EigSolver.C File Reference

Interface to LAPack and ARPack eigenvalue solvers. More...

#include "EigSolver.h"
#include "DenseMatrix.h"
#include "SPRMatrix.h"
#include "Profiler.h"
#include "IFEM.h"

Include dependency graph for EigSolver.C:

Namespaces
	eig
	Top-level functions for invoking eigenproblem solvers.

Functions
void	eig_drv1_ (const int &n, const int &nev, const int &ncv, double *d, double *v, double *work, int &ierr)
	Driver to solve a standard eigenvalue problem. More...
void	eig_drv2_ (const int &n, const int &nev, const int &ncv, const double &sig, double *d, double *v, double *work, int &ierr)
	Driver to solve a standard eigenvalue problem. More...
void	eig_drv3_ (const int &n, const int &nev, const int &ncv, double *d, double *v, double *work, int &ierr)
	Driver to solve a generalized eigenvalue problem. More...
void	eig_drv4_ (const int &n, const int &nev, const int &ncv, const double &sig, double *d, double *v, double *work, int &ierr)
	Driver to solve a generalized eigenvalue problem. More...
void	eig_drv5_ (const int &n, const int &nev, const int &ncv, const double &sig, double *d, double *v, double *work, int &ierr)
	Driver to solve a generalized eigenvalue problem. More...
void	eig_drv6_ (const int &n, const int &nev, const int &ncv, const double &sig, double *d, double *v, double *work, int &ierr)
	Driver to solve a generalized eigenvalue problem. More...
static void	_eig_ax (const SystemMatrix *A, const double *x, double *y)
	Performs the matrix-vector multiplication y = A * x.
void	eig_av_ (const double *x, double *y)
	Performs the matrix-vector multiplication y = K * x.
void	eig_mv_ (const double *x, double *y)
	Performs the matrix-vector multiplication y = M * x.
void	eig_sol_ (const double *x, double *y, int &ierr)
	Solves the linear system of equations AM y = x. More...

Variables
static SystemMatrix *	K = nullptr
	Pointer to coefficient matrix A.
static SystemMatrix *	M = nullptr
	Pointer to coefficient matrix B.
static SystemMatrix *	AM = nullptr
	Pointer to the matrix to invert.
static int	iverb = -1
	Arnoldi iteration counter (for verbose print)

Detailed Description

Interface to LAPack and ARPack eigenvalue solvers.

Date

Apr 20 2009

Author

Knut Morten Okstad / SINTEF

Function Documentation

eig_drv1_()

void eig_drv1_	(	const int &	n,
		const int &	nev,
		const int &	ncv,
		double *	d,
		double *	v,
		double *	work,
		int &	ierr
	)

Driver to solve a standard eigenvalue problem.

The regular mode is used. This is a FORTRAN 77 subroutine based on the example driver DSDRV1 from the ARPACK distribution.

See also

ARPACK documentation.

Referenced by eig::solve().

eig_drv2_()

void eig_drv2_	(	const int &	n,
		const int &	nev,
		const int &	ncv,
		const double &	sig,
		double *	d,
		double *	v,
		double *	work,
		int &	ierr
	)

Driver to solve a standard eigenvalue problem.

The shift-and-invert mode is used. This is a FORTRAN 77 subroutine based on the example driver DSDRV2 from the ARPACK distribution.

See also

ARPACK documentation.

Referenced by eig::solve().

eig_drv3_()

void eig_drv3_	(	const int &	n,
		const int &	nev,
		const int &	ncv,
		double *	d,
		double *	v,
		double *	work,
		int &	ierr
	)

Driver to solve a generalized eigenvalue problem.

The inverse mode is used. This is a FORTRAN 77 subroutine based on the example driver DSDRV3 from the ARPACK distribution.

See also

ARPACK documentation.

Referenced by eig::solve().

eig_drv4_()

void eig_drv4_	(	const int &	n,
		const int &	nev,
		const int &	ncv,
		const double &	sig,
		double *	d,
		double *	v,
		double *	work,
		int &	ierr
	)

Driver to solve a generalized eigenvalue problem.

The shift-and-invert mode is used. This is a FORTRAN 77 subroutine based on the example driver DSDRV4 from the ARPACK distribution.

See also

ARPACK documentation.

Referenced by eig::solve().

eig_drv5_()

void eig_drv5_	(	const int &	n,
		const int &	nev,
		const int &	ncv,
		const double &	sig,
		double *	d,
		double *	v,
		double *	work,
		int &	ierr
	)

Driver to solve a generalized eigenvalue problem.

The buckling mode is used. This is a FORTRAN 77 subroutine based on the example driver DSDRV5 from the ARPACK distribution.

See also

ARPACK documentation.

Referenced by eig::solve().

eig_drv6_()

void eig_drv6_	(	const int &	n,
		const int &	nev,
		const int &	ncv,
		const double &	sig,
		double *	d,
		double *	v,
		double *	work,
		int &	ierr
	)

Driver to solve a generalized eigenvalue problem.

The Cayley mode is used. This is a FORTRAN 77 subroutine based on the example driver DSDRV6 from the ARPACK distribution.

See also

ARPACK documentation.

Referenced by eig::solve().

eig_sol_()

void eig_sol_	(	const double *	x,
		double *	y,
		int &	ierr
	)

Solves the linear system of equations AM y = x.

The matrix AM depends on the eigensolver method.

References AM, IFEM::cout, StdVector::dim(), SystemMatrix::dim(), PETScMatrix::dim(), PETScMatrix::getAdm(), PETScMatrix::getDD(), DomainDecomposition::getG2LEQ(), DomainDecomposition::getGlobalEq(), PETScMatrix::getMatrix(), PETScVector::getVector(), ProcessAdm::isParallel(), DomainDecomposition::isPartitioned(), iverb, PROFILE1, utl::vector< T >::ptr(), and SystemMatrix::solve().
