SIMsolution Class Reference

Solution vector container with serialization support. More...

#include <SIMsolution.h>

Inheritance diagram for SIMsolution:

Collaboration diagram for SIMsolution:

Public Member Functions
virtual const Vectors &	getSolutions () const
	Returns a const reference to the solution vectors.
virtual Vectors &	theSolutions ()
	Returns a reference to the solution vectors (for assignment).
virtual const Vector &	getSolution (int ix=0) const
	Returns a const reference to current solution vector.
virtual void	setSolution (const RealArray &s, int ix=0)
	Modifies the current solution vector (used by sub-iterations only).

Protected Types
using	SerializeMap = std::map< std::string, std::string >
	Convenience type.

Protected Member Functions
	SIMsolution ()=default
	The default constructor is protected to allow sub-classes only.
virtual	~SIMsolution ()=default
	Empty default destructor.
void	initSolution (size_t ndof, size_t nsol=1)
	Initializes the solution vectors. More...
void	pushSolution (unsigned short int nVecState=1)
	Pushes the solution vector stack. More...
bool	saveSolution (SerializeMap &data, const std::string &name) const
	Writes current solution to a serialization container. More...
bool	restoreSolution (const SerializeMap &data, const std::string &name)
	Restores the solution from a serialization container. More...

Static Protected Member Functions
static std::string	serialize (const double *v, size_t n)
	Helper method for serializing a double array into a text string. More...
static void	deSerialize (const std::string &data, double *v, size_t n)
	Helper method for deserializing a double array from a text string. More...

Protected Attributes
Vectors	solution
	Stack of solution vectors.

Detailed Description

Solution vector container with serialization support.

Member Function Documentation

deSerialize()

void SIMsolution::deSerialize ( const std::string &  data, double *  v, size_t  n  )

staticprotected

Helper method for deserializing a double array from a text string.

Parameters

[in]	data	The serialized string
[out]	v	Pointer to double array (assumed allocated outside)
[in]	n	Length of array

Referenced by HHTSIM::deSerialize(), MultiStepSIM::deSerialize(), and NewmarkNLSIM::deSerialize().

initSolution()

void SIMsolution::initSolution ( size_t  ndof, size_t  nsol = 1  )

protected

Initializes the solution vectors.

Parameters

[in]	ndof	Number of degrees of freedom
[in]	nsol	Number of solution vectors

References solution.

Referenced by MultiStepSIM::initSol().

pushSolution()

void SIMsolution::pushSolution ( unsigned short int  nVecState = 1 )

protected

Pushes the solution vector stack.

Parameters

[in]

nVecState

Number of vectors per state

References solution.

Referenced by EigenModeSIM::advanceStep(), NewmarkSIM::advanceStep(), and NonLinSIM::advanceStep().

restoreSolution()

bool SIMsolution::restoreSolution ( const SerializeMap &  data, const std::string &  name  )

protected

Restores the solution from a serialization container.

Parameters

[in]	data	Container for serialized data
[in]	name	Name of simulator the solution belongs to

References theSolutions().

Referenced by HHTSIM::deSerialize(), MultiStepSIM::deSerialize(), and NewmarkNLSIM::deSerialize().

saveSolution()

bool SIMsolution::saveSolution ( SerializeMap &  data, const std::string &  name  ) const

protected

Writes current solution to a serialization container.

Parameters

	data	Container for serialized data
[in]	name	Name of simulator the solution belongs to

References getSolutions().

Referenced by HHTSIM::serialize(), MultiStepSIM::serialize(), and NewmarkNLSIM::serialize().

serialize()

std::string SIMsolution::serialize ( const double *  v, size_t  n  )

staticprotected

Helper method for serializing a double array into a text string.

Parameters

[in]	v	Pointer to double array
[in]	n	Length of array

Returns

The serialized string

Referenced by HHTSIM::serialize(), MultiStepSIM::serialize(), and NewmarkNLSIM::serialize().

---

The documentation for this class was generated from the following files:

• src/SIM/SIMsolution.h
• src/SIM/SIMsolution.C
