PETScVectors Class Reference

Class for representing a set of system vectors in PETSc format. More...

#include <PETScMatrix.h>

Inheritance diagram for PETScVectors:

Collaboration diagram for PETScVectors:

Public Member Functions
	PETScVectors (const PETScMatrix &A, int nvec)
	Constructor creating a set of system vectors. More...
	~PETScVectors ()
	Destructor frees up the dynamically allocated vectors.
LinAlg::MatrixType	getType () const override
	Returns the vector type.
SystemVector *	copy () const override
	Creates a copy of the system vector and returns a pointer to it.
size_t	dim () const override
	Returns the dimension of the system vector.
void	redim (size_t) override
	Sets the dimension of the system vector.
Real *	getPtr () override
	Access through pointer.
const Real *	getRef () const override
	Reference through pointer.
const Vector &	vec () const override
	Reference to underlying utl::vector.
void	init (Real) override
	Initializes the vector to a given scalar value.
void	mult (Real) override
	Multiplication with a scalar.
void	add (const SystemVector &, Real) override
	Addition of another system vector to this one.
Real	L1norm () const override
	L1-norm of the vector.
Real	L2norm () const override
	L2-norm of the vector.
Real	Linfnorm () const override
	Linfinity-norm of the vector.
void	assemble (const Vectors &vecs, const IntVec &meqn, int=0) override
	Adds element vectors into the system vector. More...
Vec	get (size_t idx)
	Returns a particular vector. More...
size_t	size () const
	Returns number of vectors.
Public Member Functions inherited from SystemVector
virtual	~SystemVector ()
	Empty destructor.
virtual void	resize (size_t n, bool=false)
	Resizes the vector to length n.
bool	empty () const
	Checks if the vector is empty.
SystemVector &	copy (const SystemVector &x)
	Copies entries from input vector x into *this.
virtual bool	endAssembly ()
	Finalizes the system vector assembly.
virtual void	dump (std::ostream &, LinAlg::StorageFormat, const char *=nullptr) const
	Dumps the system vector on a specified format.

Private Attributes
size_t	myDim
	Global dimension of vectors.
std::vector< Vec >	vectors
	Array of vectors.
const PETScMatrix &	myA
	Reference to matrix vectors are associated with.

Additional Inherited Members
Static Public Member Functions inherited from SystemVector
static SystemVector *	create (const ProcessAdm *adm, LinAlg::MatrixType vtype)
	Static method creating a vector of the given type.
Protected Member Functions inherited from SystemVector
	SystemVector ()
	The default constructor is protected to allow sub-classes only.
virtual std::ostream &	write (std::ostream &os) const
	Writes the system vector to the given output stream.

Detailed Description

Class for representing a set of system vectors in PETSc format.

Used for solving systems with multiple RHS vectors.

Constructor & Destructor Documentation

PETScVectors()

PETScVectors::PETScVectors	(	const PETScMatrix &	A,
		int	nvec
	)

Constructor creating a set of system vectors.

Parameters

A	Matrix with vector layout to use
nvec	Number of RHS vectors

References PETScMatrix::getMatrix(), myDim, size(), and vectors.

Member Function Documentation

assemble()

void PETScVectors::assemble ( const Vectors &  vecs, const IntVec &  meqn, int  = 0  )

overridevirtual

Adds element vectors into the system vector.

Parameters

[in]	vecs	The element vectors
[in]	meqn	Matrix of element equation numbers (0 based)

Implements SystemVector.

References PETScMatrix::getDD(), DomainDecomposition::getGlobalEq(), myA, and vectors.

get()

Vec PETScVectors::get ( size_t  idx )

inline

Returns a particular vector.

Parameters

idx	Index of vector to return

References vectors.

Referenced by PETScMatrix::solveMultipleRhs().

---

The documentation for this class was generated from the following files:

• src/LinAlg/PETScMatrix.h
• src/LinAlg/PETScMatrix.C
