General integrand for L2-projection of secondary solutions. More...

#include <GlbL2projector.h>

Inheritance diagram for GlbL2:

Collaboration diagram for GlbL2:

[legend]

Public Member Functions
	GlbL2 (IntegrandBase *p, size_t n)
	The constructor initializes the projection matrices. More...

	GlbL2 (FunctionBase *f, size_t n)
	Alternative constructor for projection of an explicit function. More...

	GlbL2 (const FunctionVec &f, size_t n)
	Alternative constructor for projection of explicit functions. More...

virtual	~GlbL2 ()
	The destructor frees the system matrix and system vector.

virtual SIM::SolutionMode	getMode (bool) const
	Returns current solution mode.

virtual int	getIntegrandType () const
	Defines which FE quantities are needed by the integrand.

virtual LocalIntegral *	getLocalIntegral (size_t nen, size_t iEl, bool neumann) const
	Returns a local integral contribution object for the given element. More...

virtual bool	initElement (const IntVec &MNPC, const FiniteElement &fe, const Vec3 &X0, size_t nPt, LocalIntegral &elmInt)
	Initializes current element for numerical integration. More...

virtual bool	initElement (const IntVec &MNPC1, const MxFiniteElement &fe, const uIntVec &elem_sizes, const uIntVec &basis_sizes, LocalIntegral &elmInt)
	Initializes current element for numerical integration (mixed). More...

virtual bool	initElement (const IntVec &MNPC1, const uIntVec &elem_sizes, const uIntVec &basis_sizes, LocalIntegral &elmInt)
	Dummy implementation.

virtual bool	initElement (const IntVec &, LocalIntegral &)
	Dummy implementation.

virtual bool	initElementBou (const IntVec &, LocalIntegral &)
	Dummy implementation.

virtual bool	initElementBou (const IntVec &, const uIntVec &, const uIntVec &, LocalIntegral &)
	Dummy implementation.

virtual bool	evalInt (LocalIntegral &elmInt, const FiniteElement &fe, const Vec3 &X) const
	Evaluates the integrand at an interior point. More...

virtual bool	evalIntMx (LocalIntegral &elmInt, const MxFiniteElement &fe, const Vec3 &X) const
	Evaluates the integrand at an interior point. More...

void	preAssemble (const std::vector< IntVec > &MMNPC, size_t nel)
	Pre-computes the sparsity pattern of the projection matrix A. More...

bool	solve (Matrix &sField)
	Solves the projection equation system and evaluates nodal values. More...

bool	solve (const std::vector< Matrix * > &sField)
	Solves the projection equation system and evaluates nodal values. More...

virtual LocalIntegral *	getLocalIntegral (size_t nen, size_t iEl, bool neumann=false) const=0
	Returns a local integral contribution object for the given element. More...

virtual LocalIntegral *	getLocalIntegral (const std::vector< size_t > &nen, size_t iEl, bool neumann=false) const
	Returns a local integral contribution object for the given element. More...

virtual bool	evalInt (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time, const Vec3 &X) const
	Evaluates the integrand at an interior point. More...

virtual bool	evalInt (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time, const Vec3 &X, const Vec3 &normal) const
	Evaluates the integrand at an element interface point. More...

virtual bool	evalInt (LocalIntegral &, const FiniteElement &fe, const Vec3 &) const
	Evaluates the integrand at interior points for stationary problems.

virtual bool	evalInt (LocalIntegral &, const FiniteElement &fe, const Vec3 &, const Vec3 &) const
	Evaluates the integrand at interface points, stationary problems.

virtual bool	evalIntMx (LocalIntegral &elmInt, const MxFiniteElement &fe, const TimeDomain &time, const Vec3 &X) const
	Evaluates the integrand at an interior point. More...

virtual bool	evalIntMx (LocalIntegral &elmInt, const MxFiniteElement &fe, const TimeDomain &time, const Vec3 &X, const Vec3 &normal) const
	Evaluates the integrand at an element interface point. More...

virtual bool	evalIntMx (LocalIntegral &, const MxFiniteElement &fe, const Vec3 &) const
	Evaluates the integrand at interior points for stationary problems.

virtual bool	evalIntMx (LocalIntegral &, const MxFiniteElement &fe, const Vec3 &, const Vec3 &) const
	Evaluates the integrand at interface points, stationary problems.

Public Member Functions inherited from Integrand
virtual	~Integrand ()
	Empty destructor.

virtual void	setNeumannOrder (char)
	Defines the Neumann order that is the subject of integration. More...

virtual void	initPatch (size_t)
	Define the index of the patch being processed.

virtual LocalIntegral *	getLocalIntegral (const std::vector< size_t > &nen, size_t iEl, bool neumann=false) const
	Returns a local integral contribution object for the given element. More...

virtual int	getReducedIntegration (int) const
	Returns the number of reduced-order integration points.

virtual int	getBouIntegrationPoints (int nGP) const
	Returns the number of boundary integration points.

virtual bool	reducedInt (LocalIntegral &elmInt, const FiniteElement &fe, const Vec3 &X) const
	Evaluates reduced integration terms at an interior point. More...

virtual bool	evalInt (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time, const Vec3 &X) const
	Evaluates the integrand at an interior point. More...

virtual bool	evalIntMx (LocalIntegral &elmInt, const MxFiniteElement &fe, const TimeDomain &time, const Vec3 &X) const
	Evaluates the integrand at an interior point. More...

virtual bool	evalInt (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time, const Vec3 &X, const Vec3 &normal) const
	Evaluates the integrand at an element interface point. More...

virtual bool	evalIntMx (LocalIntegral &elmInt, const MxFiniteElement &fe, const TimeDomain &time, const Vec3 &X, const Vec3 &normal) const
	Evaluates the integrand at an element interface point. More...

virtual bool	evalPoint (LocalIntegral &elmInt, const FiniteElement &fe, const Vec3 &pval)
	Evaluates the dirac-delta integrand at a specified point. More...

virtual bool	finalizeElement (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time, size_t iGP=0)
	Finalizes the element quantities after the numerical integration. More...

virtual bool	finalizeElementBou (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time)
	Finalizes the element quantities after boundary integration. More...

virtual bool	evalBou (LocalIntegral &elmInt, const FiniteElement &fe, const TimeDomain &time, const Vec3 &X, const Vec3 &normal) const
	Evaluates the integrand at a boundary point. More...

virtual bool	evalBouMx (LocalIntegral &elmInt, const MxFiniteElement &fe, const TimeDomain &time, const Vec3 &X, const Vec3 &normal) const
	Evaluates the integrand at a boundary point. More...

virtual void	setParam (const std::string &, double)
	Assigns a parameter value to property functions of the integrand.

virtual void	setParam (const std::string &, const Vec3 &)
	Assigns parameter values to property functions of the integrand.

Public Attributes
SparseMatrix *	pA
	Left-hand-side matrix of the L2-projection.

StdVector *	pB
	Right-hand-side vectors of the L2-projection.

Static Public Attributes
static LinAlg::MatrixType	MatrixType = LinAlg::SPARSE
	Matrix type for projection.

static LinSolParams *	SolverParams = nullptr
	Linear solver params projection.

Private Member Functions
void	allocate (size_t n)
	Allocates the system L2-projection matrices.

Private Attributes
IntegrandBase *	problem
	The main problem integrand.

FunctionVec	functions
	Explicit functions to L2-project.

size_t	nrhs
	Number of right-hand-size vectors.

Additional Inherited Members
Public Types inherited from Integrand
enum	Traits { STANDARD = 0 , NO_DERIVATIVES = 1 , SECOND_DERIVATIVES = 1<< 1 , THIRD_DERIVATIVES = 1<< 2 , AVERAGE = 1<< 3 , ELEMENT_CORNERS = 1<< 4 , ELEMENT_CENTER = 1<< 5 , G_MATRIX = 1<< 6 , NODAL_ROTATIONS = 1<< 7 , XO_ELEMENTS = 1<< 8 , INTERFACE_TERMS = 1<< 9 , NORMAL_DERIVS = 1<<10 , UPDATED_NODES = 1<<11 , PIOLA_MAPPING = 1<<12 , POINT_DEFORMATION = 1<<13 }
	Enum defining the additional terms that an Integrand may require. More...

Protected Member Functions inherited from Integrand
	Integrand ()
	The default constructor is protected to allow sub-classes only.

virtual bool	evalInt (LocalIntegral &, const FiniteElement &fe, const Vec3 &, const Vec3 &) const
	Evaluates the integrand at interface points, stationary problems.

virtual bool	evalIntMx (LocalIntegral &, const MxFiniteElement &fe, const Vec3 &, const Vec3 &) const
	Evaluates the integrand at interface points, stationary problems.

virtual bool	evalBou (LocalIntegral &, const FiniteElement &, const Vec3 &, const Vec3 &) const
	Evaluates the integrand at boundary points for stationary problems.

virtual bool	evalBouMx (LocalIntegral &, const MxFiniteElement &, const Vec3 &, const Vec3 &) const
	Evaluates the integrand at boundary points for stationary problems.

virtual bool	finalizeElement (LocalIntegral &elmInt, const TimeDomain &, size_t)
	Finalizes the element quantities after the numerical integration. More...

virtual bool	finalizeElement (LocalIntegral &)
	Finalizes the element quantities after the numerical integration. More...

Detailed Description

General integrand for L2-projection of secondary solutions.

Constructor & Destructor Documentation

◆ GlbL2() [1/3]

GlbL2::GlbL2	(	IntegrandBase *	p,
		size_t	n
	)

The constructor initializes the projection matrices.

Parameters

[in]	p	The main problem integrand
[in]	n	Dimension of the L2-projection matrices (number of nodes)

References allocate(), IntegrandBase::getNoFields(), and nrhs.

◆ GlbL2() [2/3]

GlbL2::GlbL2	(	FunctionBase *	f,
		size_t	n
	)

Alternative constructor for projection of an explicit function.

Parameters

[in]	f	The function to do L2-projection on
[in]	n	Dimension of the L2-projection matrices (number of nodes)

◆ GlbL2() [3/3]

GlbL2::GlbL2	(	const FunctionVec &	f,
		size_t	n
	)

Alternative constructor for projection of explicit functions.

Parameters

[in]	f	The functions to do L2-projection on
[in]	n	Dimension of the L2-projection matrices (number of nodes)

References allocate(), and nrhs.

Member Function Documentation

◆ evalInt() [1/3]

virtual bool Integrand::evalInt

inline

Evaluates the integrand at an interior point.

Parameters

	elmInt	The local integral object to receive the contributions
[in]	fe	Finite element data of current integration point
[in]	time	Parameters for nonlinear and time-dependent simulations
[in]	X	Cartesian coordinates of current integration point

The default implementation forwards to the stationary version. Reimplement this method for time-dependent or non-linear problems.

Referenced by evalIntMx().

◆ evalInt() [2/3]

virtual bool Integrand::evalInt

inline

Evaluates the integrand at an element interface point.

Parameters

	elmInt	The local integral object to receive the contributions
[in]	fe	Finite element data of current integration point
[in]	time	Parameters for nonlinear and time-dependent simulations
[in]	X	Cartesian coordinates of current integration point
[in]	normal	Interface normal vector at current integration point

The default implementation forwards to the stationary version. Reimplement this method for time-dependent or non-linear problems.

◆ evalInt() [3/3]

bool GlbL2::evalInt	(	LocalIntegral &	elmInt,
		const FiniteElement &	fe,
		const Vec3 &	X
	)		const

virtual

Evaluates the integrand at an interior point.

Parameters

	elmInt	The local integral object to receive the contributions
[in]	fe	Finite element data of current integration point
[in]	X	Cartesian coordinates of current integration point

Reimplemented from Integrand.

References ElmMats::A, ElmMats::b, FiniteElement::detJxW, IntegrandBase::diverged(), IntegrandBase::evalSol(), functions, ItgPoint::iGP, L2Mats::mnpc, FiniteElement::N, nrhs, problem, utl::vector< T >::push_back(), utl::vector< T >::reserve(), and utl::vector< T >::size().

◆ evalIntMx() [1/3]

virtual bool Integrand::evalIntMx

inline

Evaluates the integrand at an interior point.

Parameters

	elmInt	The local integral object to receive the contributions
[in]	fe	Mixed finite element data of current integration point
[in]	time	Parameters for nonlinear and time-dependent simulations
[in]	X	Cartesian coordinates of current integration point

This interface is used for mixed formulations only. The default implementation forwards to the stationary version. Reimplement this method for time-dependent or non-linear problems.

◆ evalIntMx() [2/3]

virtual bool Integrand::evalIntMx

inline

Evaluates the integrand at an element interface point.

Parameters

	elmInt	The local integral object to receive the contributions
[in]	fe	Finite element data of current integration point
[in]	time	Parameters for nonlinear and time-dependent simulations
[in]	X	Cartesian coordinates of current integration point
[in]	normal	Interface normal vector at current integration point

The default implementation forwards to the stationary version. Reimplement this method for time-dependent or non-linear problems.

◆ evalIntMx() [3/3]

bool GlbL2::evalIntMx	(	LocalIntegral &	elmInt,
		const MxFiniteElement &	fe,
		const Vec3 &	X
	)		const

virtual

Evaluates the integrand at an interior point.

Parameters

	elmInt	The local integral object to receive the contributions
[in]	fe	Mixed finite element data of current integration point
[in]	X	Cartesian coordinates of current integration point

Reimplemented from Integrand.

References ElmMats::A, ElmMats::b, L2Mats::basis_sizes, FiniteElement::detJxW, IntegrandBase::diverged(), L2Mats::elem_sizes, evalInt(), IntegrandBase::evalSol(), ItgPoint::iGP, L2Mats::mnpc, FiniteElement::N, problem, and utl::vector< T >::size().

◆ getLocalIntegral() [1/3]

virtual LocalIntegral* Integrand::getLocalIntegral

inline

Returns a local integral contribution object for the given element.

Parameters

[in]	nen	Number of nodes on each basis
[in]	iEl	Global element number (1-based)
[in]	neumann	Whether or not we are assembling Neumann BCs

This form is used for mixed formulations only. The default implementation just forwards to the single-basis version. Reimplement this method if your mixed formulation requires specialized local integral objects.

◆ getLocalIntegral() [2/3]

LocalIntegral * GlbL2::getLocalIntegral	(	size_t	nen,
		size_t	iEl,
		bool	neumann
	)		const

virtual

Returns a local integral contribution object for the given element.

Parameters

[in]	nen	Number of nodes on element
[in]	iEl	Global element number (1-based)
[in]	neumann	Whether or not we are assembling Neumann BCs

Implements Integrand.

References IntegrandBase::getLocalIntegral(), nrhs, and problem.

◆ getLocalIntegral() [3/3]

virtual LocalIntegral* Integrand::getLocalIntegral

Returns a local integral contribution object for the given element.

Parameters

[in]	nen	Number of nodes on element
[in]	iEl	Global element number (1-based)
[in]	neumann	Whether or not we are assembling Neumann BCs

◆ initElement() [1/2]

bool GlbL2::initElement	(	const IntVec &	MNPC,
		const FiniteElement &	fe,
		const Vec3 &	X0,
		size_t	nPt,
		LocalIntegral &	elmInt
	)

virtual

Initializes current element for numerical integration.

Parameters

[in]	MNPC	Matrix of nodal point correspondance for current element
[in]	fe	Nodal and integration point data for current element
[in]	X0	Cartesian coordinates of the element center
[in]	nPt	Number of integration points in this element
	elmInt	Local integral for element

Implements Integrand.

References L2Mats::elmData, IntegrandBase::initElement(), L2Mats::mnpc, and problem.

◆ initElement() [2/2]

bool GlbL2::initElement	(	const IntVec &	MNPC1,
		const MxFiniteElement &	fe,
		const uIntVec &	elem_sizes,
		const uIntVec &	basis_sizes,
		LocalIntegral &	elmInt
	)

virtual

Initializes current element for numerical integration (mixed).

Parameters

[in]	MNPC1	Matrix of nodal point correspondance for current element
[in]	fe	Nodal and integration point data for current element
[in]	elem_sizes	Size of each basis on the element
[in]	basis_sizes	Size of each basis on the patch
	elmInt	Local integral for element

Implements Integrand.

References L2Mats::basis_sizes, L2Mats::elem_sizes, L2Mats::elmData, IntegrandBase::initElement(), L2Mats::mnpc, and problem.

◆ preAssemble()

void GlbL2::preAssemble	(	const std::vector< IntVec > &	MMNPC,
		size_t	nel
	)

Pre-computes the sparsity pattern of the projection matrix A.

Parameters

[in]	MMNPC	Matrix of matrices of nodal point correspondances
[in]	nel	Number of elements

References pA, and SparseMatrix::preAssemble().

Referenced by ASMbase::L2projection().

◆ solve() [1/2]

bool GlbL2::solve ( const std::vector< Matrix * > & sField )

Solves the projection equation system and evaluates nodal values.

Parameters

[out] sField Nodal/control-point values of the projected results.

References SparseMatrix::dim(), functions, pA, pB, and SparseMatrix::solve().

◆ solve() [2/2]

bool GlbL2::solve ( Matrix & sField )

Solves the projection equation system and evaluates nodal values.

Parameters

[out] sField Nodal/control-point values of the projected results.

References SparseMatrix::dim(), nrhs, utl::matrix< T >::resize(), and SparseMatrix::solve().

Referenced by ASMbase::L2projection().

The documentation for this class was generated from the following files:

src/ASM/GlbL2projector.h
src/ASM/GlbL2projector.C

Public Member Functions

Public Attributes

Static Public Attributes

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ GlbL2() [1/3]

◆ GlbL2() [2/3]

◆ GlbL2() [3/3]

Member Function Documentation

◆ evalInt() [1/3]

◆ evalInt() [2/3]

◆ evalInt() [3/3]

◆ evalIntMx() [1/3]

◆ evalIntMx() [2/3]

◆ evalIntMx() [3/3]

◆ getLocalIntegral() [1/3]

◆ getLocalIntegral() [2/3]

◆ getLocalIntegral() [3/3]

◆ initElement() [1/2]

◆ initElement() [2/2]

◆ preAssemble()

◆ solve() [1/2]

◆ solve() [2/2]
