AnaSol Class Reference

Class for analytical solution fields (primary and secondary solution). More...

#include <AnaSol.h>

Collaboration diagram for AnaSol:

Public Member Functions
	AnaSol (RealFunc *s1=nullptr, VecFunc *s2=nullptr, VecFunc *v1=nullptr, TensorFunc *v2=nullptr, STensorFunc *v3=nullptr)
	Default constructor initializing all solution fields. More...
	AnaSol (RealFunc *s, STensorFunc *sigma)
	Constructor initializing the primary and secondary solution fields. More...
	AnaSol (VecFunc *v, STensorFunc *sigma)
	Constructor initializing the primary and secondary solution fields. More...
	AnaSol (STensorFunc *sigma)
	Constructor initializing the symmetric stress tensor field only. More...
	AnaSol (std::istream &is, const int nlines, bool scalarSol=true)
	Constructor initializing expression functions by parsing a stream. More...
	AnaSol (const tinyxml2::XMLElement *elem, bool scalarSol=true)
	Constructor initializing expression functions by parsing XML tags. More...
	AnaSol (const AnaSol &)=delete
	No copying of this class.
virtual	~AnaSol ()
	The destructor frees the analytical solution fields.
char	hasScalarSol () const
	Checks whether a scalar solution is defined.
char	hasVectorSol () const
	Checks whether a vector solution is defined.
RealFunc *	getScalarSol (size_t idx=0) const
	Returns the scalar solution, if any.
VecFunc *	getScalarSecSol (size_t idx=0) const
	Returns the secondary scalar solution, if any.
VecFunc *	getVectorSol () const
	Returns the vector solution, if any.
TensorFunc *	getVectorSecSol () const
	Returns the secondary vector solution, if any.
STensorFunc *	getStressSol () const
	Returns the stress solution, if any.
void	initPatch (size_t pIdx)
	Sets the patch to use.
virtual void	setupSecondarySolutions ()
	Make sure we have a secondary solution. More...

Protected Attributes
bool	symmetric = false
	True to use symmetric secondary solution.
std::vector< RealFunc * >	scalSol
	Primary scalar solution fields.
std::vector< VecFunc * >	scalSecSol
	Secondary scalar solution fields.
VecFunc *	vecSol
	Primary vector solution field.
TensorFunc *	vecSecSol
	Secondary solution field (vector gradient field)
STensorFunc *	stressSol
	Secondary solution field (stress field)

Private Member Functions
template<class Scalar >
void	parseExpressionFunctions (const tinyxml2::XMLElement *elem, bool scalarSol)
	Parses expression functions from XML definition.
void	parseFieldFunctions (const tinyxml2::XMLElement *elem, bool scalarSol)
	Parses field functions from XML definition.

Detailed Description

Class for analytical solution fields (primary and secondary solution).

Constructor & Destructor Documentation

AnaSol() [1/6]

AnaSol::AnaSol ( RealFunc *  s1 = nullptr, VecFunc *  s2 = nullptr, VecFunc *  v1 = nullptr, TensorFunc *  v2 = nullptr, STensorFunc *  v3 = nullptr  )

explicit

Default constructor initializing all solution fields.

Parameters

[in]	s1	Primary scalar solution field
[in]	s2	Secondary solution field, gradient
[in]	v1	Primary vector solution field
[in]	v2	Secondary solution field, gradient
[in]	v3	Secondary solution field, symmetric stress tensor

It is assumed that all the arguments are pointers to dynamically allocated objects, as the class destructor will attempt to delete them.

References scalSecSol, and scalSol.

AnaSol() [2/6]

AnaSol::AnaSol	(	RealFunc *	s,
		STensorFunc *	sigma
	)

Constructor initializing the primary and secondary solution fields.

Parameters

[in]	s	Primary scalar solution field
[in]	sigma	Symmetric stress tensor field

References scalSol.

AnaSol() [3/6]

AnaSol::AnaSol ( VecFunc *  v, STensorFunc *  sigma  )

inline

Constructor initializing the primary and secondary solution fields.

Parameters

[in]	v	Primary vector solution field
[in]	sigma	Symmetric stress tensor field

AnaSol() [4/6]

AnaSol::AnaSol ( STensorFunc *  sigma )

inlineexplicit

Constructor initializing the symmetric stress tensor field only.

Parameters

[in]

sigma

Symmetric stress tensor field

AnaSol() [5/6]

AnaSol::AnaSol	(	std::istream &	is,
		const int	nlines,
		bool	scalarSol = true
	)

Constructor initializing expression functions by parsing a stream.

Parameters

	is	The file stream to read function definition from
[in]	nlines	Number of lines to read
[in]	scalarSol	If true, the primary solution is a scalar field

References IFEM::cout, utl::readLine(), scalSecSol, scalSol, stressSol, vecSecSol, and vecSol.

AnaSol() [6/6]

AnaSol::AnaSol ( const tinyxml2::XMLElement *  elem, bool  scalarSol = true  )

explicit

Constructor initializing expression functions by parsing XML tags.

Parameters

[in]	elem	Pointer to XML-element to extract data from
[in]	scalarSol	If true, the primary solution is a scalar field

References utl::getAttribute(), parseFieldFunctions(), and symmetric.

Member Function Documentation

setupSecondarySolutions()

void AnaSol::setupSecondarySolutions ( )

virtual

Make sure we have a secondary solution.

If none is given, we use derivation (automatic or finite difference) to obtain one.

References scalSecSol, scalSol, stressSol, symmetric, vecSecSol, and vecSol.

Referenced by SIMbase::preprocessC().

---

The documentation for this class was generated from the following files:

• src/Utility/AnaSol.h
• src/Utility/AnaSol.C
