A struct of data to control the mesh refinement. More...
#include <ASMunstruct.h>
Collaboration diagram for LR::RefineData:
Public Member Functions | |
| RefineData (bool rs=false) | |
| Default constructor. | |
| void | clear () |
| Clears the refinement parameters. | |
Public Attributes | |
| bool | refShare |
| If true, force refinement of shared FE grids. | |
| IntVec | options |
| Parameters used to control the refinement. | |
| IntVec | elements |
| 0-based indices of the elements to refine | |
| RealArray | errors |
| List of error indicators for the elements. | |
| std::vector< IntVec > | MLGN |
| MLGN mapping to use for multipatch. | |
Detailed Description
A struct of data to control the mesh refinement.
The options parameters have the following interpretation:
- options[0] : the beta percentage of elements to refine
- options[1] : the knotline multiplicity (default 1)
- options[2] : the refinement scheme (default 0), see AdaptiveSetup::RefScheme
- options[3] : nonzero if testing for linear independence at all iterations
- options[4] : the maximum number of T-joints allowed in the model
- options[5] : the maximum allowed parametric aspect ratio of an element
- options[6] : one if all "gaps" are to be closed
- options[7] : one if using "true beta"
The documentation for this struct was generated from the following file:
- src/ASM/ASMunstruct.h
