ElmMats Class Reference

Class collecting the element matrices associated with a FEM problem. More...

#include <ElmMats.h>

Inheritance diagram for ElmMats:

Collaboration diagram for ElmMats:

Public Member Functions
	ElmMats (bool lhs=true)
	Default constructor.
virtual	~ElmMats ()
	Empty destructor.
void	resize (size_t nA, size_t nB, size_t nC=0)
	Defines the number of element matrices and vectors. More...
void	redim (size_t ndim)
	Sets the dimension of the element matrices and vectors. More...
virtual bool	empty () const
	Checks if the element matrices are empty.
virtual void	setStepSize (double, int)
	Updates the time step size.
virtual const Matrix &	getNewtonMatrix () const
	Returns the element-level Newton matrix.
virtual const Vector &	getRHSVector () const
	Returns the element-level right-hand-side vector.
void	printMat (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const
	Prints element matrix idx to output stream os.
void	printVec (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const
	Prints element vector idx to output stream os.
void	printScl (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const
	Prints element scalar idx to output stream os.
Public Member Functions inherited from LocalIntegral
virtual	~LocalIntegral ()
	Empty destructor.
virtual void	destruct ()
	Virtual destruction method to clean up after numerical integration.
virtual const LocalIntegral *	ref () const
	Returns the LocalIntegral object to assemble into the global one.
void	getSolution (size_t nsd, size_t nen, Matrix *u=nullptr, Matrix *v=nullptr, Matrix *a=nullptr, bool forceCurrent=false) const
	Extracts element solution vectors as nsd by nen matrices. More...

Public Attributes
std::vector< Matrix >	A
	The element coefficient matrices.
std::vector< Vector >	b
	The element right-hand-side vectors.
std::vector< double >	c
	The scalar quantities.
std::vector< const char * >	Aname
	Matrix names (for debug print)
std::vector< const char * >	Bname
	Vector names (for debug print)
std::vector< const char * >	Cname
	Scalar names (for debug print)
bool	rhsOnly
	If true, only the right-hand-sides are assembled.
bool	withLHS
	If true, left-hand-side element matrices are present.
Public Attributes inherited from LocalIntegral
Vectors	vec
	Element-level primary solution vectors.

Additional Inherited Members
Protected Member Functions inherited from LocalIntegral
	LocalIntegral ()
	The default constructor is protected to allow sub-classes only.

Detailed Description

Class collecting the element matrices associated with a FEM problem.

The class is derived from LocalIntegral such that it may be passed as argument to the Integrand::evalInt and Integrand::evalBou methods.

The class has two virtual methods returning the Newton matrix and the associated right-hand-side vector, which can be reimplemented by sub-classes to implement different time-integration schemes, mixed formulations, etc. The default versions use the first element matrix as the Newton matrix, and the first element vector as the associated right-hand-side vector.

Member Function Documentation

redim()

void ElmMats::redim

(

size_t

ndim

)

Sets the dimension of the element matrices and vectors.

Parameters

[in]

ndim

Number of rows and columns in the matrices/vectors

References A, and b.

Referenced by SIMmodal::assembleModalSystem(), IntegrandBase::getLocalIntegral(), and L2Mats::L2Mats().

resize()

void ElmMats::resize	(	size_t	nA,
		size_t	nB,
		size_t	nC = 0
	)

Defines the number of element matrices and vectors.

Parameters

[in]	nA	Number of element matrices
[in]	nB	Number of element vectors
[in]	nC	Number of scalar quantities

References A, b, and c.

Referenced by SIMmodal::assembleModalSystem(), IntegrandBase::getLocalIntegral(), L2Mats::L2Mats(), and ASMsupel::read().

---

The documentation for this class was generated from the following files:

• src/ASM/ElmMats.h
• src/ASM/ElmMats.C
