Driver for assembly of unstructured 2D spline FE models. More...

#include <ASMu2D.h>

Inheritance diagram for ASMu2D:

[legend]

Collaboration diagram for ASMu2D:

[legend]

Classes
class	BasisFunctionCache
	Implementation of basis function cache. More...

struct	DirichletEdge
	Struct representing an inhomogeneous Dirichlet boundary condition. More...

class	InterfaceChecker
	Base class that checks if an element has interface contributions. More...

Public Member Functions
	ASMu2D (unsigned char n_s=2, unsigned char n_f=2)
	Default constructor.

	ASMu2D (const ASMu2D &patch, unsigned char n_f=0)
	Copy constructor.

virtual	~ASMu2D ()
	Empty destructor.

virtual const LR::LRSplineSurface *	getBasis (int basis=1) const
	Returns the spline surface representing a basis of this patch.

virtual LR::LRSplineSurface *	getBasis (int basis=1)
	Returns the spline surface representing a basis of this patch.

virtual bool	read (std::istream &)
	Creates an instance by reading the given input stream.

virtual bool	write (std::ostream &, int) const
	Writes the geometry of the SplineSurface object to given stream.

virtual bool	generateFEMTopology ()
	Generates the finite element topology data for the patch. More...

virtual void	clear (bool retainGeometry=false)
	Clears the contents of the patch, making it empty. More...

virtual bool	getElementCoordinates (Matrix &X, int iel, bool forceItg=false) const
	Returns a matrix with nodal coordinates for an element. More...

virtual void	getElmConnectivities (IntMat &neighs, int basis=ASM::INTEGRATION_BASIS) const
	Calculates the matrix of element neighbour connectivities. More...

virtual IntMat	getElmNodes (int basis) const
	Returns the matrix of nodal point correspondance for given basis.

virtual void	getNodalCoordinates (Matrix &X, bool=false) const
	Returns a matrix with all nodal coordinates within the patch. More...

virtual Vec3	getCoord (size_t inod) const
	Returns the global coordinates for the given node. More...

virtual bool	updateCoords (const Vector &displ)
	Updates the nodal coordinates for this patch. More...

virtual void	getBoundaryNodes (int lIndex, IntVec &nodes, int basis, int=1, int orient=0, bool local=false) const
	Finds the global (or patch-local) node numbers on a patch boundary. More...

virtual bool	getOrder (int &p1, int &p2, int &p3) const
	Returns the polynomial order in each parameter direction. More...

virtual size_t	getNoNodes (int basis=0) const
	Returns the total number of nodes in this patch.

virtual size_t	getNoProjectionNodes () const
	Returns the number of projection nodes for this patch.

bool	diagonalRefine (int minBasisfunctions)
	Refines along the diagonal of the LR-spline patch. More...

bool	cornerRefine (int minBasisfunctions)
	Refines the lower-left corner of the LR-spline patch. More...

bool	uniformRefine (int minBasisfunctions)
	Refines the LR-spline patch uniformly. More...

virtual bool	uniformRefine (int dir, int nInsert)
	Refines the parametrization by inserting tensor knots uniformly. More...

virtual bool	refine (int dir, const RealArray &xi, double scale)
	Refines the parametrization by inserting extra tensor knots. More...

virtual bool	refine (const LR::RefineData &prm, Vectors &sol)
	Refines the mesh adaptively. More...

virtual bool	raiseOrder (int ru, int rv)
	Raises the order of the tensor spline object for this patch. More...

virtual bool	createProjectionBasis (bool init)
	Creates a separate projection basis for this patch. More...

virtual void	setMinimumSize (double size)
	Sets the minimum element area for adaptive refinement.

virtual double	getMinimumSize (int nrefinements) const
	Defines the minimum element area for adaptive refinement. More...

virtual bool	checkElementSize (int elmId, bool globalNum=true) const
	Checks if the specified element is larger than the minimum size. More...

virtual void	extractElmRes (const Matrix &globRes, Matrix &elmRes, size_t internalFirst) const
	Extracts element results for this patch from a global vector. More...

void	copyRefinement (LR::LRSplineSurface *basis, int multiplicity=1) const
	Copies the refinement to another surface. More...

virtual void	constrainEdge (int dir, bool open, int dof, int code, char basis)
	Constrains all DOFs on a given boundary edge. More...

virtual size_t	constrainEdgeLocal (int dir, bool open, int dof, int code, bool project=false)
	Constrains all DOFs in local directions on a given boundary edge. More...

virtual void	constrainCorner (int I, int J, int dof, int code=0, char basis=1)
	Constrains a corner node identified by the two parameter indices. More...

virtual void	constrainNode (double xi, double eta, int dof, int code=0)
	Constrains a node identified by two relative parameter values. More...

virtual bool	connectPatch (int edge, ASM2D &neighbor, int nedge, bool revers, int=0, bool coordCheck=true, int thick=1)
	Connects all matching nodes on two adjacent boundary edges. More...

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates an integral over the interior patch domain. More...

virtual bool	integrate (Integrand &integrand, int lIndex, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates a boundary integral over a patch edge. More...

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time, const ASM::InterfaceChecker &iChk)
	Evaluates an integral over element interfaces in the patch. More...

virtual bool	diracPoint (Integrand &integrand, GlobalIntegral &glbInt, const double *param, const Vec3 &pval)
	Integrates a spatial dirac-delta function over a patch. More...

virtual bool	updateDirichlet (const std::map< int, RealFunc * > &func, const std::map< int, VecFunc * > &vfunc, double time, const std::map< int, int > *g2l=nullptr)
	Updates the time-dependent in-homogeneous Dirichlet coefficients. More...

virtual int	getCorner (int I, int J, int basis) const
	Returns the node index for a given corner. More...

virtual int	evalPoint (const double xi, double param, Vec3 &X) const
	Evaluates the geometry at a specified point. More...

virtual int	findElementContaining (const double *param) const
	Returns the element that contains a specified spatial point. More...

virtual double	findPoint (Vec3 &X, double *param) const
	Searches for the specified Cartesian point in the patch. More...

virtual bool	getGridParameters (RealArray &prm, int dir, int nSegSpan) const
	Calculates parameter values for visualization nodal points. More...

virtual bool	tesselate (ElementBlock &grid, const int *npe) const
	Creates a quad element model of this patch for visualization. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f, bool piola) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool=false, int deriv=0, int=0) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalProjSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f) const
	Evaluates the projected solution field at all visualization points. More...

virtual bool	evaluate (const FunctionBase *func, RealArray &vec, int, double time) const
	Evaluates and interpolates a function over a given geometry. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe, char project='\0') const
	Evaluates the secondary solution field at all visualization points. More...

virtual bool	separateProjectionBasis () const
	Checks if a separate projection basis is used for this patch.

virtual Field *	getProjectedField (const Vector &coefs) const
	Returns a field using the projection basis. More...

virtual Fields *	getProjectedFields (const Vector &coefs, size_t=0) const
	Returns a field using the projection basis. More...

virtual void	storeMesh (const std::string &fName, int fType) const
	Stores the mesh basis to encapsulated postscript files. More...

void	setOutputMaster (const ASMu2D *pch)
	Set master patch for VTF output. More...

virtual LR::LRSpline *	evalSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool=false) const
	Evaluates the secondary solution field at the given points. More...

bool	edgeL2projection (const DirichletEdge &edge, const FunctionBase &values, Real2DMat &result, double time) const
	Projects inhomogenuous dirichlet conditions by continuous L2-fit. More...

virtual bool	transferGaussPtVars (const LR::LRSpline *old_basis, const RealArray &oldVar, RealArray &newVar, int nGauss) const
	Transfers Gauss point variables from old basis to this patch. More...

virtual bool	transferGaussPtVarsN (const LR::LRSpline *old_basis, const RealArray &oldVar, RealArray &newVar, int nGauss) const
	Transfers Gauss point variables from old basis to this patch. More...

virtual bool	transferCntrlPtVars (const LR::LRSpline *old_basis, RealArray &newVar, int nGauss) const
	Transfers control point variables from old basis to this patch. More...

virtual size_t	getNoBoundaryElms (char lIndex, char ldim) const
	Returns the number of elements on a boundary.

bool	rational () const
	Query whether basis is rational or not.

virtual bool	refine (const LR::RefineData &prm, Vectors &sol)
	Refines the mesh adaptively. More...

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time)=0
	Evaluates an integral over the interior patch domain. More...

virtual bool	integrate (Integrand &integrand, int lIndex, GlobalIntegral &glbInt, const TimeDomain &time)=0
	Evaluates a boundary integral over a patch face/edge. More...

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time, const ASM::InterfaceChecker &iChk)
	Evaluates an integral over element interfaces in the patch. More...

virtual bool	transferCntrlPtVars (const LR::LRSpline *oldBasis, RealArray &newVar, int nGauss) const=0
	Transfers control point variables from old basis to this patch. More...

bool	transferCntrlPtVars (LR::LRSpline *oldBasis, const RealArray &oldVar, RealArray &newVar, int nGauss, int nf=1) const
	Transfers control point variables from old basis to this patch. More...

Public Member Functions inherited from ASMLRSpline
virtual	~ASMLRSpline ()
	Empty destructor.

virtual bool	empty () const
	Checks if the patch is empty.

virtual bool	getParameterDomain (Real2DMat &, IntVec *) const
	Returns parameter values and node numbers of the domain corners.

const LR::LRSpline *	getRefinementBasis () const
	Returns a const pointer to refinement basis.

IntVec	getFunctionsForElements (const IntVec &elements, bool globalId=false) const
	Returns a list of basis functions having support on given elements.

void	getFunctionsForElements (IntSet &functions, const IntVec &elements, bool globalId=true) const
	Returns a list of basis functions having support on given elements.

virtual IntVec	getBoundaryCovered (const IntSet &nodes) const
	Returns all boundary functions that are covered by the given nodes. More...

IntVec	getOverlappingNodes (const IntSet &nodes, int dir=7) const
	Returns all functions whose support overlap with the input nodes. More...

IntVec	getOverlappingNodes (int node, int dir=7) const
	Returns all functions whose support overlap with the input node. More...

bool	transferCntrlPtVars (LR::LRSpline *oldBasis, const RealArray &oldVar, RealArray &newVar, int nGauss, int nf=1) const
	Transfers control point variables from old basis to this patch. More...

virtual std::pair< size_t, double >	findClosestNode (const Vec3 &X) const
	Finds the node that is closest to the given point X.

virtual Vec3	getElementCenter (int iel) const
	Returns the coordinates of the element center.

virtual void	getNoIntPoints (size_t &nPt, size_t &nIPt)
	Computes the total number of integration points in this patch.

virtual void	swapProjectionBasis ()
	Swaps between the first and second projection basis.

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f=0, bool piola=false) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular=true, int deriv=0, int n_f=0) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe=nullptr, char project=0) const
	Evaluates the secondary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool regular=true) const
	Evaluates the secondary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const IntVec &elements) const
	Evaluates the secondary solution field at element centers. More...

Public Member Functions inherited from ASMbase
virtual	~ASMbase ()
	The destructor frees the dynamically allocated data objects.

ASMbase *	cloneUnShared () const
	Returns a copy of this patch with identical FE discretization. More...

virtual bool	readBasis (std::istream &, size_t)
	Reads a basis from the given input stream.

virtual void	addHole (double, double, double)
	Adds a circular immersed boundary in the physical geometry.

virtual void	addHole (double, double, double, double, double)
	Adds an oval immersed boundary in the physical geometry.

virtual bool	setGeometry (RealFunc *, double, double)
	Defines the immersed geometry from a scalar function.

virtual bool	addXElms (short int dim, short int item, size_t nXn, IntVec &nodes)
	Adds extraordinary elements associated with a patch boundary. More...

bool	addLagrangeMultipliers (size_t iel, const IntVec &mGLag, unsigned char nnLag=1)
	Adds a set of Lagrange multipliers to the specified element. More...

bool	addGlobalLagrangeMultipliers (const IntVec &mGLag, unsigned char nnLag=1)
	Adds global Lagrange multipliers to the system. More...

virtual void	setGauss (int ng)
	Defines the numerical integration scheme nGauss in the patch.

void	setNoFields (unsigned char n)
	Defines the number of solution fields in the patch. More...

void	setElementActivator (IntFunc *efunc)
	Sets the element activation function.

const IntFunc *	getElementActivator () const
	Returns a pointer to the element activation function.

unsigned char	getNoSpaceDim () const
	Returns the number of spatial dimensions.

unsigned char	getNoParamDim () const
	Returns the number of parameter dimensions.

virtual unsigned char	getNoFields (int b=0) const
	Returns the number of solution fields.

unsigned char	getNoLagPerNode () const
	Returns the number of Lagrange multipliers per node.

virtual size_t	getNodeIndex (int globalNum, bool=false) const
	Returns local 1-based index of the node with given global number. More...

virtual int	getNodeID (size_t inod, bool=false) const
	Returns the global node number for the given node. More...

size_t	getElmIndex (int globalNum) const
	Returns local 1-based index of element with given global number. More...

int	getElmID (size_t iel) const
	Returns the global element number for the given element. More...

virtual unsigned char	getNodalDOFs (size_t inod) const
	Returns the number of DOFs per node. More...

virtual char	getNodeType (size_t inod) const
	Returns the classification of a node. More...

bool	isLMn (size_t n) const
	Returns true if node n is a Lagrange multiplier node.

bool	isRMn (size_t n) const
	Returns true if node n is a master node of a rigid coupling.

char	getLMType (size_t inod) const
	Returns the type of a Lagrange multiplier node. More...

virtual void	getBoundary1Nodes (int lIndex, IntVec &nodes, int basis=0, int orient=-1, bool local=false, bool open=false) const
	Finds the global (or patch-local) node numbers on a patch boundary. More...

void	getBoundaryElms (int lIndex, IntVec &elms, int orient=-1, bool local=false) const
	Finds the global (or patch-local) element numbers on a boundary. More...

virtual int	getNodeSetIdx (const std::string &) const
	Returns (1-based) index of a predefined node set in the patch.

virtual const IntVec &	getNodeSet (int) const
	Returns an indexed predefined node set.

virtual bool	isInNodeSet (int, int) const
	Checks if a node is within a predefined node set.

virtual int	parseNodeSet (const std::string &, const char *)
	Defines a node set by parsing a list of node numbers.

virtual int	parseNodeBox (const std::string &, const char *)
	Defines a node set by parsing a 3D bounding box.

virtual int	getElementSetIdx (const std::string &) const
	Returns (1-based) index of a predefined element set in the patch.

virtual const IntVec &	getElementSet (int) const
	Returns an indexed predefined element set.

virtual bool	getElementSet (int, std::string &) const
	Returns the name of an indexed predefined element set.

virtual bool	isInElementSet (int, int) const
	Checks if an element is within a predefined element set.

virtual int	parseElemSet (const std::string &, const char *)
	Defines an element set by parsing a list of element numbers.

virtual int	parseElemBox (const std::string &, const std::string &, const char *)
	Defines an element set by parsing a 3D bounding box.

void	printNodes (std::ostream &os) const
	Prints out the nodal coordinates of this patch to the given stream.

void	printElements (std::ostream &os) const
	Prints out element connections of this patch to the given stream.

virtual void	printElmInfo (int, const IntegrandBase *) const
	Prints out additional app-dependent element information.

virtual void	shiftGlobalNodeNums (int nshift)
	Increase all global node numbers by nshift.

void	setGlobalNodeNums (const IntVec &nodes)
	Sets the global node numbers for this patch.

const IntVec &	getMyNodeNums () const
	Returns the actual global node numbers of this patch.

const IntVec &	getGlobalNodeNums () const
	Returns the global node numbers of this patch.

virtual void	shiftGlobalElmNums (int eshift)
	Increase all global element numbers by eshift.

const IntVec &	getGlobalElementNums () const
	Returns the global element numbers of this patch.

void	setActiveElements (IntVec *active)
	Sets the list of active elements during assembly.

bool	isElementActive (int iel, double time=-1.0) const
	Returns true if element with 0-based index iel is active.

bool	inActive (double time) const
	Returns true if none of the elements in the patch are active.

double	getAge (int iel, double time) const
	Returns the age of the element with 0-based index iel.

bool	isElementInPartition (int iel) const
	Returns true if element is in process partition. More...

const IntVec &	getElementNodes (int iel) const
	Returns the nodal point correspondance array for an element. More...

virtual size_t	getNoBasis () const
	Returns number of bases of this patch.

size_t	getNoElms (bool includeZeroVolElms=false, bool includeXElms=false) const
	Returns the total number of elements in this patch. More...

int	getMaxElmNo () const
	Returns the highest external element number in this patch.

size_t	getNoMPCs () const
	Returns the total number of multi-point constraint equations.

virtual void	getNoBouPoints (size_t &nPt, char ldim, char lindx)
	Computes the number of boundary integration points in this patch.

BCVec::const_iterator	begin_BC () const
	Returns the beginning of the BCode array.

BCVec::const_iterator	end_BC () const
	Returns the end of the BCode array.

IntMat::const_iterator	begin_elm () const
	Returns the beginning of the MNPC array.

IntMat::const_iterator	end_elm () const
	Returns the end of the MNPC array.

MPCIter	begin_MPC () const
	Returns the beginning of the mpcs set.

MPCIter	end_MPC () const
	Returns the end of the mpcs set.

MPC *	findMPC (int node, int dof) const
	Returns a pointer to the MPC object for a specified slave, if any. More...

bool	isShared () const
	Returns true if this patch shares FE data with another patch.

bool	hasXNodes () const
	Returns true if this patch has additional (extraordinary) nodes.

virtual void	copyParameterDomain (const ASMbase *)
	Copies the parameter domain from another patch.

virtual void	closeBoundaries (int dir=1, int basis=0, int master=1)
	Makes two opposite boundaries periodic. More...

bool	mergeNodes (size_t inod, int globalNum, bool verbose=true)
	Merges a given node in this patch with a given global node. More...

int	renumberNodes (std::map< int, int > &old2new, int &nNod)
	Renumbers the global node numbers in this patch. More...

bool	renumberNodes (const std::map< int, int > &old2new, const std::vector< int > &new2old={}, int renumGN=0, std::map< int, int > *degenElm=nullptr)
	Renumbers the global node numbers referred by this patch. More...

virtual bool	initConstraints ()
	Initializes the multi-point constraint coefficients.

virtual void	setNodeNumbers (const IntVec &nodes)
	Sets the global node numbers for this patch. More...

bool	hasTimeDependentDirichlet (const std::map< int, RealFunc * > &func, const std::map< int, VecFunc * > &vfunc)
	Checks for time-dependent in-homogeneous Dirichlet conditions. More...

virtual bool	transform (const Matrix &)
	Applies a transformation matrix from local to global system.

virtual void	initMADOF (const int *)
	Initializes the patch level MADOF array for mixed problems.

virtual void	generateThreadGroups (char, bool, bool)
	Generates element groups for multi-threading of boundary integrals.

virtual bool	validateThreadGroups (const SAM *) const
	Validates the threading groups based on the assembly data in SAM.

virtual bool	integrateEdge (Integrand &integrand, int lEdge, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates a boundary integral over a patch edge. More...

virtual ElementBlock *	immersedGeometry (char *) const
	Returns an additional geometry to visualize (immersed boundaries).

virtual ElementBlock *	extraGeometry (char *) const
	Returns an additional geometry to visualize (spiders, etc.).

virtual void	filterResults (Matrix &, const ElementBlock *) const
	Filters out result point values that are outside physical domain.

virtual bool	getSolution (Matrix &sField, const Vector &locSol, const IntVec &nodes) const
	Extract the primary solution field at the specified nodes. More...

virtual bool	immersedSolution (Matrix &, const Vector &) const
	Evaluates the primary solution at the immersed geometry points.

virtual bool	extraSolution (Matrix &, const Vector &) const
	Evaluates the primary solution at the extra geometry points.

virtual bool	evalSolutionPiola (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular) const
	Evaluates the primary solution field with Piola mapping. More...

virtual bool	evaluate (const ASMbase *basis, const Vector &locVec, RealArray &vec, int basisNum=1) const
	Evaluates and interpolates a field over a given geometry. More...

virtual bool	evaluate (const Field *f, RealArray &vec, int basisNum=1) const
	Evaluates and interpolates a scalar field over a given geometry. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const IntVec &elements) const
	Evaluates the secondary solution field at element centers. More...

bool	globalL2projection (Matrix &sField, const L2Integrand &integrand, bool continuous=false, bool enforceEnds=false) const
	Projects the secondary solution using a (discrete) global L2-fit. More...

bool	L2projection (Matrix &sField, IntegrandBase *integrand, const TimeDomain &time)
	Projects the secondary solution using a continuous global L2-fit. More...

bool	L2projection (Matrix &fVals, FunctionBase *function, double t=0.0)
	Projects an explicit function using a continuous global L2-fit. More...

bool	L2projection (const std::vector< Matrix * > &fVals, const std::vector< FunctionBase * > &function, double t=0.0)
	Projects explicit functions using a continuous global L2-fit. More...

virtual size_t	getNoRefineNodes () const
	Returns the number of nodes on refinement basis for this patch.

virtual size_t	getNoRefineElms () const
	Returns the number of elements on refinement basis for this patch.

virtual void	extractElmRes (const Vector &globRes, Vector &elmRes, size_t internalFirst=0) const
	Extracts element results for this patch from a global vector. More...

bool	extractNodalVec (const RealArray &globVec, RealArray &nodeVec, const int *madof, int ngnod=-1) const
	Extracts nodal results for this patch from the global vector. More...

virtual void	extractNodeVec (const RealArray &globVec, RealArray &nodeVec, unsigned char nndof=0, int basis=0) const
	Extracts nodal results for this patch from the global vector. More...

virtual bool	injectNodeVec (const RealArray &nodeVec, RealArray &globVec, unsigned char nndof=0, int basis=0) const
	Injects nodal results for this patch into the global vector. More...

bool	injectNodalVec (const RealArray &nodeVec, RealArray &globVec, const IntVec &madof, int basis=0) const
	Injects nodal results for this patch into the global vector. More...

bool	add2PC (int slave, int dir, int master, int code=0)
	Creates and adds a two-point constraint to this patch. More...

bool	addMPC (MPC *&mpc, int code=0, bool verbose=false, bool overrideD=false)
	Adds a general multi-point-constraint (MPC) equation to this patch. More...

virtual bool	addRigidCpl (int lindx, int ldim, int basis, int &gMaster, const Vec3 &Xmaster, bool extraPt=true)
	Adds MPC-equations representing a rigid coupling to this patch. More...

void	addRigidCouplings (int gMaster, const Vec3 &Xmaster, const IntVec &slaveNodes)
	Adds MPC-equations representing a rigid coupling to this patch. More...

void	constrainPatch (int dof, int code=0)
	Constrains all nodes in the patch. More...

void	constrainNodes (const IntVec &nodes, int dof, int code=0, bool overrideD=false)
	Constrains a list of nodes in the patch. More...

bool	constrainXnode (int node, int dof, int code=0)
	Constrains an extraordinary node in the patch. More...

int	prescribe (size_t inod, int dirs, int code, bool overrideD=false)
	Constrains DOFs in the given node to the given value. More...

int	fix (size_t inod, int dirs=123)
	Constrains DOFs in the given node to zero. More...

bool	isFixed (int node, int dof, bool all=false) const
	Checks if the given DOFs are fixed. More...

Public Member Functions inherited from ASMunstruct
virtual	~ASMunstruct ()
	Empty destructor.

Public Member Functions inherited from ASM2D
virtual	~ASM2D ()
	Empty destructor.

ASMbase *	clone (const CharVec &nf=CharVec()) const
	Returns a copy of this patch with identical FE discretization. More...

virtual bool	checkRightHandSystem ()
	Checks that the patch is modelled in a right-hand-side system.

virtual bool	refine (int dir, const std::vector< double > &xi, double scale=1.0)=0
	Refines the parametrization by inserting extra knots. More...

virtual bool	getGridParameters (std::vector< double > &prm, int dir, int nSegSpan) const =0
	Calculates parameter values for visualization nodal points. More...

Static Public Member Functions
static void	computeBasisNurbs (double u, double v, Go::BasisPtsSf &bas, int iel, const LR::LRSplineSurface &spline)
	Evaluate NURBS basis functions in a point.

static void	computeBasisNurbs (double u, double v, Go::BasisDerivsSf &bas, int iel, const LR::LRSplineSurface &spline)
	Evaluate NURBS basis functions and first derivatives in a point.

static void	computeBasisNurbs (double u, double v, Go::BasisDerivsSf2 &bas, int iel, const LR::LRSplineSurface &spline)
	Evaluate NURBS basis functions and two derivatives in a point.

static void	computeBasisNurbs (double u, double v, Go::BasisDerivsSf3 &bas, int iel, const LR::LRSplineSurface &spline)
	Evaluate NURBS basis functions and three derivatives in a point.

static bool	getCoordinates (Matrix &X, unsigned char nsd, const LR::LRSplineSurface &spline, int iel=-1)
	Returns a matrix with control point coordinates. More...

Static Public Member Functions inherited from ASMLRSpline
static Go::BsplineBasis	getBezierBasis (int p, double start=-1.0, double end=1.0)
	Returns a Bezier basis of order p.

static void	Sort (int u, int v, int orient, std::vector< LR::Basisfunction * > &functions)
	Sort basis functions based on local knot vectors.

Static Public Member Functions inherited from ASMbase
static void	resetNumbering (int n=0)
	Resets the global element and node counters.

static int	renumberNodes (const ASMVec &model, std::map< int, int > &old2new)
	Renumbers all global node numbers in the entire model. More...

static void	mergeAndGetAllMPCs (const ASMVec &model, MPCSet &allMPCs)
	Computes the set of all MPC-equations over the whole model. More...

static void	resolveMPCchains (const MPCSet &allMPCs, const ASMVec &model, bool setPtrOnly=false)
	Resolves (possibly multi-level) chaining in MPC-equations. More...

Static Public Member Functions inherited from ASM2D
static ASMbase *	create (ASM::Discretization type, unsigned char nd, const CharVec &nf, bool mixedFEM=false)
	Creates a two-parametric patch of specified discretization type. More...

static ASMbase *	create (ASM::Discretization type, unsigned char nf=1)
	Creates a two-parametric patch of specified discretization type. More...

Protected Member Functions
bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time, const Real3DMat &itgPts)
	Evaluates an integral over the interior patch domain. More...

LR::LRSplineSurface *	projectSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

LR::LRSplineSurface *	scRecovery (const IntegrandBase &integrand) const
	Projects the secondary solution using a superconvergent approach. More...

LR::LRSplineSurface *	regularInterpolation (const RealArray &upar, const RealArray &vpar, const Matrix &points, int basis) const
	Interpolates an LR spline at a given set of parametric coordinates. More...

virtual void	findBoundaryElms (IntVec &elms, int lIndex, int orient) const
	Finds the patch-local element numbers on a patch boundary. More...

virtual bool	assembleL2matrices (SystemMatrix &A, SystemVector &B, const L2Integrand &integrand, bool continuous) const
	Assembles L2-projection matrices for the secondary solution. More...

bool	connectBasis (int edge, ASMu2D &neighbor, int nedge, bool revers, int basis=1, int slave=0, int master=0, bool coordCheck=true, int thick=1)
	Connects all matching nodes on two adjacent boundary edges. More...

void	getGaussPointParameters (RealArray &uGP, int dir, int nGauss, int iel, const double xi, const LR::LRSplineSurface spline=nullptr) const
	Extracts parameter values of the Gauss points in one direction. More...

bool	getGrevilleParameters (RealArray &prm, int dir, int basisNum=1) const
	Calculates parameter values for the Greville points. More...

double	getParametricLength (int iel, int dir) const
	Returns boundary edge length in the parameter space for an element. More...

double	getElementCorners (int iel, std::vector< Vec3 > &XC, RealArray *uC=nullptr) const
	Computes the element corner coordinates. More...

void	getCornerPoints (int iel, std::vector< utl::Point > &XC) const
	Computes the element corner coordinates and parameters. More...

bool	evaluateBasis (int iel, FiniteElement &fe, int derivs=0) const
	Evaluates the basis functions and derivatives of an element. More...

void	computeBasis (double u, double v, Go::BasisPtsSf &bas, int iel, const LR::LRSplineSurface *spline=nullptr) const
	Evaluate basis functions in a point.

void	computeBasis (double u, double v, Go::BasisDerivsSf &bas, int iel, const LR::LRSplineSurface *spline=nullptr) const
	Evaluate basis functions and first derivatives in a point.

void	computeBasis (double u, double v, Go::BasisDerivsSf2 &bas, int iel, const LR::LRSplineSurface *spline=nullptr) const
	Evaluate basis functions and two derivatives in a point.

void	computeBasis (double u, double v, Go::BasisDerivsSf3 &bas, int iel, const LR::LRSplineSurface *spline=nullptr) const
	Evaluate basis functions and three derivatives in a point.

virtual int	evalPoint (int iel, const double *param, Vec3 &X) const
	Evaluates the geometry at a specified point. More...

void	generateThreadGroups (const Integrand &integrand, bool silence, bool ignoreGlobalLM)
	Generates element groups for multi-threading of interior integrals. More...

virtual void	generateThreadGroupsFromElms (const IntVec &elms)
	Generate element groups from a partition.

virtual void	generateProjThreadGroupsFromElms (const IntVec &elms)
	Generate element groups from a partition.

virtual void	changeNumThreads ()
	Hook for changing number of threads.

virtual void	remapErrors (RealArray &errors, const RealArray &origErr, bool elemErrors) const
	Remap element wise errors to basis functions. More...

virtual void	extendRefinementDomain (IntSet &refineIndices, const IntSet &neighborIndices) const
	Extends the refinement domain with information for neighbors. More...

std::shared_ptr< LR::LRSplineSurface >	createLRfromTensor ()
	Converts current tensor spline object to LR-spline.

void	generateBezierBasis ()
	Generate bezier basis.

void	generateBezierExtraction ()
	Generate bezier extraction operators.

void	writePostscriptElementsNurbs (std::shared_ptr< LR::LRSplineSurface > mesh, std::ostream &out, bool close=true, int nu=2, int nv=2)
	Write NURBS elements as postscript file.

void	writePostscriptMeshWithControlPointsNurbs (std::shared_ptr< LR::LRSplineSurface > mesh, std::ostream &out, int nu=2, int nv=2)
	Write NURBS elements as postscript file.

Protected Member Functions inherited from ASMLRSpline
	ASMLRSpline (unsigned char n_p, unsigned char n_s, unsigned char n_f)
	The constructor sets the space dimensions. More...

	ASMLRSpline (const ASMLRSpline &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data. More...

bool	doRefine (const LR::RefineData &prm, LR::LRSpline *lrspline)
	Refines the mesh adaptively. More...

virtual int	evalPoint (const double xi, double param, Vec3 &X) const=0
	Evaluates the geometry at a specified point. More...

Protected Member Functions inherited from ASMbase
	ASMbase (unsigned char n_p, unsigned char n_s, unsigned char n_f)
	The constructor sets the number of space dimensions and fields. More...

	ASMbase (const ASMbase &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data. More...

	ASMbase (const ASMbase &patch)
	Default copy constructor, copying everything except neighbors. More...

void	addLocal2GlobalCpl (int iSlave, int master, const Tensor &Tlg)
	Creates constraint equations coupling global DOFs to local DOFs. More...

bool	add3PC (int slave, int dir, int master1, int master2, int code=0)
	Creates and adds a three-point constraint to this patch. More...

bool	addPeriodicity (size_t master, size_t slave, int dir)
	Creates and adds a periodicity constraint to this patch. More...

void	makePeriodic (size_t master, size_t slave, int dirs=123)
	Creates periodicity constraints between two nodes in this patch. More...

void	addNeighbor (ASMbase *pch)
	Adds a patch to the list of neighbors of this patch. More...

bool	createRgdMasterNode (int &gMaster, const Vec3 &Xmaster)
	Creates an additional master node for a rigid coupling. More...

void	addRigidMPC (int gSlave, int gMaster, const Vec3 &dX)
	Adds MPC-equations representing a rigid arm to a 6-DOF node. More...

int	getNoGaussPt (int p, bool neumann=false) const
	Returns the number of Gauss points to use in one direction. More...

int	searchCtrlPt (RealArray::const_iterator cit, RealArray::const_iterator end, const Vec3 &X, int dimension, double tol=0.001) const
	Helper method used by evalPoint to search for a control point. More...

bool	allDofs (int dirs) const
	Returns true if dirs constains all local DOFs in the patch.

bool	writeLagBasis (std::ostream &os, const char *type) const
	Writes a Lagrangian basis to the given stream.

Protected Member Functions inherited from ASMunstruct
	ASMunstruct ()
	The constructor is protected to allow objects of sub-classes only.

Protected Member Functions inherited from ASM2D
	ASM2D ()
	The constructor is protected to allow objects of sub-classes only.

Static Protected Member Functions
static std::shared_ptr< LR::LRSplineSurface >	createLRNurbs (const Go::SplineSurface &srf)
	Converts a rational spline surface to a LR NURBS surface.

Static Protected Member Functions inherited from ASMLRSpline
static bool	checkThreadGroups (const IntMat &groups, const std::vector< const LR::LRSpline * > &bases, const LR::LRSpline *threadBasis)
	Santity check thread groups. More...

Static Protected Member Functions inherited from ASMbase
static bool	deformedConfig (const Matrix &Xnod, Vectors &eVec, bool force2nd=false)
	Calculates the deformed configuration for current element. More...

static bool	collapseNodes (ASMbase &pch1, int node1, ASMbase &pch2, int node2)
	Collapses the given two nodes into one. More...

Static Protected Member Functions inherited from ASM2D
static double	getElementSize (const std::vector< Vec3 > &XC)
	Returns characteristic element size based on corner coordinates.

Protected Attributes
std::shared_ptr< LR::LRSplineSurface >	lrspline
	The LR-spline surface object.

bool	is_rational = false
	True if basis is rational.

const ASMu2D *	outputMaster = nullptr
	Master patch to use for VTF output.

Go::SplineSurface *	tensorspline
	Pointer to original tensor spline object.

Go::SplineSurface *	tensorPrjBas
	Pointer to tensor spline projection base.

std::vector< DirichletEdge >	dirich
	Inhomogeneous Dirichlet boundary condition data.

const Matrices &	bezierExtract
	Bezier extraction matrices.

Matrices	myBezierExtract
	Bezier extraction matrices.

Go::BsplineBasis	bezier_u
	Bezier basis in the u-direction.

Go::BsplineBasis	bezier_v
	Bezier basis in the v-direction.

std::vector< std::unique_ptr< BasisFunctionCache > >	myCache
	Basis function cache.

Protected Attributes inherited from ASMLRSpline
std::shared_ptr< LR::LRSpline >	geomB
	Pointer to spline object of the geometry basis.

std::shared_ptr< LR::LRSpline >	projB
	Pointer to spline object of the projection basis.

std::shared_ptr< LR::LRSpline >	projB2
	Pointer to spline object of the secondary projection basis.

std::shared_ptr< LR::LRSpline >	refB
	Pointer to spline object of the refinement basis.

ThreadGroups	threadGroups
	Element groups for multi-threaded assembly.

ThreadGroups	projThreadGroups
	Element groups for multi-threaded assembly - projection basis.

ThreadGroups	proj2ThreadGroups
	Element groups for multi-threaded assembly - second projection basis.

Protected Attributes inherited from ASMbase
unsigned char	ndim
	Number of parametric dimensions (1, 2 or 3)

unsigned char	nsd
	Number of space dimensions (ndim <= nsd <= 3)

unsigned char	nf
	Number of primary solution fields (1 or larger)

unsigned char	nLag
	Number of Lagrange multipliers per node.

size_t	nel
	Number of regular elements in this patch.

size_t	nnod
	Number of regular nodes in this patch.

const IntVec &	MLGE
	Matrix of Local to Global Element numbers.

const IntVec &	MLGN
	Matrix of Local to Global Node numbers.

const IntMat &	MNPC
	Matrix of Nodal Point Correspondance.

const char	shareFE
	Flag telling whether this patch shares its data with another patch. More...

BCVec	BCode
	Array of Boundary Condition codes.

MPCMap	dCode
	Inhomogeneous Dirichlet condition codes for the MPCs.

MPCSet	mpcs
	All multi-point constraints with the slave in this patch.

IntVec	myMLGE
	The actual Matrix of Local to Global Element numbers.

IntVec	myMLGN
	The actual Matrix of Local to Global Node numbers.

IntMat	myMNPC
	The actual Matrix of Nodal Point Correspondance.

IntVec	myElms
	Elements on patch - used with partitioning.

int	nGauss
	Numerical integration scheme for this patch. More...

size_t	firstEl
	Global index to first element within this patch.

size_t	firstIp
	Global index to first interior integration point.

std::map< char, size_t >	firstBp
	Global indices to first integration point for the Neumann boundaries.

ASMVec	neighbors
	Patches having nodes in common with this one.

std::map< size_t, XYZ >	myRmaster
	Rigid master nodal points.

Private Member Functions
bool	evaluateBasisNurbs (int iel, FiniteElement &fe, int derivs) const
	Evaluates the NURBS basis functions and derivatives of an element. More...

Private Attributes
double	aMin
	Minimum element area for adaptive refinement.

Additional Inherited Members
Public Types inherited from ASMbase
using	BCVec = std::vector< BC >
	Nodal boundary condition container.

Public Types inherited from ASM2D
typedef std::vector< unsigned char >	CharVec
	Convenience type.

Public Attributes inherited from ASMbase
size_t	idx
	Index of this patch in the multi-patch model.

Static Public Attributes inherited from ASMbase
static bool	fixHomogeneousDirichlet = true
	If true, pre-eliminate fixed DOFs.

static int	dbgElm = 0
	One-based element index to print debugging info for.

static double	modelSize = 1.0
	Characteristic model size. More...

Protected Types inherited from ASMbase
using	XYZ = std::array< double, 3 >
	Convenience type definition.

Static Protected Attributes inherited from ASMbase
static std::map< int, int >	xNode
	Auxilliary node number map used when establishing Dirichlet constraints.

static int	gEl = 0
	Global element counter.

static int	gNod = 0
	Global node counter.

Detailed Description

Driver for assembly of unstructured 2D spline FE models.

This class contains methods common for 2D LR-spline patches.

Member Function Documentation

◆ assembleL2matrices()

bool ASMu2D::assembleL2matrices	(	SystemMatrix &	A,
		SystemVector &	B,
		const L2Integrand &	integrand,
		bool	continuous
	)		const

protectedvirtual

Assembles L2-projection matrices for the secondary solution.

Parameters

[out]	A	Left-hand-side matrix
[out]	B	Right-hand-side vectors
[in]	integrand	Object with problem-specific data and methods
[in]	continuous	If false, a discrete L2-projection is used

Reimplemented from ASMbase.

References SystemMatrix::assemble(), SystemVector::assemble(), computeBasis(), L2Integrand::evaluate(), expandTensorGrid(), SplineUtils::extractBasis(), ASM::GEOMETRY_BASIS, getBasis(), GaussQuadrature::getCoord(), getElementCoordinates(), getElmNodes(), getGaussPointParameters(), ASMbase::getNoGaussPt(), getNoProjectionNodes(), GaussQuadrature::getWeight(), utl::Jacobian(), lrspline, ASMbase::nnod, utl::matrix< T >::outer_product(), SystemMatrix::preAssemble(), ASM::PROJECTION_BASIS, ASMLRSpline::projThreadGroups, utl::matrix< T >::rows(), and ThreadGroups::size().

◆ checkElementSize()

bool ASMu2D::checkElementSize	(	int	elmId,
		bool	globalNum = `true`
	)		const

virtual

Checks if the specified element is larger than the minimum size.

Parameters

[in]	elmId	Global/patch-local element index
[in]	globalNum	If true, elmId is global otherwise patch-local

Reimplemented from ASMbase.

◆ clear()

void ASMu2D::clear ( bool retainGeometry = false )

virtual

Clears the contents of the patch, making it empty.

Parameters

[in] retainGeometry If true, the spline geometry is not cleared. This is used to reinitialize the patch after it has been refined.

Reimplemented from ASMbase.

Reimplemented in ASMu2Dmx.

References ASMbase::clear(), dirich, ASMLRSpline::geomB, lrspline, myCache, ASMLRSpline::projThreadGroups, ASMbase::shareFE, tensorPrjBas, and tensorspline.

Referenced by ASMu2Dmx::clear().

◆ connectBasis()

bool ASMu2D::connectBasis	(	int	edge,
		ASMu2D &	neighbor,
		int	nedge,
		bool	revers,
		int	basis = `1`,
		int	slave = `0`,
		int	master = `0`,
		bool	coordCheck = `true`,
		int	thick = `1`
	)

protected

Connects all matching nodes on two adjacent boundary edges.

Parameters

[in]	edge	Local edge index of this patch, in range [1,4]
	neighbor	The neighbor patch
[in]	nedge	Local edge index of neighbor patch, in range [1,4]
[in]	revers	Indicates whether the two edges have opposite directions
[in]	basis	Which basis to connect the nodes for (mixed methods)
[in]	slave	0-based index of the first slave node in this basis
[in]	master	0-based index of the first master node in this basis
[in]	coordCheck	False to disable coordinate checks
[in]	thick	Thickness of connection

References getBoundaryNodes(), and ASMbase::isShared().

Referenced by ASMu2Dmx::connectPatch(), and connectPatch().

◆ connectPatch()

bool ASMu2D::connectPatch	(	int	edge,
		ASM2D &	neighbor,
		int	nedge,
		bool	revers,
		int	= `0`,
		bool	coordCheck = `true`,
		int	thick = `1`
	)

virtual

Connects all matching nodes on two adjacent boundary edges.

Parameters

[in]	edge	Local edge index of this patch, in range [1,4]
	neighbor	The neighbor patch
[in]	nedge	Local edge index of neighbor patch, in range [1,4]
[in]	revers	Indicates whether the two edges have opposite directions
[in]	coordCheck	False to disable coordinate checks
[in]	thick	Thickness of connection

Implements ASM2D.

Reimplemented in ASMu2Dmx.

References ASMbase::addNeighbor(), and connectBasis().

◆ constrainCorner()

void ASMu2D::constrainCorner	(	int	I,
		int	J,
		int	dof,
		int	code = `0`,
		char	basis = `1`
	)

virtual

Constrains a corner node identified by the two parameter indices.

Parameters

[in]	I	Parameter index in u-direction
[in]	J	Parameter index in v-direction
[in]	dof	Which DOFs to constrain at the node
[in]	code	Inhomogeneous dirichlet condition code
[in]	basis	Which basis to constrain node for

The sign of the two indices is used to define whether we want the node at the beginning or the end of that parameter direction. The magnitude of the indices are not used.

Implements ASM2D.

References getCorner(), and ASMbase::prescribe().

◆ constrainEdge()

void ASMu2D::constrainEdge	(	int	dir,
		bool	open,
		int	dof,
		int	code,
		char	basis
	)

virtual

Constrains all DOFs on a given boundary edge.

Parameters

[in]	dir	Parameter direction defining the edge to constrain
[in]	open	If true, exclude the end points of the edge
[in]	dof	Which DOFs to constrain at each node along the edge
[in]	code	Inhomogeneous dirichlet condition code
[in]	basis	Which basis to constrain edge for

A negative code value implies direct evaluation of the Dirichlet condition function at the control point. Positive code implies projection onto the spline basis representing the boundary curve (needed for curved edges and/or non-constant functions).

Implements ASM2D.

Reimplemented in ASMu2DC1.

References dirich, ASMu2D::DirichletEdge::edg, utl::findIndex(), getBasis(), getNoNodes(), ASMu2D::DirichletEdge::isCorner(), ASMu2D::DirichletEdge::lr, lrspline, ASMu2D::DirichletEdge::MLGE, ASMu2D::DirichletEdge::MLGN, ASMu2D::DirichletEdge::MNPC, and ASMbase::prescribe().

Referenced by ASMu2DC1::constrainEdge().

◆ constrainEdgeLocal()

size_t ASMu2D::constrainEdgeLocal	(	int	dir,
		bool	open,
		int	dof,
		int	code,
		bool	project = `false`
	)

virtual

Constrains all DOFs in local directions on a given boundary edge.

Parameters

[in]	dir	Parameter direction defining the edge to constrain
[in]	open	If true, exclude the end points of the edge
[in]	dof	Which local DOFs to constrain at each node on the edge
[in]	code	Inhomogeneous dirichlet condition code
[in]	project	If true, the local axis directions are projected

Returns: Number of additional nodes added due to local axis constraints

Implements ASM2D.

◆ constrainNode()

void ASMu2D::constrainNode	(	double	xi,
		double	eta,
		int	dof,
		int	code = `0`
	)

virtual

Constrains a node identified by two relative parameter values.

Parameters

[in]	xi	Parameter in u-direction
[in]	eta	Parameter in v-direction
[in]	dof	Which DOFs to constrain at the node
[in]	code	Inhomogeneous dirichlet condition code

The parameter values have to be in the domain [0.0,1.0], where 0.0 means the beginning of the domain and 1.0 means the end. For values in between, the actual index is taken as the integer value closest to r*n, where r denotes the given relative parameter value, and n is the number of nodes along that parameter direction.

Implements ASM2D.

References IFEM::cout, ASMLRSpline::evalPoint(), getCoord(), ASMbase::nnod, and ASMbase::prescribe().

◆ copyRefinement()

void ASMu2D::copyRefinement	(	LR::LRSplineSurface *	basis,
		int	multiplicity = `1`
	)		const

Copies the refinement to another surface.

Parameters

	basis	Surface to copy refinement to
[in]	multiplicity	Wanted multiplicity

References getBasis(), and ASM::REFINEMENT_BASIS.

Referenced by ASMu2Dmx::refine().

◆ cornerRefine()

bool ASMu2D::cornerRefine ( int minBasisfunctions )

Refines the lower-left corner of the LR-spline patch.

Progressively refine until the LR-spline object contains at least minBasisfunctions basis functions.

Parameters

[in] minBasisfunctions lower bound on number of basis functions

References lrspline, and ASMbase::shareFE.

◆ createProjectionBasis()

bool ASMu2D::createProjectionBasis ( bool init )

virtual

Creates a separate projection basis for this patch.

This method is supposed to be invoked twice during the model generation. In the first call, with init = true, the spline surface object is cloned and the two pointers are then swapped, such that the subsequent refine and raiseOrder operations will apply to the projection basis and not on the geometry basis. In the second call, the pointers are swapped back.

The method can also be invoked twice with init = false in case the projection basis is to be read from a file.

Reimplemented from ASMbase.

References tensorspline.

◆ diagonalRefine()

bool ASMu2D::diagonalRefine ( int minBasisfunctions )

Refines along the diagonal of the LR-spline patch.

Progressively refine until the LR-spline object contains at least minBasisfunctions basis functions.

Parameters

[in] minBasisfunctions lower bound on number of basis functions

References lrspline, and ASMbase::shareFE.

◆ diracPoint()

bool ASMu2D::diracPoint	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const double *	param,
		const Vec3 &	pval
	)

virtual

Integrates a spatial dirac-delta function over a patch.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	param	Parameters of the non-zero point of dirac-delta function
[in]	pval	Function value at the specified point

Reimplemented from ASMbase.

References GlobalIntegral::assemble(), LocalIntegral::destruct(), Integrand::evalPoint(), evaluateBasis(), ASMbase::firstEl, Integrand::getLocalIntegral(), ItgPoint::idx, ItgPoint::iel, lrspline, ASMbase::MLGE, ASMbase::MNPC, ItgPoint::u, and ItgPoint::v.

◆ edgeL2projection()

bool ASMu2D::edgeL2projection	(	const DirichletEdge &	edge,
		const FunctionBase &	values,
		Real2DMat &	result,
		double	time
	)		const

Projects inhomogenuous dirichlet conditions by continuous L2-fit.

Parameters

[in]	edge	low-level edge information needed to do integration
[in]	values	inhomogenuous function which is to be fitted
[out]	result	fitted value in terms of control-point values
[in]	time	time used in dynamic problems

References FunctionBase::dim(), ASMu2D::DirichletEdge::edg, ASM::GEOMETRY_BASIS, getBasis(), GaussQuadrature::getCoord(), getElementCoordinates(), getGaussPointParameters(), ASMbase::getNoGaussPt(), getParametricLength(), GaussQuadrature::getWeight(), lrspline, ASMu2D::DirichletEdge::MLGE, ASMu2D::DirichletEdge::MLGN, ASMu2D::DirichletEdge::MNPC, and SparseMatrix::resize().

Referenced by updateDirichlet().

◆ evalPoint() [1/2]

int ASMu2D::evalPoint	(	const double *	xi,
		double *	param,
		Vec3 &	X
	)		const

virtual

Evaluates the geometry at a specified point.

Parameters

[in]	xi	Dimensionless parameters in range [0.0,1.0] of the point
[out]	param	The (u,v) parameters of the point in knot-span domain
[out]	X	The Cartesian coordinates of the point

Returns: Local node number within the patch that matches the point, if any; 0 if no node (control point) matches this point

If param is NULL, then xi is taken to be in the parameter domain of the LR-spline object instead of the dimensionless [0,1] domain.

Implements ASMbase.

References ASMLRSpline::evalPoint(), ASM::GEOMETRY_BASIS, getBasis(), lrspline, and ASMbase::nel.

◆ evalPoint() [2/2]

int ASMu2D::evalPoint	(	int	iel,
		const double *	param,
		Vec3 &	X
	)		const

protectedvirtual

Evaluates the geometry at a specified point.

Parameters

[in]	iel	0-based local element index
[in]	param	The (u,v) parameters of the point in knot-span domain
[out]	X	The Cartesian coordinates of the point

Returns: Local node number within the patch that matches the point, if any; 0 if no node (control point) matches this point

Implements ASMLRSpline.

References computeBasis(), ASM::GEOMETRY_BASIS, getBasis(), getElementCoordinates(), and lrspline.

◆ evalProjSolution()

bool ASMu2D::evalProjSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const int *	npe,
		int	n_f
	)		const

virtual

Evaluates the projected solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	npe	Number of visualization nodes over each knot span
[in]	n_f	If nonzero, mixed evaluates n_f fields on first basis

Reimplemented from ASMbase.

References ASMLRSpline::evalSolution(), utl::matrix< T >::fillColumn(), getGridParameters(), Fields::getNoFields(), getProjectedFields(), utl::matrix< T >::resize(), separateProjectionBasis(), and Fields::valueFE().

◆ evalSolution() [1/5]

LR::LRSpline * ASMu2D::evalSolution ( const IntegrandBase & integrand ) const

virtual

Projects the secondary solution field onto the primary basis.

Parameters

[in] integrand Object with problem-specific data and methods

Implements ASMLRSpline.

◆ evalSolution() [2/5]

bool ASMu2D::evalSolution	(	Matrix &	sField,
		const IntegrandBase &	integrand,
		const int *	npe,
		char	project = `'\0'`
	)		const

virtual

Evaluates the secondary solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	npe	Number of visualization nodes over each knot span
[in]	project	Flag indicating result recovery method (0=none, 'D'=direct evaluation, 'S'=superconvergent recovery)

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. If npe is null, the solution is recovered or evaluated at the Greville points and then projected onto the spline basis to obtain the control point values, which then are returned through sField. If npe is not null and project is defined, the solution is also projected onto the spline basis, and then evaluated at the npe points.

Reimplemented from ASMbase.

References ASMLRSpline::evalSolution(), utl::matrix< T >::fillColumn(), getGridParameters(), SplineUtils::project(), projectSolution(), utl::matrix< T >::resize(), and scRecovery().

◆ evalSolution() [3/5]

bool ASMu2D::evalSolution	(	Matrix &	sField,
		const IntegrandBase &	integrand,
		const RealArray *	gpar,
		bool	= `false`
	)		const

virtual

Evaluates the secondary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	gpar	Parameter values of the result sampling points

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. We assume that the parameter value array gpar contains the u and v parameters directly for each sampling point.

Reimplemented from ASMbase.

Reimplemented in ASMu2Dmx.

References computeBasis(), FiniteElement::d2NdX2, FiniteElement::d3NdX3, ASMbase::deformedConfig(), FiniteElement::detJxW, FiniteElement::dNdX, utl::matrixBase< T >::empty(), IntegrandBase::evalSol(), SplineUtils::extractBasis(), utl::matrix< T >::fillColumn(), ASMbase::firstIp, FiniteElement::G, getElementCoordinates(), Integrand::getIntegrandType(), getNodalCoordinates(), FiniteElement::H, utl::Hessian(), utl::Hessian2(), ItgPoint::iGP, utl::Jacobian(), lrspline, ASMbase::MNPC, FiniteElement::N, ASMbase::nsd, FiniteElement::p, PROFILE2, FiniteElement::q, utl::matrix< T >::resize(), Integrand::SECOND_DERIVATIVES, utl::vector< T >::size(), Integrand::THIRD_DERIVATIVES, ItgPoint::u, Integrand::UPDATED_NODES, and ItgPoint::v.

◆ evalSolution() [4/5]

bool ASMu2D::evalSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const int *	npe,
		int	n_f,
		bool	piola
	)		const

virtual

Evaluates the primary solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector in DOF-order
[in]	npe	Number of visualization nodes over each knot span
[in]	n_f	If nonzero, mixed evaluates n_f fields on first basis
[in]	piola	If true, use piola mapping

Reimplemented from ASMbase.

References ASMLRSpline::evalSolution(), ASMbase::evalSolutionPiola(), and getGridParameters().

◆ evalSolution() [5/5]

bool ASMu2D::evalSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const RealArray *	gpar,
		bool	= `false`,
		int	deriv = `0`,
		int	= `0`
	)		const

virtual

Evaluates the primary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	gpar	Parameter values of the result sampling points
[in]	deriv	Derivative order to return

Reimplemented from ASMbase.

Reimplemented in ASMu2Dmx.

References computeBasis(), FiniteElement::dNdX, evaluateBasis(), SplineUtils::extractBasis(), utl::matrix< T >::fillColumn(), utl::gather(), getElementCoordinates(), getNoNodes(), utl::Hessian(), utl::Jacobian(), lrspline, ASMbase::MNPC, utl::matrix< T >::multiply(), utl::matrix3d< T >::multiply(), FiniteElement::N, FiniteElement::p, PROFILE2, FiniteElement::q, utl::matrix< T >::resize(), utl::vector< T >::size(), ItgPoint::u, and ItgPoint::v.

◆ evaluate()

bool ASMu2D::evaluate	(	const FunctionBase *	func,
		RealArray &	vec,
		int	,
		double	time
	)		const

virtual

Evaluates and interpolates a function over a given geometry.

Parameters

[in]	func	The function to evaluate
[out]	vec	The obtained coefficients after interpolation
[in]	time	Current time

Reimplemented from ASMbase.

References ASMbase::L2projection().

◆ evaluateBasis()

bool ASMu2D::evaluateBasis	(	int	iel,
		FiniteElement &	fe,
		int	derivs = `0`
	)		const

protected

Evaluates the basis functions and derivatives of an element.

Parameters

[in]	iel	0-based element index
	fe	Integration point data for current element
[in]	derivs	Derivative order of the basis functions

References bezier_u, ItgPoint::eta, evaluateBasisNurbs(), is_rational, lrspline, PROFILE3, ItgPoint::u, ItgPoint::v, and ItgPoint::xi.

Referenced by diracPoint(), and evalSolution().

◆ evaluateBasisNurbs()

bool ASMu2D::evaluateBasisNurbs	(	int	iel,
		FiniteElement &	fe,
		int	derivs
	)		const

private

Evaluates the NURBS basis functions and derivatives of an element.

Parameters

[in]	iel	0-based element index
	fe	Integration point data for current element
[in]	derivs	Derivative order of the basis functions

References bezier_u, bezier_v, bezierExtract, FiniteElement::detJxW, FiniteElement::dNdX, utl::vector< T >::dot(), ItgPoint::eta, getElementCoordinates(), ItgPoint::iGP, utl::Jacobian(), lrspline, utl::matrix< T >::multiply(), FiniteElement::N, utl::matrix< T >::outer_product(), PROFILE3, utl::vector< T >::size(), utl::matrixBase< T >::sum(), utl::vector< T >::sum(), ItgPoint::u, ItgPoint::v, and ItgPoint::xi.

Referenced by evaluateBasis().

◆ extendRefinementDomain()

void ASMu2D::extendRefinementDomain	(	IntSet &	refineIndices,
		const IntSet &	neighborIndices
	)		const

protectedvirtual

Extends the refinement domain with information for neighbors.

Parameters

refineIndices	List of basis functions to refine
neighborIndices	Basis functions to refine from neighbor patches

Reimplemented from ASMunstruct.

References getBasis(), GlobalNodes::getBoundaryNodes(), and ASM::REFINEMENT_BASIS.

◆ extractElmRes()

void ASMu2D::extractElmRes	(	const Matrix &	globRes,
		Matrix &	elmRes,
		size_t	internalFirst
	)		const

virtual

Extracts element results for this patch from a global vector.

Parameters

[in]	globRes	Global matrix of element results
[out]	elmRes	Element results for this patch
[in]	internalFirst	Global index of first element in the patch

Reimplemented from ASMbase.

References extractElmRes(), ASMbase::extractElmRes(), and outputMaster.

Referenced by extractElmRes().

◆ findBoundaryElms()

void ASMu2D::findBoundaryElms	(	IntVec &	elms,
		int	lIndex,
		int	orient
	)		const

protectedvirtual

Finds the patch-local element numbers on a patch boundary.

Parameters

[out]	elms	Array of element numbers
[in]	lIndex	Local index of the boundary edge
[in]	orient	Orientation of boundary (used for sorting)

Implements ASMbase.

References getBasis(), and getEdgeEnum().

◆ findElementContaining()

int ASMu2D::findElementContaining ( const double * param ) const

virtual

Returns the element that contains a specified spatial point.

Parameters

[in] param The parameters of the point in the knot-span domain

Returns: Local element number within the patch that contains the point

Implements ASMbase.

References lrspline.

◆ findPoint()

double ASMu2D::findPoint	(	Vec3 &	X,
		double *	param
	)		const

virtual

Searches for the specified Cartesian point in the patch.

Parameters

	X	The Cartesian coordinates of the point, updated on output
[out]	param	The parameters of the point in the knot-span domain

Returns: Distance from the point X to the found point

Implements ASMbase.

◆ generateFEMTopology()

bool ASMu2D::generateFEMTopology ( )

virtual

Generates the finite element topology data for the patch.

The data generated are the element-to-node connectivity array, and the arrays of global node and element numbers.

Implements ASMbase.

Reimplemented in ASMu2Dmx, ASMu2DIB, and ASMu2DC1.

References createLRfromTensor(), createLRNurbs(), LR::createMNPC(), ASMbase::firstEl, ASMbase::gEl, generateBezierBasis(), generateBezierExtraction(), ASMLRSpline::geomB, ASMbase::gNod, lrspline, ASMbase::MLGN, ASMbase::myMLGE, ASMbase::myMLGN, ASMbase::myMNPC, ASMbase::nel, ASMbase::nnod, ASMLRSpline::projB, ASMLRSpline::refB, ASMbase::shareFE, and tensorPrjBas.

Referenced by ASMu2DC1::generateFEMTopology(), and ASMu2DIB::generateFEMTopology().

◆ generateThreadGroups()

void ASMu2D::generateThreadGroups	(	const Integrand &	integrand,
		bool	silence,
		bool	ignoreGlobalLM
	)

protectedvirtual

Generates element groups for multi-threading of interior integrals.

Parameters

[in]	integrand	Object with problem-specific data and methods
[in]	silence	If true, suppress threading group outprint
[in]	ignoreGlobalLM	If true ignore global multipliers in sanity check

Reimplemented from ASMbase.

Reimplemented in ASMu2Dmx.

References ThreadGroups::analyzeUnstruct(), IFEM::cout, LR::generateThreadGroups(), getBasis(), ASM::PROJECTION_BASIS, ASM::PROJECTION_BASIS_2, ASMLRSpline::projThreadGroups, ThreadGroups::size(), and ASMLRSpline::threadGroups.

◆ getBoundaryNodes()

void ASMu2D::getBoundaryNodes	(	int	lIndex,
		IntVec &	nodes,
		int	basis,
		int	= `1`,
		int	orient = `0`,
		bool	local = `false`
	)		const

virtual

Finds the global (or patch-local) node numbers on a patch boundary.

Parameters

[in]	lIndex	Local index of the boundary edge
	nodes	Array of node numbers
[in]	basis	Which basis to grab nodes for (for mixed methods)
[in]	orient	Orientation of boundary (used for sorting)
[in]	local	If true, return patch-local node numbers

Implements ASMbase.

Reimplemented in ASMu2Dmx.

References getBasis(), getEdgeEnum(), getNoNodes(), ASMbase::idx, and ASMLRSpline::Sort().

Referenced by connectBasis(), and ASMu2Dmx::getBoundaryNodes().

◆ getCoord()

Vec3 ASMu2D::getCoord ( size_t inod ) const

virtual

Returns the global coordinates for the given node.

Parameters

[in] inod 1-based node index local to current patch

Implements ASMbase.

Reimplemented in ASMu2Dmx.

References lrspline, and ASMbase::nsd.

Referenced by constrainNode().

◆ getCoordinates()

bool ASMu2D::getCoordinates	(	Matrix &	X,
		unsigned char	nsd,
		const LR::LRSplineSurface &	spline,
		int	iel = `-1`
	)

static

Returns a matrix with control point coordinates.

Parameters

[out]	X	3 \(\times\)n-matrix, where n is the number of points
[in]	nsd	Number of spatial dimensions
[in]	spline	Spline to extract coefficients from
[in]	iel	1-based element index, if -1 return for all control points

In case of NURBS, this is not strictly correct as we then return the rational spline coefficients rather than nodal (control point) coordinates. But since these are used as coefficients, and not coordinates at caller sites, we do this for simplicity.

Consider introducing ASMbase::getCoefficients() to lessen confusion.

References utl::matrix< T >::fillColumn(), ASMbase::nsd, and utl::matrix< T >::resize().

Referenced by LRSplineField::evalMapping(), getElementCoordinates(), and getNodalCoordinates().

◆ getCorner()

int ASMu2D::getCorner	(	int	I,
		int	J,
		int	basis
	)		const

virtual

Returns the node index for a given corner.

Parameters

[in]	I	-1 or +1 for either umin or umax corner
[in]	J	-1 or +1 for either vmin or vmax corner
[in]	basis	which basis to consider (for mixed methods)

Implements ASM2D.

References getBasis(), and getNoNodes().

Referenced by constrainCorner().

◆ getCornerPoints()

void ASMu2D::getCornerPoints	(	int	iel,
		std::vector< utl::Point > &	XC
	)		const

protected

Computes the element corner coordinates and parameters.

Parameters

[in]	iel	1-based element index
[out]	XC	Coordinates and parameters of the element corners

References getElementCorners().

Referenced by ASMu2DIB::generateFEMTopology().

◆ getElementCoordinates()

bool ASMu2D::getElementCoordinates	(	Matrix &	X,
		int	iel,
		bool	forceItg = `false`
	)		const

virtual

Returns a matrix with nodal coordinates for an element.

Parameters

[in]	iel	1-based element index
[out]	X	3 \(\times\)n-matrix, where n is the number of nodes in one element
[in]	forceItg	If true return integration basis element coordinates

Implements ASMbase.

References ASM::GEOMETRY_BASIS, getBasis(), getCoordinates(), ASM::INTEGRATION_BASIS, lrspline, and ASMbase::nsd.

Referenced by assembleL2matrices(), edgeL2projection(), evalPoint(), ASMu2Dmx::evalSolution(), evalSolution(), ASMu2Dmx::evalSolutionPiola(), evaluateBasisNurbs(), integrate(), and ASMu2Dmx::integrate().

◆ getElementCorners()

double ASMu2D::getElementCorners	(	int	iel,
		std::vector< Vec3 > &	XC,
		RealArray *	uC = `nullptr`
	)		const

protected

Computes the element corner coordinates.

Parameters

[in]	iel	1-based element index
[out]	XC	Coordinates of the element corners
[out]	uC	Spline parameters of the element corners (optional)

Returns: Characteristic element size

References ASMLRSpline::evalPoint(), ASM2D::getElementSize(), and lrspline.

Referenced by getCornerPoints(), integrate(), and ASMu2Dmx::integrate().

◆ getElmConnectivities()

void ASMu2D::getElmConnectivities	(	IntMat &	neighs,
		int	basis = `ASM::INTEGRATION_BASIS`
	)		const

virtual

Calculates the matrix of element neighbour connectivities.

Parameters

[out]	neighs	List of element neighbors for each element
[in]	basis	Basis to obtain connectivities for

Implements ASMbase.

References getBasis(), ASM::INTEGRATION_BASIS, and ASMbase::MLGE.

◆ getGaussPointParameters()

void ASMu2D::getGaussPointParameters	(	RealArray &	uGP,
		int	dir,
		int	nGauss,
		int	iel,
		const double *	xi,
		const LR::LRSplineSurface *	spline = `nullptr`
	)		const

protected

Extracts parameter values of the Gauss points in one direction.

Parameters

[out]	uGP	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)
[in]	nGauss	Number of Gauss points along a knot-span
[in]	iel	1-based element index
[in]	xi	Dimensionless Gauss point coordinates [-1,1]
[in]	spline	If given get gauss points for this spline instead of integration basis

References LR::getGaussPointParameters(), lrspline, and ASMbase::nGauss.

Referenced by assembleL2matrices(), edgeL2projection(), integrate(), ASMu2Dmx::integrate(), and scRecovery().

◆ getGrevilleParameters()

bool ASMu2D::getGrevilleParameters	(	RealArray &	prm,
		int	dir,
		int	basisNum = `1`
	)		const

protected

Calculates parameter values for the Greville points.

Parameters

[out]	prm	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)
[in]	basisNum	Which basis to get Greville point parameters for

References getBasis().

Referenced by projectSolution(), and scRecovery().

◆ getGridParameters()

bool ASMu2D::getGridParameters	(	RealArray &	prm,
		int	dir,
		int	nSegSpan
	)		const

virtual

Calculates parameter values for visualization nodal points.

Parameters

[out]	prm	Parameter values in given direction for all points
[in]	dir	Parameter direction (0,1)
[in]	nSegSpan	Number of visualization segments over each knot-span

References ElementBlock::eps, getGridParameters(), lrspline, and outputMaster.

Referenced by evalProjSolution(), evalSolution(), and getGridParameters().

◆ getMinimumSize()

double ASMu2D::getMinimumSize ( int nrefinements ) const

virtual

Defines the minimum element area for adaptive refinement.

Parameters

[in] nrefinements Maximum number of adaptive refinement levels

Reimplemented from ASMbase.

References aMin, and lrspline.

◆ getNodalCoordinates()

virtual void ASMu2D::getNodalCoordinates	(	Matrix &	X,
		bool	= `false`
	)		const

inlinevirtual

Returns a matrix with all nodal coordinates within the patch.

Parameters

[out] X 3 \(\times\)n-matrix, where n is the number of nodes in the patch

Implements ASMbase.

References getCoordinates(), lrspline, and ASMbase::nsd.

Referenced by evalSolution().

◆ getOrder()

bool ASMu2D::getOrder	(	int &	p1,
		int &	p2,
		int &	p3
	)		const

virtual

Returns the polynomial order in each parameter direction.

Parameters

[out]	p1	Order in first (u) direction
[out]	p2	Order in second (v) direction
[out]	p3	Order in third (w) direction

Reimplemented from ASMbase.

References lrspline.

◆ getParametricLength()

double ASMu2D::getParametricLength	(	int	iel,
		int	dir
	)		const

protected

Returns boundary edge length in the parameter space for an element.

Parameters

[in]	iel	1-based element index
[in]	dir	Local index of the boundary edge

References lrspline.

Referenced by edgeL2projection(), integrate(), and ASMu2Dmx::integrate().

◆ getProjectedField()

Field * ASMu2D::getProjectedField ( const Vector & coefs ) const

virtual

Returns a field using the projection basis.

Parameters

[in] coefs The coefficients for the field

Reimplemented from ASMbase.

References getBasis(), getNoProjectionNodes(), is_rational, ASM::PROJECTION_BASIS, and utl::vector< T >::size().

◆ getProjectedFields()

Fields * ASMu2D::getProjectedFields	(	const Vector &	coefs,
		size_t	= `0`
	)		const

virtual

Returns a field using the projection basis.

Parameters

[in] coefs The coefficients for the field

Reimplemented from ASMbase.

References getBasis(), getNoProjectionNodes(), is_rational, ASM::PROJECTION_BASIS, and utl::vector< T >::size().

Referenced by evalProjSolution().

◆ integrate() [1/7]

bool ASMu2D::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time
	)

virtual

Evaluates an integral over the interior patch domain.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Implements ASMbase.

Reimplemented in ASMu2Dmx, and ASMu2DIB.

◆ integrate() [2/7]

virtual bool ASMbase::integrate

Evaluates an integral over the interior patch domain.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Referenced by ASMu2DIB::integrate().

◆ integrate() [3/7]

virtual bool ASMbase::integrate

inline

Evaluates an integral over element interfaces in the patch.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	iChk	Object checking if an element interface has contributions

◆ integrate() [4/7]

bool ASMu2D::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time,
		const ASM::InterfaceChecker &	iChk
	)

virtual

Evaluates an integral over element interfaces in the patch.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	iChk	Object checking if an element interface has contributions

Reimplemented from ASMbase.

Reimplemented in ASMu2Dmx.

References GlobalIntegral::assemble(), Vec4::assign(), computeBasis(), LocalIntegral::destruct(), FiniteElement::detJxW, FiniteElement::dNdX, ASM::InterfaceChecker::elmBorderMask(), ItgPoint::eta, Integrand::evalInt(), SplineUtils::extractBasis(), Integrand::finalizeElement(), ASMbase::firstEl, FiniteElement::G, ASMLRSpline::geomB, Integrand::getBouIntegrationPoints(), GaussQuadrature::getCoord(), getElementCoordinates(), Integrand::getIntegrandType(), ASMu2D::InterfaceChecker::getIntersections(), Integrand::getLocalIntegral(), GaussQuadrature::getWeight(), ASMu2D::InterfaceChecker::hasContribution(), ItgPoint::idx, ItgPoint::iel, Integrand::initElement(), Integrand::INTERFACE_TERMS, ASMbase::isElementInPartition(), utl::Jacobian(), lrspline, ASMbase::MLGE, ASMbase::MNPC, ASMbase::myElms, FiniteElement::N, ASMbase::nGauss, ASMbase::nsd, PROFILE2, TimeDomain::t, ItgPoint::u, ItgPoint::v, and ItgPoint::xi.

◆ integrate() [5/7]

bool ASMu2D::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time,
		const Real3DMat &	itgPts
	)

protected

Evaluates an integral over the interior patch domain.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations
[in]	itgPts	Parameters and weights of the integration points

References GlobalIntegral::assemble(), Vec4::assign(), computeBasis(), FiniteElement::d2NdX2, ASMbase::dbgElm, ASMbase::deformedConfig(), LocalIntegral::destruct(), FiniteElement::detJxW, FiniteElement::dNdX, Integrand::ELEMENT_CENTER, Integrand::ELEMENT_CORNERS, Integrand::evalInt(), SplineUtils::extractBasis(), Integrand::finalizeElement(), TimeDomain::first, ASMbase::firstEl, ASMbase::firstIp, FiniteElement::G, getElementCoordinates(), getElementCorners(), Integrand::getIntegrandType(), Integrand::getLocalIntegral(), Integrand::getReducedIntegration(), FiniteElement::H, FiniteElement::h, utl::Hessian(), ItgPoint::idx, ItgPoint::iel, ItgPoint::iGP, Integrand::initElement(), TimeDomain::it, utl::Jacobian(), lrspline, ASMbase::MLGE, ASMbase::MNPC, ASMbase::myElms, FiniteElement::N, ASMbase::nel, ASMbase::nsd, ThreadGroups::oneGroup(), FiniteElement::p, PROFILE2, PROFILE3, FiniteElement::q, LocalIntegral::ref(), Integrand::SECOND_DERIVATIVES, TimeDomain::t, ASMLRSpline::threadGroups, GlobalIntegral::threadSafe(), ItgPoint::u, Vec4::u, Integrand::UPDATED_NODES, ItgPoint::v, LocalIntegral::vec, and FiniteElement::XC.

◆ integrate() [6/7]

bool ASMu2D::integrate	(	Integrand &	integrand,
		int	lIndex,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time
	)

virtual

Evaluates a boundary integral over a patch edge.

Parameters

	integrand	Object with problem-specific data and methods
[in]	lIndex	Local index of the boundary edge
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Implements ASMbase.

Reimplemented in ASMu2Dmx.

References GlobalIntegral::assemble(), Vec4::assign(), computeBasis(), ASMbase::dbgElm, LocalIntegral::destruct(), FiniteElement::detJxW, FiniteElement::dNdX, Integrand::ELEMENT_CORNERS, ItgPoint::eta, Integrand::evalBou(), SplineUtils::extractBasis(), Integrand::finalizeElementBou(), ASMbase::firstBp, ASMbase::firstEl, FiniteElement::G, Integrand::getBouIntegrationPoints(), GaussQuadrature::getCoord(), getElementCoordinates(), getElementCorners(), getGaussPointParameters(), Integrand::getIntegrandType(), Integrand::getLocalIntegral(), ASMbase::getNoGaussPt(), getParametricLength(), GaussQuadrature::getWeight(), FiniteElement::h, ItgPoint::idx, ItgPoint::iel, ItgPoint::iGP, Integrand::initElementBou(), ASMbase::isElementInPartition(), utl::Jacobian(), lrspline, ASMbase::MLGE, ASMbase::MNPC, ASMbase::myElms, FiniteElement::N, ASMbase::nsd, FiniteElement::p, PROFILE2, FiniteElement::q, LocalIntegral::ref(), Integrand::setNeumannOrder(), TimeDomain::t, ItgPoint::u, ItgPoint::v, FiniteElement::XC, and ItgPoint::xi.

◆ integrate() [7/7]

virtual bool ASMbase::integrate

Evaluates a boundary integral over a patch face/edge.

Parameters

	integrand	Object with problem-specific data and methods
[in]	lIndex	Local index of the boundary face/edge
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

◆ projectSolution()

LR::LRSplineSurface * ASMu2D::projectSolution ( const IntegrandBase & integrand ) const

protected

Projects the secondary solution field onto the primary basis.

Parameters

[in] integrand Object with problem-specific data and methods

References ASMLRSpline::evalSolution(), getGrevilleParameters(), PROFILE2, and regularInterpolation().

Referenced by evalSolution().

◆ raiseOrder()

bool ASMu2D::raiseOrder	(	int	ru,
		int	rv
	)

virtual

Raises the order of the tensor spline object for this patch.

Parameters

[in]	ru	Number of times to raise the order in u-direction
[in]	rv	Number of times to raise the order in v-direction

Implements ASM2D.

References ASMbase::shareFE, and tensorspline.

◆ refine() [1/3]

bool ASMLRSpline::refine

Refines the mesh adaptively.

Parameters

[in]	prm	Input data used to control the mesh refinement
	sol	Control point results values that are transferred to new mesh

◆ refine() [2/3]

bool ASMu2D::refine	(	const LR::RefineData &	prm,
		Vectors &	sol
	)

virtual

Refines the mesh adaptively.

Parameters

[in]	prm	Input data used to control the mesh refinement
	sol	Control point results values that are transferred to new mesh

Reimplemented from ASMLRSpline.

Reimplemented in ASMu2Dmx.

References IFEM::cout, LR::RefineData::elements, LR::RefineData::errors, getBasis(), lrspline, ASM::PROJECTION_BASIS, ASMLRSpline::refine(), and separateProjectionBasis().

◆ refine() [3/3]

bool ASMu2D::refine	(	int	dir,
		const RealArray &	xi,
		double	scale
	)

virtual

Refines the parametrization by inserting extra tensor knots.

Parameters

[in]	dir	Parameter direction to refine
[in]	xi	Relative positions of added knots in each existing knot span
[in]	scale	Scaling factor for the added knot values

References ASMbase::shareFE, and tensorspline.

◆ regularInterpolation()

LR::LRSplineSurface * ASMu2D::regularInterpolation	(	const RealArray &	upar,
		const RealArray &	vpar,
		const Matrix &	points,
		int	basis
	)		const

protected

Interpolates an LR spline at a given set of parametric coordinates.

Parameters

[in]	upar	Parametric interpolation points in the u-direction
[in]	vpar	Parametric interpolation points in the v-direction
[in]	points	Interpolation values stored as one point per matrix row
[in]	basis	Which basis to interpolate onto

Returns: A LRSplineSurface representation of the interpolated points

References utl::matrix< T >::cols(), computeBasis(), StdVector::dim(), getBasis(), utl::interleave(), lrspline, SparseMatrix::resize(), utl::matrix< T >::rows(), and SparseMatrix::solve().

Referenced by projectSolution(), and scRecovery().

◆ remapErrors()

void ASMu2D::remapErrors	(	RealArray &	errors,
		const RealArray &	origErr,
		bool	elemErrors
	)		const

protectedvirtual

Remap element wise errors to basis functions.

Parameters

	errors	The remapped errors
[in]	origErr	The element wise errors on the geometry mesh
[in]	elemErrors	If true, map to elements instead of basis functions

Reimplemented from ASMunstruct.

Reimplemented in ASMu2Dmx.

References getBasis().

◆ scRecovery()

LR::LRSplineSurface * ASMu2D::scRecovery ( const IntegrandBase & integrand ) const

protected

Projects the secondary solution using a superconvergent approach.

Parameters

[in] integrand Object with problem-specific data and methods

References IntegrandBase::derivativeOrder(), evalMonomials(), ASMLRSpline::evalSolution(), expandTensorGrid(), GaussQuadrature::getCoord(), getGaussPointParameters(), getGrevilleParameters(), IntegrandBase::getNoFields(), lrspline, PROFILE2, regularInterpolation(), and DenseMatrix::solve().

Referenced by evalSolution().

◆ setOutputMaster()

void ASMu2D::setOutputMaster ( const ASMu2D * pch )

inline

Set master patch for VTF output.

Parameters

pch	Master patch to use

References outputMaster.

◆ storeMesh()

void ASMu2D::storeMesh	(	const std::string &	fName,
		int	fType
	)		const

virtual

Stores the mesh basis to encapsulated postscript files.

Parameters

[in]	fName	Prefix for file names
[in]	fType	Flag telling which file type(s) to write

Reimplemented from ASMunstruct.

Reimplemented in ASMu2Dmx.

References is_rational, lrspline, writePostscriptElementsNurbs(), and writePostscriptMeshWithControlPointsNurbs().

◆ tesselate()

bool ASMu2D::tesselate	(	ElementBlock &	grid,
		const int *	npe
	)		const

virtual

Creates a quad element model of this patch for visualization.

Parameters

[out]	grid	The generated quadrilateral grid
[in]	npe	Number of visualization nodes over each knot span

Note: The number of element nodes must be set in grid on input.

Each nodal point in grid is generated once for each element using it. This results in a lot of unnecessary duplicates (if ElementBlock::eps is 0.0), but is preferable instead of figuring out all element topology information.

Setting ElementBlock::eps > 0.0 will handle the case of internal C^-1 continuities automatically, in that result quantities along the discontinuity will not be unique.

Implements ASMbase.

References ElementBlock::eps, ASMLRSpline::evalPoint(), lrspline, ElementBlock::setCoor(), ElementBlock::setElmId(), ElementBlock::setNode(), ElementBlock::setParams(), and ElementBlock::unStructResize().

◆ transferCntrlPtVars() [1/3]

bool ASMu2D::transferCntrlPtVars	(	const LR::LRSpline *	old_basis,
		RealArray &	newVar,
		int	nGauss
	)		const

virtual

Transfers control point variables from old basis to this patch.

Parameters

[in]	old_basis	The LR-spline basis to transfer from
[out]	newVar	Gauss point variables associated with this patch
[in]	nGauss	Number of Gauss points along a knot-span

Implements ASMLRSpline.

◆ transferCntrlPtVars() [2/3]

virtual bool ASMLRSpline::transferCntrlPtVars

Transfers control point variables from old basis to this patch.

Parameters

[in]	oldBasis	The LR-spline basis to transfer from
[out]	newVar	Gauss point variables associated with this patch
[in]	nGauss	Number of Gauss points along a knot-span

◆ transferCntrlPtVars() [3/3]

bool ASMLRSpline::transferCntrlPtVars

Transfers control point variables from old basis to this patch.

Parameters

[in]	oldBasis	The LR-spline basis to transfer from
[in]	oldVar	Control point variables associated with oldBasis
[out]	newVar	Gauss point variables associated with this patch
[in]	nGauss	Number of Gauss points along a knot-span
[in]	nf	Number of field components

◆ transferGaussPtVars()

bool ASMu2D::transferGaussPtVars	(	const LR::LRSpline *	old_basis,
		const RealArray &	oldVar,
		RealArray &	newVar,
		int	nGauss
	)		const

virtual

Transfers Gauss point variables from old basis to this patch.

Parameters

[in]	old_basis	The LR-spline basis to transfer from
[in]	oldVar	Gauss point variables associated with oldBasis
[out]	newVar	Gauss point variables associated with this patch
[in]	nGauss	Number of Gauss points along a knot-span

Implements ASMLRSpline.

◆ transferGaussPtVarsN()

bool ASMu2D::transferGaussPtVarsN	(	const LR::LRSpline *	old_basis,
		const RealArray &	oldVar,
		RealArray &	newVar,
		int	nGauss
	)		const

virtual

Transfers Gauss point variables from old basis to this patch.

Parameters

[in]	old_basis	The LR-spline basis to transfer from
[in]	oldVar	Gauss point variables associated with oldBasis
[out]	newVar	Gauss point variables associated with this patch
[in]	nGauss	Number of Gauss points along a knot-span

Implements ASMLRSpline.

◆ uniformRefine() [1/2]

bool ASMu2D::uniformRefine	(	int	dir,
		int	nInsert
	)

virtual

Refines the parametrization by inserting tensor knots uniformly.

Parameters

[in]	dir	Parameter direction to refine
[in]	nInsert	Number of extra knots to insert in each knot-span

Implements ASM2D.

References ASMbase::shareFE, and tensorspline.

◆ uniformRefine() [2/2]

bool ASMu2D::uniformRefine ( int minBasisfunctions )

Refines the LR-spline patch uniformly.

Inserts one (global) line at a time until the LR-spline object contains at least minBasisfunctions basis functions.

Parameters

[in] minBasisfunctions lower bound on number of basis functions

References lrspline, and ASMbase::shareFE.

◆ updateCoords()

bool ASMu2D::updateCoords ( const Vector & displ )

virtual

Updates the nodal coordinates for this patch.

Parameters

[in] displ Incremental displacements to update the coordinates with

Implements ASMbase.

◆ updateDirichlet()

bool ASMu2D::updateDirichlet	(	const std::map< int, RealFunc * > &	func,
		const std::map< int, VecFunc * > &	vfunc,
		double	time,
		const std::map< int, int > *	g2l = `nullptr`
	)

virtual

Updates the time-dependent in-homogeneous Dirichlet coefficients.

Parameters

[in]	func	Scalar property fields
[in]	vfunc	Vector property fields
[in]	time	Current time
[in]	g2l	Pointer to global-to-local node number mapping

Reimplemented from ASMbase.

References dirich, edgeL2projection(), ASMbase::MLGN, ASMbase::mpcs, and ASMbase::updateDirichlet().

The documentation for this class was generated from the following files:

src/ASM/LR/ASMu2D.h
src/ASM/LR/ASMu2D.C
src/ASM/LR/ASMu2Dnurbs.C
src/ASM/LR/ASMu2Drecovery.C

Classes

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ assembleL2matrices()

◆ checkElementSize()

◆ clear()

◆ connectBasis()

◆ connectPatch()

◆ constrainCorner()

◆ constrainEdge()

◆ constrainEdgeLocal()

◆ constrainNode()

◆ copyRefinement()

◆ cornerRefine()

◆ createProjectionBasis()

◆ diagonalRefine()

◆ diracPoint()

◆ edgeL2projection()

◆ evalPoint() [1/2]

◆ evalPoint() [2/2]

◆ evalProjSolution()

◆ evalSolution() [1/5]

◆ evalSolution() [2/5]

◆ evalSolution() [3/5]

◆ evalSolution() [4/5]

◆ evalSolution() [5/5]

◆ evaluate()

◆ evaluateBasis()

◆ evaluateBasisNurbs()

◆ extendRefinementDomain()

◆ extractElmRes()

◆ findBoundaryElms()

◆ findElementContaining()

◆ findPoint()

◆ generateFEMTopology()

◆ generateThreadGroups()

◆ getBoundaryNodes()

◆ getCoord()

◆ getCoordinates()

◆ getCorner()

◆ getCornerPoints()

◆ getElementCoordinates()

◆ getElementCorners()

◆ getElmConnectivities()

◆ getGaussPointParameters()

◆ getGrevilleParameters()

◆ getGridParameters()

◆ getMinimumSize()

◆ getNodalCoordinates()

◆ getOrder()

◆ getParametricLength()

◆ getProjectedField()

◆ getProjectedFields()

◆ integrate() [1/7]

◆ integrate() [2/7]

◆ integrate() [3/7]

◆ integrate() [4/7]

◆ integrate() [5/7]

◆ integrate() [6/7]

◆ integrate() [7/7]

◆ projectSolution()

◆ raiseOrder()

◆ refine() [1/3]

◆ refine() [2/3]

◆ refine() [3/3]

◆ regularInterpolation()

◆ remapErrors()

◆ scRecovery()

◆ setOutputMaster()

◆ storeMesh()

◆ tesselate()

◆ transferCntrlPtVars() [1/3]
