Driver for assembly of unstructured 3D spline mixed FE models. More...

#include <ASMu3Dmx.h>

Inheritance diagram for ASMu3Dmx:

[legend]

Collaboration diagram for ASMu3Dmx:

[legend]

Public Member Functions
	ASMu3Dmx (const CharVec &n_f)
	The constructor initializes the dimension of each basis.

	ASMu3Dmx (const ASMu3Dmx &patch, const CharVec &n_f=CharVec(3, 0))
	Copy constructor.

virtual	~ASMu3Dmx ()=default
	Empty destructor.

virtual const LR::LRSplineVolume *	getBasis (int basis=1) const
	Returns the spline volume representing a basis of this patch.

virtual LR::LRSplineVolume *	getBasis (int basis=1)
	Returns the spline volume representing a basis of this patch.

virtual bool	readBasis (std::istream &is, size_t basis)
	Reads a basis from the given input stream.

virtual bool	generateFEMTopology ()
	Generates the finite element topology data for the patch. More...

virtual void	clear (bool retainGeometry)
	Clears the contents of the patch, making it empty. More...

virtual size_t	getNoBasis () const
	Returns the number of bases.

virtual size_t	getNoNodes (int basis) const
	Returns the total number of nodes in this patch.

virtual unsigned char	getNoFields (int basis) const
	Returns the number of solution fields.

virtual unsigned char	getNodalDOFs (size_t inod) const
	Returns the number of DOFs per node. More...

virtual char	getNodeType (size_t inod) const
	Returns the classification of a node. More...

virtual Vec3	getCoord (size_t inod) const
	Returns the global coordinates for the given node. More...

virtual void	initMADOF (const int *sysMadof)
	Initializes the patch level MADOF array for mixed problems.

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates an integral over the interior patch domain. More...

virtual bool	integrate (Integrand &integrand, int lIndex, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates a boundary integral over a patch edge. More...

virtual bool	getSolution (Matrix &sField, const Vector &locSol, const IntVec &nodes) const
	Extracts the primary solution field at the specified nodes. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool, int deriv, int nf) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool) const
	Evaluates the secondary solution field at the given points. More...

virtual void	extractNodeVec (const RealArray &globVec, RealArray &nodeVec, unsigned char, int basis) const
	Extracts nodal results for this patch from the global vector. More...

virtual bool	injectNodeVec (const RealArray &nodeVec, RealArray &globVec, unsigned char, int basis) const
	Injects nodal results for this patch into a global vector. More...

virtual size_t	getNoRefineNodes () const
	Returns the number of refinement nodes for this patch.

virtual size_t	getNoRefineElms () const
	Returns the number of refinement elements for this patch.

virtual bool	refine (const LR::RefineData &prm, Vectors &sol)
	Refines the mesh adaptively. More...

virtual void	remapErrors (RealArray &errors, const RealArray &origErr, bool elemErrors) const
	Remaps element-wise errors from geometry mesh to refinement mesh. More...

virtual bool	separateProjectionBasis () const
	Checks if a separate projection basis is used for this patch.

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f, bool piola) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool=false, int deriv=0, int=0) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe, char project='\0') const
	Evaluates the secondary solution field at all visualization points. More...

virtual LR::LRSpline *	evalSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool=false) const
	Evaluates the secondary solution field at the given points. More...

virtual bool	refine (int dir, const RealArray &xi)
	Refines the parametrization by inserting extra tensor knots. More...

virtual bool	refine (const LR::RefineData &prm, Vectors &sol)
	Refines the mesh adaptively. More...

virtual bool	refine (const LR::RefineData &prm, Vectors &sol)
	Refines the mesh adaptively. More...

Public Member Functions inherited from ASMu3D
	ASMu3D (unsigned char n_f=3)
	Default constructor.

	ASMu3D (const ASMu3D &patch, unsigned char n_f=0)
	Copy constructor.

virtual	~ASMu3D ()
	Empty destructor.

virtual bool	read (std::istream &)
	Creates an instance by reading the given input stream.

virtual bool	write (std::ostream &, int) const
	Writes the geometry of the SplineVolume object to given stream.

virtual bool	getElementCoordinates (Matrix &X, int iel, bool forceItg=false) const
	Returns a matrix with nodal coordinates for an element. More...

virtual void	getElmConnectivities (IntMat &neighs, int basis=ASM::INTEGRATION_BASIS) const
	Calculates the matrix of element neighbour connectivities. More...

virtual IntMat	getElmNodes (int basis) const
	Returns the matrix of nodal point correspondance for given basis.

virtual void	getNodalCoordinates (Matrix &X, bool=false) const
	Returns a matrix with all nodal coordinates within the patch. More...

virtual bool	updateCoords (const Vector &displ)
	Updates the nodal coordinates for this patch. More...

virtual void	getBoundaryNodes (int lIndex, IntVec &nodes, int basis, int, int orient, bool local) const
	Finds the global (or patch-local) node numbers on a patch boundary. More...

virtual void	getBoundary1Nodes (int lEdge, IntVec &nodes, int basis, int orient, bool local, bool open=false) const
	Finds the global (or patch-local) node numbers on a patch boundary. More...

virtual int	getCorner (int I, int J, int K, int basis) const
	Returns the node index for a given corner. More...

virtual bool	getOrder (int &p1, int &p2, int &p3) const
	Returns the polynomial order in each parameter direction. More...

virtual size_t	getNoProjectionNodes () const
	Returns the number of projection nodes for this patch.

virtual bool	uniformRefine (int dir, int nInsert)
	Refines the parametrization by inserting tensor knots uniformly. More...

virtual bool	refine (int dir, const RealArray &xi)
	Refines the parametrization by inserting extra tensor knots. More...

virtual bool	raiseOrder (int ru, int rv, int rw, bool setOrder)
	Raises the order of the tensor spline object for this patch. More...

virtual bool	createProjectionBasis (bool init)
	Creates a separate projection basis for this patch. More...

virtual void	setMinimumSize (double size)
	Sets the minimum element volume for adaptive refinement.

virtual double	getMinimumSize (int nrefinements) const
	Defines the minimum element volume for adaptive refinement. More...

virtual bool	checkElementSize (int elmId, bool globalNum=true) const
	Checks if the specified element is larger than the minimum size. More...

void	copyRefinement (LR::LRSplineVolume *basis, int multiplicity=1) const
	Copies the refinement to another spline volume. More...

virtual void	constrainFace (int dir, bool open, int dof, int code=0, char basis=1)
	Constrains all DOFs on a given boundary face. More...

virtual size_t	constrainFaceLocal (int dir, bool open, int dof, int code=0, bool project=false, char T1='\0')
	Constrains all DOFs in local directions on a given boundary face. More...

virtual void	constrainEdge (int lEdge, bool open, int dof, int code=0, char basis=1)
	Constrains all DOFs on a given boundary edge. More...

virtual void	constrainLine (int fdir, int ldir, double xi, int dof, int code=0, char basis=1)
	Constrains all DOFs along a line on a given boundary face. More...

virtual void	constrainCorner (int I, int J, int K, int dof, int code=0, char basis=1)
	Constrains a corner node identified by the three parameter indices. More...

virtual void	constrainNode (double xi, double eta, double zeta, int dof, int code=0)
	Constrains a node identified by three relative parameter values. More...

virtual bool	connectPatch (int face, ASM3D &neighbor, int nface, int norient, int=0, bool coordCheck=true, int thick=1)
	Connects all matching nodes on two adjacent boundary faces. More...

virtual void	getNoBouPoints (size_t &nPt, char ldim, char lindx)
	Computes the number of boundary integration points in this patch.

virtual bool	integrateEdge (Integrand &integrand, int lEdge, GlobalIntegral &glbInt, const TimeDomain &time)
	Evaluates a boundary integral over a patch edge. More...

virtual bool	diracPoint (Integrand &integrand, GlobalIntegral &glbInt, const double *param, const Vec3 &pval)
	Integrates a spatial dirac-delta function over a patch. More...

virtual bool	updateDirichlet (const std::map< int, RealFunc * > &func, const std::map< int, VecFunc * > &vfunc, double time, const std::map< int, int > *g2l=nullptr)
	Updates the time-dependent in-homogeneous Dirichlet coefficients. More...

virtual int	evalPoint (const double xi, double param, Vec3 &X) const
	Evaluates the geometry at a specified point. More...

virtual int	findElementContaining (const double *param) const
	Returns the element that contains a specified spatial point. More...

virtual double	findPoint (Vec3 &X, double *param) const
	Searches for the specified Cartesian point in the patch. More...

virtual bool	getGridParameters (RealArray &prm, int dir, int nSegSpan) const
	Calculates parameter values for visualization nodal points. More...

virtual bool	tesselate (ElementBlock &grid, const int *npe) const
	Creates a hexahedron element model of this patch for visualization. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f, bool piola) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalProjSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f) const
	Evaluates the projected solution field at all visualization points. More...

virtual bool	evaluate (const FunctionBase *func, RealArray &vec, int, double time) const
	Evaluates and interpolates a function over a given geometry. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe, char project='\0') const
	Evaluates the secondary solution field at all visualization points. More...

virtual Field *	getProjectedField (const Vector &coefs) const
	Returns a field using the projection basis. More...

virtual Fields *	getProjectedFields (const Vector &coefs, size_t=0) const
	Returns a field using the projection basis. More...

void	setOutputMaster (const ASMu3D *pch)
	Set master patch for VTF output. More...

virtual void	extractElmRes (const Matrix &globRes, Matrix &elmRes, size_t internalFirst) const
	Extracts element results for this patch from a global vector. More...

virtual LR::LRSpline *	evalSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

bool	faceL2projection (const DirichletFace &face, const FunctionBase &values, Real2DMat &result, double time) const
	Projects inhomogenuous dirichlet conditions by continuous L2-fit. More...

virtual bool	transferGaussPtVars (const LR::LRSpline *old_basis, const RealArray &oldVar, RealArray &newVar, int nGauss) const
	Transfers Gauss point variables from old basis to this patch. More...

virtual bool	transferGaussPtVarsN (const LR::LRSpline *old_basis, const RealArray &oldVar, RealArray &newVar, int nGauss) const
	Transfers Gauss point variables from old basis to this patch. More...

virtual bool	transferCntrlPtVars (const LR::LRSpline *old_basis, RealArray &newVar, int nGauss) const
	Transfers control point variables from old basis to this patch. More...

virtual size_t	getNoBoundaryElms (char lIndex, char ldim) const
	Returns the number of elements on a boundary.

virtual bool	refine (const LR::RefineData &prm, Vectors &sol)
	Refines the mesh adaptively. More...

virtual bool	transferCntrlPtVars (const LR::LRSpline *oldBasis, RealArray &newVar, int nGauss) const=0
	Transfers control point variables from old basis to this patch. More...

bool	transferCntrlPtVars (LR::LRSpline *oldBasis, const RealArray &oldVar, RealArray &newVar, int nGauss, int nf=1) const
	Transfers control point variables from old basis to this patch. More...

Public Member Functions inherited from ASMLRSpline
virtual	~ASMLRSpline ()
	Empty destructor.

virtual bool	empty () const
	Checks if the patch is empty.

virtual bool	getParameterDomain (Real2DMat &, IntVec *) const
	Returns parameter values and node numbers of the domain corners.

const LR::LRSpline *	getRefinementBasis () const
	Returns a const pointer to refinement basis.

IntVec	getFunctionsForElements (const IntVec &elements, bool globalId=false) const
	Returns a list of basis functions having support on given elements.

void	getFunctionsForElements (IntSet &functions, const IntVec &elements, bool globalId=true) const
	Returns a list of basis functions having support on given elements.

virtual IntVec	getBoundaryCovered (const IntSet &nodes) const
	Returns all boundary functions that are covered by the given nodes. More...

IntVec	getOverlappingNodes (const IntSet &nodes, int dir=7) const
	Returns all functions whose support overlap with the input nodes. More...

IntVec	getOverlappingNodes (int node, int dir=7) const
	Returns all functions whose support overlap with the input node. More...

bool	transferCntrlPtVars (LR::LRSpline *oldBasis, const RealArray &oldVar, RealArray &newVar, int nGauss, int nf=1) const
	Transfers control point variables from old basis to this patch. More...

virtual std::pair< size_t, double >	findClosestNode (const Vec3 &X) const
	Finds the node that is closest to the given point X.

virtual Vec3	getElementCenter (int iel) const
	Returns the coordinates of the element center.

virtual void	getNoIntPoints (size_t &nPt, size_t &nIPt)
	Computes the total number of integration points in this patch.

virtual void	swapProjectionBasis ()
	Swaps between the first and second projection basis.

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const int *npe, int n_f=0, bool piola=false) const
	Evaluates the primary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular=true, int deriv=0, int n_f=0) const
	Evaluates the primary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const int *npe=nullptr, char project=0) const
	Evaluates the secondary solution field at all visualization points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const RealArray *gpar, bool regular=true) const
	Evaluates the secondary solution field at the given points. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const IntVec &elements) const
	Evaluates the secondary solution field at element centers. More...

Public Member Functions inherited from ASMbase
virtual	~ASMbase ()
	The destructor frees the dynamically allocated data objects.

ASMbase *	cloneUnShared () const
	Returns a copy of this patch with identical FE discretization. More...

virtual void	addHole (double, double, double)
	Adds a circular immersed boundary in the physical geometry.

virtual void	addHole (double, double, double, double, double)
	Adds an oval immersed boundary in the physical geometry.

virtual bool	setGeometry (RealFunc *, double, double)
	Defines the immersed geometry from a scalar function.

virtual bool	addXElms (short int dim, short int item, size_t nXn, IntVec &nodes)
	Adds extraordinary elements associated with a patch boundary. More...

bool	addLagrangeMultipliers (size_t iel, const IntVec &mGLag, unsigned char nnLag=1)
	Adds a set of Lagrange multipliers to the specified element. More...

bool	addGlobalLagrangeMultipliers (const IntVec &mGLag, unsigned char nnLag=1)
	Adds global Lagrange multipliers to the system. More...

virtual void	setGauss (int ng)
	Defines the numerical integration scheme nGauss in the patch.

void	setNoFields (unsigned char n)
	Defines the number of solution fields in the patch. More...

void	setElementActivator (IntFunc *efunc)
	Sets the element activation function.

const IntFunc *	getElementActivator () const
	Returns a pointer to the element activation function.

unsigned char	getNoSpaceDim () const
	Returns the number of spatial dimensions.

unsigned char	getNoParamDim () const
	Returns the number of parameter dimensions.

unsigned char	getNoLagPerNode () const
	Returns the number of Lagrange multipliers per node.

virtual size_t	getNodeIndex (int globalNum, bool=false) const
	Returns local 1-based index of the node with given global number. More...

virtual int	getNodeID (size_t inod, bool=false) const
	Returns the global node number for the given node. More...

size_t	getElmIndex (int globalNum) const
	Returns local 1-based index of element with given global number. More...

int	getElmID (size_t iel) const
	Returns the global element number for the given element. More...

bool	isLMn (size_t n) const
	Returns true if node n is a Lagrange multiplier node.

bool	isRMn (size_t n) const
	Returns true if node n is a master node of a rigid coupling.

char	getLMType (size_t inod) const
	Returns the type of a Lagrange multiplier node. More...

void	getBoundaryElms (int lIndex, IntVec &elms, int orient=-1, bool local=false) const
	Finds the global (or patch-local) element numbers on a boundary. More...

virtual int	getNodeSetIdx (const std::string &) const
	Returns (1-based) index of a predefined node set in the patch.

virtual const IntVec &	getNodeSet (int) const
	Returns an indexed predefined node set.

virtual bool	isInNodeSet (int, int) const
	Checks if a node is within a predefined node set.

virtual int	parseNodeSet (const std::string &, const char *)
	Defines a node set by parsing a list of node numbers.

virtual int	parseNodeBox (const std::string &, const char *)
	Defines a node set by parsing a 3D bounding box.

virtual int	getElementSetIdx (const std::string &) const
	Returns (1-based) index of a predefined element set in the patch.

virtual const IntVec &	getElementSet (int) const
	Returns an indexed predefined element set.

virtual bool	getElementSet (int, std::string &) const
	Returns the name of an indexed predefined element set.

virtual bool	isInElementSet (int, int) const
	Checks if an element is within a predefined element set.

virtual int	parseElemSet (const std::string &, const char *)
	Defines an element set by parsing a list of element numbers.

virtual int	parseElemBox (const std::string &, const std::string &, const char *)
	Defines an element set by parsing a 3D bounding box.

void	printNodes (std::ostream &os) const
	Prints out the nodal coordinates of this patch to the given stream.

void	printElements (std::ostream &os) const
	Prints out element connections of this patch to the given stream.

virtual void	printElmInfo (int, const IntegrandBase *) const
	Prints out additional app-dependent element information.

virtual void	shiftGlobalNodeNums (int nshift)
	Increase all global node numbers by nshift.

void	setGlobalNodeNums (const IntVec &nodes)
	Sets the global node numbers for this patch.

const IntVec &	getMyNodeNums () const
	Returns the actual global node numbers of this patch.

const IntVec &	getGlobalNodeNums () const
	Returns the global node numbers of this patch.

virtual void	shiftGlobalElmNums (int eshift)
	Increase all global element numbers by eshift.

const IntVec &	getGlobalElementNums () const
	Returns the global element numbers of this patch.

void	setActiveElements (IntVec *active)
	Sets the list of active elements during assembly.

bool	isElementActive (int iel, double time=-1.0) const
	Returns true if element with 0-based index iel is active.

bool	inActive (double time) const
	Returns true if none of the elements in the patch are active.

double	getAge (int iel, double time) const
	Returns the age of the element with 0-based index iel.

bool	isElementInPartition (int iel) const
	Returns true if element is in process partition. More...

const IntVec &	getElementNodes (int iel) const
	Returns the nodal point correspondance array for an element. More...

size_t	getNoElms (bool includeZeroVolElms=false, bool includeXElms=false) const
	Returns the total number of elements in this patch. More...

int	getMaxElmNo () const
	Returns the highest external element number in this patch.

size_t	getNoMPCs () const
	Returns the total number of multi-point constraint equations.

BCVec::const_iterator	begin_BC () const
	Returns the beginning of the BCode array.

BCVec::const_iterator	end_BC () const
	Returns the end of the BCode array.

IntMat::const_iterator	begin_elm () const
	Returns the beginning of the MNPC array.

IntMat::const_iterator	end_elm () const
	Returns the end of the MNPC array.

MPCIter	begin_MPC () const
	Returns the beginning of the mpcs set.

MPCIter	end_MPC () const
	Returns the end of the mpcs set.

MPC *	findMPC (int node, int dof) const
	Returns a pointer to the MPC object for a specified slave, if any. More...

bool	isShared () const
	Returns true if this patch shares FE data with another patch.

bool	hasXNodes () const
	Returns true if this patch has additional (extraordinary) nodes.

virtual void	copyParameterDomain (const ASMbase *)
	Copies the parameter domain from another patch.

virtual void	closeBoundaries (int dir=1, int basis=0, int master=1)
	Makes two opposite boundaries periodic. More...

bool	mergeNodes (size_t inod, int globalNum, bool verbose=true)
	Merges a given node in this patch with a given global node. More...

int	renumberNodes (std::map< int, int > &old2new, int &nNod)
	Renumbers the global node numbers in this patch. More...

bool	renumberNodes (const std::map< int, int > &old2new, const std::vector< int > &new2old={}, int renumGN=0, std::map< int, int > *degenElm=nullptr)
	Renumbers the global node numbers referred by this patch. More...

virtual bool	initConstraints ()
	Initializes the multi-point constraint coefficients.

virtual void	setNodeNumbers (const IntVec &nodes)
	Sets the global node numbers for this patch. More...

bool	hasTimeDependentDirichlet (const std::map< int, RealFunc * > &func, const std::map< int, VecFunc * > &vfunc)
	Checks for time-dependent in-homogeneous Dirichlet conditions. More...

virtual bool	transform (const Matrix &)
	Applies a transformation matrix from local to global system.

virtual void	generateThreadGroups (char, bool, bool)
	Generates element groups for multi-threading of boundary integrals.

virtual bool	validateThreadGroups (const SAM *) const
	Validates the threading groups based on the assembly data in SAM.

virtual bool	integrate (Integrand &integrand, GlobalIntegral &glbInt, const TimeDomain &time, const ASM::InterfaceChecker &iChk)
	Evaluates an integral over element interfaces in the patch. More...

virtual ElementBlock *	immersedGeometry (char *) const
	Returns an additional geometry to visualize (immersed boundaries).

virtual ElementBlock *	extraGeometry (char *) const
	Returns an additional geometry to visualize (spiders, etc.).

virtual void	filterResults (Matrix &, const ElementBlock *) const
	Filters out result point values that are outside physical domain.

virtual bool	immersedSolution (Matrix &, const Vector &) const
	Evaluates the primary solution at the immersed geometry points.

virtual bool	extraSolution (Matrix &, const Vector &) const
	Evaluates the primary solution at the extra geometry points.

virtual bool	evalSolutionPiola (Matrix &sField, const Vector &locSol, const RealArray *gpar, bool regular) const
	Evaluates the primary solution field with Piola mapping. More...

virtual bool	evaluate (const ASMbase *basis, const Vector &locVec, RealArray &vec, int basisNum=1) const
	Evaluates and interpolates a field over a given geometry. More...

virtual bool	evaluate (const Field *f, RealArray &vec, int basisNum=1) const
	Evaluates and interpolates a scalar field over a given geometry. More...

virtual bool	evalSolution (Matrix &sField, const IntegrandBase &integrand, const IntVec &elements) const
	Evaluates the secondary solution field at element centers. More...

bool	globalL2projection (Matrix &sField, const L2Integrand &integrand, bool continuous=false, bool enforceEnds=false) const
	Projects the secondary solution using a (discrete) global L2-fit. More...

bool	L2projection (Matrix &sField, IntegrandBase *integrand, const TimeDomain &time)
	Projects the secondary solution using a continuous global L2-fit. More...

bool	L2projection (Matrix &fVals, FunctionBase *function, double t=0.0)
	Projects an explicit function using a continuous global L2-fit. More...

bool	L2projection (const std::vector< Matrix * > &fVals, const std::vector< FunctionBase * > &function, double t=0.0)
	Projects explicit functions using a continuous global L2-fit. More...

virtual void	extractElmRes (const Vector &globRes, Vector &elmRes, size_t internalFirst=0) const
	Extracts element results for this patch from a global vector. More...

bool	extractNodalVec (const RealArray &globVec, RealArray &nodeVec, const int *madof, int ngnod=-1) const
	Extracts nodal results for this patch from the global vector. More...

bool	injectNodalVec (const RealArray &nodeVec, RealArray &globVec, const IntVec &madof, int basis=0) const
	Injects nodal results for this patch into the global vector. More...

bool	add2PC (int slave, int dir, int master, int code=0)
	Creates and adds a two-point constraint to this patch. More...

bool	addMPC (MPC *&mpc, int code=0, bool verbose=false, bool overrideD=false)
	Adds a general multi-point-constraint (MPC) equation to this patch. More...

virtual bool	addRigidCpl (int lindx, int ldim, int basis, int &gMaster, const Vec3 &Xmaster, bool extraPt=true)
	Adds MPC-equations representing a rigid coupling to this patch. More...

void	addRigidCouplings (int gMaster, const Vec3 &Xmaster, const IntVec &slaveNodes)
	Adds MPC-equations representing a rigid coupling to this patch. More...

void	constrainPatch (int dof, int code=0)
	Constrains all nodes in the patch. More...

void	constrainNodes (const IntVec &nodes, int dof, int code=0, bool overrideD=false)
	Constrains a list of nodes in the patch. More...

bool	constrainXnode (int node, int dof, int code=0)
	Constrains an extraordinary node in the patch. More...

int	prescribe (size_t inod, int dirs, int code, bool overrideD=false)
	Constrains DOFs in the given node to the given value. More...

int	fix (size_t inod, int dirs=123)
	Constrains DOFs in the given node to zero. More...

bool	isFixed (int node, int dof, bool all=false) const
	Checks if the given DOFs are fixed. More...

Public Member Functions inherited from ASMunstruct
virtual	~ASMunstruct ()
	Empty destructor.

virtual void	storeMesh (const std::string &fName, int fType=15) const
	Stores the mesh basis to encapsulated postscript files. More...

Public Member Functions inherited from ASM3D
virtual	~ASM3D ()
	Empty destructor.

ASMbase *	clone (const CharVec &nf=CharVec()) const
	Returns a copy of this patch with identical FE discretization. More...

virtual bool	checkRightHandSystem ()
	Checks that the patch is modelled in a right-hand-side system.

virtual bool	refine (int dir, const std::vector< double > &xi)=0
	Refines the parametrization by inserting extra knots. More...

virtual bool	getGridParameters (std::vector< double > &prm, int dir, int nSegSpan) const =0
	Calculates parameter values for visualization nodal points. More...

Protected Member Functions
void	generateThreadGroups (const Integrand &integrand, bool silence, bool ignoreGlobalLM)
	Generates element groups for multi-threading of interior integrals. More...

Protected Member Functions inherited from ASMu3D
LR::LRSplineVolume *	projectSolution (const IntegrandBase &integrand) const
	Projects the secondary solution field onto the primary basis. More...

LR::LRSplineVolume *	scRecovery (const IntegrandBase &integrand) const
	Projects the secondary solution using a superconvergent approach. More...

LR::LRSplineVolume *	regularInterpolation (const RealArray &upar, const RealArray &vpar, const RealArray &wpar, const Matrix &points, int basis) const
	Interpolates an LR spline at a given set of parametric coordinates. More...

virtual void	findBoundaryElms (IntVec &elms, int lIndex, int orient) const
	Finds the patch-local element numbers on a patch boundary. More...

virtual bool	assembleL2matrices (SystemMatrix &A, SystemVector &B, const L2Integrand &integrand, bool continuous) const
	Assembles L2-projection matrices for the secondary solution. More...

bool	connectBasis (int face, ASMu3D &neighbor, int nface, int norient, int basis=1, int slave=0, int master=0, bool coordCheck=true, int thick=1)
	Connects all matching nodes on two adjacent boundary faces. More...

void	getGaussPointParameters (RealArray &uGP, int dir, int nGauss, int iel, const double xi, const LR::LRSplineVolume spline=nullptr) const
	Extracts parameter values of the Gauss points in one direction. More...

bool	getGrevilleParameters (RealArray &prm, int dir, int basisNum=1) const
	Calculates parameter values for the Greville points. More...

bool	getQuasiInterplParameters (RealArray &prm, int dir) const
	Calculates parameter values for the Quasi-Interpolation points. More...

double	getParametricArea (int iel, int dir) const
	Returns boundary face area in the parameter space for an element. More...

double	getElementCorners (int iel, std::vector< Vec3 > &XC, RealArray *uC=nullptr) const
	Computes the element corner coordinates. More...

void	getCornerPoints (int iel, std::vector< utl::Point > &XC) const
	Computes the element corner coordinates and parameters. More...

void	evaluateBasis (int iel, double u, double v, double w, Vector &N, Matrix &dNdu, int basis=1) const
	Evaluate all basis functions and first derivatives on one element.

void	evaluateBasis (Vector &N, Matrix &dNdu, const Matrix &C, const Matrix &B) const
	Evaluate all basis functions and first derivatives on one element.

void	evaluateBasis (int iel, FiniteElement &fe, Matrix &dNdu, int basis=1) const
	Evaluate all basis functions and first derivatives on one element.

void	evaluateBasis (int iel, double u, double v, double w, Vector &N, Matrix &dNdu, Matrix3D &d2Ndu2, int basis=1) const
	Evaluate all basis functions and second order derivatives on one element.

virtual int	evalPoint (int iel, const double *param, Vec3 &X) const
	Evaluates the geometry at a specified point. More...

virtual void	generateThreadGroupsFromElms (const IntVec &elms)
	Generate element groups from a partition.

virtual void	generateProjThreadGroupsFromElms (const IntVec &elms)
	Generate element groups from a partition.

virtual void	changeNumThreads ()
	Hook for changing number of threads.

virtual void	extendRefinementDomain (IntSet &refineIndices, const IntSet &neighborIndices) const
	Extends the refinement domain with information for neighbors. More...

std::shared_ptr< LR::LRSplineVolume >	createLRfromTensor ()
	Converts current tensor spline object to LR-spline.

Protected Member Functions inherited from ASMLRSpline
	ASMLRSpline (unsigned char n_p, unsigned char n_s, unsigned char n_f)
	The constructor sets the space dimensions. More...

	ASMLRSpline (const ASMLRSpline &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data. More...

bool	doRefine (const LR::RefineData &prm, LR::LRSpline *lrspline)
	Refines the mesh adaptively. More...

virtual int	evalPoint (const double xi, double param, Vec3 &X) const=0
	Evaluates the geometry at a specified point. More...

Protected Member Functions inherited from ASMbase
	ASMbase (unsigned char n_p, unsigned char n_s, unsigned char n_f)
	The constructor sets the number of space dimensions and fields. More...

	ASMbase (const ASMbase &patch, unsigned char n_f)
	Special copy constructor for sharing of FE data. More...

	ASMbase (const ASMbase &patch)
	Default copy constructor, copying everything except neighbors. More...

void	addLocal2GlobalCpl (int iSlave, int master, const Tensor &Tlg)
	Creates constraint equations coupling global DOFs to local DOFs. More...

bool	add3PC (int slave, int dir, int master1, int master2, int code=0)
	Creates and adds a three-point constraint to this patch. More...

bool	addPeriodicity (size_t master, size_t slave, int dir)
	Creates and adds a periodicity constraint to this patch. More...

void	makePeriodic (size_t master, size_t slave, int dirs=123)
	Creates periodicity constraints between two nodes in this patch. More...

void	addNeighbor (ASMbase *pch)
	Adds a patch to the list of neighbors of this patch. More...

bool	createRgdMasterNode (int &gMaster, const Vec3 &Xmaster)
	Creates an additional master node for a rigid coupling. More...

void	addRigidMPC (int gSlave, int gMaster, const Vec3 &dX)
	Adds MPC-equations representing a rigid arm to a 6-DOF node. More...

int	getNoGaussPt (int p, bool neumann=false) const
	Returns the number of Gauss points to use in one direction. More...

int	searchCtrlPt (RealArray::const_iterator cit, RealArray::const_iterator end, const Vec3 &X, int dimension, double tol=0.001) const
	Helper method used by evalPoint to search for a control point. More...

bool	allDofs (int dirs) const
	Returns true if dirs constains all local DOFs in the patch.

bool	writeLagBasis (std::ostream &os, const char *type) const
	Writes a Lagrangian basis to the given stream.

Protected Member Functions inherited from ASMunstruct
	ASMunstruct ()
	The constructor is protected to allow objects of sub-classes only.

Protected Member Functions inherited from ASM3D
	ASM3D ()
	The constructor is protected to allow objects of sub-classes only.

Private Types
using	SplinePtr = std::shared_ptr< LR::LRSplineVolume >
	Pointer to spline.

Private Types inherited from ASMmxBase
enum	MixedType { NONE = 0 , FULL_CONT_RAISE_BASIS1 , REDUCED_CONT_RAISE_BASIS1 , FULL_CONT_RAISE_BASIS2 , REDUCED_CONT_RAISE_BASIS2 , DIV_COMPATIBLE , SUBGRID }
	Enum defining available mixed formulation types. More...

typedef std::vector< std::shared_ptr< Go::SplineSurface > >	SurfaceVec
	Convenience type.

typedef std::vector< std::shared_ptr< Go::SplineVolume > >	VolumeVec
	Convenience type.

Private Member Functions
void	getElementsAt (const RealArray &param, std::vector< int > &elms, std::vector< size_t > *sizes=nullptr) const
	Finds the elements and associted sizes at given parametric point. More...

Private Member Functions inherited from ASMmxBase
	ASMmxBase (const std::vector< unsigned char > &n_f)
	The constructor sets the number of field variables. More...

void	initMx (const std::vector< int > &MLGN, const int *sysMadof)
	Initializes the patch level MADOF array. More...

void	extractNodeVecMx (const RealArray &glbVec, RealArray &nodVec, int basis) const
	Extracts nodal results for this patch from the global vector. More...

void	injectNodeVecMx (RealArray &glbVec, const RealArray &nodVec, int basis) const
	Injects nodal results for this patch into a global vector. More...

bool	getSolutionMx (Matrix &sField, const Vector &locSol, const std::vector< int > &nodes) const
	Extracts the primary solution field at the specified nodes. More...

Private Attributes
std::vector< SplinePtr >	m_basis
	All bases.

LR::LRSplineVolume *	threadBasis
	Basis for thread groups.

Private Attributes inherited from ASMmxBase
bool	piola = false
	True if last used integrand was Piola mapped.

std::vector< size_t >	elem_size
	Number of basis functions per element in each basis.

std::vector< size_t >	nb
	Total number of basis functions in each basis.

std::vector< unsigned char >	nfx
	Number of fields on each basis.

Additional Inherited Members
Public Types inherited from ASMbase
using	BCVec = std::vector< BC >
	Nodal boundary condition container.

Public Types inherited from ASM3D
typedef std::vector< unsigned char >	CharVec
	Convenience type.

Static Public Member Functions inherited from ASMLRSpline
static Go::BsplineBasis	getBezierBasis (int p, double start=-1.0, double end=1.0)
	Returns a Bezier basis of order p.

static void	Sort (int u, int v, int orient, std::vector< LR::Basisfunction * > &functions)
	Sort basis functions based on local knot vectors.

Static Public Member Functions inherited from ASMbase
static void	resetNumbering (int n=0)
	Resets the global element and node counters.

static int	renumberNodes (const ASMVec &model, std::map< int, int > &old2new)
	Renumbers all global node numbers in the entire model. More...

static void	mergeAndGetAllMPCs (const ASMVec &model, MPCSet &allMPCs)
	Computes the set of all MPC-equations over the whole model. More...

static void	resolveMPCchains (const MPCSet &allMPCs, const ASMVec &model, bool setPtrOnly=false)
	Resolves (possibly multi-level) chaining in MPC-equations. More...

Static Public Member Functions inherited from ASM3D
static ASMbase *	create (ASM::Discretization type, const CharVec &nf, bool mixedFEM=false)
	Creates a three-parametric patch of specified discretization type. More...

static ASMbase *	create (ASM::Discretization type, unsigned char nf=1)
	Creates a three-parametric patch of specified discretization type. More...

Public Attributes inherited from ASMbase
size_t	idx
	Index of this patch in the multi-patch model.

Static Public Attributes inherited from ASMbase
static bool	fixHomogeneousDirichlet = true
	If true, pre-eliminate fixed DOFs.

static int	dbgElm = 0
	One-based element index to print debugging info for.

static double	modelSize = 1.0
	Characteristic model size. More...

Protected Types inherited from ASMbase
using	XYZ = std::array< double, 3 >
	Convenience type definition.

Static Protected Member Functions inherited from ASMLRSpline
static bool	checkThreadGroups (const IntMat &groups, const std::vector< const LR::LRSpline * > &bases, const LR::LRSpline *threadBasis)
	Santity check thread groups. More...

Static Protected Member Functions inherited from ASMbase
static bool	deformedConfig (const Matrix &Xnod, Vectors &eVec, bool force2nd=false)
	Calculates the deformed configuration for current element. More...

static bool	collapseNodes (ASMbase &pch1, int node1, ASMbase &pch2, int node2)
	Collapses the given two nodes into one. More...

Static Protected Member Functions inherited from ASM3D
static double	getElementSize (const std::vector< Vec3 > &XC)
	Returns characteristic element size based on corner coordinates.

Protected Attributes inherited from ASMu3D
std::shared_ptr< LR::LRSplineVolume >	lrspline
	The LR-spline volume object.

const ASMu3D *	outputMaster = nullptr
	Master patch to use for VTF output.

Go::SplineVolume *	tensorspline
	Pointer to original tensor spline object.

Go::SplineVolume *	tensorPrjBas
	Pointer to tensor spline projection base.

std::vector< DirichletFace >	dirich
	Inhomogeneous Dirichlet boundary condition data.

const Matrices &	bezierExtract
	Bezier extraction matrices.

Matrices	myBezierExtract
	Bezier extraction matrices.

std::vector< std::unique_ptr< BasisFunctionCache > >	myCache
	Basis function cache.

Protected Attributes inherited from ASMLRSpline
std::shared_ptr< LR::LRSpline >	geomB
	Pointer to spline object of the geometry basis.

std::shared_ptr< LR::LRSpline >	projB
	Pointer to spline object of the projection basis.

std::shared_ptr< LR::LRSpline >	projB2
	Pointer to spline object of the secondary projection basis.

std::shared_ptr< LR::LRSpline >	refB
	Pointer to spline object of the refinement basis.

ThreadGroups	threadGroups
	Element groups for multi-threaded assembly.

ThreadGroups	projThreadGroups
	Element groups for multi-threaded assembly - projection basis.

ThreadGroups	proj2ThreadGroups
	Element groups for multi-threaded assembly - second projection basis.

Protected Attributes inherited from ASMbase
unsigned char	ndim
	Number of parametric dimensions (1, 2 or 3)

unsigned char	nsd
	Number of space dimensions (ndim <= nsd <= 3)

unsigned char	nf
	Number of primary solution fields (1 or larger)

unsigned char	nLag
	Number of Lagrange multipliers per node.

size_t	nel
	Number of regular elements in this patch.

size_t	nnod
	Number of regular nodes in this patch.

const IntVec &	MLGE
	Matrix of Local to Global Element numbers.

const IntVec &	MLGN
	Matrix of Local to Global Node numbers.

const IntMat &	MNPC
	Matrix of Nodal Point Correspondance.

const char	shareFE
	Flag telling whether this patch shares its data with another patch. More...

BCVec	BCode
	Array of Boundary Condition codes.

MPCMap	dCode
	Inhomogeneous Dirichlet condition codes for the MPCs.

MPCSet	mpcs
	All multi-point constraints with the slave in this patch.

IntVec	myMLGE
	The actual Matrix of Local to Global Element numbers.

IntVec	myMLGN
	The actual Matrix of Local to Global Node numbers.

IntMat	myMNPC
	The actual Matrix of Nodal Point Correspondance.

IntVec	myElms
	Elements on patch - used with partitioning.

int	nGauss
	Numerical integration scheme for this patch. More...

size_t	firstEl
	Global index to first element within this patch.

size_t	firstIp
	Global index to first interior integration point.

std::map< char, size_t >	firstBp
	Global indices to first integration point for the Neumann boundaries.

ASMVec	neighbors
	Patches having nodes in common with this one.

std::map< size_t, XYZ >	myRmaster
	Rigid master nodal points.

Static Protected Attributes inherited from ASMbase
static std::map< int, int >	xNode
	Auxilliary node number map used when establishing Dirichlet constraints.

static int	gEl = 0
	Global element counter.

static int	gNod = 0
	Global node counter.

Static Private Member Functions inherited from ASMmxBase
static SurfaceVec	establishBases (Go::SplineSurface *surf, MixedType type)
	Establish mixed bases in 2D. More...

static VolumeVec	establishBases (Go::SplineVolume *svol, MixedType type)
	Establish mixed bases in 3D. More...

static Go::SplineSurface *	adjustBasis (const Go::SplineSurface &surf, const std::array< SplineUtils::AdjustOp, 2 > &ops)
	Returns a C^p-1 basis of one degree higher than *surf.

static Go::SplineVolume *	adjustBasis (const Go::SplineVolume &svol, const std::array< SplineUtils::AdjustOp, 3 > &ops)
	Returns a C^p-1 basis of one degree higher than *svol.

Static Private Attributes inherited from ASMmxBase
static MixedType	Type = ASMmxBase::FULL_CONT_RAISE_BASIS1
	Type of mixed formulation used.

static char	itgBasis = 2
	1-based index of basis representing the integration elements

static bool	includeExtra = false
	True to include extra basis (geometry/projection) as FE basis.

Detailed Description

Driver for assembly of unstructured 3D spline mixed FE models.

This class implements a two-field mixed formulation with splines as basis functions. The first field is of one order higher than the second field, and its basis is obtained by order-elevating the input spline object once. By default, the geometry is represented by the second (lower order) basis, however, by negating the n_f1 argument to the constructor, the first basis is used instead.

Member Function Documentation

◆ clear()

void ASMu3Dmx::clear ( bool retainGeometry )

virtual

Clears the contents of the patch, making it empty.

Parameters

[in] retainGeometry If true, the spline geometry is not cleared. This is used to reinitialize the patch after it has been refined.

Reimplemented from ASMu3D.

References ASMu3D::clear(), and m_basis.

◆ evalSolution() [1/7]

LR::LRSpline * ASMu3D::evalSolution

Projects the secondary solution field onto the primary basis.

Parameters

[in] integrand Object with problem-specific data and methods

◆ evalSolution() [2/7]

bool ASMu3D::evalSolution

Evaluates the secondary solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	npe	Number of visualization nodes over each knot span
[in]	project	Flag indicating result recovery method (0=none, 'D'=direct evaluation, 'S'=superconvergent recovery)

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. If npe is null, the solution is recovered or evaluated at the Greville points and then projected onto the spline basis to obtain the control point values, which then are returned through sField. If npe is not null and project is defined, the solution is also projected onto the spline basis, and then evaluated at the npe points.

◆ evalSolution() [3/7]

bool ASMu3Dmx::evalSolution	(	Matrix &	sField,
		const IntegrandBase &	integrand,
		const RealArray *	gpar,
		bool
	)		const

virtual

Evaluates the secondary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	gpar	Parameter values of the result sampling points

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. When regular is true, it is assumed that the parameter value array gpar forms a regular tensor-product point grid of dimension gpar[0].size() X gpar[1].size(). Otherwise, we assume that it contains the u and v parameters directly for each sampling point.

Reimplemented from ASMu3D.

References utl::matrixBase< T >::empty(), IntegrandBase::evalSol(), SplineUtils::extractBasis(), utl::matrix< T >::fillColumn(), ASMbase::firstIp, ASM::GEOMETRY_BASIS, getBasis(), ASMu3D::getElementCoordinates(), getElementsAt(), Integrand::getIntegrandType(), ASMmxBase::itgBasis, ASMu3D::lrspline, m_basis, ASMbase::MNPC, ASMmxBase::nb, utl::matrix< T >::resize(), Integrand::SECOND_DERIVATIVES, and utl::vector< T >::size().

◆ evalSolution() [4/7]

bool ASMu3D::evalSolution

Evaluates the secondary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	integrand	Object with problem-specific data and methods
[in]	gpar	Parameter values of the result sampling points

The secondary solution is derived from the primary solution, which is assumed to be stored within the integrand for current patch. We assume that the parameter value array gpar contains the u, v and w parameters directly for each sampling point.

◆ evalSolution() [5/7]

bool ASMu3D::evalSolution

Evaluates the primary solution field at all visualization points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector in DOF-order
[in]	npe	Number of visualization nodes over each knot span
[in]	n_f	If nonzero, mixed evaluates n_f fields on first basis
[in]	piola	If true, use piola mapping

◆ evalSolution() [6/7]

bool ASMu3Dmx::evalSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const RealArray *	gpar,
		bool	,
		int	deriv,
		int	nf
	)		const

virtual

Evaluates the primary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	gpar	Parameter values of the result sampling points
[in]	deriv	Derivative order to return
[in]	nf	If nonzero, evaluates nf fields on first basis

When regular is true, it is assumed that the parameter value array gpar forms a regular tensor-product point grid of dimension gpar[0].size() X gpar[1].size(). Otherwise, we assume that it contains the u and v parameters directly for each sampling point.

Reimplemented from ASMu3D.

References utl::vector< T >::begin(), utl::vector< T >::end(), utl::matrix< T >::fillColumn(), getElementsAt(), m_basis, utl::matrix< T >::multiply(), ASMmxBase::nb, ASMbase::nf, ASMmxBase::nfx, utl::vector< T >::ptr(), and utl::matrix< T >::resize().

◆ evalSolution() [7/7]

bool ASMu3D::evalSolution

Evaluates the primary solution field at the given points.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	gpar	Parameter values of the result sampling points
[in]	deriv	Derivative order to return

◆ extractNodeVec()

void ASMu3Dmx::extractNodeVec	(	const RealArray &	globVec,
		RealArray &	nodeVec,
		unsigned char	,
		int	basis
	)		const

virtual

Extracts nodal results for this patch from the global vector.

Parameters

[in]	globVec	Global solution vector in DOF-order
[out]	nodeVec	Nodal result vector for this patch
[in]	basis	Which basis (or 0 for both) to extract nodal values for

Reimplemented from ASMbase.

References ASMmxBase::extractNodeVecMx().

Referenced by refine().

◆ generateFEMTopology()

bool ASMu3Dmx::generateFEMTopology ( )

virtual

Generates the finite element topology data for the patch.

The data generated are the element-to-node connectivity array, the node-to-IJ-index array, as well as global node and element numbers.

Reimplemented from ASMu3D.

References ASMmxBase::adjustBasis(), ASMmxBase::DIV_COMPATIBLE, ASMmxBase::establishBases(), ASMbase::firstEl, ASMmxBase::FULL_CONT_RAISE_BASIS1, ASMmxBase::FULL_CONT_RAISE_BASIS2, ASMbase::gEl, ASMLRSpline::geomB, ASMbase::gNod, ASMmxBase::includeExtra, ASMmxBase::itgBasis, ASMu3D::lrspline, m_basis, ASMbase::myMLGE, ASMbase::myMLGN, ASMbase::myMNPC, ASMmxBase::nb, ASMbase::nel, ASMbase::nnod, ASMmxBase::NONE, ASMLRSpline::projB, ASMLRSpline::projB2, SplineUtils::Raise, ASMmxBase::REDUCED_CONT_RAISE_BASIS1, ASMmxBase::REDUCED_CONT_RAISE_BASIS2, ASMLRSpline::refB, ASMbase::shareFE, ASMmxBase::SUBGRID, ASMu3D::tensorspline, and ASMmxBase::Type.

◆ generateThreadGroups()

void ASMu3Dmx::generateThreadGroups	(	const Integrand &	integrand,
		bool	silence,
		bool	ignoreGlobalLM
	)

protectedvirtual

Generates element groups for multi-threading of interior integrals.

Parameters

[in]	integrand	Object with problem-specific data and methods
[in]	silence	If true, suppress threading group outprint
[in]	ignoreGlobalLM	If true, ignore global multipliers in sanity check

Reimplemented from ASMu3D.

References ThreadGroups::analyzeUnstruct(), ASMLRSpline::checkThreadGroups(), IFEM::cout, ASMmxBase::DIV_COMPATIBLE, LR::generateThreadGroups(), getBasis(), ASMmxBase::includeExtra, m_basis, ASMLRSpline::proj2ThreadGroups, ASMLRSpline::projB, ASMLRSpline::projB2, ASMLRSpline::projThreadGroups, ASMmxBase::REDUCED_CONT_RAISE_BASIS1, ASMmxBase::REDUCED_CONT_RAISE_BASIS2, ThreadGroups::size(), ASMmxBase::SUBGRID, threadBasis, ASMLRSpline::threadGroups, and ASMmxBase::Type.

◆ getCoord()

Vec3 ASMu3Dmx::getCoord ( size_t inod ) const

virtual

Returns the global coordinates for the given node.

Parameters

[in] inod 1-based node index local to current patch

Reimplemented from ASMu3D.

References getBasis(), ASMmxBase::nb, and ASMbase::nsd.

◆ getElementsAt()

void ASMu3Dmx::getElementsAt	(	const RealArray &	param,
		std::vector< int > &	elms,
		std::vector< size_t > *	sizes = `nullptr`
	)		const

private

Finds the elements and associted sizes at given parametric point.

Parameters

[in]	param	Parametric point to find elements at
[out]	elms	List of elements on each basis containing given point
[out]	sizes	List of element sizes (number of element nodes)

References ASM::GEOMETRY_BASIS, getBasis(), ASMu3D::lrspline, and m_basis.

Referenced by evalSolution(), and integrate().

◆ getNodalDOFs()

unsigned char ASMu3Dmx::getNodalDOFs ( size_t inod ) const

virtual

Returns the number of DOFs per node.

Parameters

[in] inod 1-based node index local to current patch

Reimplemented from ASMbase.

References ASMbase::isLMn(), ASMmxBase::nb, ASMmxBase::nfx, and ASMbase::nLag.

◆ getNodeType()

char ASMu3Dmx::getNodeType ( size_t inod ) const

virtual

Returns the classification of a node.

Parameters

[in] inod 1-based node index local to current patch

Reimplemented from ASMbase.

References ASMbase::isLMn(), and ASMmxBase::nb.

◆ getSolution()

bool ASMu3Dmx::getSolution	(	Matrix &	sField,
		const Vector &	locSol,
		const IntVec &	nodes
	)		const

virtual

Extracts the primary solution field at the specified nodes.

Parameters

[out]	sField	Solution field
[in]	locSol	Solution vector local to current patch
[in]	nodes	1-based local node numbers to extract solution for

Reimplemented from ASMbase.

References ASMmxBase::getSolutionMx().

◆ injectNodeVec()

bool ASMu3Dmx::injectNodeVec	(	const RealArray &	nodeVec,
		RealArray &	globVec,
		unsigned char	,
		int	basis
	)		const

virtual

Injects nodal results for this patch into a global vector.

Parameters

[in]	nodeVec	Nodal result vector for this patch
[out]	globVec	Global solution vector in DOF-order
[in]	basis	Which basis (or 0 for both) to extract nodal values for

Reimplemented from ASMbase.

References ASMmxBase::injectNodeVecMx().

◆ integrate() [1/2]

bool ASMu3Dmx::integrate	(	Integrand &	integrand,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time
	)

virtual

Evaluates an integral over the interior patch domain.

Parameters

	integrand	Object with problem-specific data and methods
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Reimplemented from ASMu3D.

References utl::vector< T >::add(), GlobalIntegral::assemble(), Vec4::assign(), Integrand::AVERAGE, MxFiniteElement::basis(), ASM::cachePolicy, BasisFunctionCache< Dim >::clear(), BasisFunctionCache< Dim >::coord(), LocalIntegral::destruct(), FiniteElement::detJxW, BasisFunctionVals::dNdu, Integrand::ELEMENT_CENTER, Integrand::ELEMENT_CORNERS, ItgPoint::eta, Integrand::evalIntMx(), Integrand::finalizeElement(), ASMbase::firstEl, ASMbase::firstIp, FiniteElement::G, Integrand::G_MATRIX, ASM::GEOMETRY_BASIS, getBasis(), ASMu3D::getElementCoordinates(), ASMu3D::getElementCorners(), getElementsAt(), utl::getGmat(), Integrand::getIntegrandType(), Integrand::getLocalIntegral(), getNoBasis(), BasisFunctionCache< Dim >::getParam(), Integrand::getReducedIntegration(), FiniteElement::h, MxFiniteElement::Hessian(), ItgPoint::idx, ItgPoint::iel, ItgPoint::iGP, Integrand::initElement(), ASMmxBase::itgBasis, MxFiniteElement::Jacobian(), utl::Jacobian(), ASMu3D::lrspline, m_basis, ASMbase::MLGE, ASMbase::MNPC, ASMu3D::myCache, ASMbase::myElms, BasisFunctionVals::N, FiniteElement::Navg, ASMmxBase::nb, ASMbase::nel, ASMbase::nGauss, BasisFunctionCache< Dim >::nGauss(), ThreadGroups::oneGroup(), ASM::PRE_CACHE, PROFILE2, LocalIntegral::ref(), utl::vector< T >::resize(), Integrand::SECOND_DERIVATIVES, ASMmxBase::SUBGRID, TimeDomain::t, threadBasis, ASMLRSpline::threadGroups, GlobalIntegral::threadSafe(), SplineUtils::toVec3(), ASMmxBase::Type, ItgPoint::u, ItgPoint::v, ItgPoint::w, BasisFunctionCache< Dim >::weight(), FiniteElement::XC, ItgPoint::xi, and ItgPoint::zeta.

◆ integrate() [2/2]

bool ASMu3Dmx::integrate	(	Integrand &	integrand,
		int	lIndex,
		GlobalIntegral &	glbInt,
		const TimeDomain &	time
	)

virtual

Evaluates a boundary integral over a patch edge.

Parameters

	integrand	Object with problem-specific data and methods
[in]	lIndex	Local index of the boundary edge
	glbInt	The integrated quantity
[in]	time	Parameters for nonlinear/time-dependent simulations

Reimplemented from ASMu3D.

References ASMbase::firstBp, ASM::GEOMETRY_BASIS, getBasis(), Integrand::getBouIntegrationPoints(), GaussQuadrature::getCoord(), getFaceEnum(), GaussQuadrature::getWeight(), ASMu3D::lrspline, m_basis, ASMbase::myElms, ASMbase::nGauss, and PROFILE2.

◆ refine() [1/4]

bool ASMu3D::refine

Refines the mesh adaptively.

Parameters

[in]	prm	Input data used to control the mesh refinement
	sol	Control point results values that are transferred to new mesh

◆ refine() [2/4]

bool ASMLRSpline::refine

Refines the mesh adaptively.

Parameters

[in]	prm	Input data used to control the mesh refinement
	sol	Control point results values that are transferred to new mesh

References ASMLRSpline::geomB, ASMLRSpline::projB, and ASMLRSpline::projB2.

◆ refine() [3/4]

bool ASMu3Dmx::refine	(	const LR::RefineData &	prm,
		Vectors &	sol
	)

virtual

Refines the mesh adaptively.

Parameters

[in]	prm	Input data used to control the refinement
	sol	Control point results values that are transferred to new mesh

Reimplemented from ASMu3D.

References LR::contractControlPoints(), ASMu3D::copyRefinement(), ASMLRSpline::doRefine(), LR::RefineData::elements, LR::RefineData::errors, LR::extendControlPoints(), extractNodeVec(), TimeIntegration::get(), getBasis(), m_basis, ASMmxBase::nb, ASMmxBase::nfx, ASMLRSpline::projB, ASMLRSpline::projB2, ASMmxBase::REDUCED_CONT_RAISE_BASIS1, ASMmxBase::REDUCED_CONT_RAISE_BASIS2, ASMLRSpline::refB, ASM::REFINEMENT_BASIS, ASMbase::shareFE, ASMmxBase::SUBGRID, and ASMmxBase::Type.

◆ refine() [4/4]

bool ASMu3D::refine

Refines the parametrization by inserting extra tensor knots.

Parameters

[in]	dir	Parameter direction to refine
[in]	xi	Relative positions of added knots in each existing knot span

◆ remapErrors()

void ASMu3Dmx::remapErrors	(	RealArray &	errors,
		const RealArray &	origErr,
		bool	elemErrors
	)		const

virtual

Remaps element-wise errors from geometry mesh to refinement mesh.

Parameters

[out]	errors	The remapped errors
[in]	origErr	The element-wise errors on the geometry mesh
[in]	elemErrors	If true, map to elements and not basis functions

Reimplemented from ASMu3D.

References getBasis(), ASMmxBase::itgBasis, and ASMLRSpline::refB.

The documentation for this class was generated from the following files:

src/ASM/LR/ASMu3Dmx.h
src/ASM/LR/ASMu3Dmx.C

Public Member Functions

Protected Member Functions

Private Types

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ clear()

◆ evalSolution() [1/7]

◆ evalSolution() [2/7]

◆ evalSolution() [3/7]

◆ evalSolution() [4/7]

◆ evalSolution() [5/7]

◆ evalSolution() [6/7]

◆ evalSolution() [7/7]

◆ extractNodeVec()

◆ generateFEMTopology()

◆ generateThreadGroups()

◆ getCoord()

◆ getElementsAt()

◆ getNodalDOFs()

◆ getNodeType()

◆ getSolution()

◆ injectNodeVec()

◆ integrate() [1/2]

◆ integrate() [2/2]

◆ refine() [1/4]

◆ refine() [2/4]

◆ refine() [3/4]

◆ refine() [4/4]

◆ remapErrors()
