Number of components in field
[in]	patches	The geometry the field is defined over
[in]	diffBasis	If non-null, use diffBasis base from patch vector
[in]	component	Component to use from field

References depFields.

Referenced by registerDependency().

registerDependency() [2/3]

void SIMdependency::registerDependency ( SIMdependency *  sim, const std::string &  name, short int  nvc, const PatchVec &  patches, const int *  MADOF  )

virtual

Registers a dependency on a field from another SIM object.

Parameters

[in]	sim	The SIM object holding the field we depend on
[in]	name	Name of field we depend on
[in]	nvc	Number of components in field
[in]	patches	The geometry the field is defined over
[in]	MADOF	The MADOF array to associate with this field

References depFields, and registerDependency().

registerDependency() [3/3]

void SIMdependency::registerDependency ( SIMdependency *  sim, const std::string &  name, short int  nvc = 1  )

virtual

Registers a dependency on a field from another SIM object.

Parameters

[in]	sim	The SIM object holding the field we depend on
[in]	name	Name of field we depend on
[in]	nvc	Number of components in field

References depFields, and getName().

---

The documentation for this class was generated from the following files:

• src/SIM/SIMdependency.h
• src/SIM/SIMdependency.C
