Class containing domain decomposition related partitioning. More...

#include <DomainDecomposition.h>

Collaboration diagram for DomainDecomposition:

[legend]

Classes
struct	BlockInfo
	Struct with information per matrix block. More...

class	OrientIterator
	Iterator for matching nodes on edges/faces with a given orientation and index. More...

class	SlaveOrder
	Functor to order ghost connections. More...

Public Member Functions
	DomainDecomposition ()
	Default constructor.

bool	setup (const ProcessAdm &adm, const SIMbase &sim)
	Setup domain decomposition. More...

bool	setup (const ProcessAdm &adm, const IntMat &neighs, const IntMat &meqn)
	Setup domain decomposition. More...

void	setup (const int neq)
	Setup single-process domain decomposition. More...

std::vector< std::set< int > >	getSubdomains (int nx, int ny, int nz, int overlap, size_t block) const
	Obtain local subdomains for an equation block. More...

int	getMinEq (size_t idx=0) const
	Get first equation owned by this process.

int	getMaxEq (size_t idx=0) const
	Get last equation owned by this process.

int	getNoGlbEqs (size_t idx=0) const
	Get total number of equations in a block.

int	getMinNode () const
	Get first node owned by this process.

int	getMaxNode () const
	Get last node owned by this process.

int	getMinDOF () const
	Get first DOF owned by this process.

int	getMaxDOF () const
	Get last DOF owned by this process.

void	setPatchOwner (size_t p, size_t owner)
	Set owner for a patch.

int	getPatchOwner (size_t p) const
	Get process owning patch p.

int	getGlobalEq (int lEq, size_t idx=0) const
	Get global equation number. More...

const IntVec &	getMLGEQ (size_t idx=0) const
	Obtain local-to-global equation mapping.

const std::set< int > &	getBlockEqs (size_t idx) const
	Obtain local-to-global equation mapping. More...

const std::map< int, int > &	getG2LEQ (size_t idx) const
	Obtain global-to-local equation mapping. More...

const IntVec &	getMLGN () const
	Obtain local-to-global node mapping.

const SAMpatch *	getSAM () const
	Returns associated SAM.

size_t	getNoBlocks () const
	Returns number of matrix blocks.

bool	isPartitioned () const
	Returns whether a graph based partition is used.

const IntVec &	getElms () const
	Returns elements in partition.

void	setElms (const IntVec &elms, const std::string &save)
	Set elements in partition.

void	clear ()
	Clear out partitioning information.

Static Public Member Functions
static IntMat	calcSubdomains (size_t nel1, size_t nel2, size_t nel3, size_t g1, size_t g2, size_t g3, size_t overlap)
	Calculates subdomains with a given overlap. More...

Public Attributes
std::set< ASM::Interface, SlaveOrder >	ghostConnections
	Connections to other processes.

Private Member Functions
bool	calcGlobalNodeNumbers (const ProcessAdm &adm, const SIMbase &sim)
	Calculate the global node numbers for given finite element model.

bool	calcGlobalEqNumbers (const ProcessAdm &adm, const SIMbase &sim)
	Calculate the global equation numbers for an element model.

template<class Callback >
bool	calcGlobalEqNumbersPart (const ProcessAdm &adm, const Callback &cb)
	Calculate the global equation numbers for a partitioned model.

bool	sanityCheckCorners (const SIMbase &sim)
	Sanity check model. More...

bool	graphPartition (const ProcessAdm &adm, const IntMat &neigh)
	Setup domain decomposition based on graph partitioning.

Static Private Member Functions
static IntMat	calcSubdomains1D (size_t nel1, size_t g1, size_t overlap)
	Calculates a 1D partitioning with a given overlap. More...

static IntMat	calcSubdomains2D (size_t nel1, size_t nel2, size_t g1, size_t g2, size_t overlap)
	Calculates 2D subdomains with a given overlap. More...

static IntMat	calcSubdomains3D (size_t nel1, size_t nel2, size_t nel3, size_t g1, size_t g2, size_t g3, size_t overlap)
	Calculates 3D subdomains with a given overlap. More...

Private Attributes
std::map< int, int >	patchOwner
	Process that owns a particular patch.

IntVec	MLGN
	Process-local-to-global node numbers.

std::vector< BlockInfo >	blocks
	Equation mappings for all matrix blocks.

IntVec	myElms
	Elements in partition.

int	minDof = 0
	First DOF we own.

int	maxDof = 0
	Last DOF we own.

int	minNode = 0
	First node we own.

int	maxNode = 0
	Last node we own.

const SAMpatch *	sam = nullptr
	The assembly handler the DD is constructed for.

std::string	savePart
	Non-empty to save partitioning to file.

Detailed Description

Class containing domain decomposition related partitioning.

Member Function Documentation

◆ calcSubdomains()

IntMat DomainDecomposition::calcSubdomains	(	size_t	nel1,
		size_t	nel2,
		size_t	nel3,
		size_t	g1,
		size_t	g2,
		size_t	g3,
		size_t	overlap
	)

static

Calculates subdomains with a given overlap.

Parameters

[in]	nel1	Number of knot-spans in first parameter direction.
[in]	nel2	Number of knot-spans in second parameter direction.
[in]	nel3	Number of knot-spans in third parameter direction.
[in]	g1	Number of subdomains in first parameter direction.
[in]	g2	Number of subdomains in second parameter direction.
[in]	g3	Number of subdomains in third parameter direction.
[in]	overlap	Overlap of subdomains.

nel values determine the dimensionality.

References calcSubdomains1D(), calcSubdomains2D(), and calcSubdomains3D().

Referenced by getSubdomains().

◆ calcSubdomains1D()

IntMat DomainDecomposition::calcSubdomains1D	(	size_t	nel1,
		size_t	g1,
		size_t	overlap
	)

staticprivate

Calculates a 1D partitioning with a given overlap.

Parameters

[in]	nel1	Number of knot-spans in first parameter direction.
[in]	g1	Number of subdomains in first parameter direction.
[in]	overlap	Overlap of subdomains.

Referenced by calcSubdomains().

◆ calcSubdomains2D()

IntMat DomainDecomposition::calcSubdomains2D	(	size_t	nel1,
		size_t	nel2,
		size_t	g1,
		size_t	g2,
		size_t	overlap
	)

staticprivate

Calculates 2D subdomains with a given overlap.

Parameters

[in]	nel1	Number of knot-spans in first parameter direction.
[in]	nel2	Number of knot-spans in second parameter direction.
[in]	g1	Number of subdomains in first parameter direction.
[in]	g2	Number of subdomains in second parameter direction.
[in]	overlap	Overlap of subdomains.

Referenced by calcSubdomains().

◆ calcSubdomains3D()

IntMat DomainDecomposition::calcSubdomains3D	(	size_t	nel1,
		size_t	nel2,
		size_t	nel3,
		size_t	g1,
		size_t	g2,
		size_t	g3,
		size_t	overlap
	)

staticprivate

Calculates 3D subdomains with a given overlap.

Parameters

[in]	nel1	Number of knot-spans in first parameter direction.
[in]	nel2	Number of knot-spans in second parameter direction.
[in]	nel3	Number of knot-spans in third parameter direction.
[in]	g1	Number of subdomains in first parameter direction.
[in]	g2	Number of subdomains in second parameter direction.
[in]	g3	Number of subdomains in third parameter direction.
[in]	overlap	Overlap of subdomains.

Referenced by calcSubdomains().

◆ getBlockEqs()

const std::set<int>& DomainDecomposition::getBlockEqs ( size_t idx ) const

inline

Obtain local-to-global equation mapping.

Parameters

idx	Block equation index (global block not included).

References blocks.

Referenced by ISTL::BlockPreconditioner::apply(), ISTL::BlockPreconditioner::BlockPreconditioner(), calcGlobalEqNumbers(), PETScMatrix::initAssembly(), ISTL::BlockPreconditioner::post(), ISTL::BlockPreconditioner::pre(), and PETScMatrix::setParameters().

◆ getG2LEQ()

const std::map<int,int>& DomainDecomposition::getG2LEQ ( size_t idx ) const

inline

Obtain global-to-local equation mapping.

Parameters

idx	Block equation index

References blocks.

Referenced by _eig_ax(), ISTL::BlockPreconditioner::BlockPreconditioner(), eig_sol_(), SAMpatchPETSc::expandSolution(), PETScMatrix::setupGlb2Blk(), and PETScMatrix::solveEig().

◆ getGlobalEq()

int DomainDecomposition::getGlobalEq	(	int	lEq,
		size_t	idx = `0`
	)		const

Get global equation number.

Parameters

lEq	Local equation number
idx	Block to get index for

References blocks.

Referenced by _eig_ax(), PETScMatrix::add(), PETScVectors::assemble(), eig_sol_(), PETScVector::endAssembly(), PETScMatrix::initAssembly(), PETScSolParams::setupAdditiveSchwarz(), PETScMatrix::setupGlb2Blk(), and ISTLSolParams::setupPC().

◆ getSubdomains()

std::vector< std::set< int > > DomainDecomposition::getSubdomains	(	int	nx,
		int	ny,
		int	nz,
		int	overlap,
		size_t	block
	)		const

Obtain local subdomains for an equation block.

Parameters

nx	Number of domains in x
ny	Number of domains in y
nz	Number of domains in z
overlap	Overlap
block	Block to obtain equations for

Returns: Vector with equations on each subdomain

References blocks, calcSubdomains(), SAM::getElmEqns(), SAM::getElmNodes(), getNoBlocks(), SAM::getNodeEqns(), SAM::getNodeType(), ASMstruct::getNoStructElms(), and getSAM().

Referenced by PETScSolParams::setupAdditiveSchwarz(), and ISTLSolParams::setupPCInternal().

◆ sanityCheckCorners()

bool DomainDecomposition::sanityCheckCorners ( const SIMbase & sim )

private

Sanity check model.

Collects the corners of all patches in the model and make sure nodes with matching coordinates have the same global node ID.

References ProcessAdm::dd, ASMbase::getCoord(), ASM2D::getCorner(), ASM3D::getCorner(), SIMbase::getLocalPatchIndex(), getMLGN(), ASMbase::getNoBasis(), ASMbase::getNodeID(), SIMbase::getNoPatches(), ProcessAdm::getNoProcs(), ASMbase::getNoSpaceDim(), SIMbase::getNoSpaceDim(), SIMbase::getPatch(), getPatchOwner(), SIMadmin::getProcessAdm(), and ProcessAdm::isParallel().

Referenced by setup().

◆ setup() [1/3]

void DomainDecomposition::setup ( const int neq )

Setup single-process domain decomposition.

neq Number of equations

References blocks.

◆ setup() [2/3]

bool DomainDecomposition::setup	(	const ProcessAdm &	adm,
		const IntMat &	neighs,
		const IntMat &	meqn
	)

Setup domain decomposition.

Parameters

[in]	adm	Process administrator to setup dd across
[in]	neighs	Element connection graph for model
[in]	meqn	Matrix of element equation numbers

References blocks, calcGlobalEqNumbersPart(), IFEM::cout, getMaxEq(), getMinEq(), ProcessAdm::getNoProcs(), ProcessAdm::getProcId(), graphPartition(), and ProcessAdm::isParallel().

◆ setup() [3/3]

bool DomainDecomposition::setup	(	const ProcessAdm &	adm,
		const SIMbase &	sim
	)

Setup domain decomposition.

Parameters

[in]	adm	Process administrator to setup dd across
[in]	sim	Simulator with model to partition

References LinSolParams::BlockParams::basis, blocks, calcGlobalEqNumbers(), calcGlobalEqNumbersPart(), calcGlobalNodeNumbers(), LinSolParams::BlockParams::comps, IFEM::cout, ProcessAdm::dd, ASMbase::generateThreadGroupsFromElms(), LinSolParams::getBlock(), utl::getDigits(), SIMbase::getElmConnectivities(), SAM::getEquation(), SAM::getEquations(), SIMbase::getFEModel(), ASMbase::getLMType(), getMaxEq(), getMaxNode(), getMinEq(), getMinNode(), LinSolParams::getNoBlocks(), ASMbase::getNodeID(), ProcessAdm::getNoProcs(), SIMbase::getPatch(), ProcessAdm::getProcId(), getSAM(), SIMbase::getSAM(), SIMbase::getSolParams(), ghostConnections, graphPartition(), ASMbase::isLMn(), ProcessAdm::isParallel(), myElms, sam, and sanityCheckCorners().

Referenced by SIMbase::merge(), and SIMbase::preprocessC().

The documentation for this class was generated from the following files:

src/ASM/DomainDecomposition.h
src/ASM/DomainDecomposition.C
