Driver for assembly of structured 2D spline FE models. More...

#include <ASMs2D.h>

Inheritance diagram for ASMs2D:

[legend]

Collaboration diagram for ASMs2D:

[legend]

Classes
class	BasisFunctionCache
	Implementation of basis function cache. More...

struct	BlockNodes
	Struct with data for definition of global node numbers of a patch. More...

struct	DirichletEdge
	Struct representing an inhomogeneous Dirichlet boundary condition. More...

struct	Edge
	Struct for edge node definitions. More...

struct	IJ
	Struct for nodal point data. More...

class	InterfaceChecker
	Base class that checks if an element has interface contributions. More...

Public Member Functions
	ASMs2D (unsigned char n_s=2, unsigned char n_f=2)
	Default constructor.

	ASMs2D (const ASMs2D &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data.

	ASMs2D (const ASMs2D &patch)
	Default copy constructor copying everything.

virtual	~ASMs2D ()
	The destructor frees the dynamically allocated boundary curves.

virtual Go::SplineCurve *	getBoundary (int dir, int=1)
	Returns the spline curve representing a boundary of this patch. More...

virtual Go::SplineSurface *	getBasis (int basis=1)
	Returns the spline surface representing a basis of this patch.

virtual const Go::SplineSurface *	getBasis (int basis=1) const
	Returns the spline surface representing a basis of this patch.

virtual void	copyParameterDomain (const ASMbase *other)
	Copies the parameter domain from the other patch.

virtual bool	read (std::istream &)
	Creates an instance by reading the given input stream.

virtual bool	write (std::ostream &, int) const
	Writes the geometry of the SplineSurface object to given stream.

virtual bool	generateFEMTopology ()
	Generates the finite element topology data for the patch. More...

virtual void	clear (bool retainGeometry=false)
	Clears the contents of the patch, making it empty. More...

virtual bool	addXElms (short int dim, short int item, size_t nXn, IntVec &nodes)
	Adds extraordinary elements associated with a patch boundary. More...

bool	addInterfaceElms (const ASM::InterfaceChecker &iChk)
	Adds interface elements with coupling to all element DOFs. More...

virtual size_t	getNodeIndex (int globalNum, bool noAddedNodes=false) const
	Returns local 1-based index of the node with given global number. More...

virtual int	getNodeID (size_t inod, bool noAddedNodes=false) const
	Returns the global node number for the given node. More...

virtual bool	getElementCoordinates (Matrix &X, int iel, bool forceItg=false) const
	Returns a matrix with nodal coordinates for an element. More...

virtual void	getNodalCoordinates (Matrix &X, bool geo=false) const
	Returns a matrix with all nodal coordinates within the patch. More...

virtual Vec3	getCoord (size_t inod) const
	Returns the global coordinates for the given node. More...

virtual Vec3	getElementCenter (int iel) const
	Returns the coordinate of the element center.

virtual bool	updateCoords (const Vector &displ)
	Updates the nodal coordinates for this patch. More...

virtual void	getBoundaryNodes (int lIndex, IntVec &nodes, int basis, int thick=1, int=0, bool local=false) const
	Finds the global (or patch-local) node numbers on a patch boundary. More...

virtual int	getCorner (int I, int J, int basis) const
	Returns the node index for a given corner. More...

bool	assignNodeNumbers (BlockNodes &nodes, int basis=0)
	Assigns new global node numbers for all nodes of the patch. More...

virtual bool	checkRightHandSystem ()
	Checks that the patch is modelled in a right-hand-side system. More...

virtual bool	refine (int dir, const RealArray &xi, double scale=1.0)
	Refines the parametrization by inserting extra knots. More...

virtual bool	uniformRefine (int dir, int nInsert)
	Refines the parametrization by inserting extra knots uniformly. More...

virtual bool	raiseOrder (int ru, int rv)
	Raises the order of the SplineSurface object for this patch. More...

virtual bool	createProjectionBasis (bool init)
	Creates a separate projection basis for this patch. More...

virtual bool	separateProjectionBasis () const
	Checks if a separate projection basis is used for this patch.

virtual void	constrainEdge (int dir, bool open, int dof, int code, char basis)
	Constrains all DOFs on a given boundary edge. More...

virtual size_t	constrainEdgeLocal (int dir, bool open, int dof, int code, bool project=false)
	Constrains all DOFs in local directions on a given boundary edge. More...

virtual void	constrainCorner (int I, int J, int dof, int code=0, char basis=1)
	Constrains a corner node identified by the two parameter indices. More...

virtual void	constrainNode (double xi, double eta, int dof, int code=0)
	Constrains a node identified by two relative parameter values. More...

virtual bool	connectPatch (int edge, ASM2D &neighbor, int nedge, bool revers, int=0, bool coordCheck=true, int thick=1)
	Connects all matching nodes on two adjacent boundary edges. More...

virtual void	closeBoundaries (int dir, int basis, int master)
	Makes two opposite boundary edges periodic. More...

virtual bool	collapseEdge (int dir, int basis=1)
	Collapses a degenereated edge into a single node. More...

virtual bool	addRigidCpl (int lindx, int ldim, int basis, int &gMaster, const Vec3 &Xmaster, bool extraPt)
	Adds MPCs representing a rigid coupling to this patch. More...

virtual void	setNodeNumbers (const IntVec &nodes)
	Sets the global node numbers for this patch. More...

virtual bool	updateDirichlet (const std::map< int, RealFunc * > &func, const std::map< int, VecFunc * > &vfunc, double time, const std::map< int, int > *g2l=nullptr)
	Updates the time-dependent in-homogeneous Dirichlet coefficients. More...

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates an integral over the interior patch domain. More...

virtual bool	integrate (Integrand &integrand, int lIndex, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates a boundary integral over a patch edge. More...

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time, const ASM::InterfaceChecker &iChk)
	Evaluates an integral over element interfaces in the patch. More...

virtual int	evalPoint (const double xi, double param, Vec3 &X) const
	Evaluates the geometry at a specified point. More...

virtual int	findElementContaining (const double *param) const
	Returns the element that contains a specified spatial point. More...

virtual double	findPoint (Vec3 &X, double *param) const
	Searches for the specified Cartesian point in the patch. More...

virtual bool	getGridParameters (RealArray &prm, int dir, int nSegSpan) const
	Calculates parameter values for visualization nodal points. More...

virtual bool	tesselate (ElementBlock &grid, const int *npe) const
	Creates a quad element model of this patch for visualization. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f, bool piola) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular=true, int deriv=0, int=0) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalProjSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f) const
	Evaluates the projected solution field at all visualization points. More...

virtual bool	evaluate (const ASMbase *basis, const Vector &locVec, RealArray &vec, int basisNum) const
	Evaluates and interpolates a field over a given geometry. More...

virtual bool	evaluate (const Field *field, RealArray &vec, int basisNum) const
	Evaluates and interpolates a field over a given geometry. More...

virtual bool	evaluate (const FunctionBase *func, RealArray &vec, int basisNum, double time) const
	Evaluates and interpolates a function over a given geometry. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe=nullptr, char project=0) const
	Evaluates the secondary solution field at all visualization points. More...

virtual Go::GeomObject *	evalSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool regular=true) const
	Evaluates the secondary solution field at the given points. More...

virtual bool	getOrder (int &p1, int &p2, int &p3) const
	Returns the polynomial order in each parameter direction. More...

virtual bool	getSize (int &n1, int &n2, int basis=0) const
	Returns the number of nodal points in each parameter direction. More...

virtual bool	getSize (int &n1, int &n2, int &n3, int basis) const
	Returns the number of nodal points in each parameter direction. More...

virtual bool	getNoStructElms (int &n1, int &n2, int &n3) const
	Returns the number of elements in each parameter direction. More...

virtual void	getElmConnectivities (IntMat &neigh, int basis=ASM::INTEGRATION_BASIS) const
	Calculates the matrix of element neighbour connectivities. More...

virtual IntMat	getElmNodes (int basis) const
	Returns the matrix of nodal point correspondance for given basis.

virtual size_t	getNoBoundaryElms (char lIndex, char ldim) const
	Returns the number of elements on a boundary.

virtual size_t	getNoNodes (int basis=0) const
	Returns the total number of nodes in this patch.

virtual size_t	getNoProjectionNodes () const
	Returns the number of projection nodes for this patch.

virtual bool	getParameterDomain (Real2DMat &u, IntVec *corners) const
	Returns parameter values and node numbers of the domain corners. More...

virtual void	evaluateBasis (double u, double v, double, Vector &N) const
	Evaluates the basis functions at the specified point. More...

void	extractBasis (double u, double v, Vector &N, Matrix &dNdu, bool fromRight=true) const
	Establishes matrices with basis functions and 1st derivatives. More...

void	extractBasis (double u, double v, Vector &N, Matrix &dNdu, Matrix3D &d2Ndu2, bool fromRight=true) const
	Establishes matrices with basis functions, 1st and 2nd derivatives. More...

void	extractBasis (double u, double v, int dir, int p, Vector &dN, bool fromRight=true) const
	Establishes a vector with basis function derivatives. More...

virtual Field *	getProjectedField (const Vector &coefs) const
	Returns a field using the projection basis. More...

virtual Fields *	getProjectedFields (const Vector &coefs, size_t=0) const
	Returns a field using the projection basis. More...

Public Member Functions inherited from ASMstruct
virtual	~ASMstruct ()
	The destructor frees the dynamically allocated spline objects.

virtual bool	empty () const
	Checks if the patch is empty.

virtual bool	diracPoint (Integrand &integr, GlobalIntegral &glInt, const double *u, const Vec3 &pval)
	Integrates a spatial dirac-delta function over a patch. More...

virtual void	swapProjectionBasis ()
	Swaps between the first and second projection basis.

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f=0, bool piola=false) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular=true, int deriv=0, int n_f=0) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe=nullptr, char project=0) const
	Evaluates the secondary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool regular=true) const
	Evaluates the secondary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const IntVec &elements) const
	Evaluates the secondary solution field at element centers. More...

Public Member Functions inherited from ASMbase
virtual	~ASMbase ()
	The destructor frees the dynamically allocated data objects.

ASMbase *	cloneUnShared () const
	Returns a copy of this patch with identical FE discretization. More...

virtual bool	readBasis (std::istream &, size_t)
	Reads a basis from the given input stream.

virtual void	addHole (double, double, double)
	Adds a circular immersed boundary in the physical geometry.

virtual void	addHole (double, double, double, double, double)
	Adds an oval immersed boundary in the physical geometry.

virtual bool	setGeometry (RealFunc *, double, double)
	Defines the immersed geometry from a scalar function.

bool	addLagrangeMultipliers (size_t iel, const IntVec &mGLag, unsigned char nnLag=1)
	Adds a set of Lagrange multipliers to the specified element. More...

bool	addGlobalLagrangeMultipliers (const IntVec &mGLag, unsigned char nnLag=1)
	Adds global Lagrange multipliers to the system. More...

virtual void	setGauss (int ng)
	Defines the numerical integration scheme nGauss in the patch.

void	setNoFields (unsigned char n)
	Defines the number of solution fields in the patch. More...

void	setElementActivator (IntFunc *efunc)
	Sets the element activation function.

const IntFunc *	getElementActivator () const
	Returns a pointer to the element activation function.

virtual void	setMinimumSize (double)
	Sets the minimum element size for adaptive refinement.

virtual double	getMinimumSize (int=0) const
	Defines the minimum element size for adaptive refinement.

virtual bool	checkElementSize (int, bool=true) const
	Checks if the specified element is larger than the minimum size.

unsigned char	getNoSpaceDim () const
	Returns the number of spatial dimensions.

unsigned char	getNoParamDim () const
	Returns the number of parameter dimensions.

virtual unsigned char	getNoFields (int b=0) const
	Returns the number of solution fields.

unsigned char	getNoLagPerNode () const
	Returns the number of Lagrange multipliers per node.

size_t	getElmIndex (int globalNum) const
	Returns local 1-based index of element with given global number. More...

int	getElmID (size_t iel) const
	Returns the global element number for the given element. More...

virtual unsigned char	getNodalDOFs (size_t inod) const
	Returns the number of DOFs per node. More...

virtual char	getNodeType (size_t inod) const
	Returns the classification of a node. More...

bool	isLMn (size_t n) const
	Returns true if node n is a Lagrange multiplier node.

bool	isRMn (size_t n) const
	Returns true if node n is a master node of a rigid coupling.

char	getLMType (size_t inod) const
	Returns the type of a Lagrange multiplier node. More...

virtual void	getBoundary1Nodes (int lIndex, IntVec &nodes, int basis=0, int orient=-1, bool local=false, bool open=false) const
	Finds the global (or patch-local) node numbers on a patch boundary. More...

void	getBoundaryElms (int lIndex, IntVec &elms, int orient=-1, bool local=false) const
	Finds the global (or patch-local) element numbers on a boundary. More...

virtual int	getNodeSetIdx (const std::string &) const
	Returns (1-based) index of a predefined node set in the patch.

virtual const IntVec &	getNodeSet (int) const
	Returns an indexed predefined node set.

virtual bool	isInNodeSet (int, int) const
	Checks if a node is within a predefined node set.

virtual int	parseNodeSet (const std::string &, const char *)
	Defines a node set by parsing a list of node numbers.

virtual int	parseNodeBox (const std::string &, const char *)
	Defines a node set by parsing a 3D bounding box.

virtual int	getElementSetIdx (const std::string &) const
	Returns (1-based) index of a predefined element set in the patch.

virtual const IntVec &	getElementSet (int) const
	Returns an indexed predefined element set.

virtual bool	getElementSet (int, std::string &) const
	Returns the name of an indexed predefined element set.

virtual bool	isInElementSet (int, int) const
	Checks if an element is within a predefined element set.

virtual int	parseElemSet (const std::string &, const char *)
	Defines an element set by parsing a list of element numbers.

virtual int	parseElemBox (const std::string &, const std::string &, const char *)
	Defines an element set by parsing a 3D bounding box.

virtual std::pair< size_t, double >	findClosestNode (const Vec3 &) const
	Finds the node that is closest to the given point.

void	printNodes (std::ostream &os) const
	Prints out the nodal coordinates of this patch to the given stream.

void	printElements (std::ostream &os) const
	Prints out element connections of this patch to the given stream.

virtual void	printElmInfo (int, const IntegrandBase *) const
	Prints out additional app-dependent element information.

virtual void	shiftGlobalNodeNums (int nshift)
	Increase all global node numbers by nshift.

void	setGlobalNodeNums (const IntVec &nodes)
	Sets the global node numbers for this patch.

const IntVec &	getMyNodeNums () const
	Returns the actual global node numbers of this patch.

const IntVec &	getGlobalNodeNums () const
	Returns the global node numbers of this patch.

virtual void	shiftGlobalElmNums (int eshift)
	Increase all global element numbers by eshift.

const IntVec &	getGlobalElementNums () const
	Returns the global element numbers of this patch.

void	setActiveElements (IntVec *active)
	Sets the list of active elements during assembly.

bool	isElementActive (int iel, double time=-1.0) const
	Returns true if element with 0-based index iel is active.

bool	inActive (double time) const
	Returns true if none of the elements in the patch are active.

double	getAge (int iel, double time) const
	Returns the age of the element with 0-based index iel.

bool	isElementInPartition (int iel) const
	Returns true if element is in process partition. More...

const IntVec &	getElementNodes (int iel) const
	Returns the nodal point correspondance array for an element. More...

virtual size_t	getNoBasis () const
	Returns number of bases of this patch.

size_t	getNoElms (bool includeZeroVolElms=false, bool includeXElms=false) const
	Returns the total number of elements in this patch. More...

int	getMaxElmNo () const
	Returns the highest external element number in this patch.

size_t	getNoMPCs () const
	Returns the total number of multi-point constraint equations.

virtual void	getNoIntPoints (size_t &nPt, size_t &nIPt)
	Computes the total number of integration points in this patch.

virtual void	getNoBouPoints (size_t &nPt, char ldim, char lindx)
	Computes the number of boundary integration points in this patch.

BCVec::const_iterator	begin_BC () const
	Returns the beginning of the BCode array.

BCVec::const_iterator	end_BC () const
	Returns the end of the BCode array.

IntMat::const_iterator	begin_elm () const
	Returns the beginning of the MNPC array.

IntMat::const_iterator	end_elm () const
	Returns the end of the MNPC array.

MPCIter	begin_MPC () const
	Returns the beginning of the mpcs set.

MPCIter	end_MPC () const
	Returns the end of the mpcs set.

MPC *	findMPC (int node, int dof) const
	Returns a pointer to the MPC object for a specified slave, if any. More...

bool	isShared () const
	Returns true if this patch shares FE data with another patch.

bool	hasXNodes () const
	Returns true if this patch has additional (extraordinary) nodes.

bool	mergeNodes (size_t inod, int globalNum, bool verbose=true)
	Merges a given node in this patch with a given global node. More...

int	renumberNodes (std::map< int, int > &old2new, int &nNod)
	Renumbers the global node numbers in this patch. More...

bool	renumberNodes (const std::map< int, int > &old2new, const std::vector< int > &new2old={}, int renumGN=0, std::map< int, int > *degenElm=nullptr)
	Renumbers the global node numbers referred by this patch. More...

virtual bool	initConstraints ()
	Initializes the multi-point constraint coefficients.

bool	hasTimeDependentDirichlet (const std::map< int, RealFunc * > &func, const std::map< int, VecFunc * > &vfunc)
	Checks for time-dependent in-homogeneous Dirichlet conditions. More...

virtual bool	transform (const Matrix &)
	Applies a transformation matrix from local to global system.

virtual void	initMADOF (const int *)
	Initializes the patch level MADOF array for mixed problems.

virtual void	generateThreadGroups (char, bool, bool)
	Generates element groups for multi-threading of boundary integrals.

virtual bool	integrateEdge (Integrand &integrand, int lEdge, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates a boundary integral over a patch edge. More...

virtual ElementBlock *	immersedGeometry (char *) const
	Returns an additional geometry to visualize (immersed boundaries).

virtual ElementBlock *	extraGeometry (char *) const
	Returns an additional geometry to visualize (spiders, etc.).

virtual void	filterResults (Matrix &, const ElementBlock *) const
	Filters out result point values that are outside physical domain.

virtual bool	getSolution (Matrix &sField, const Vector &locSol, const IntVec &nodes) const
	Extract the primary solution field at the specified nodes. More...

virtual bool	immersedSolution (Matrix &, const Vector &) const
	Evaluates the primary solution at the immersed geometry points.

virtual bool	extraSolution (Matrix &, const Vector &) const
	Evaluates the primary solution at the extra geometry points.

virtual bool	evalSolutionPiola (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular) const
	Evaluates the primary solution field with Piola mapping. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const IntVec &elements) const
	Evaluates the secondary solution field at element centers. More...

bool	globalL2projection (Matrix &sField, const L2Integrand &integrand, bool continuous=false, bool enforceEnds=false) const
	Projects the secondary solution using a (discrete) global L2-fit. More...

bool	L2projection (Matrix &sField, IntegrandBase *integrand, const TimeDomain &time)
	Projects the secondary solution using a continuous global L2-fit. More...

bool	L2projection (Matrix &fVals, FunctionBase *function, double t=0.0)
	Projects an explicit function using a continuous global L2-fit. More...

bool	L2projection (const std::vector< Matrix * > &fVals, const std::vector< FunctionBase * > &function, double t=0.0)
	Projects explicit functions using a continuous global L2-fit. More...

virtual size_t	getNoRefineNodes () const
	Returns the number of nodes on refinement basis for this patch.

virtual size_t	getNoRefineElms () const
	Returns the number of elements on refinement basis for this patch.

virtual void	extractElmRes (const Vector &globRes, Vector &elmRes, size_t internalFirst=0) const
	Extracts element results for this patch from a global vector. More...

virtual void	extractElmRes (const Matrix &globRes, Matrix &elmRes, size_t internalFirst=0) const
	Extracts element results for this patch from a global vector. More...

bool	extractNodalVec (const RealArray &globVec, RealArray &nodeVec, const int *madof, int ngnod=-1) const
	Extracts nodal results for this patch from the global vector. More...

virtual void	extractNodeVec (const RealArray &globVec, RealArray &nodeVec, unsigned char nndof=0, int basis=0) const
	Extracts nodal results for this patch from the global vector. More...

virtual bool	injectNodeVec (const RealArray &nodeVec, RealArray &globVec, unsigned char nndof=0, int basis=0) const
	Injects nodal results for this patch into the global vector. More...

bool	injectNodalVec (const RealArray &nodeVec, RealArray &globVec, const IntVec &madof, int basis=0) const
	Injects nodal results for this patch into the global vector. More...

bool	add2PC (int slave, int dir, int master, int code=0)
	Creates and adds a two-point constraint to this patch. More...

bool	addMPC (MPC *&mpc, int code=0, bool verbose=false, bool overrideD=false)
	Adds a general multi-point-constraint (MPC) equation to this patch. More...

void	addRigidCouplings (int gMaster, const Vec3 &Xmaster, const IntVec &slaveNodes)
	Adds MPC-equations representing a rigid coupling to this patch. More...

void	constrainPatch (int dof, int code=0)
	Constrains all nodes in the patch. More...

void	constrainNodes (const IntVec &nodes, int dof, int code=0, bool overrideD=false)
	Constrains a list of nodes in the patch. More...

bool	constrainXnode (int node, int dof, int code=0)
	Constrains an extraordinary node in the patch. More...

int	prescribe (size_t inod, int dirs, int code, bool overrideD=false)
	Constrains DOFs in the given node to the given value. More...

int	fix (size_t inod, int dirs=123)
	Constrains DOFs in the given node to zero. More...

bool	isFixed (int node, int dof, bool all=false) const
	Checks if the given DOFs are fixed. More...

Public Member Functions inherited from ASM2D
virtual	~ASM2D ()
	Empty destructor.

ASMbase *	clone (const CharVec &nf=CharVec()) const
	Returns a copy of this patch with identical FE discretization. More...

virtual bool	refine (int dir, const std::vector< double > &xi, double scale=1.0)=0
	Refines the parametrization by inserting extra knots. More...

virtual bool	getGridParameters (std::vector< double > &prm, int dir, int nSegSpan) const =0
	Calculates parameter values for visualization nodal points. More...

Static Public Member Functions
static void	scatterInd (int n1, int n2, int p1, int p2, const int *start, IntVec &index)
	Auxilliary function for computation of basis function indices.

Static Public Member Functions inherited from ASMbase
static void	resetNumbering (int n=0)
	Resets the global element and node counters.

static int	renumberNodes (const ASMVec &model, std::map< int, int > &old2new)
	Renumbers all global node numbers in the entire model. More...

static void	mergeAndGetAllMPCs (const ASMVec &model, MPCSet &allMPCs)
	Computes the set of all MPC-equations over the whole model. More...

static void	resolveMPCchains (const MPCSet &allMPCs, const ASMVec &model, bool setPtrOnly=false)
	Resolves (possibly multi-level) chaining in MPC-equations. More...

Static Public Member Functions inherited from ASM2D
static ASMbase *	create (ASM::Discretization type, unsigned char nd, const CharVec &nf, bool mixedFEM=false)
	Creates a two-parametric patch of specified discretization type. More...

static ASMbase *	create (ASM::Discretization type, unsigned char nf=1)
	Creates a two-parametric patch of specified discretization type. More...

Protected Member Functions
bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time, const Real3DMat &itgPts)
	Evaluates an integral over the interior patch domain. More...

virtual void	findBoundaryElms (IntVec &elms, int lIndex, int=0) const
	Finds the patch-local element numbers on a patch boundary. More...

virtual bool	assembleL2matrices (SystemMatrix &A, SystemVector &B, const L2Integrand &integrand, bool continuous) const
	Assembles L2-projection matrices for the secondary solution. More...

bool	connectBasis (int edge, ASMs2D &neighbor, int nedge, bool revers, int basis=1, int slave=0, int master=0, bool coordCheck=true, int thick=1)
	Connects all matching nodes on two adjacent boundary edges. More...

void	getGaussPointParameters (RealArray &uGP, int dir, int nGauss, const double *xi) const
	Extracts parameter values of the Gauss points in one direction. More...

bool	getGrevilleParameters (RealArray &prm, int dir, int basisNum=1) const
	Calculates parameter values for the Greville points. More...

bool	getQuasiInterplParameters (RealArray &prm, int dir) const
	Calculates parameter values for the Quasi-Interpolation points. More...

double	getParametricArea (int iel) const
	Returns the area in the parameter space for an element. More...

double	getParametricLength (int iel, int dir) const
	Returns boundary edge length in the parameter space for an element. More...

bool	getElementCoordinatesPrm (Matrix &X, double u, double v) const
	Returns a matrix with nodal coordinates for element containing given parameters. More...

void	getElementBorders (int i1, int i2, double u, double v) const
	Computes the element border parameters. More...

virtual void	getElementBorders (int iel, double *u) const
	Computes the element border parameters. More...

double	getElementCorners (int i1, int i2, std::vector< Vec3 > &XC, RealArray *uC=nullptr) const
	Computes the element corner coordinates. More...

void	getCornerPoints (int i1, int i2, std::vector< utl::Point > &XC) const
	Computes the element corner coordinates and parameters. More...

virtual void	generateThreadGroups (const Integrand &integrand, bool silence, bool ignoreGlobalLM)
	Generates element groups for multi-threading of interior integrals. More...

virtual void	changeNumThreads ()
	Hook for changing number of threads.

void	generateThreadGroups (size_t strip1, size_t strip2, bool silence, bool ignoreGlobalLM)
	Generates element groups for multi-threading of interior integrals. More...

virtual void	generateThreadGroupsFromElms (const IntVec &elms)
	Generates element groups from a partition.

virtual void	generateProjThreadGroupsFromElms (const IntVec &elms)
	Generate element groups from a partition.

virtual bool	validateThreadGroups (const SAM *sam) const
	Validates the threading groups based on the assembly data in SAM.

virtual int	getFirstItgElmNode () const
	Returns 0-based index of first node on integration basis.

virtual int	getLastItgElmNode () const
	Returns 0-based index of last node on integration basis.

virtual void	generateThreadGroups (const Integrand &, bool, bool)
	Generates element groups for multi-threading of interior integrals.

virtual void	generateThreadGroups (char, bool, bool)
	Generates element groups for multi-threading of boundary integrals.

Protected Member Functions inherited from ASMstruct
	ASMstruct (unsigned char n_p, unsigned char n_s, unsigned char n_f)
	The constructor sets the number of space dimensions and fields. More...

	ASMstruct (const ASMstruct &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data. More...

bool	addXNodes (unsigned short int dim, size_t nXn, IntVec &nodes)
	Adds extraordinary nodes associated with a patch boundary. More...

bool	checkThreadGroups (const std::vector< std::set< int >> &nodes, int group, bool ignoreGlobalLM)
	Performs a sanity check on the thread groups. More...

Protected Member Functions inherited from ASMbase
	ASMbase (unsigned char n_p, unsigned char n_s, unsigned char n_f)
	The constructor sets the number of space dimensions and fields. More...

	ASMbase (const ASMbase &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data. More...

	ASMbase (const ASMbase &patch)
	Default copy constructor, copying everything except neighbors. More...

void	addLocal2GlobalCpl (int iSlave, int master, const Tensor &Tlg)
	Creates constraint equations coupling global DOFs to local DOFs. More...

bool	add3PC (int slave, int dir, int master1, int master2, int code=0)
	Creates and adds a three-point constraint to this patch. More...

bool	addPeriodicity (size_t master, size_t slave, int dir)
	Creates and adds a periodicity constraint to this patch. More...

void	makePeriodic (size_t master, size_t slave, int dirs=123)
	Creates periodicity constraints between two nodes in this patch. More...

void	addNeighbor (ASMbase *pch)
	Adds a patch to the list of neighbors of this patch. More...

bool	createRgdMasterNode (int &gMaster, const Vec3 &Xmaster)
	Creates an additional master node for a rigid coupling. More...

void	addRigidMPC (int gSlave, int gMaster, const Vec3 &dX)
	Adds MPC-equations representing a rigid arm to a 6-DOF node. More...

int	getNoGaussPt (int p, bool neumann=false) const
	Returns the number of Gauss points to use in one direction. More...

int	searchCtrlPt (RealArray::const_iterator cit, RealArray::const_iterator end, const Vec3 &X, int dimension, double tol=0.001) const
	Helper method used by evalPoint to search for a control point. More...

bool	allDofs (int dirs) const
	Returns true if dirs constains all local DOFs in the patch.

bool	writeLagBasis (std::ostream &os, const char *type) const
	Writes a Lagrangian basis to the given stream.

Protected Member Functions inherited from ASM2D
	ASM2D ()
	The constructor is protected to allow objects of sub-classes only.

Protected Attributes
std::shared_ptr< Go::SplineSurface >	surf
	The actual spline surface object.

Go::SplineCurve *	bou [4]
	Pointers to the four boundary curves.

bool	swapV
	Has the v-parameter direction been swapped?

const IndexVec &	nodeInd
	IJ-pairs for the control points (nodes)

IndexVec	myNodeInd
	The actual IJ-pair container.

std::map< size_t, size_t >	xnMap
	Node index map used by getCoord()

std::map< size_t, size_t >	nxMap
	Node index map used by getNodeID()

std::vector< DirichletEdge >	dirich
	Inhomogeneous Dirichlet boundary condition data.

ThreadGroups	threadGroups
	Element groups for multi-threaded assembly.

std::vector< std::unique_ptr< BasisFunctionCache > >	myCache
	Basis function cache.

Protected Attributes inherited from ASMstruct
std::shared_ptr< Go::GeomObject >	geomB
	Pointer to spline object of the geometry basis.

std::shared_ptr< Go::GeomObject >	projB
	Pointer to spline object of the projection basis.

std::shared_ptr< Go::GeomObject >	projB2
	Pointer to spline object of the secondary projection basis.

ThreadGroups	projThreadGroups
	Element groups for multi-threaded assembly - projection basis.

ThreadGroups	proj2ThreadGroups
	Element groups for multi-threaded assembly - second projection basis.

Protected Attributes inherited from ASMbase
unsigned char	ndim
	Number of parametric dimensions (1, 2 or 3)

unsigned char	nsd
	Number of space dimensions (ndim <= nsd <= 3)

unsigned char	nf
	Number of primary solution fields (1 or larger)

unsigned char	nLag
	Number of Lagrange multipliers per node.

size_t	nel
	Number of regular elements in this patch.

size_t	nnod
	Number of regular nodes in this patch.

const IntVec &	MLGE
	Matrix of Local to Global Element numbers.

const IntVec &	MLGN
	Matrix of Local to Global Node numbers.

const IntMat &	MNPC
	Matrix of Nodal Point Correspondance.

const char	shareFE
	Flag telling whether this patch shares its data with another patch. More...

BCVec	BCode
	Array of Boundary Condition codes.

MPCMap	dCode
	Inhomogeneous Dirichlet condition codes for the MPCs.

MPCSet	mpcs
	All multi-point constraints with the slave in this patch.

IntVec	myMLGE
	The actual Matrix of Local to Global Element numbers.

IntVec	myMLGN
	The actual Matrix of Local to Global Node numbers.

IntMat	myMNPC
	The actual Matrix of Nodal Point Correspondance.

IntVec	myElms
	Elements on patch - used with partitioning.

int	nGauss
	Numerical integration scheme for this patch. More...

size_t	firstEl
	Global index to first element within this patch.

size_t	firstIp
	Global index to first interior integration point.

std::map< char, size_t >	firstBp
	Global indices to first integration point for the Neumann boundaries.

ASMVec	neighbors
	Patches having nodes in common with this one.

std::map< size_t, XYZ >	myRmaster
	Rigid master nodal points.

Private Types
typedef std::vector< IJ >	IndexVec
	Node index container.

typedef std::pair< int, int >	Ipair
	Convenience type.

Private Member Functions
Go::SplineSurface *	projectSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

Go::SplineSurface *	scRecovery (const IntegrandBase &) const
	Projects the secondary solution using a superconvergent approach.

Go::SplineSurface *	projectSolutionLocal (const IntegrandBase &) const
	Projects the secondary solution using Quasi-Interpolation.

Go::SplineSurface *	projectSolutionLocalApprox (const IntegrandBase &) const
	Projects the secondary solution using Variation Diminishing Spline Approximation.

Go::SplineSurface *	projectSolutionLeastSquare (const IntegrandBase &) const
	Projects the secondary solution using Least-Square Approximation.

bool	getOrder (int &p1, int &p2) const
	Returns the polynomial order in each parameter direction. More...

int	coeffInd (size_t inod) const
	Returns an index into the internal coefficient array for a node. More...

Static Private Member Functions
static void	createMNPC (const Go::SplineSurface *srf, IntMat &MNPC)
	Creates matrix of nodal point correspondance for a spline surface.

Additional Inherited Members
Public Types inherited from ASMbase
using	BCVec = std::vector< BC >
	Nodal boundary condition container.

Public Types inherited from ASM2D
typedef std::vector< unsigned char >	CharVec
	Convenience type.

Public Attributes inherited from ASMbase
size_t	idx
	Index of this patch in the multi-patch model.

Static Public Attributes inherited from ASMbase
static bool	fixHomogeneousDirichlet = true
	If true, pre-eliminate fixed DOFs.

static int	dbgElm = 0
	One-based element index to print debugging info for.

static double	modelSize = 1.0
	Characteristic model size. More...

Protected Types inherited from ASMbase
using	XYZ = std::array< double, 3 >
	Convenience type definition.

Static Protected Member Functions inherited from ASMbase
static bool	deformedConfig (const Matrix &Xnod, Vectors &eVec, bool force2nd=false)
	Calculates the deformed configuration for current element. More...

static bool	collapseNodes (ASMbase &pch1, int node1, ASMbase &pch2, int node2)
	Collapses the given two nodes into one. More...

Static Protected Member Functions inherited from ASM2D
static double	getElementSize (const std::vector< Vec3 > &XC)
	Returns characteristic element size based on corner coordinates.

Static Protected Attributes inherited from ASMbase
static std::map< int, int >	xNode
	Auxilliary node number map used when establishing Dirichlet constraints.

static int	gEl = 0
	Global element counter.

static int	gNod = 0
	Global node counter.

Detailed Description

Driver for assembly of structured 2D spline FE models.

This class contains methods common for structured 2D spline patches.

Member Function Documentation

◆ addInterfaceElms()

bool ASMs2D::addInterfaceElms ( const ASM::InterfaceChecker & iChk )

Adds interface elements with coupling to all element DOFs.

Parameters

[in] iChk Object checking if an element interface has contributions

References ASMbase::gEl, ASM::InterfaceChecker::hasContribution(), utl::merge(), ASMbase::MLGE, ASMbase::MNPC, ASMbase::myMLGE, ASMbase::myMNPC, ASMbase::nel, ASMbase::shareFE, and surf.

Referenced by ASMs2DIB::generateFEMTopology().

◆ addRigidCpl()

bool ASMs2D::addRigidCpl	(	int	lindx,
		int	ldim,
		int	basis,
		int &	gMaster,
		const Vec3 &	Xmaster,
		bool	extraPt
	)

virtual

Adds MPCs representing a rigid coupling to this patch.

Parameters

[in]	lindx	Local index of the boundary item that should be rigid
[in]	ldim	Dimension of the boundary item that should be rigid
[in]	basis	Which basis to add rigid coupling for (mixed methods)
	gMaster	Global node number of the master node
[in]	Xmaster	Position of the master nodal point
[in]	extraPt	If true, the master point is not a patch node

Returns: true if a new global node was added, otherwise false

Reimplemented from ASMbase.

Reimplemented in ASMs2DC1.

References ASMbase::addRigidCpl(), IFEM::cout, ASMbase::idx, ThreadGroups::stripDir, and threadGroups.

◆ addXElms()

bool ASMs2D::addXElms	(	short int	dim,
		short int	item,
		size_t	nXn,
		IntVec &	nodes
	)

virtual

Adds extraordinary elements associated with a patch boundary.

Parameters

[in]	dim	Dimension of the boundary (should be 1)
[in]	item	Local index of the boundary edge
[in]	nXn	Number of extraordinary nodes
[out]	nodes	Global numbers assigned to the extraordinary nodes

Reimplemented from ASMbase.

Reimplemented in ASMs2DTri, and ASMs2DLag.

References ASMstruct::addXNodes(), ASMbase::MLGE, ASMbase::MNPC, ASMbase::myMNPC, ASMbase::nel, and surf.

◆ assembleL2matrices()

bool ASMs2D::assembleL2matrices	(	SystemMatrix &	A,
		SystemVector &	B,
		const L2Integrand &	integrand,
		bool	continuous
	)		const

protectedvirtual

Assembles L2-projection matrices for the secondary solution.

Parameters

[out]	A	Left-hand-side matrix
[out]	B	Right-hand-side vectors
[in]	integrand	Object with problem-specific data and methods
[in]	continuous	If false, a discrete L2-projection is used

Reimplemented from ASMbase.

Reimplemented in ASMs2DLag.

References L2Integrand::evaluate(), ASM::GEOMETRY_BASIS, getBasis(), GaussQuadrature::getCoord(), getElmNodes(), SplineUtils::getGaussParameters(), ASMbase::getNoBasis(), ASMbase::getNoGaussPt(), getNoProjectionNodes(), GaussQuadrature::getWeight(), ASMbase::idx, ASMbase::nnod, SystemMatrix::preAssemble(), and ASM::PROJECTION_BASIS.

◆ assignNodeNumbers()

bool ASMs2D::assignNodeNumbers	(	BlockNodes &	nodes,
		int	basis = `0`
	)

Assigns new global node numbers for all nodes of the patch.

Parameters

	nodes	Object with global nodes numbers to assign to this patch
[in]	basis	Which basis to assign node numbers for in mixed methods

The global node numbers generated by generateFEMTopology() are non-unique in the sense that a node that is shared by two (or more) patches along a common interface has a different number in each patch. This method therefore assigns a new global number to each node in the patch. The data provided through the nodes argument is sufficient to determine the unique global number under the assumption that they are ordered in the sequence determined by the local orientation of the patch and its edges.

References ASMs2D::BlockNodes::edges, getSize(), ASMs2D::BlockNodes::ibnod, ASMs2D::BlockNodes::inc, ASMbase::MLGN, ASMbase::myMLGN, ASMs2D::Edge::next(), ASMs2D::BlockNodes::next(), ASMs2D::BlockNodes::nnodI, nodeInd, and ASMbase::shareFE.

◆ checkRightHandSystem()

bool ASMs2D::checkRightHandSystem ( )

virtual

Checks that the patch is modelled in a right-hand-side system.

If it isn't, the v-parameter direction is swapped.

Reimplemented from ASM2D.

References ASMbase::shareFE, surf, and swapV.

◆ clear()

void ASMs2D::clear ( bool retainGeometry = false )

virtual

Clears the contents of the patch, making it empty.

Parameters

[in] retainGeometry If true, the spline geometry is not cleared. This is used to reinitialize the patch after it has been refined.

Reimplemented from ASMbase.

Reimplemented in ASMs2DLag, ASMs2DmxLag, and ASMs2Dmx.

References ASMbase::clear(), ASMstruct::geomB, myNodeInd, nxMap, ASMstruct::projB, surf, and xnMap.

Referenced by ASMs2Dmx::clear(), and ASMs2DLag::clear().

◆ closeBoundaries()

void ASMs2D::closeBoundaries	(	int	dir,
		int	basis,
		int	master
	)

virtual

Makes two opposite boundary edges periodic.

Parameters

[in]	dir	Parameter direction defining the periodic edges
[in]	basis	Which basis to connect (mixed methods)
[in]	master	1-based index of the first master node in this basis

Reimplemented from ASMbase.

Reimplemented in ASMs2DmxLag, ASMs2Dmx, and ASMs2DC1.

References utl::getDirs(), ASMbase::getNoFields(), getSize(), ASMbase::makePeriodic(), ThreadGroups::stripDir, and threadGroups.

Referenced by ASMs2Dmx::closeBoundaries(), and ASMs2DmxLag::closeBoundaries().

◆ coeffInd()

int ASMs2D::coeffInd ( size_t inod ) const

private

Returns an index into the internal coefficient array for a node.

Parameters

[in] inod 0-based node index local to current patch

References ASMbase::nnod, nodeInd, and surf.

Referenced by getCoord(), and getElementCoordinates().

◆ collapseEdge()

bool ASMs2D::collapseEdge	(	int	dir,
		int	basis = `1`
	)

virtual

Collapses a degenereated edge into a single node.

Parameters

[in]	dir	Parameter direction defining the edge to collapse
[in]	basis	Which basis to collapse edge for

References ASMbase::collapseNodes(), getCoord(), getSize(), ASMbase::nnod, ThreadGroups::stripDir, swapV, and threadGroups.

Referenced by SIM2D::parseGeometryTag().

◆ connectBasis()

bool ASMs2D::connectBasis	(	int	edge,
		ASMs2D &	neighbor,
		int	nedge,
		bool	revers,
		int	basis = `1`,
		int	slave = `0`,
		int	master = `0`,
		bool	coordCheck = `true`,
		int	thick = `1`
	)

protected

Connects all matching nodes on two adjacent boundary edges.

Parameters

[in]	edge	Local edge index of this patch, in range [1,4]
	neighbor	The neighbor patch
[in]	nedge	Local edge index of neighbor patch, in range [1,4]
[in]	revers	Indicates whether the two edges have opposite directions
[in]	basis	Which basis to connect the nodes for (mixed methods)
[in]	slave	0-based index of the first slave node in this basis
[in]	master	0-based index of the first master node in this basis
[in]	coordCheck	False to disable coordinate checks (periodic connections)
[in]	thick	Thickness of connection

References ASMbase::isShared().

Referenced by ASMs2Dmx::connectPatch(), ASMs2DmxLag::connectPatch(), and connectPatch().

◆ connectPatch()

bool ASMs2D::connectPatch	(	int	edge,
		ASM2D &	neighbor,
		int	nedge,
		bool	revers,
		int	= `0`,
		bool	coordCheck = `true`,
		int	thick = `1`
	)

virtual

Connects all matching nodes on two adjacent boundary edges.

Parameters

[in]	edge	Local edge index of this patch, in range [1,4]
	neighbor	The neighbor patch
[in]	nedge	Local edge index of neighbor patch, in range [1,4]
[in]	revers	Indicates whether the two edges have opposite directions
[in]	coordCheck	False to disable coordinate checks (periodic connections)
[in]	thick	Thickness of connection

Implements ASM2D.

Reimplemented in ASMs2DmxLag, and ASMs2Dmx.

References connectBasis(), and swapV.

Referenced by SIM2D::parse().

◆ constrainCorner()

void ASMs2D::constrainCorner	(	int	I,
		int	J,
		int	dof,
		int	code = `0`,
		char	basis = `1`
	)

virtual

Constrains a corner node identified by the two parameter indices.

Parameters

[in]	I	Parameter index in u-direction
[in]	J	Parameter index in v-direction
[in]	dof	Which DOFs to constrain at the node
[in]	code	Inhomogeneous dirichlet condition code
[in]	basis	Which basis to constrain node for

The sign of the two indices is used to define whether we want the node at the beginning or the end of that parameter direction. The magnitude of the indices are not used.

Implements ASM2D.

References getCorner(), getSize(), and ASMbase::prescribe().

◆ constrainEdge()

void ASMs2D::constrainEdge	(	int	dir,
		bool	open,
		int	dof,
		int	code,
		char	basis
	)

virtual

Constrains all DOFs on a given boundary edge.

Parameters

[in]	dir	Parameter direction defining the edge to constrain
[in]	open	If true, exclude the end points of the edge
[in]	dof	Which DOFs to constrain at each node along the edge
[in]	code	Inhomogeneous dirichlet condition code
[in]	basis	Which basis to constrain edge for

A negative code value implies direct evaluation of the Dirichlet condition function at the control point. Positive code implies projection onto the spline basis representing the boundary curve (needed for curved edges and/or non-constant functions).

Implements ASM2D.

Reimplemented in ASMs2DC1, and ASMs2DLag.

References dirich, getBoundary(), getSize(), ASMbase::prescribe(), and swapV.

Referenced by ASMs2DLag::constrainEdge().

◆ constrainEdgeLocal()

size_t ASMs2D::constrainEdgeLocal	(	int	dir,
		bool	open,
		int	dof,
		int	code,
		bool	project = `false`
	)

virtual

Constrains all DOFs in local directions on a given boundary edge.

Parameters

[in]	dir	Parameter direction defining the edge to constrain
[in]	open	If true, exclude the end points of the edge
[in]	dof	Which local DOFs to constrain at each node on the edge
[in]	code	Inhomogeneous dirichlet condition code
[in]	project	If true, the local axis directions are projected

Returns: Number of additional nodes added due to local axis constraints

The local coordinate systems in which the constraints are applied, are constructed from the tangent direction of the edge curve, evaluated at the Greville points (giving the local Y-direction). The local X-direction is then the outward-directed normal, defined from the cross product between the surface normal vector and the edge tangent. If project is true, the tangent- and normal direction vectors are projected onto the curve basis of the edge in order to obtain corresponding control point values. Otherwise, they are used directly.

A negative code value implies direct evaluation of the Dirichlet condition function at the control point. Positive code implies projection onto the spline basis representing the boundary curve (needed for curved edges and/or non-constant functions).

Implements ASM2D.

References MPC::addMaster(), ASMbase::addMPC(), Vec3::cross(), dirich, getBoundary(), getGrevilleParameters(), getSize(), ASMbase::gNod, ASMbase::isFixed(), ASMbase::MLGN, ASMbase::myMLGN, ASMbase::nf, Vec3::normalize(), ASMbase::nsd, nxMap, ASMbase::prescribe(), SplineUtils::project(), ASMbase::shareFE, surf, swapV, SplineUtils::toVec3(), Vec3::x, xnMap, ASMbase::xNode, Vec3::y, and Vec3::z.

◆ constrainNode()

void ASMs2D::constrainNode	(	double	xi,
		double	eta,
		int	dof,
		int	code = `0`
	)

virtual

Constrains a node identified by two relative parameter values.

Parameters

[in]	xi	Parameter in u-direction
[in]	eta	Parameter in v-direction
[in]	dof	Which DOFs to constrain at the node
[in]	code	Inhomogeneous dirichlet condition code

The parameter values have to be in the domain [0.0,1.0], where 0.0 means the beginning of the domain and 1.0 means the end. For values in between, the actual index is taken as the integer value closest to r*n, where r denotes the given relative parameter value, and n is the number of nodes along that parameter direction.

Implements ASM2D.

Reimplemented in ASMs2DC1.

References getSize(), ASMbase::prescribe(), and swapV.

◆ createProjectionBasis()

bool ASMs2D::createProjectionBasis ( bool init )

virtual

Creates a separate projection basis for this patch.

This method is supposed to be invoked twice during the model generation. In the first call, with init = true, the spline surface object *surf is cloned into *proj and the two pointers are then swapped, such that the subsequent refine and raiseOrder operations will apply to the projection basis and not on the geometry basis. In the second call, the pointers are swapped back.

The method can also be invoked twice with init = false in case the projection basis is to be read from a file.

Reimplemented from ASMbase.

References surf.

◆ evalPoint()

int ASMs2D::evalPoint	(	const double *	xi,
		double *	param,
		Vec3 &	X
	)		const

virtual

Evaluates the geometry at a specified point.

Parameters

[in]	xi	Dimensionless parameters in range [0.0,1.0] of the point
[out]	param	The (u,v) parameters of the point in knot-span domain
[out]	X	The Cartesian coordinates of the point

Returns: Local node number within the patch that matches the point, if any; 0 if no node (control point) matches this point

Implements ASMbase.

Reimplemented in ASMs2Dmx, and ASMs2DLag.

References ASM::GEOMETRY_BASIS, getBasis(), SplineUtils::point(), ASMbase::searchCtrlPt(), and surf.

◆ evalProjSolution()

bool ASMs2D::evalProjSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const int *	npe,
		int	n_f
	)		const

virtual

Evaluates the projected solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	npe	Number of visualization nodes over each knot span
[in]	n_f	If nonzero, mixed evaluates n_f fields on first basis

Reimplemented from ASMbase.

References ASMstruct::evalSolution(), utl::matrix< T >::fillColumn(), getGridParameters(), Fields::getNoFields(), getProjectedFields(), utl::matrix< T >::resize(), separateProjectionBasis(), and Fields::valueFE().

◆ evalSolution() [1/5]

Go::GeomObject * ASMs2D::evalSolution ( const IntegrandBase & integrand ) const

virtual

Projects the secondary solution field onto the primary basis.

Parameters

[in] integrand Object with problem-specific data and methods

Implements ASMstruct.

References projectSolution().

◆ evalSolution() [2/5]

bool ASMs2D::evalSolution	(	Matrix &	sField,
		const IntegrandBase &	integrand,
		const int *	npe = `nullptr`,
		char	project = `0`
	)		const

virtual

Evaluates the secondary solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	npe	Number of visualization nodes over each knot span
[in]	project	Flag indicating result recovery method (0=none, 'D'=direct evaluation, 'S'=superconvergent recovery)

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. If npe is null, the solution is recovered or evaluated at the Greville points and then projected onto the spline basis to obtain the control point values, which then are returned through sField. If npe is not null and project is defined, the solution is also projected onto the spline basis, and then evaluated at the npe points.

Reimplemented from ASMbase.

Reimplemented in ASMs2DTri, ASMs2DmxLag, and ASMs2DLag.

References ASMstruct::evalSolution(), utl::matrix< T >::fill(), getGridParameters(), SplineUtils::project(), projectSolution(), projectSolutionLeastSquare(), projectSolutionLocal(), projectSolutionLocalApprox(), utl::matrix< T >::resize(), and scRecovery().

◆ evalSolution() [3/5]

bool ASMs2D::evalSolution	(	Matrix &	sField,
		const IntegrandBase &	integrand,
		const RealArray *	gpar,
		bool	regular = `true`
	)		const

virtual

Evaluates the secondary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	gpar	Parameter values of the result sampling points
[in]	regular	Flag indicating how the sampling points are defined

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. When regular is true, it is assumed that the parameter value array gpar forms a regular tensor-product point grid of dimension gpar[0].size() X gpar[1].size(). Otherwise, we assume that it contains the u and v parameters directly for each sampling point.

Reimplemented from ASMbase.

Reimplemented in ASMs2DmxLag, ASMs2Dmx, ASMs2DLag, ASMs2DSpec, and ASMs2DTri.

References FiniteElement::age, Vec4::assign(), FiniteElement::d2NdX2, FiniteElement::d3NdX3, ASMbase::deformedConfig(), FiniteElement::detJxW, FiniteElement::dNdX, utl::matrixBase< T >::empty(), IntegrandBase::evalSol(), SplineUtils::extractBasis(), utl::matrix< T >::fillColumn(), findElementContaining(), ASMbase::firstIp, FiniteElement::G, utl::gather(), Integrand::getIntegrandType(), getNodalCoordinates(), IntegrandBase::getTimeLevel(), FiniteElement::H, utl::Hessian(), utl::Hessian2(), ItgPoint::iGP, utl::Jacobian(), FiniteElement::N, ASMbase::nsd, FiniteElement::p, PROFILE2, FiniteElement::q, utl::matrix< T >::resize(), scatterInd(), Integrand::SECOND_DERIVATIVES, utl::vector< T >::size(), surf, Vec4::t, Integrand::THIRD_DERIVATIVES, ItgPoint::u, Integrand::UPDATED_NODES, and ItgPoint::v.

◆ evalSolution() [4/5]

bool ASMs2D::evalSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const int *	npe,
		int	n_f,
		bool	piola
	)		const

virtual

Evaluates the primary solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector in DOF-order
[in]	npe	Number of visualization nodes over each knot span
[in]	n_f	If nonzero, mixed evaluates n_f fields on first basis
[in]	piola	If true, use piola mapping

Reimplemented from ASMbase.

Reimplemented in ASMs2DLag.

References ASMstruct::evalSolution(), ASMbase::evalSolutionPiola(), and getGridParameters().

Referenced by evaluate().

◆ evalSolution() [5/5]

bool ASMs2D::evalSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const RealArray *	gpar,
		bool	regular = `true`,
		int	deriv = `0`,
		int	= `0`
	)		const

virtual

Evaluates the primary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	gpar	Parameter values of the result sampling points
[in]	regular	Flag indicating how the sampling points are defined
[in]	deriv	Derivative order to return

When regular is true, it is assumed that the parameter value array gpar forms a regular tensor-product point grid of dimension gpar[0].size() X gpar[1].size(). Otherwise, we assume that it contains the u and v parameters directly for each sampling point.

Reimplemented from ASMbase.

Reimplemented in ASMs2DLag, ASMs2Dmx, and ASMs2DmxLag.

References SplineUtils::extractBasis(), utl::matrix< T >::fillColumn(), utl::gather(), getNodalCoordinates(), utl::Hessian(), utl::Jacobian(), utl::matrix< T >::multiply(), utl::matrix3d< T >::multiply(), ASMbase::nsd, PROFILE2, utl::matrix< T >::resize(), scatterInd(), utl::vector< T >::size(), and surf.

◆ evaluate() [1/3]

bool ASMs2D::evaluate	(	const ASMbase *	basis,
		const Vector &	locVec,
		RealArray &	vec,
		int	basisNum
	)		const

virtual

Evaluates and interpolates a field over a given geometry.

Parameters

[in]	basis	The basis of the field to evaluate
[in]	locVec	The coefficients of the field to evaluate
[out]	vec	The obtained coefficients after interpolation
[in]	basisNum	Basis number (mixed)

Reimplemented from ASMbase.

Reimplemented in ASMs2DLag.

References evalSolution(), getBasis(), getGrevilleParameters(), utl::matrix< T >::rows(), and surf.

◆ evaluate() [2/3]

bool ASMs2D::evaluate	(	const Field *	field,
		RealArray &	vec,
		int	basisNum
	)		const

virtual

Evaluates and interpolates a field over a given geometry.

Parameters

[in]	field	The field to evaluate
[out]	vec	The obtained coefficients after interpolation
[in]	basisNum	Basis number (mixed)

Note: A Variation Diminishing Spline Approximation is used here as the regular interpolation method in GoTools only works with uniform knots.

Reimplemented from ASMbase.

References getBasis(), getGrevilleParameters(), utl::vector< T >::push_back(), utl::vector< T >::reserve(), and Field::valueFE().

◆ evaluate() [3/3]

bool ASMs2D::evaluate	(	const FunctionBase *	func,
		RealArray &	vec,
		int	basisNum,
		double	time
	)		const

virtual

Evaluates and interpolates a function over a given geometry.

Parameters

[in]	func	The function to evaluate
[out]	vec	The obtained coefficients after interpolation
[in]	basisNum	Basis number (mixed)
[in]	time	Current time

Reimplemented from ASMbase.

References FunctionBase::dim(), getBasis(), and SplineUtils::project().

◆ evaluateBasis()

void ASMs2D::evaluateBasis	(	double	u,
		double	v,
		double	,
		Vector &	N
	)		const

virtual

Evaluates the basis functions at the specified point.

Parameters

[in]	u	First parameter value of evaluation point
[in]	v	Second parameter value of evaluation point
[out]	N	Basis function values

Implements ASMstruct.

References surf.

◆ extractBasis() [1/3]

void ASMs2D::extractBasis	(	double	u,
		double	v,
		int	dir,
		int	p,
		Vector &	dN,
		bool	fromRight = `true`
	)		const

Establishes a vector with basis function derivatives.

Parameters

[in]	u	First parameter value of current integration point
[in]	v	Second parameter value of current integration point
[in]	dir	Which parameter to establish derivatives with respect to
[in]	p	The derivation order
[out]	dN	Basis function derivatives
[in]	fromRight	If true, evaluate from right if at a knot

References utl::vector< T >::resize(), and surf.

◆ extractBasis() [2/3]

void ASMs2D::extractBasis	(	double	u,
		double	v,
		Vector &	N,
		Matrix &	dNdu,
		bool	fromRight = `true`
	)		const

Establishes matrices with basis functions and 1st derivatives.

Parameters

[in]	u	First parameter value of current integration point
[in]	v	Second parameter value of current integration point
[out]	N	Basis function values
[out]	dNdu	First derivatives of basis functions
[in]	fromRight	If true, evaluate from right if at a knot

References SplineUtils::extractBasis(), and surf.

Referenced by integrate().

◆ extractBasis() [3/3]

void ASMs2D::extractBasis	(	double	u,
		double	v,
		Vector &	N,
		Matrix &	dNdu,
		Matrix3D &	d2Ndu2,
		bool	fromRight = `true`
	)		const

Establishes matrices with basis functions, 1st and 2nd derivatives.

Parameters

[in]	u	First parameter value of current integration point
[in]	v	Second parameter value of current integration point
[out]	N	Basis function values
[out]	dNdu	First derivatives of basis functions
[out]	d2Ndu2	Second derivatives of basis functions
[in]	fromRight	If true, evaluate from right if at a knot

References SplineUtils::extractBasis(), and surf.

◆ findBoundaryElms()

void ASMs2D::findBoundaryElms	(	IntVec &	elms,
		int	lIndex,
		int	= `0`
	)		const

protectedvirtual

Finds the patch-local element numbers on a patch boundary.

Parameters

[out]	elms	Array of element numbers
[in]	lIndex	Local index of the boundary edge

Implements ASMbase.

Reimplemented in ASMs2DLag.

References surf.

◆ findElementContaining()

int ASMs2D::findElementContaining ( const double * param ) const

virtual

Returns the element that contains a specified spatial point.

Parameters

[in] param The parameters of the point in the knot-span domain

Returns: Local element number within the patch that contains the point

Implements ASMbase.

References surf.

Referenced by evalSolution().

◆ findPoint()

double ASMs2D::findPoint	(	Vec3 &	X,
		double *	param
	)		const

virtual

Searches for the specified Cartesian point in the patch.

Parameters

	X	The Cartesian coordinates of the point, updated on output
[out]	param	The parameters of the point in the knot-span domain

Returns: Distance from the point X to the found point

Implements ASMbase.

References surf, Vec3::x, Vec3::y, and Vec3::z.

◆ generateFEMTopology()

bool ASMs2D::generateFEMTopology ( )

virtual

Generates the finite element topology data for the patch.

The data generated are the element-to-node connectivity array, the node-to-IJ-index array, as well as global node and element numbers.

Implements ASMbase.

Reimplemented in ASMu2DLag, ASMs2DTri, ASMs2DmxLag, ASMs2Dmx, ASMs2DLag, ASMs2DIB, and ASMs2DC1.

References ASMstruct::projB, and surf.

Referenced by ASMs2DC1::generateFEMTopology(), and ASMs2DIB::generateFEMTopology().

◆ generateThreadGroups() [1/2]

void ASMs2D::generateThreadGroups	(	const Integrand &	integrand,
		bool	silence,
		bool	ignoreGlobalLM
	)

protectedvirtual

Generates element groups for multi-threading of interior integrals.

Parameters

[in]	integrand	Object with problem-specific data and methods
[in]	silence	If true, suppress threading group outprint
[in]	ignoreGlobalLM	Sanity check option

Reimplemented from ASMbase.

Reimplemented in ASMs2Dmx, ASMs2DTri, ASMs2DLag, and ASMu2DLag.

References generateThreadGroups(), getBasis(), ASMbase::nel, ThreadGroups::oneGroup(), ASMstruct::proj2ThreadGroups, ASM::PROJECTION_BASIS_2, ASMstruct::projThreadGroups, ThreadGroups::stripDir, surf, and threadGroups.

◆ generateThreadGroups() [2/2]

void ASMs2D::generateThreadGroups	(	size_t	strip1,
		size_t	strip2,
		bool	silence,
		bool	ignoreGlobalLM
	)

protected

Generates element groups for multi-threading of interior integrals.

Parameters

[in]	strip1	Strip width in first direction
[in]	strip2	Strip width in second direction
[in]	silence	If true, suppress threading group outprint
[in]	ignoreGlobalLM	Sanity check option

Lamba for setting up thread groups for basis.

References ThreadGroups::calcGroups(), ASMstruct::checkThreadGroups(), IFEM::cout, getBasis(), ASMbase::MLGE, ASMbase::MNPC, ASMstruct::proj2ThreadGroups, ASM::PROJECTION_BASIS, ASM::PROJECTION_BASIS_2, ASMstruct::projThreadGroups, separateProjectionBasis(), ThreadGroups::size(), surf, and threadGroups.

◆ getBoundary()

Go::SplineCurve * ASMs2D::getBoundary	(	int	dir,
		int	= `1`
	)

virtual

Returns the spline curve representing a boundary of this patch.

Parameters

[in] dir Parameter direction defining which boundary to return

Reimplemented in ASMs2Dmx.

References bou, and surf.

Referenced by constrainEdge(), and constrainEdgeLocal().

◆ getBoundaryNodes()

void ASMs2D::getBoundaryNodes	(	int	lIndex,
		IntVec &	nodes,
		int	basis,
		int	thick = `1`,
		int	= `0`,
		bool	local = `false`
	)		const

virtual

Finds the global (or patch-local) node numbers on a patch boundary.

Parameters

[in]	lIndex	Local index of the boundary edge
	nodes	Array of node numbers
[in]	basis	Which basis to grab nodes for (for mixed methods)
[in]	thick	Thickness of connection
[in]	local	If true, return patch-local node numbers

Implements ASMbase.

Reimplemented in ASMu2DLag, and ASMs2Dmx.

References getSize(), and ASMbase::idx.

Referenced by ASMs2DC1::addRigidCpl(), and ASMs2Dmx::getBoundaryNodes().

◆ getCoord()

Vec3 ASMs2D::getCoord ( size_t inod ) const

virtual

Returns the global coordinates for the given node.

Parameters

[in] inod 1-based node index local to current patch

Implements ASMbase.

Reimplemented in ASMs2Dmx, and ASMs2DLag.

References coeffInd(), ASMbase::MLGN, ASMbase::myRmaster, ASMbase::nnod, ASMbase::nsd, surf, and xnMap.

Referenced by ASMs2DC1::addRigidCpl(), collapseEdge(), ASMs2DC1::initConstraints(), and ASMs2DC1::updateDirichlet().

◆ getCorner()

int ASMs2D::getCorner	(	int	I,
		int	J,
		int	basis
	)		const

virtual

Returns the node index for a given corner.

Parameters

[in]	I	-1 or +1 for either umin or umax corner
[in]	J	-1 or +1 for either vmin or vmax corner
[in]	basis	which basis to consider (for mixed methods)

Implements ASM2D.

References getSize(), and swapV.

Referenced by constrainCorner().

◆ getCornerPoints()

void ASMs2D::getCornerPoints	(	int	i1,
		int	i2,
		std::vector< utl::Point > &	XC
	)		const

protected

Computes the element corner coordinates and parameters.

Parameters

[in]	i1	Parameter index in u-direction
[in]	i2	Parameter index in v-direction
[out]	XC	Coordinates and parameters of the element corners

References getElementCorners().

Referenced by ASMs2DIB::generateFEMTopology().

◆ getElementBorders() [1/2]

void ASMs2D::getElementBorders	(	int	i1,
		int	i2,
		double *	u,
		double *	v
	)		const

protected

Computes the element border parameters.

Parameters

[in]	i1	Parameter index in u-direction
[in]	i2	Parameter index in v-direction
[out]	u	Parameter values of the west-east borders
[out]	v	Parameter values of the south-north borders

References surf.

Referenced by getElementBorders(), getElementCorners(), integrate(), and ASMs2Dmx::integrate().

◆ getElementBorders() [2/2]

void ASMs2D::getElementBorders	(	int	iel,
		double *	u
	)		const

protectedvirtual

Computes the element border parameters.

Parameters

[in]	iel	1-based element index
[out]	u	Parameter values of the element borders

Implements ASMstruct.

References getElementBorders(), and surf.

◆ getElementCoordinates()

bool ASMs2D::getElementCoordinates	(	Matrix &	X,
		int	iel,
		bool	forceItg = `false`
	)		const

virtual

Returns a matrix with nodal coordinates for an element.

Parameters

[out]	X	3 \(\times\)n-matrix, where n is the number of nodes in one element
[in]	iel	1-based element index local to current patch
[in]	forceItg	If true, return the integration basis coordinates otherwise the geometry basis coordinates are returned

Implements ASMbase.

Reimplemented in ASMs2DLag.

References coeffInd(), utl::matrix< T >::cols(), ASM::GEOMETRY_BASIS, getBasis(), getElementCoordinatesPrm(), getFirstItgElmNode(), ASMs2D::IJ::I, ASMs2D::IJ::J, ASMbase::MNPC, nodeInd, ASMbase::nsd, utl::matrix< T >::resize(), and surf.

Referenced by ASMs2DmxLag::evalSolution(), integrate(), and ASMs2Dmx::integrate().

◆ getElementCoordinatesPrm()

bool ASMs2D::getElementCoordinatesPrm	(	Matrix &	X,
		double	u,
		double	v
	)		const

protected

Returns a matrix with nodal coordinates for element containing given parameters.

Parameters

[out]	X	3 \(\times\)n-matrix, where n is the number of nodes
[in]	u	First parameter of point
[in]	v	Second parameter of point

References utl::matrix< T >::cols(), ASM::GEOMETRY_BASIS, getBasis(), ASMbase::nsd, and utl::matrix< T >::resize().

Referenced by ASMs2DmxLag::evalSolution(), ASMs2Dmx::evalSolutionPiola(), and getElementCoordinates().

◆ getElementCorners()

double ASMs2D::getElementCorners	(	int	i1,
		int	i2,
		std::vector< Vec3 > &	XC,
		RealArray *	uC = `nullptr`
	)		const

protected

Computes the element corner coordinates.

Parameters

[in]	i1	Parameter index in u-direction
[in]	i2	Parameter index in v-direction
[out]	XC	Coordinates of the element corners
[out]	uC	Spline parameters of the element corners (optional)

Returns: Characteristic element size

References getElementBorders(), ASM2D::getElementSize(), ASMbase::nsd, and surf.

Referenced by getCornerPoints(), integrate(), ASMs2Dmx::integrate(), and ASMs2DmxLag::integrate().

◆ getElmConnectivities()

void ASMs2D::getElmConnectivities	(	IntMat &	neigh,
		int	basis = `ASM::INTEGRATION_BASIS`
	)		const

virtual

Calculates the matrix of element neighbour connectivities.

Parameters

[out]	neigh	List of element neighbors for each element
[in]	basis	Basis to obtain connectivities for

Implements ASMbase.

References getBasis(), ASMbase::idx, ASM::INTEGRATION_BASIS, and ASMbase::MLGE.

◆ getGaussPointParameters()

void ASMs2D::getGaussPointParameters	(	RealArray &	uGP,
		int	dir,
		int	nGauss,
		const double *	xi
	)		const

protected

Extracts parameter values of the Gauss points in one direction.

Parameters

[out]	uGP	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)
[in]	nGauss	Number of Gauss points along a knot-span
[in]	xi	Dimensionless Gauss point coordinates [-1,1]

References SplineUtils::getGaussParameters(), ASMbase::nGauss, and surf.

◆ getGrevilleParameters()

bool ASMs2D::getGrevilleParameters	(	RealArray &	prm,
		int	dir,
		int	basisNum = `1`
	)		const

protected

Calculates parameter values for the Greville points.

Parameters

[out]	prm	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)
[in]	basisNum	Which basis to get Greville point parameters for

References getBasis().

Referenced by constrainEdgeLocal(), evaluate(), projectSolution(), projectSolutionLocalApprox(), and scRecovery().

◆ getGridParameters()

bool ASMs2D::getGridParameters	(	RealArray &	prm,
		int	dir,
		int	nSegSpan
	)		const

virtual

Calculates parameter values for visualization nodal points.

Parameters

[out]	prm	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)
[in]	nSegSpan	Number of visualization segments over each knot-span

Reimplemented in ASMs2DSpec.

References surf.

Referenced by ASMs2DLag::evalPoint(), evalProjSolution(), evalSolution(), ASMs2DLag::generateFEMTopology(), ASMs2DmxLag::generateFEMTopology(), ASMs2DTri::integrate(), ASMs2DLag::integrate(), and tesselate().

◆ getNodalCoordinates()

void ASMs2D::getNodalCoordinates	(	Matrix &	X,
		bool	geo = `false`
	)		const

virtual

Returns a matrix with all nodal coordinates within the patch.

Parameters

[out]	X	3 \(\times\)n-matrix, where n is the number of nodes
[in]	geo	If true, coordinates for the geometry basis are returned otherwise the integration basis coordinates are returned

Implements ASMbase.

Reimplemented in ASMs2DLag.

References ASM::GEOMETRY_BASIS, getBasis(), ASMbase::nsd, utl::matrix< T >::resize(), and surf.

Referenced by ASMs2Dmx::evalSolution(), and evalSolution().

◆ getNodeID()

int ASMs2D::getNodeID	(	size_t	inod,
		bool	noAddedNodes = `false`
	)		const

virtual

Returns the global node number for the given node.

Parameters

[in]	inod	1-based node index local to current patch
[in]	noAddedNodes	If true, use nxMap to find the real node

Reimplemented from ASMbase.

References ASMbase::MLGN, and nxMap.

Referenced by ASMu2DLag::getBoundaryNodes().

◆ getNodeIndex()

size_t ASMs2D::getNodeIndex	(	int	globalNum,
		bool	noAddedNodes = `false`
	)		const

virtual

Returns local 1-based index of the node with given global number.

If the given node number is not present, 0 is returned.

Parameters

[in]	globalNum	Global node number
[in]	noAddedNodes	If true, use xnMap to find the real node

Reimplemented from ASMbase.

References utl::findIndex(), ASMbase::MLGN, ASMbase::nnod, and xnMap.

Referenced by ASMu2DLag::addToNodeSet(), ASMu2DLag::generateThreadGroupsMultiColored(), ASMs2DC1::initConstraints(), ASMu2DLag::isInNodeSet(), ASMu2DLag::parseNodeSet(), and ASMs2DC1::updateDirichlet().

◆ getNoStructElms()

bool ASMs2D::getNoStructElms	(	int &	n1,
		int &	n2,
		int &	n3
	)		const

virtual

Returns the number of elements in each parameter direction.

Parameters

[out]	n1	Number of nodes in first (u) direction
[out]	n2	Number of nodes in second (v) direction
[out]	n3	Number of nodes in third (w) direction

Implements ASMstruct.

References surf.

◆ getOrder() [1/2]

bool ASMs2D::getOrder	(	int &	p1,
		int &	p2
	)		const

private

Returns the polynomial order in each parameter direction.

Parameters

[out]	p1	Order in first (u) direction
[out]	p2	Order in second (v) direction

References surf.

Referenced by getOrder().

◆ getOrder() [2/2]

bool ASMs2D::getOrder	(	int &	p1,
		int &	p2,
		int &	p3
	)		const

virtual

Returns the polynomial order in each parameter direction.

Parameters

[out]	p1	Order in first (u) direction
[out]	p2	Order in second (v) direction
[out]	p3	Order in third (w) direction (always zero)

Reimplemented from ASMbase.

Reimplemented in ASMs2DLag.

References getOrder().

◆ getParameterDomain()

bool ASMs2D::getParameterDomain	(	Real2DMat &	u,
		IntVec *	corners
	)		const

virtual

Returns parameter values and node numbers of the domain corners.

Parameters

[out]	u	Parameter values of the domain corners
[out]	corners	1-based indices of the corner nodes (optional)

Implements ASMbase.

References surf.

◆ getParametricArea()

double ASMs2D::getParametricArea ( int iel ) const

protected

Returns the area in the parameter space for an element.

Parameters

[in] iel Element index

References ASMbase::MNPC.

Referenced by ASMs2DmxLag::evalSolution(), integrate(), and ASMs2Dmx::integrate().

◆ getParametricLength()

double ASMs2D::getParametricLength	(	int	iel,
		int	dir
	)		const

protected

Returns boundary edge length in the parameter space for an element.

Parameters

[in]	iel	Element index
[in]	dir	Local index of the boundary edge

References ASMbase::MNPC.

Referenced by integrate(), and ASMs2Dmx::integrate().

◆ getProjectedField()

Field * ASMs2D::getProjectedField ( const Vector & coefs ) const

virtual

Returns a field using the projection basis.

Parameters

[in] coefs The coefficients for the field

Reimplemented from ASMbase.

References getNoProjectionNodes(), ASMstruct::projB, and utl::vector< T >::size().

◆ getProjectedFields()

Fields * ASMs2D::getProjectedFields	(	const Vector &	coefs,
		size_t	= `0`
	)		const

virtual

Returns a field using the projection basis.

Parameters

[in] coefs The coefficients for the field

Reimplemented from ASMbase.

References getNoProjectionNodes(), ASMstruct::projB, and utl::vector< T >::size().

Referenced by evalProjSolution().

◆ getQuasiInterplParameters()

bool ASMs2D::getQuasiInterplParameters	(	RealArray &	prm,
		int	dir
	)		const

protected

Calculates parameter values for the Quasi-Interpolation points.

Parameters

[out]	prm	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)

References surf.

Referenced by projectSolutionLocal().

◆ getSize() [1/2]

bool ASMs2D::getSize	(	int &	n1,
		int &	n2,
		int &	n3,
		int	basis
	)		const

virtual

Returns the number of nodal points in each parameter direction.

Parameters

[out]	n1	Number of nodes in first (u) direction
[out]	n2	Number of nodes in second (v) direction
[out]	n3	Number of nodes in third (w) direction
[in]	basis	Which basis to return size parameters for (mixed methods)

Implements ASMstruct.

References getSize().

◆ getSize() [2/2]

bool ASMs2D::getSize	(	int &	n1,
		int &	n2,
		int	basis = `0`
	)		const

virtual

Returns the number of nodal points in each parameter direction.

Parameters

[out]	n1	Number of nodes in first (u) direction
[out]	n2	Number of nodes in second (v) direction
[in]	basis	Which basis to return size parameters for (mixed methods)

Reimplemented in ASMs2DLag, ASMs2DmxLag, and ASMs2Dmx.

References surf.

Referenced by assignNodeNumbers(), closeBoundaries(), ASMs2DC1::closeBoundaries(), collapseEdge(), ASMs2DC1::connectC1(), constrainCorner(), ASMs2DC1::constrainCorner(), constrainEdge(), ASMs2DC1::constrainEdge(), constrainEdgeLocal(), constrainNode(), ASMs2DC1::constrainNode(), getBoundaryNodes(), getCorner(), getSize(), and ASMs2Dmx::getSize().

◆ integrate() [1/4]

bool ASMs2D::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time
	)

virtual

Evaluates an integral over the interior patch domain.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Implements ASMbase.

Reimplemented in ASMu2DLag, ASMs2DTri, ASMs2DSpec, ASMs2DmxLag, ASMs2Dmx, ASMs2DLag, and ASMs2DIB.

Referenced by ASMs2DIB::integrate().

◆ integrate() [2/4]

bool ASMs2D::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time,
		const ASM::InterfaceChecker &	iChk
	)

virtual

Evaluates an integral over element interfaces in the patch.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	iChk	Object checking if an element interface has contributions

Reimplemented from ASMbase.

Reimplemented in ASMs2Dmx.

References FiniteElement::age, GlobalIntegral::assemble(), Vec4::assign(), LocalIntegral::destruct(), FiniteElement::detJxW, FiniteElement::dNdX, Integrand::ELEMENT_CORNERS, ASM::InterfaceChecker::elmBorderMask(), ItgPoint::eta, Integrand::evalInt(), extractBasis(), ASMbase::firstEl, utl::matrix< T >::getColumn(), GaussQuadrature::getCoord(), getElementBorders(), getElementCoordinates(), getElementCorners(), Integrand::getIntegrandType(), Integrand::getLocalIntegral(), ASMbase::getNoGaussPt(), getParametricLength(), GaussQuadrature::getWeight(), FiniteElement::h, ASM::InterfaceChecker::hasContribution(), ItgPoint::idx, ItgPoint::iel, Integrand::initElement(), Integrand::INTERFACE_TERMS, utl::Jacobian(), utl::merge(), ASMbase::MLGE, ASMbase::MNPC, FiniteElement::N, ASMbase::nel, Integrand::NORMAL_DERIVS, FiniteElement::p, PROFILE2, LocalIntegral::ref(), surf, TimeDomain::t, ItgPoint::u, ItgPoint::v, FiniteElement::XC, and ItgPoint::xi.

◆ integrate() [3/4]

bool ASMs2D::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time,
		const Real3DMat &	itgPts
	)

protected

Evaluates an integral over the interior patch domain.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	itgPts	Parameters and weights of the integration points

References FiniteElement::age, GlobalIntegral::assemble(), Vec4::assign(), FiniteElement::d2NdX2, ASMbase::dbgElm, ASMbase::deformedConfig(), LocalIntegral::destruct(), FiniteElement::detJxW, FiniteElement::dNdX, Integrand::ELEMENT_CENTER, Integrand::ELEMENT_CORNERS, ASMstruct::empty(), Integrand::evalInt(), SplineUtils::extractBasis(), Integrand::finalizeElement(), TimeDomain::first, ASMbase::firstEl, ASMbase::firstIp, FiniteElement::G, Integrand::G_MATRIX, getElementCoordinates(), getElementCorners(), utl::getGmat(), Integrand::getIntegrandType(), Integrand::getLocalIntegral(), getParametricArea(), Integrand::getReducedIntegration(), FiniteElement::H, FiniteElement::h, utl::Hessian(), ItgPoint::idx, ItgPoint::iel, ItgPoint::iGP, Integrand::initElement(), TimeDomain::it, utl::Jacobian(), ASMbase::MLGE, ASMbase::MNPC, ASMbase::myElms, FiniteElement::N, ASMbase::nel, ASMbase::nsd, ThreadGroups::oneStripe(), FiniteElement::p, PROFILE2, PROFILE3, FiniteElement::q, LocalIntegral::ref(), Integrand::SECOND_DERIVATIVES, utl::vector< T >::size(), ThreadGroups::size(), surf, TimeDomain::t, threadGroups, GlobalIntegral::threadSafe(), ItgPoint::u, Vec4::u, Integrand::UPDATED_NODES, ItgPoint::v, LocalIntegral::vec, and FiniteElement::XC.

◆ integrate() [4/4]

bool ASMs2D::integrate	(	Integrand &	integrand,
		int	lIndex,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time
	)

virtual

Evaluates a boundary integral over a patch edge.

Parameters

	integrand	Object with problem-specific data and methods
[in]	lIndex	Local index [1,4] of the boundary edge
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Implements ASMbase.

Reimplemented in ASMs2DTri, ASMs2DSpec, ASMs2DmxLag, ASMs2Dmx, and ASMs2DLag.

References FiniteElement::age, GlobalIntegral::assemble(), Vec4::assign(), ASMbase::dbgElm, LocalIntegral::destruct(), FiniteElement::detJxW, FiniteElement::dNdX, Integrand::ELEMENT_CORNERS, ItgPoint::eta, Integrand::evalBou(), SplineUtils::extractBasis(), Integrand::finalizeElementBou(), ASMbase::firstBp, ASMbase::firstEl, FiniteElement::G, Integrand::G_MATRIX, Integrand::getBouIntegrationPoints(), GaussQuadrature::getCoord(), getElementCoordinates(), getElementCorners(), SplineUtils::getGaussParameters(), utl::getGmat(), Integrand::getIntegrandType(), Integrand::getLocalIntegral(), ASMbase::getNoGaussPt(), getParametricLength(), GaussQuadrature::getWeight(), FiniteElement::h, ItgPoint::idx, ItgPoint::iel, ItgPoint::iGP, Integrand::initElementBou(), ASMbase::isElementInPartition(), utl::Jacobian(), ASMbase::MLGE, ASMbase::MNPC, ASMbase::myElms, FiniteElement::N, ASMbase::nsd, FiniteElement::p, PROFILE2, FiniteElement::q, LocalIntegral::ref(), Integrand::setNeumannOrder(), utl::vector< T >::size(), surf, TimeDomain::t, ItgPoint::u, ItgPoint::v, FiniteElement::XC, ItgPoint::xi, and Integrand::XO_ELEMENTS.

◆ projectSolution()

Go::SplineSurface * ASMs2D::projectSolution ( const IntegrandBase & integrand ) const

private

Projects the secondary solution field onto the primary basis.

Parameters

[in] integrand Object with problem-specific data and methods

References ASMstruct::evalSolution(), getBasis(), getGrevilleParameters(), PROFILE2, and utl::matrix< T >::rows().

Referenced by evalSolution().

◆ raiseOrder()

bool ASMs2D::raiseOrder	(	int	ru,
		int	rv
	)

virtual

Raises the order of the SplineSurface object for this patch.

Parameters

[in]	ru	Number of times to raise the order in u-direction
[in]	rv	Number of times to raise the order in v-direction

Implements ASM2D.

References ASMbase::shareFE, and surf.

◆ refine()

bool ASMs2D::refine	(	int	dir,
		const RealArray &	xi,
		double	scale = `1.0`
	)

virtual

Refines the parametrization by inserting extra knots.

Parameters

[in]	dir	Parameter direction to refine
[in]	xi	Relative positions of added knots in each existing knot span
[in]	scale	Scaling factor for the added knot values

References ASMbase::shareFE, and surf.

◆ setNodeNumbers()

void ASMs2D::setNodeNumbers ( const IntVec & nodes )

virtual

Sets the global node numbers for this patch.

Parameters

[in] nodes Vector of global node numbers (zero-based)

Reimplemented from ASMbase.

References ASMbase::myMLGN, ASMbase::setNodeNumbers(), surf, and swapV.

◆ tesselate()

bool ASMs2D::tesselate	(	ElementBlock &	grid,
		const int *	npe
	)		const

virtual

Creates a quad element model of this patch for visualization.

Parameters

[out]	grid	The generated quadrilateral grid
[in]	npe	Number of visualization nodes over each knot span

Note: The number of element nodes must be set in grid on input.

Implements ASMbase.

Reimplemented in ASMu2DLag, ASMs2DTri, and ASMs2DLag.

References getGridParameters(), ElementBlock::getNoNodes(), ASMbase::nsd, ElementBlock::resize(), ElementBlock::setCoor(), ElementBlock::setElmId(), ElementBlock::setNode(), ElementBlock::setParams(), and surf.

Referenced by ASMs2DLag::tesselate().

◆ uniformRefine()

bool ASMs2D::uniformRefine	(	int	dir,
		int	nInsert
	)

virtual

Refines the parametrization by inserting extra knots uniformly.

Parameters

[in]	dir	Parameter direction to refine
[in]	nInsert	Number of extra knots to insert in each knot-span

Implements ASM2D.

References ASMbase::shareFE, and surf.

◆ updateCoords()

bool ASMs2D::updateCoords ( const Vector & displ )

virtual

Updates the nodal coordinates for this patch.

Parameters

[in] displ Incremental displacements to update the coordinates with

Implements ASMbase.

Reimplemented in ASMs2DLag.

References ASMbase::MLGN, ASMbase::nsd, ASMbase::shareFE, utl::vector< T >::size(), and surf.

◆ updateDirichlet()

bool ASMs2D::updateDirichlet	(	const std::map< int, RealFunc * > &	func,
		const std::map< int, VecFunc * > &	vfunc,
		double	time,
		const std::map< int, int > *	g2l = `nullptr`
	)

virtual

Updates the time-dependent in-homogeneous Dirichlet coefficients.

Parameters

[in]	func	Scalar property fields
[in]	vfunc	Vector property fields
[in]	time	Current time
[in]	g2l	Pointer to global-to-local node number mapping

This method projects the function describing the in-homogeneous Dirichlet boundary condition onto the spline basis defining the boundary curve, in order to find the control point values which are used as the prescribed values of the boundary DOFs.

Reimplemented from ASMbase.

Reimplemented in ASMs2DC1.

References dirich, ASMbase::MLGN, ASMbase::mpcs, SplineUtils::project(), and ASMbase::updateDirichlet().

Referenced by ASMs2DC1::updateDirichlet().

The documentation for this class was generated from the following files:

src/ASM/ASMs2D.h
src/ASM/ASMs2D.C
src/ASM/ASMs2Drecovery.C

Classes

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Private Types

Private Member Functions

Static Private Member Functions

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ addInterfaceElms()

◆ addRigidCpl()

◆ addXElms()

◆ assembleL2matrices()

◆ assignNodeNumbers()

◆ checkRightHandSystem()

◆ clear()

◆ closeBoundaries()

◆ coeffInd()

◆ collapseEdge()

◆ connectBasis()

◆ connectPatch()

◆ constrainCorner()

◆ constrainEdge()

◆ constrainEdgeLocal()

◆ constrainNode()

◆ createProjectionBasis()

◆ evalPoint()

◆ evalProjSolution()

◆ evalSolution() [1/5]

◆ evalSolution() [2/5]

◆ evalSolution() [3/5]

◆ evalSolution() [4/5]

◆ evalSolution() [5/5]

◆ evaluate() [1/3]

◆ evaluate() [2/3]

◆ evaluate() [3/3]

◆ evaluateBasis()

◆ extractBasis() [1/3]

◆ extractBasis() [2/3]

◆ extractBasis() [3/3]

◆ findBoundaryElms()

◆ findElementContaining()

◆ findPoint()

◆ generateFEMTopology()

◆ generateThreadGroups() [1/2]

◆ generateThreadGroups() [2/2]

◆ getBoundary()

◆ getBoundaryNodes()

◆ getCoord()

◆ getCorner()

◆ getCornerPoints()

◆ getElementBorders() [1/2]

◆ getElementBorders() [2/2]

◆ getElementCoordinates()

◆ getElementCoordinatesPrm()

◆ getElementCorners()

◆ getElmConnectivities()

◆ getGaussPointParameters()

◆ getGrevilleParameters()

◆ getGridParameters()

◆ getNodalCoordinates()

◆ getNodeID()

◆ getNodeIndex()

◆ getNoStructElms()

◆ getOrder() [1/2]

◆ getOrder() [2/2]

◆ getParameterDomain()

◆ getParametricArea()

◆ getParametricLength()

◆ getProjectedField()

◆ getProjectedFields()

◆ getQuasiInterplParameters()

◆ getSize() [1/2]

◆ getSize() [2/2]

◆ integrate() [1/4]

◆ integrate() [2/4]

◆ integrate() [3/4]

◆ integrate() [4/4]
