Adaptive solution driver for linear static FEM simulators. More...

#include <AdaptiveSIM.h>

Inheritance diagram for AdaptiveSIM:

[legend]

Collaboration diagram for AdaptiveSIM:

[legend]

Public Member Functions
	AdaptiveSIM (SIMoutput &sim, bool sa=true)
	The constructor initializes default adaptation parameters. More...

virtual	~AdaptiveSIM ()
	Empty destructor.

bool	initAdaptor (size_t normGroup=0)
	Initializes the projs and prefix arrays. More...

bool	solveStep (const char *inputfile, int iStep, bool withRF=false, std::streamsize precision=6)
	Assembles and solves the linear FE equations on current mesh. More...

bool	adaptMesh (int iStep, std::streamsize outPrec=0)
	Refines the current mesh based on the element norms. More...

bool	adaptMesh (int iStep, Vectors &sol, std::streamsize outPrec=0)
	Refines the current mesh based on the element norms. More...

bool	writeGlv (const char *infile, int iStep)
	Writes current mesh and results to the VTF-file. More...

const Vector &	getSolution (size_t idx=0) const
	Accesses the solution of the linear system.

const Vector &	getProjection (size_t idx=0) const
	Accesses the projections.

const Vectors &	getProjections () const
	Access all the projections.

const Matrix &	getEnorm () const
	Access the calculated element-wise norms.

virtual bool	parse (char *keyWord, std::istream &is)
	Parses a data section from an input stream. More...

virtual bool	parse (const tinyxml2::XMLElement *elem)
	Parses a data section from an XML document. More...

virtual bool	preprocessC (const IntVec &ignored, bool fixDup, double time0)
	Performs some pre-processing tasks on the FE model. More...

Public Member Functions inherited from SIMadmin
virtual	~SIMadmin ()
	Empty destructor.

virtual bool	read (const char *fileName)
	Reads model data from the specified input file *fileName.

virtual bool	preprocess (const IntVec &ignored={}, bool fixDup=false)
	Performs some pre-processing tasks on the FE model.

const ProcessAdm &	getProcessAdm () const
	Returns the parallel process administrator.

int	getGlobalProcessID () const
	Returns the global process ID. More...

const std::string &	getHeading () const
	Returns the simulator heading.

void	setHeading (const std::string &heading)
	Defines the simulator heading.

void	printHeading (int &supStep) const
	Prints the heading of this simulator, if any, to IFEM::cout.

Public Member Functions inherited from XMLInputBase
bool	readXML (const char *fileName, bool verbose=true)
	Reads an XML input file. More...

bool	loadXML (const char *xml)
	Loads data from an XML-formatted text string. More...

Public Member Functions inherited from AdaptiveSetup
	AdaptiveSetup (SIMoutput &sim, bool sa=true)
	The constructor initializes default adaptation parameters. More...

virtual	~AdaptiveSetup ()
	Empty destructor.

void	setAdaptationNorm (size_t g, size_t i=0)
	Sets the norm group/index of the norm to base mesh adaptation on.

bool	initPrm (size_t normGroup)
	Initializes the norm group parameters. More...

int	calcRefinement (LR::RefineData &prm, int iStep, const Vectors &gNorm, const Vector &refIn, int currDofs=-1) const
	Calculates mesh refinement control data based on error estimates. More...

bool	parse (char *keyWord, std::istream &is)
	Parses a data section from an input stream. More...

bool	parse (const tinyxml2::XMLElement *elem)
	Parses a data section from an XML document. More...

void	printNorms (const Vectors &gNorm, const Vectors &dNorm, const Matrix &eNorm, size_t w=36, bool printModelNorms=true) const
	Prints out global norms to the log stream. More...

bool	writeMesh (int iStep) const
	Dumps current mesh to external file(s) for inspection. More...

size_t	eIdx () const
	Returns the row-index of the element norm to use for adaptation.

Protected Member Functions
virtual bool	assembleAndSolveSystem ()
	Assembles and solves the linear FE equation system.

virtual bool	savePoints (int iStep) const
	Saves point results to output file for a given refinement step. More...

Protected Member Functions inherited from SIMadmin
	SIMadmin (const char *heading=nullptr)
	The default constructor initializes the process administrator.

	SIMadmin (SIMadmin &anotherSIM)
	Copy constructor.

Protected Member Functions inherited from XMLInputBase
const tinyxml2::XMLElement *	loadFile (tinyxml2::XMLDocument &doc, const char *fileName, bool verbose=false)
	Loads an XML input file into a tinyxml2::XMLDocument object. More...

virtual const char **	getPrioritizedTags () const
	Returns a list of prioritized XML-tags.

Protected Attributes
Vectors	solution
	All solutions (including Galerkin projections)

Protected Attributes inherited from SIMadmin
ProcessAdm	adm
	Parallel administrator.

int	myPid
	Processor ID in parallel simulations.

int	nProc
	Number of processors in parallel simulations.

std::string	myHeading
	Heading written before reading the input file.

Protected Attributes inherited from AdaptiveSetup
SIMoutput &	model
	The isogeometric FE model.

size_t	adaptor
	Norm group to base the mesh adaptation on.

size_t	adNorm
	Which norm to base the mesh adaptation on.

size_t	eRow
	Row-index in eNorm of the norm to use for adaptation.

double	rCond
	Actual reciprocal condition number of the last mesh.

Private Attributes
Vectors	gNorm
	Global norms.

Vectors	dNorm
	Dual global norms.

Matrix	eNorm
	Element norms.

Matrix	fNorm
	Dual element norms.

int	geoBlk
	Running VTF geometry block counter.

int	nBlock
	Running VTF result block counter.

std::vector< Vector >	projs
	Projected secondary solutions.

std::vector< Vector >	projd
	Projected dual solutions.

std::vector< std::string >	prefix
	Norm prefices for VTF-output.

Additional Inherited Members
Public Attributes inherited from SIMadmin
SIMoptions &	opt
	Simulation control parameters.

Static Public Attributes inherited from SIMadmin
static int	msgLevel = 2
	Controls the console output amount during solving.

Protected Types inherited from SIMadmin
using	IntVec = std::vector< int >
	Convenience alias.

Detailed Description

Adaptive solution driver for linear static FEM simulators.

This class contains data and methods for solving linear static FE problems adaptively, based on element error norms as refinement indicators.

Constructor & Destructor Documentation

◆ AdaptiveSIM()

AdaptiveSIM::AdaptiveSIM	(	SIMoutput &	sim,
		bool	sa = `true`
	)

explicit

The constructor initializes default adaptation parameters.

Parameters

	sim	The FE model
[in]	sa	If true, this is a stand-alone driver

References geoBlk, nBlock, and solution.

Member Function Documentation

◆ adaptMesh() [1/2]

bool AdaptiveSIM::adaptMesh	(	int	iStep,
		std::streamsize	outPrec = `0`
	)

Refines the current mesh based on the element norms.

Parameters

[in]	iStep	Refinement step counter
[in]	outPrec	Number of digits after the decimal point in norm print

Referenced by AdaptiveISolver< T1, SolutionTransfer >::adaptMesh().

◆ adaptMesh() [2/2]

bool AdaptiveSIM::adaptMesh	(	int	iStep,
		Vectors &	sol,
		std::streamsize	outPrec = `0`
	)

Refines the current mesh based on the element norms.

Parameters

[in]	iStep	Refinement step counter
	sol	Vectors for solution transfer
[in]	outPrec	Number of digits after the decimal point in norm print

References AdaptiveSetup::calcRefinement(), IFEM::cout, dNorm, utl::matrixBase< T >::empty(), eNorm, AdaptiveSetup::eRow, fNorm, utl::matrix< T >::getRow(), gNorm, AdaptiveSetup::model, utl::LogStream::precision(), AdaptiveSetup::printNorms(), SIMinput::refine(), and AdaptiveSetup::writeMesh().

◆ initAdaptor()

bool AdaptiveSIM::initAdaptor ( size_t normGroup = 0 )

Initializes the projs and prefix arrays.

Parameters

[in] normGroup Index to the norm group to base mesh adaptation on

References SIMoptions::format, SIMbase::haveDualSol(), AdaptiveSetup::initPrm(), AdaptiveSetup::model, SIMadmin::opt, prefix, projd, SIMoptions::project, and projs.

◆ parse() [1/2]

bool AdaptiveSIM::parse	(	char *	keyWord,
		std::istream &	is
	)

virtual

Parses a data section from an input stream.

Parameters

[in]	keyWord	Keyword of current data section to read
	is	The file stream to read from

Reimplemented from SIMadmin.

References AdaptiveSetup::parse().

◆ parse() [2/2]

bool AdaptiveSIM::parse ( const tinyxml2::XMLElement * elem )

virtual

Parses a data section from an XML document.

Parameters

[in] elem The XML element to parse

Reimplemented from SIMadmin.

References AdaptiveSetup::parse().

◆ preprocessC()

bool AdaptiveSIM::preprocessC	(	const IntVec &	ignored,
		bool	fixDup,
		double	time0
	)

virtual

Performs some pre-processing tasks on the FE model.

Parameters

[in]	ignored	Indices of patches to be ignored in the analysis
[in]	fixDup	Merge duplicated FE nodes on patch interfaces?
[in]	time0	Initial time for time-dependent dirichlet conditions

Reimplemented from SIMadmin.

References AdaptiveSetup::model, and SIMbase::preprocessC().

◆ savePoints()

bool AdaptiveSIM::savePoints ( int iStep ) const

protectedvirtual

Saves point results to output file for a given refinement step.

Parameters

[in] iStep Refinement step counter

By default, this method just forwards to the underlying model.

Reimplemented in AdaptiveISolver< T1, SolutionTransfer >.

References AdaptiveSetup::model, SIMoutput::savePoints(), and solution.

Referenced by solveStep().

◆ solveStep()

bool AdaptiveSIM::solveStep	(	const char *	inputfile,
		int	iStep,
		bool	withRF = `false`,
		std::streamsize	precision = `6`
	)

Assembles and solves the linear FE equations on current mesh.

Parameters

[in]	inputfile	File to read model parameters from after refinement
[in]	iStep	Refinement step counter
[in]	withRF	Whether nodal reaction forces should be computed or not
[in]	precision	Number of digits after decimal point

References AdaptiveSetup::adaptor, assembleAndSolveSystem(), utl::matrixBase< T >::clear(), SIMoutput::clearProperties(), utl::matrix< T >::cols(), ProcessAdm::cout, dNorm, SIMoutput::dumpResults(), eNorm, AdaptiveSetup::eRow, fNorm, SIMoptions::format, geoBlk, SIMbase::getNoRHS(), SIMadmin::getProcessAdm(), gNorm, SIMbase::initSystem(), AdaptiveSetup::model, SIMadmin::msgLevel, SIMoptions::nGauss, SIMadmin::opt, SIMadmin::preprocess(), projd, SIMbase::project(), SIMoptions::project, projs, SIMadmin::read(), utl::matrix< T >::rows(), savePoints(), SIMbase::setMode(), SIMbase::setQuadratureRule(), solution, SIMbase::solutionNorms(), SIMoptions::solver, SIMoutput::writeGlvG(), SIMoutput::writeGlvStep(), and AdaptiveSetup::writeMesh().

◆ writeGlv()

bool AdaptiveSIM::writeGlv	(	const char *	infile,
		int	iStep
	)

Writes current mesh and results to the VTF-file.

Parameters

[in]	infile	File name used to construct the VTF-file name from
[in]	iStep	Refinement step counter

References utl::matrixBase< T >::empty(), eNorm, fNorm, SIMoptions::format, geoBlk, AdaptiveSetup::model, nBlock, SIMadmin::opt, prefix, SIMoptions::project, projs, SIMbase::setMode(), solution, SIMoutput::writeGlvBC(), SIMoutput::writeGlvG(), SIMoutput::writeGlvN(), SIMoutput::writeGlvP(), SIMoutput::writeGlvS(), SIMoutput::writeGlvS1(), SIMoutput::writeGlvStep(), and SIMoutput::writeGlvT().

The documentation for this class was generated from the following files:

src/SIM/AdaptiveSIM.h
src/SIM/AdaptiveSIM.C
