Fields Class Reference

Base class for vector fields. More...

#include <Fields.h>

Inheritance diagram for Fields:

Collaboration diagram for Fields:

Public Member Functions
virtual	~Fields ()
	Empty destructor.
unsigned char	getNoFields () const
	Returns the number of field components.
size_t	getNoElm () const
	Returns the number of elements.
size_t	getNoNodes () const
	Returns the number of nodal/control points.
const char *	getFieldName () const
	Returns the name of field.
virtual bool	valueNode (size_t node, Vector &vals) const
	Computes the value at a given node/control point. More...
virtual bool	valueFE (const ItgPoint &x, Vector &vals) const =0
	Computes the value for a given local coordinate. More...
virtual bool	valueCoor (const Vec4 &x, Vector &vals) const
	Computes the value for a given global coordinate. More...
virtual bool	gradFE (const ItgPoint &x, Matrix &grad) const =0
	Computes the gradient for a given local coordinate. More...
virtual bool	gradCoor (const Vec4 &x, Matrix &grad) const
	Computes the gradient for a given global coordinate. More...
virtual bool	hessianFE (const ItgPoint &x, Matrix3D &H) const
	Computes the hessian for a given local coordinate. More...

Static Public Member Functions
static Fields *	create (const ASMbase *pch, const RealArray &v, char basis=1, int nf=0, const char *name=nullptr)
	Creates a dynamically allocated field object. More...

Protected Member Functions
	Fields (const char *name=nullptr)
	The constructor sets the field name. More...

Protected Attributes
unsigned char	nf
	Number of field components.
size_t	nelm
	Number of elements/knot-spans.
size_t	nno
	Number of nodes/control points.
std::string	fname
	Name of the field.
Vector	values
	Field values.

Detailed Description

Base class for vector fields.

This class incapsulates the data and methods needed to store and evaluate a vector field. This is an abstract base class, and the fields associated with a specific field type are implemented as subclasses, for instance 1D, 2D and 3D spline formulations or Lagrange formulations.

Constructor & Destructor Documentation

Fields()

Fields::Fields ( const char *  name = nullptr )

inlineexplicitprotected

The constructor sets the field name.

Parameters

[in]

name

Name of field

References fname.

Member Function Documentation

create()

Fields * Fields::create ( const ASMbase *  pch, const RealArray &  v, char  basis = 1, int  nf = 0, const char *  name = nullptr  )

static

Creates a dynamically allocated field object.

Parameters

[in]	pch	The spline patch on which the field is to be defined on
[in]	v	Array of nodal/control point field values
[in]	basis	Basis to use from patch
[in]	nf	Number of components in field
[in]	name	Name of field

References nf.

Referenced by FieldsFuncBase::addPatchField(), and SIMdependency::extractPatchDependencies().

gradCoor()

virtual bool Fields::gradCoor ( const Vec4 &  x, Matrix &  grad  ) const

inlinevirtual

Computes the gradient for a given global coordinate.

Parameters

[in]	x	Global coordinate of evaluation point
[out]	grad	Gradient at given global coordinate

gradFE()

virtual bool Fields::gradFE ( const ItgPoint &  x, Matrix &  grad  ) const

pure virtual

Computes the gradient for a given local coordinate.

Parameters

[in]	x	Local coordinate of evaluation point
[out]	grad	Gradient at local point in given element

Implemented in SplineFields3Dmx, SplineFields3D, SplineFields2Dmx, SplineFields2D, SplineFields1D, LRSplineFields3Dmx, LRSplineFields3D, LRSplineFields2Dmx, LRSplineFields2D, LagrangeFields3D, and LagrangeFields2D.

hessianFE()

virtual bool Fields::hessianFE ( const ItgPoint &  x, Matrix3D &  H  ) const

inlinevirtual

Computes the hessian for a given local coordinate.

Parameters

[in]	x	Local coordinate of evaluation point
[out]	H	Hessian at local point in given element

Reimplemented in SplineFields3Dmx, SplineFields3D, SplineFields2Dmx, SplineFields2D, SplineFields1D, LRSplineFields3Dmx, LRSplineFields3D, LRSplineFields2Dmx, and LRSplineFields2D.

valueCoor()

virtual bool Fields::valueCoor ( const Vec4 &  x, Vector &  vals  ) const

inlinevirtual

Computes the value for a given global coordinate.

Parameters

[in]	x	Global/physical coordinate for point
[out]	vals	Values at given global coordinate

Reimplemented in SplineFields3Dmx, SplineFields3D, SplineFields2Dmx, SplineFields2D, LRSplineFields3Dmx, LRSplineFields3D, LRSplineFields2Dmx, and LRSplineFields2D.

valueFE()

virtual bool Fields::valueFE ( const ItgPoint &  x, Vector &  vals  ) const

pure virtual

Computes the value for a given local coordinate.

Parameters

[in]	x	Local coordinate of evaluation point
[out]	vals	Values at local point in given element

Implemented in SplineFields3Dmx, SplineFields3D, SplineFields2Dmx, SplineFields2D, SplineFields1D, LRSplineFields3Dmx, LRSplineFields3D, LRSplineFields2Dmx, LRSplineFields2D, LagrangeFields3D, and LagrangeFields2D.

Referenced by ASMs2D::evalProjSolution(), ASMs3D::evalProjSolution(), ASMu2D::evalProjSolution(), ASMu3D::evalProjSolution(), and ASMs1D::evalProjSolution().

valueNode()

bool Fields::valueNode ( size_t  node, Vector &  vals  ) const

virtual

Computes the value at a given node/control point.

Parameters

[in]	node	1-based node/control point index
[out]	vals	Values at given node/control point

Reimplemented in SplineFields3Dmx, SplineFields3D, SplineFields2Dmx, SplineFields2D, LRSplineFields3Dmx, LRSplineFields3D, LRSplineFields2Dmx, LRSplineFields2D, LagrangeFields3D, and LagrangeFields2D.

References utl::vector< T >::fill(), nf, nno, utl::vector< T >::ptr(), utl::vector< T >::resize(), and values.

---

The documentation for this class was generated from the following files:

• src/ASM/Fields.h
• src/ASM/Fields.C
