This is a sub-class of SAMpatch with support for parallel processing. More...

#include <SAMpatchPETSc.h>

Inheritance diagram for SAMpatchPETSc:

Collaboration diagram for SAMpatchPETSc:

[legend]

Public Member Functions
	SAMpatchPETSc (const std::map< int, int > &g2ln, const ProcessAdm &padm)
	The constructor initializes the l2gn array. More...

virtual	~SAMpatchPETSc ()
	The destructor destroys the index set arrays.

virtual Real	dot (const Vector &x, const Vector &y, char dofType='D') const
	Computes the dot-product of two vectors. More...

virtual Real	normL2 (const Vector &x, char dofType='D') const
	Computes the L2-norm of a vector. More...

virtual Real	normInf (const Vector &x, size_t &comp, char dofType='D') const
	Computes the inf-norm of a vector. More...

virtual bool	expandSolution (const SystemVector &solVec, Vector &dofVec, Real scaleSD) const
	Expands a solution vector from equation-ordering to DOF-ordering. More...

Public Member Functions inherited from SAMpatch
	SAMpatch ()
	Empty default constructor.

virtual	~SAMpatch ()
	Empty destructor.

bool	init (const std::vector< ASMbase * > &patches, int numNod, const std::vector< char > &dTypes)
	Allocates the dynamic arrays and populates them with data. More...

bool	updateConstraintEqs (const Vector *prevSol=nullptr)
	Updates the multi-point constraint array TTCC. More...

std::vector< ASMbase * >::const_iterator	begin () const
	Returns the start iterator of the patch container.

std::vector< ASMbase * >::const_iterator	end () const
	Returns the end iterator of the patch container.

size_t	getNoPatches () const
	Returns the number of patches in model.

virtual bool	merge (const SAM other, const std::map< int, int > old2new)
	Merges the assembly data from another SIM with this.

Public Member Functions inherited from SAM
	SAM ()
	The constructor initializes an empty object.

virtual	~SAM ()
	The destructor frees the dynamically allocated arrays.

void	print (std::ostream &os) const
	Prints out the key data to the given stream.

template<class T >
void	printVector (T &os, const RealArray &vec, const char *heading=nullptr) const
	Prints out a nodal DOF vector to the given stream.

int	getNoElms () const
	Returns the number of elements in the model.

int	getNoNodes (char dofType='A') const
	Returns the number of FE nodes in the model. More...

int	getNoDOFs () const
	Returns the total number of DOFs in the model.

int	getNoSpecifiedDOFs () const
	Returns the number of specified DOFs in the model.

int	getNoConstraints () const
	Returns the total number of constraint equations in the model.

int	getNoEquations () const
	Returns the number of equations (free DOFs) in the model.

IntSet	getEquations (char dType, int dof=0) const
	Returns the equations numbers for a given DOF type. More...

const int *	getMADOF () const
	Returns the Matrix of Accumulated DOFs.

const int *	getMEQN () const
	Returns the Matrix of EQuation Numbers.

void	getDofCouplings (IntVec &irow, IntVec &jcol) const
	Computes the sparse structure (DOF couplings) in the system matrix. More...

void	getDofCouplings (std::vector< IntSet > &dofc) const
	Finds the set of free DOFs coupled to each free DOF.

bool	assembleSystem (SystemMatrix &sysK, SystemVector &sysRHS, const Matrix &eK, int iel=0, RealArray *reactionForces=nullptr) const
	Adds an element stiffness matrix into the system stiffness matrix. More...

bool	assembleSystem (SystemMatrix &sysM, const Matrix &eM, int iel=0) const
	Adds an element matrix into the corresponding system matrix. More...

bool	assembleSystem (SystemVector &sysRHS, const Matrix &eK, int iel=0, RealArray *reactionForces=nullptr) const
	Adds element stiffness contributions to the system load vector. More...

bool	assembleSystem (SystemVector &sysRHS, const RealArray &eS, int iel=0, RealArray *reactionForces=nullptr) const
	Adds an element load vector into the system load vector. More...

bool	assembleSystem (SystemVector &sysRHS, const Real nS, int inod=0, RealArray reactionForces=nullptr) const
	Adds a node load vector into the system load vector. More...

bool	assembleSystem (SystemVector &sysRHS, Real S, const std::pair< int, int > &dof) const
	Adds a node load vector into the system load vector. More...

void	addToRHS (SystemVector &sysRHS, const RealArray &S) const
	Adds a global load vector into the system load vector. More...

bool	getElmNodes (IntVec &mnpc, int iel) const
	Finds the matrix of nodal point correspondance for an element. More...

bool	getElmEqns (IntVec &meen, int iel, size_t nedof=0) const
	Finds the matrix of equation numbers for an element. More...

void	getUniqueEqns (IntSet &meen, int iel) const
	Finds the set of unique equation numbers for an element. More...

bool	getNodeEqns (IntVec &mnen, int inod) const
	Finds the matrix of equation numbers for a node. More...

char	getNodeType (int inod) const
	Returns the DOF classification of a given node. More...

std::pair< int, int >	getNodeDOFs (int inod) const
	Returns the first and last DOFs for a node. More...

std::pair< int, int >	getNodeAndLocalDof (int idof, bool eqno=false) const
	Returns the internal node number and local index for a global DOF. More...

int	getEquation (int inod, int ldof) const
	Finds the equation number corresponding to a local nodal DOF. More...

Real	getDofVal (const RealArray &dofVec, int inod, int ldof) const
	Returns specified solution component from a global solution vector. More...

bool	expandVector (const Vector &solVec, Vector &dofVec) const
	Expands a solution vector from equation-ordering to DOF-ordering. More...

bool	getSolVec (RealArray &solVec, const RealArray &dofVec) const
	Extracts equation-ordered solution vector from DOF-ordered vector. More...

bool	applyDirichlet (Vector &dofVec) const
	Applies the non-homogenous Dirichlet BCs to the given vector. More...

Real	norm2 (const Vector &x, char dofType='D') const
	Computes the l2-norm of a vector of length NDOF. More...

virtual Real	normReact (const RealArray &u, const RealArray &rf) const
	Computes the energy norm contributions from nodal reaction forces. More...

Real	getReaction (int dir, const RealArray &rf, const IntVec *nodes=nullptr) const
	Returns the total reaction force in the given coordinate direction. More...

bool	haveReaction (int dir, const IntVec *nodes=nullptr) const
	Checks for total reaction force in the given coordinate direction. More...

bool	getNodalReactions (int inod, const RealArray &rf, RealArray &nrf) const
	Returns a vector of reaction forces for a given node. More...

Private Attributes
int	nProc
	Number of processes.

IntVec	ghostNodes
	Indices for the ghost nodes.

IntVec	l2gn
	Local-to-global node numbers for this processor.

const ProcessAdm &	adm
	Parallel process administrator.

Additional Inherited Members
Protected Member Functions inherited from SAMpatch
bool	initNodeDofs (const std::vector< char > &dTypes)
	Initializes the nodal arrays MINEX, MADOF and MSC.

bool	initElementConn ()
	Initializes the element topology arrays MPMNPC and MMNPC.

bool	initConstraintEqs ()
	Initializes the multi-point constraint arrays MPMCEQ, MMCEQ and TTCC.

Protected Member Functions inherited from SAM
bool	initSystemEquations ()
	Initializes the DOF-to-equation connectivity array MEQN.

void	assembleRHS (Real *RHS, Real value, int ieq) const
	Adds a scalar value into a system right hand-side vector. More...

void	assembleReactions (RealArray &rf, const RealArray &eS, int iel) const
	Assembles reaction forces for the fixed and prescribed DOFs. More...

bool	expandVector (const Real *solVec, Vector &dofVec, Real scaleSD) const
	Expands a solution vector from equation-ordering to DOF-ordering. More...

void	printStatusCodes (std::ostream &os) const
	Prints out the DOF status codes to the given stream.

void	printCEQ (std::ostream &os, int iceq) const
	Prints out a constraint equation to the given stream.

void	printMEQN (std::ostream &os) const
	Prints out the equation number mapping to the given stream.

Protected Attributes inherited from SAM
int &	nnod
	Number of nodes.

int &	nel
	Number of elements.

int &	ndof
	Number of DOFs.

int &	nspdof
	Number of specified DOFs.

int &	nceq
	Number of constraint equations.

int &	neq
	Number of system equations.

int &	nmmnpc
	Number of elements in MMNPC.

int &	nmmceq
	Number of elements in MMCEQ.

int *	mpmnpc
	Matrix of pointers to MNPCs in MMNPC.

int *	mmnpc
	Matrix of matrices of nodal point correspondances.

int *	madof
	Matrix of accumulated DOFs.

int *	msc
	Matrix of status codes.

int *	mpmceq
	Matrix of pointers to MCEQs in MMCEQ.

int *	mmceq
	Matrix of matrices of constraint equation definitions.

Real *	ttcc
	Table of tables of constraint equation coefficients.

int *	minex
	Matrix of internal to external node numbers.

int *	meqn
	Matrix of equation numbers.

std::vector< char >	nodeType
	Nodal DOF classification.

std::vector< char >	dof_type
	Individual DOF classification.

Detailed Description

This is a sub-class of SAMpatch with support for parallel processing.

Constructor & Destructor Documentation

◆ SAMpatchPETSc()

SAMpatchPETSc::SAMpatchPETSc	(	const std::map< int, int > &	g2ln,
		const ProcessAdm &	padm
	)

The constructor initializes the l2gn array.

Parameters

[in]	g2ln	Global-to-local node numbers for this processor
[in]	padm	Parallel process administrator

References adm, ProcessAdm::getNoProcs(), LinAlgInit::increfs(), and nProc.

Member Function Documentation

◆ dot()

Real SAMpatchPETSc::dot	(	const Vector &	x,
		const Vector &	y,
		char	dofType = `'D'`
	)		const

virtual

Computes the dot-product of two vectors.

Parameters

[in]	x	First vector in dot-product
[in]	y	Second vector in dot-product
[in]	dofType	Only consider DOFs of this type

Returns: Value of dot-product

Both vectors are defined over all nodes in the patch, i.e. for parallel vectors the ghost entries are also included.

Reimplemented from SAM.

References adm, ProcessAdm::dd, SAM::dot(), ProcessAdm::isParallel(), DomainDecomposition::isPartitioned(), utl::vector< T >::ptr(), and utl::vector< T >::size().

◆ expandSolution()

bool SAMpatchPETSc::expandSolution	(	const SystemVector &	solVec,
		Vector &	dofVec,
		Real	scaleSD
	)		const

virtual

Expands a solution vector from equation-ordering to DOF-ordering.

Parameters

[in]	solVec	Solution vector, length = NEQ
[out]	dofVec	Degrees of freedom vector, length = NDOF
[in]	scaleSD	Scaling factor for specified (slave) DOFs

Returns: false if the length of solVec is invalid, otherwise true

The size of the solution vector that comes out of the linear equation solver equals the number of free DOFs in the system (=NEQ). That is, all fixed or constrained (slave) DOFs are not present. Before we can compute derived element quantities we therefore need to extract the resulting solution values also for the constrained DOFs.

Reimplemented from SAM.

References adm, ProcessAdm::dd, StdVector::dim(), SAM::expandSolution(), DomainDecomposition::getG2LEQ(), DomainDecomposition::getMLGEQ(), StdVector::getPtr(), PETScVector::getVector(), ProcessAdm::isParallel(), and DomainDecomposition::isPartitioned().

◆ normInf()

Real SAMpatchPETSc::normInf	(	const Vector &	x,
		size_t &	comp,
		char	dofType = `'D'`
	)		const

virtual

Computes the inf-norm of a vector.

Parameters

[in]	x	Vector for norm computation
	comp	Local nodal DOF on input, index of the largest value on output
[in]	dofType	Only consider DOFs of this type

Returns: Value of inf-norm

The vector is defined over all nodes in the patch, i.e. for parallel vectors the ghost entries are also included.

Reimplemented from SAM.

References adm, ProcessAdm::dd, ProcessAdm::isParallel(), DomainDecomposition::isPartitioned(), SAM::normInf(), and Real.

◆ normL2()

Real SAMpatchPETSc::normL2	(	const Vector &	x,
		char	dofType = `'D'`
	)		const

virtual

Computes the L2-norm of a vector.

Parameters

[in]	x	Vector for norm computation
[in]	dofType	Only consider DOFs of this type

Returns: Value of L2-norm

The vector is defined over all nodes in the patch, i.e. for parallel vectors the ghost entries are also included.

Reimplemented from SAM.

References adm, ProcessAdm::dd, ProcessAdm::isParallel(), DomainDecomposition::isPartitioned(), SAM::normL2(), utl::vector< T >::ptr(), and utl::vector< T >::size().

The documentation for this class was generated from the following files:

src/ASM/SAMpatchPETSc.h
src/ASM/SAMpatchPETSc.C

Public Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ SAMpatchPETSc()

Member Function Documentation

◆ dot()

◆ expandSolution()

◆ normInf()

◆ normL2()
