Base class for multi-step solution drivers. More...

#include <MultiStepSIM.h>

Inheritance diagram for MultiStepSIM:

[legend]

Collaboration diagram for MultiStepSIM:

[legend]

Public Types
enum	SubIt { ITER = 0 , FIRST = 1 , LAST = 2 , NONE = 3 }
	Enum describing sub-iteration status.

Public Member Functions
virtual void	printProblem (bool stopInputTimer=false) const
	Prints out problem-specific data to the log stream. More...

virtual const char **	getPrioritizedTags () const
	Returns a list of prioritized XML-tags.

virtual bool	parse (const tinyxml2::XMLElement *elem)
	Parses a data section from an XML document. More...

virtual void	initPrm ()
	Initializes time integration parameters for the integrand.

virtual void	initSol (size_t nSol=1, size_t nDof=0)
	Initializes the primary solution vectors. More...

bool	initEqSystem (bool withRF=true, size_t nScl=0)
	Allocates the FE system matrices. More...

virtual bool	advanceStep (TimeStep &param, bool updateTime=true)
	Advances the time/load step one step forward. More...

virtual SIM::ConvStatus	solveStep (TimeStep &param, SIM::SolutionMode=SIM::STATIC, double zero_tolerance=1.0e-8, std::streamsize outPrec=0)=0
	Solves the FE equations at current time/load step. More...

virtual bool	preprocess (const std::vector< int > &ignored, bool fixDup)
	Performs some pre-processing tasks on the FE model. More...

void	setStartGeo (int gID)
	Initializes the geometry block counter.

bool	saveModel (const char *fileName)
	Opens a new VTF-file and writes the model geometry to it. More...

bool	saveModel (int &gBlock, int &rBlock, const char *fileName=nullptr, bool clearG=true)
	Opens a new VTF-file and writes the model geometry to it. More...

bool	saveModel (int &gBlock, int &rBlock, double time)
	Writes the model geometry and BCs to an already opened VTF-file. More...

bool	saveStep (int iStep, double time, const char *vecName=nullptr)
	Saves the converged solution to VTF file of a given time/load step. More...

bool	saveStep (int iStep, int &rBlock, double time, const char *vecName=nullptr)
	Saves the converged solution to VTF file of a given time/load step. More...

bool	saveStep (int iStep, int &rBlock, const char *vecName)
	Saves the converged solution to VTF file of a given time/load step. More...

virtual bool	serialize (SerializeMap &data) const
	Serializes the solution vectors for restarting purposes. More...

virtual bool	deSerialize (const SerializeMap &data)
	Restores the solution vectors from a serialized state. More...

bool	checkForRestart ()
	Restores the solution from a serialized state in case of restart.

void	dumpStep (int iStep, double time, utl::LogStream &os, bool withID=true) const
	Dumps the primary solution for inspection. More...

virtual void	dumpResults (double time, utl::LogStream &os, std::streamsize precision=3, bool formatted=true) const
	Dumps solution variables at user-defined points. More...

bool	hasPointResultFile () const
	Returns whether a points result file has been defined or not.

bool	savePoints (double time, int step) const
	Saves point-wise solution to file for a given time/load step. More...

virtual bool	isLinear () const
	Returns whether this solution driver is linear or not.

virtual bool	isDynamic () const
	Returns whether this is a dynamic solution driver or not.

const SIMoutput &	getModel () const
	Returns a const reference to the FE model.

void	setSubIteration (SubIt flag)
	Updates the sub-iteration flag.

SubIt	getSubIteration () const
	Returns the sub-iteration flag.

virtual size_t	numSolution () const
	Returns the number of solution vectors.

virtual const Vector &	realSolution (int i=0) const
	Returns a const reference to the current real solution vector. More...

virtual const Vectors &	realSolutions (bool=false)
	Returns a const reference to the current real solution vectors. More...

double *	theRefNorm ()
	Returns a pointer to the reference norm variable.

const double *	getRefNorm () const
	Returns a const pointer to the reference norm variable.

virtual bool	parse (char *keyWord, std::istream &is)
	Parses a data section from an input stream.

virtual bool	parse (const tinyxml2::XMLElement *elem)
	Parses a data section from an XML document.

Public Member Functions inherited from SIMsolution
virtual const Vectors &	getSolutions () const
	Returns a const reference to the solution vectors.

virtual Vectors &	theSolutions ()
	Returns a reference to the solution vectors (for assignment).

virtual const Vector &	getSolution (int ix=0) const
	Returns a const reference to current solution vector.

virtual void	setSolution (const RealArray &s, int ix=0)
	Modifies the current solution vector (used by sub-iterations only).

Public Member Functions inherited from SIMadmin
virtual	~SIMadmin ()
	Empty destructor.

virtual bool	read (const char *fileName)
	Reads model data from the specified input file *fileName.

virtual bool	parse (char *keyWord, std::istream &is)
	Parses a data section from an input stream.

virtual bool	preprocessC (const IntVec &, bool, double=0.0)
	Performs some pre-processing tasks on the FE model.

const ProcessAdm &	getProcessAdm () const
	Returns the parallel process administrator.

int	getGlobalProcessID () const
	Returns the global process ID. More...

const std::string &	getHeading () const
	Returns the simulator heading.

void	setHeading (const std::string &heading)
	Defines the simulator heading.

void	printHeading (int &supStep) const
	Prints the heading of this simulator, if any, to IFEM::cout.

Public Member Functions inherited from XMLInputBase
bool	readXML (const char *fileName, bool verbose=true)
	Reads an XML input file. More...

bool	loadXML (const char *xml)
	Loads data from an XML-formatted text string. More...

Protected Types
enum	NormOp { MAX , ALL }
	Enum describing reference norm options.

Protected Types inherited from SIMsolution
using	SerializeMap = std::map< std::string, std::string >
	Convenience type.

Protected Types inherited from SIMadmin
using	IntVec = std::vector< int >
	Convenience alias.

Protected Member Functions
	MultiStepSIM (SIMbase &sim)
	The constructor initializes the FE model reference. More...

void	printStep (const TimeStep &param) const
	Prints out time/load step identification. More...

virtual bool	solutionNorms (const TimeDomain &, double zero_tolerance=1.0e-8, std::streamsize outPrec=0)
	Computes and prints some solution norm quantities. More...

int	getLastSavedStep () const
	Returns the last step that was saved to VTF.

Protected Member Functions inherited from SIMsolution
	SIMsolution ()=default
	The default constructor is protected to allow sub-classes only.

virtual	~SIMsolution ()=default
	Empty default destructor.

void	initSolution (size_t ndof, size_t nsol=1)
	Initializes the solution vectors. More...

void	pushSolution (unsigned short int nVecState=1)
	Pushes the solution vector stack. More...

bool	saveSolution (SerializeMap &data, const std::string &name) const
	Writes current solution to a serialization container. More...

bool	restoreSolution (const SerializeMap &data, const std::string &name)
	Restores the solution from a serialization container. More...

Protected Member Functions inherited from SIMadmin
	SIMadmin (const char *heading=nullptr)
	The default constructor initializes the process administrator.

	SIMadmin (SIMadmin &anotherSIM)
	Copy constructor.

Protected Member Functions inherited from XMLInputBase
const tinyxml2::XMLElement *	loadFile (tinyxml2::XMLDocument &doc, const char *fileName, bool verbose=false)
	Loads an XML input file into a tinyxml2::XMLDocument object. More...

Protected Attributes
SIMoutput &	model
	The isogeometric FE model.

Vector	loadVec
	System load vector (for output to VTF)

Vector	residual
	Residual force vector.

Vector	linsol
	Linear solution vector.

NormOp	refNopt
	Reference norm option.

double	refNorm
	Reference norm value used in convergence checks.

double	rCond
	Reciprocal condition number of the linear equation system.

SubIt	subiter
	Sub-iteration flag.

size_t	nRHSvec
	Number of right-hand-side vectors to assemble.

char	rotUpd
	Option for how to update of nodal rotations.

int	geoBlk
	Running VTF geometry block counter.

int	nBlock
	Running VTF result block counter.

Protected Attributes inherited from SIMsolution
Vectors	solution
	Stack of solution vectors.

Protected Attributes inherited from SIMadmin
ProcessAdm	adm
	Parallel administrator.

int	myPid
	Processor ID in parallel simulations.

int	nProc
	Number of processors in parallel simulations.

std::string	myHeading
	Heading written before reading the input file.

Private Attributes
bool	saveBCs
	If true, Dirchlet boundary conditions are saved to VTF.

int	lastSt
	The last time/load step that was saved to VTF.

Additional Inherited Members
Public Attributes inherited from SIMadmin
SIMoptions &	opt
	Simulation control parameters.

Static Public Attributes inherited from SIMadmin
static int	msgLevel = 2
	Controls the console output amount during solving.

Static Protected Member Functions inherited from SIMsolution
static std::string	serialize (const double *v, size_t n)
	Helper method for serializing a double array into a text string. More...

static void	deSerialize (const std::string &data, double *v, size_t n)
	Helper method for deserializing a double array from a text string. More...

Detailed Description

Base class for multi-step solution drivers.

Constructor & Destructor Documentation

◆ MultiStepSIM()

MultiStepSIM::MultiStepSIM ( SIMbase & sim )

explicitprotected

The constructor initializes the FE model reference.

Parameters

sim	The FE model

References geoBlk, lastSt, SIMadmin::msgLevel, nBlock, nRHSvec, rCond, refNopt, refNorm, rotUpd, saveBCs, and subiter.

Member Function Documentation

◆ advanceStep()

bool MultiStepSIM::advanceStep	(	TimeStep &	param,
		bool	updateTime = `true`
	)

virtual

Advances the time/load step one step forward.

Parameters

	param	Time stepping parameters
[in]	updateTime	If false, the time parameters are not incremented

Reimplemented in NonLinSIM, NewmarkSIM, GenAlphaSIM, and EigenModeSIM.

References TimeStep::increment(), model, rotUpd, TimeStep::step, and SIMbase::updateRotations().

Referenced by EigenModeSIM::advanceStep(), NewmarkSIM::advanceStep(), and NonLinSIM::advanceStep().

◆ deSerialize()

bool MultiStepSIM::deSerialize ( const SerializeMap & data )

virtual

Restores the solution vectors from a serialized state.

Parameters

[in] data Container for serialized data

Reimplemented in NewmarkNLSIM, and HHTSIM.

References SIMsolution::deSerialize(), SIMbase::getName(), model, refNorm, and SIMsolution::restoreSolution().

Referenced by checkForRestart().

◆ dumpResults()

void MultiStepSIM::dumpResults	(	double	time,
		utl::LogStream &	os,
		std::streamsize	precision = `3`,
		bool	formatted = `true`
	)		const

virtual

Dumps solution variables at user-defined points.

Parameters

[in]	time	Current time/load parameter
[in]	os	The output stream to write the solution to
[in]	precision	Number of digits after the decimal point
[in]	formatted	If false, write all result points on a single line

Reimplemented in NewmarkSIM.

References SIMoutput::dumpMoreResults(), SIMoutput::dumpResults(), model, numSolution(), and realSolution().

◆ dumpStep()

void MultiStepSIM::dumpStep	(	int	iStep,
		double	time,
		utl::LogStream &	os,
		bool	withID = `true`
	)		const

Dumps the primary solution for inspection.

Parameters

[in]	iStep	Time/load step identifier
[in]	time	Current time/load parameter
[in]	os	The output stream to write the solution to
[in]	withID	If true, write node ID and coordinates too

References SIMoutput::dumpPrimSol(), model, numSolution(), and realSolution().

◆ initEqSystem()

bool MultiStepSIM::initEqSystem	(	bool	withRF = `true`,
		size_t	nScl = `0`
	)

Allocates the FE system matrices.

Parameters

[in]	withRF	Whether nodal reaction forces should be computed or not
[in]	nScl	Number of global scalar quantities to integrate

References SIMbase::initSystem(), model, nRHSvec, SIMadmin::opt, and SIMoptions::solver.

◆ initSol()

void MultiStepSIM::initSol	(	size_t	nSol = `1`,
		size_t	nDof = `0`
	)

virtual

Initializes the primary solution vectors.

Parameters

[in]	nSol	Number of consecutive solutions stored in core
[in]	nDof	Number of degrees of freedom (solution vector length)

Reimplemented in NewmarkNLSIM, HHTSIM, GenAlphaSIM, and EigenModeSIM.

References SIMbase::getNoDOFs(), SIMbase::getNoSolutions(), SIMsolution::initSolution(), model, and SIMsolution::solution.

Referenced by NonLinSIM::init(), EigenModeSIM::initSol(), GenAlphaSIM::initSol(), HHTSIM::initSol(), NewmarkNLSIM::initSol(), and TimeIntegration::SIMImplicitLMM< Solver >::solveStep().

◆ parse()

bool MultiStepSIM::parse ( const tinyxml2::XMLElement * elem )

virtual

Parses a data section from an XML document.

Parameters

[in] elem The XML element to parse

Reimplemented from SIMadmin.

Reimplemented in NonLinSIM, NewmarkSIM, NewmarkNLSIM, HHTSIM, GenAlphaSIM, and EigenModeSIM.

References saveBCs.

◆ preprocess()

bool MultiStepSIM::preprocess	(	const std::vector< int > &	ignored,
		bool	fixDup
	)

virtual

Performs some pre-processing tasks on the FE model.

Parameters

[in]	ignored	Indices of patches to ignore in the analysis
[in]	fixDup	Merge duplicated FE nodes on patch interfaces?

Reimplemented from SIMadmin.

References model, and SIMadmin::preprocess().

◆ printProblem()

void MultiStepSIM::printProblem ( bool stopInputTimer = false ) const

virtual

Prints out problem-specific data to the log stream.

Parameters

[in] stopInputTimer If true, stop file input timer before print

Reimplemented in NewmarkSIM, NewmarkNLSIM, HHTSIM, and EigenModeSIM.

References model, SIMbase::printProblem(), utl::profiler, and Profiler::stop().

Referenced by EigenModeSIM::printProblem(), and NewmarkSIM::printProblem().

◆ printStep()

void MultiStepSIM::printStep ( const TimeStep & param ) const

protected

Prints out time/load step identification.

Parameters

[in] param Time stepping parameters

References ProcessAdm::cout, TimeDomain::dt, SIMadmin::getProcessAdm(), model, utl::LogStream::precision(), SIMbase::printStep(), TimeStep::step, TimeDomain::t, and TimeStep::time.

Referenced by EigenModeSIM::solveStep(), and NewmarkSIM::solveStep().

◆ realSolution()

virtual const Vector& MultiStepSIM::realSolution ( int i = 0 ) const

inlinevirtual

Returns a const reference to the current real solution vector.

This method is overridden by simulators that work on a different solution space during the response integration than the actual FE space. This method is then supposed to return the expanded solution vector. The default implementation is the same as SIMsolution::getSolution().

References SIMsolution::solution.

Referenced by dumpResults(), NewmarkSIM::dumpResults(), dumpStep(), savePoints(), saveStep(), and solutionNorms().

◆ realSolutions()

virtual const Vectors& MultiStepSIM::realSolutions ( bool = false )

inlinevirtual

Returns a const reference to the current real solution vectors.

This method is overridden by simulators that work on a different solution space during the response integration than the actual FE space. This method is then supposed to return the expanded solution vectors. The default implementation is the same as SIMsolution::theSolutions().

References SIMsolution::solution.

Referenced by NewmarkSIM::solutionNorms().

◆ saveModel() [1/3]

bool MultiStepSIM::saveModel ( const char * fileName )

Opens a new VTF-file and writes the model geometry to it.

Parameters

[in] fileName File name used to construct the VTF-file name from

References geoBlk, and nBlock.

◆ saveModel() [2/3]

bool MultiStepSIM::saveModel	(	int &	gBlock,
		int &	rBlock,
		const char *	fileName = `nullptr`,
		bool	clearG = `true`
	)

Opens a new VTF-file and writes the model geometry to it.

Parameters

	gBlock	Running geometry block counter
	rBlock	Running result block counter
[in]	fileName	File name used to construct the VTF-file name from
[in]	clearG	If true, clear geometry blocks if filename is null

References SIMbase::getNoParamDim(), model, SIMoptions::nViz, SIMadmin::opt, and PROFILE1.

◆ saveModel() [3/3]

bool MultiStepSIM::saveModel	(	int &	gBlock,
		int &	rBlock,
		double	time
	)

Writes the model geometry and BCs to an already opened VTF-file.

Parameters

	gBlock	Running geometry block counter
	rBlock	Running result block counter
[in]	time	Time parameter for evolving grids

References PROFILE1.

◆ savePoints()

bool MultiStepSIM::savePoints	(	double	time,
		int	step
	)		const

Saves point-wise solution to file for a given time/load step.

Parameters

[in]	time	Time/load step parameter
[in]	step	Time/load step counter

References model, numSolution(), realSolution(), and SIMoutput::savePoints().

◆ saveStep() [1/3]

bool MultiStepSIM::saveStep	(	int	iStep,
		double	time,
		const char *	vecName = `nullptr`
	)

Saves the converged solution to VTF file of a given time/load step.

Parameters

[in]	iStep	Time/load step identifier
[in]	time	Current time/load parameter
[in]	vecName	Optional name of primary solution vector field

References SIMoptions::discretization, geoBlk, SIMbase::getNoDOFs(), lastSt, loadVec, model, nBlock, numSolution(), SIMoptions::nViz, SIMadmin::opt, PROFILE1, SIMoptions::pSolOnly, residual, SIMoptions::saveTrac, SIMbase::setMode(), utl::vector< T >::size(), SIMoutput::writeGlvA(), SIMoutput::writeGlvS(), SIMoutput::writeGlvStep(), SIMoutput::writeGlvT(), and SIMoutput::writeGlvV().

Referenced by saveStep().

◆ saveStep() [2/3]

bool MultiStepSIM::saveStep	(	int	iStep,
		int &	rBlock,
		const char *	vecName
	)

Saves the converged solution to VTF file of a given time/load step.

Parameters

[in]	iStep	Time/load step identifier
	rBlock	Running result block counter
[in]	vecName	Name of primary solution vector field

This method only writes the primary solution vector as a vector field. It is mainly used when this simulator is a component in a coupled simulation, and where the secondary solution is of minor interest.

References model, numSolution(), realSolution(), and SIMoutput::writeGlvV().

◆ saveStep() [3/3]

bool MultiStepSIM::saveStep	(	int	iStep,
		int &	rBlock,
		double	time,
		const char *	vecName = `nullptr`
	)

Saves the converged solution to VTF file of a given time/load step.

Parameters

[in]	iStep	Time/load step identifier
	rBlock	Running result block counter
[in]	time	Current time/load parameter
[in]	vecName	Optional name of primary solution vector field

Use this method when other simulators write results to the same VTF-file. The internal result block counter nBlock is syncronized with the argument rBlock before the results of this simulator are written, to avoid that multiple result blocks receive the same result block ID.

References nBlock, and saveStep().

◆ serialize()

bool MultiStepSIM::serialize ( SerializeMap & data ) const

virtual

Serializes the solution vectors for restarting purposes.

Parameters

data	Container for serialized data

Reimplemented in NewmarkNLSIM, and HHTSIM.

References SIMbase::getName(), model, refNorm, SIMsolution::saveSolution(), and SIMsolution::serialize().

◆ solutionNorms()

bool MultiStepSIM::solutionNorms	(	const TimeDomain &	,
		double	zero_tolerance = `1.0e-8`,
		std::streamsize	outPrec = `0`
	)

protectedvirtual

Computes and prints some solution norm quantities.

Parameters

[in]	zero_tolerance	Truncate norm values smaller than this to zero
[in]	outPrec	Number of digits after the decimal point in norm print

Reimplemented in NewmarkSIM.

References model, numSolution(), SIMbase::printSolutionSummary(), realSolution(), and utl::zero_print_tol.

Referenced by NonLinSIM::solveIteration(), and EigenModeSIM::solveStep().

◆ solveStep()

virtual SIM::ConvStatus MultiStepSIM::solveStep	(	TimeStep &	param,
		SIM::SolutionMode	= `SIM::STATIC`,
		double	zero_tolerance = `1.0e-8`,
		std::streamsize	outPrec = `0`
	)

pure virtual

Solves the FE equations at current time/load step.

Parameters

	param	Time stepping parameters
[in]	zero_tolerance	Truncate norm values smaller than this to zero
[in]	outPrec	Number of digits after the decimal point in norm print

Implemented in NewmarkSIM, EigenModeSIM, and NonLinSIM.

The documentation for this class was generated from the following files:

src/SIM/MultiStepSIM.h
src/SIM/MultiStepSIM.C

Public Types

Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Private Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ MultiStepSIM()

Member Function Documentation

◆ advanceStep()

◆ deSerialize()

◆ dumpResults()

◆ dumpStep()

◆ initEqSystem()

◆ initSol()

◆ parse()

◆ preprocess()

◆ printProblem()

◆ printStep()

◆ realSolution()

◆ realSolutions()

◆ saveModel() [1/3]

◆ saveModel() [2/3]

◆ saveModel() [3/3]

◆ savePoints()

◆ saveStep() [1/3]

◆ saveStep() [2/3]

◆ saveStep() [3/3]

◆ serialize()

◆ solutionNorms()

◆ solveStep()
