Local integral container class for L2-projections. More...
Inheritance diagram for L2Mats:
Collaboration diagram for L2Mats:
Public Member Functions | |
| L2Mats (GlbL2 &p, size_t nen, size_t nf, LocalIntegral *q=nullptr) | |
| The constructor initializes pointers and references. More... | |
| virtual | ~L2Mats () |
| Empty destructor. | |
| virtual void | destruct () |
| Destruction method to clean up after numerical integration. | |
 Public Member Functions inherited from ElmMats | |
| ElmMats (bool lhs=true) | |
| Default constructor. | |
| virtual | ~ElmMats () |
| Empty destructor. | |
| void | resize (size_t nA, size_t nB, size_t nC=0) |
| Defines the number of element matrices and vectors. More... | |
| void | redim (size_t ndim) |
| Sets the dimension of the element matrices and vectors. More... | |
| virtual bool | empty () const |
| Checks if the element matrices are empty. | |
| virtual void | setStepSize (double, int) |
| Updates the time step size. | |
| virtual const Matrix & | getNewtonMatrix () const |
| Returns the element-level Newton matrix. | |
| virtual const Vector & | getRHSVector () const |
| Returns the element-level right-hand-side vector. | |
| void | printMat (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const |
| Prints element matrix idx to output stream os. | |
| void | printVec (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const |
| Prints element vector idx to output stream os. | |
| void | printScl (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const |
| Prints element scalar idx to output stream os. | |
| Public Member Functions inherited from LocalIntegral | |
| virtual | ~LocalIntegral () |
| Empty destructor. | |
| virtual const LocalIntegral * | ref () const |
| Returns the LocalIntegral object to assemble into the global one. | |
| void | getSolution (size_t nsd, size_t nen, Matrix *u=nullptr, Matrix *v=nullptr, Matrix *a=nullptr, bool forceCurrent=false) const |
| Extracts element solution vectors as nsd by nen matrices. More... | |
Public Attributes | |
| GlbL2 & | gl2Int |
| The global L2-projection integrand. | |
| LocalIntegral * | elmData |
| Element data associated with problem integrand. | |
| IntVec | mnpc |
| Matrix of element nodal correspondance. | |
| uIntVec | elem_sizes |
| Size of each basis on the element. | |
| uIntVec | basis_sizes |
| Size of each basis on the patch. | |
| Public Attributes inherited from ElmMats | |
| std::vector< Matrix > | A |
| The element coefficient matrices. | |
| std::vector< Vector > | b |
| The element right-hand-side vectors. | |
| std::vector< double > | c |
| The scalar quantities. | |
| std::vector< const char * > | Aname |
| Matrix names (for debug print) | |
| std::vector< const char * > | Bname |
| Vector names (for debug print) | |
| std::vector< const char * > | Cname |
| Scalar names (for debug print) | |
| bool | rhsOnly |
| If true, only the right-hand-sides are assembled. | |
| bool | withLHS |
| If true, left-hand-side element matrices are present. | |
| Public Attributes inherited from LocalIntegral | |
| Vectors | vec |
| Element-level primary solution vectors. | |
Additional Inherited Members | |
| Protected Member Functions inherited from LocalIntegral | |
| LocalIntegral () | |
| The default constructor is protected to allow sub-classes only. | |
Detailed Description
Local integral container class for L2-projections.
Constructor & Destructor Documentation
◆ L2Mats()
|
inline |
The constructor initializes pointers and references.
- Parameters
-
[in] p The global L2 integrand object containing projection matrices [in] nen Number of element nodes [in] nf Number of field components [in] q Pointer to element data associated with the problem integrand
References ElmMats::redim(), and ElmMats::resize().
The documentation for this class was generated from the following file:
- src/ASM/GlbL2projector.C
