Class for storage of general algebraic system of equations. More...

#include <AlgEqSystem.h>

Inheritance diagram for AlgEqSystem:

Collaboration diagram for AlgEqSystem:

[legend]

Classes
struct	SysMatrixPair
	Struct defining a coefficient matrix and an associated RHS-vector. More...

Public Member Functions
	AlgEqSystem (const SAM &s, const ProcessAdm *a=nullptr)
	The constructor sets its reference to SAM and ProcessAdm objects.

	AlgEqSystem (const AlgEqSystem &a)
	Copy constructor.

virtual	~AlgEqSystem ()
	The destructor frees the dynamically allocated objects.

AlgEqSystem &	operator= (const AlgEqSystem &s)
	Assignment operator.

AlgEqSystem &	copy (const AlgEqSystem &that)
	Makes this a copy of that*.

AlgEqSystem &	add (const AlgEqSystem &that)
	Adds that to *this (assuming similar structure).

bool	init (LinAlg::MatrixType mtype, const LinSolParams *spar=nullptr, size_t nmat=1, size_t nvec=1, size_t nscl=0, bool reactions=false, int num_threads_SLU=1, bool forcePreAss=false)
	Allocates the system matrices of the specified format. More...

void	clear ()
	Erases the system matrices and frees dynamically allocated storage.

bool	setAssociatedVector (size_t imat, size_t ivec)
	Associates a system vector to a system matrix. More...

virtual void	initialize (char initLHS)
	Initializes the system matrices to zero. More...

virtual bool	finalize (bool newLHS)
	Finalizes the system matrices after element assembly. More...

virtual bool	assemble (const LocalIntegral *elmObj, int elmId)
	Adds a set of element matrices into the algebraic equation system. More...

size_t	getNoRHS () const
	Returns the number of right-hand-side vectors allocated.

const SAM &	getSAM () const
	Returns a const reference to the SAM object.

SystemMatrix *	getMatrix (size_t i=0)
	Returns the i'th matrix of the equation system.

SystemVector *	getVector (size_t i=0)
	Returns the i'th right-hand-side vector of the equation system.

double	getScalar (size_t i=0)
	Returns the i'th scalar quantity.

void	addScalar (double s, size_t i=0)
	Adds the value s to the i'th scalar quantity.

const std::vector< double > &	getScalars () const
	Returns a const reference to the assembled scalars.

const std::vector< double > *	getReactions () const
	Returns a pointer to the nodal reaction forces, if any.

bool	staticCondensation (Matrix &Ared, Vector &bred, const std::vector< int > &extNodes, size_t imat=0, const char *recmatFile=nullptr) const
	Performs static condensation of the indicated equation system. More...

bool	recoverInternals (const Matrix &Rmat, const std::vector< int > &extNodes, const Vector &xe, Vector &xFull) const
	Performs recovery of internal DOF values from the external DOFs. More...

Public Member Functions inherited from GlobalIntegral
	GlobalIntegral ()
	The default constructor.

virtual	~GlobalIntegral ()
	Empty destructor.

virtual bool	threadSafe () const
	Returns true if all elements can be assembled in parallel.

virtual bool	haveContributions (size_t, const std::vector< Property > &) const
	Returns false if no contributions from a specified patch.

Static Public Member Functions
static bool	readRecoveryMatrix (Matrix &Rmat, const char *recmatFile)
	Reads the recovery matrix from file. More...

Private Attributes
std::vector< SysMatrixPair >	A
	The actual coefficient matrices.

std::vector< SystemVector * >	b
	The actual right-hand-side vectors.

std::vector< double >	c
	Global scalar quantities.

std::vector< double > *	d
	Multithreading buffer for the scalar values.

std::vector< double >	R
	Nodal reaction forces.

const SAM &	sam
	Data for FE assembly management.

const ProcessAdm *	adm
	Parallel process administrator.

Detailed Description

Class for storage of general algebraic system of equations.

Member Function Documentation

◆ assemble()

bool AlgEqSystem::assemble	(	const LocalIntegral *	elmObj,
		int	elmId
	)

virtual

Adds a set of element matrices into the algebraic equation system.

Parameters

[in]	elmObj	Pointer to the element matrices to add into *this
[in]	elmId	Global number of the element associated with *elmObj

Reimplemented from GlobalIntegral.

References A, ElmMats::A, SAM::assembleSystem(), b, ElmMats::b, c, ElmMats::c, d, ElmMats::empty(), ElmMats::getNewtonMatrix(), ElmMats::getRHSVector(), ElmMats::printMat(), ElmMats::printScl(), ElmMats::printVec(), R, ElmMats::rhsOnly, sam, and ElmMats::withLHS.

Referenced by SIMmodal::assembleModalSystem().

◆ finalize()

bool AlgEqSystem::finalize ( bool newLHS )

virtual

Finalizes the system matrices after element assembly.

Parameters

[in] newLHS If false, only right-hand-side vectors was assembled

Reimplemented from GlobalIntegral.

References A, b, c, d, SAM::expandSolution(), SAM::printVector(), and sam.

Referenced by SIMmodal::assembleModalSystem(), and SIMbase::assembleSystem().

◆ init()

bool AlgEqSystem::init	(	LinAlg::MatrixType	mtype,
		const LinSolParams *	spar = `nullptr`,
		size_t	nmat = `1`,
		size_t	nvec = `1`,
		size_t	nscl = `0`,
		bool	reactions = `false`,
		int	num_threads_SLU = `1`,
		bool	forcePreAss = `false`
	)

Allocates the system matrices of the specified format.

Parameters

[in]	mtype	The matrix format to use for all matrices
[in]	spar	Input parameters for the linear equation solver
[in]	nmat	Number of system matrices to allocate
[in]	nvec	Number of system vectors to allocate
[in]	nscl	Number of scalar quantities to allocate
[in]	reactions	If false, no reaction forces will be computed
[in]	num_threads_SLU	Number of threads for SuperLU_MT
[in]	forcePreAss	If true, force preassembly for sparse matrices

References A, adm, b, c, SystemMatrix::create(), SystemVector::create(), SAM::getNoEquations(), SAM::getNoSpecifiedDOFs(), PROFILE, R, and sam.

Referenced by SIMmodal::assembleModalSystem(), and SIMbase::initSystem().

◆ initialize()

void AlgEqSystem::initialize ( char initLHS )

virtual

Initializes the system matrices to zero.

Parameters

[in] initLHS If false, only initialize right-hand-side vectors

Reimplemented from GlobalIntegral.

References A, b, c, d, and R.

Referenced by SIMmodal::assembleModalSystem(), and SIMbase::assembleSystem().

◆ readRecoveryMatrix()

bool AlgEqSystem::readRecoveryMatrix	(	Matrix &	Rmat,
		const char *	recmatFile
	)

static

Reads the recovery matrix from file.

Parameters

[out]	Rmat	The recovery matrix, xi = Rmat*xe
[in]	recmatFile	Name of recovery matrix file

References c, utl::matrixBase< T >::ptr(), and utl::matrix< T >::resize().

◆ recoverInternals()

bool AlgEqSystem::recoverInternals	(	const Matrix &	Rmat,
		const std::vector< int > &	extNodes,
		const Vector &	xe,
		Vector &	xFull
	)		const

Performs recovery of internal DOF values from the external DOFs.

Parameters

[in]	Rmat	Recovery matrix
[in]	extNodes	List of external nodes whose DOFs were retained
[in]	xe	External DOF values
[out]	xFull	Expanded solution vector with all DOFs

References SAM::expandVector(), SAM::getNodeEqns(), SAM::getNoEquations(), utl::matrix< T >::multiply(), sam, and utl::vector< T >::size().

◆ setAssociatedVector()

bool AlgEqSystem::setAssociatedVector	(	size_t	imat,
		size_t	ivec
	)

Associates a system vector to a system matrix.

Parameters

[in]	imat	Index of a coefficient matrix
[in]	ivec	Index of the system vector to associate with the matrix

The purpose of this method is to define which right-hand-side vector (if any) should receive contributions when assembling a coefficient matrix, when the system to be assembled has explicit constraint equations for which the dependent DOFs have been eliminated.

References A, and b.

Referenced by SIMbase::setAssociatedRHS().

◆ staticCondensation()

bool AlgEqSystem::staticCondensation	(	Matrix &	Ared,
		Vector &	bred,
		const std::vector< int > &	extNodes,
		size_t	imat = `0`,
		const char *	recmatFile = `nullptr`
	)		const

Performs static condensation of the indicated equation system.

Parameters

[out]	Ared	Reduced System matrix
[out]	bred	Associated reduced right-hand-side vector
[in]	extNodes	List of external nodes whose DOFs to retain
[in]	imat	Index of the system matrix-vector pair to condensate
[in]	recmatFile	Name of recovery matrix file

References A, IFEM::cout, utl::matrix< T >::fillColumn(), SAM::getNodeEqns(), utl::vector< T >::ptr(), utl::matrix< T >::resize(), SparseMatrix::rows(), sam, eig::solve(), and SparseMatrix::split().

The documentation for this class was generated from the following files:

src/ASM/AlgEqSystem.h
src/ASM/AlgEqSystem.C
