Explicit Runge-Kutta based time stepping for SIM classes. More...

#include <SIMExplicitRK.h>

Inheritance diagram for TimeIntegration::SIMExplicitRK< Solver >:

Collaboration diagram for TimeIntegration::SIMExplicitRK< Solver >:

[legend]

Public Member Functions
	SIMExplicitRK (Solver &solv, Method type, bool standalone=true)
	Constructor. More...

const ProcessAdm &	getProcessAdm () const
	Returns the parallel process administrator. More...

virtual bool	solveStep (TimeStep &tp)
	Computes the solution for the current time step. More...

bool	solveRK (Vectors &stages, const TimeStep &tp)
	Applies the Runge-Kutta scheme. More...

bool	advanceStep (TimeStep &tp)
	Advances the time step one step forward. More...

bool	saveModel (char *fileName, int &geoBlk, int &nBlock)
	Opens a new VTF-file and writes the model geometry to it. More...

bool	saveStep (const TimeStep &tp, int &nBlock)
	Saves the converged results of a given time step to VTF file. More...

void	registerFields (DataExporter &exporter)
	Registers fields for output to a data exporter. More...

bool	serialize (std::map< std::string, std::string > &data)
	Serialize internal state for restarting purposes. More...

bool	deSerialize (const std::map< std::string, std::string > &data)
	Set internal state from a serialized state. More...

void	setLinear (bool enable)
	Mark operator as linear to avoid repeated assembly and factorization.

Protected Attributes
Solver &	solver
	Reference to simulator.

RKTableaux	RK
	Tableaux of Runge-Kutta coefficients.

bool	alone
	If true, this is a standalone solver.

bool	linear = false
	If true mass matrix is constant.

Detailed Description

template<class Solver>
class TimeIntegration::SIMExplicitRK< Solver >

Explicit Runge-Kutta based time stepping for SIM classes.

Template can be instanced over any SIM implementing ISolver, and which derive from SIMbase.

Constructor & Destructor Documentation

◆ SIMExplicitRK()

template<class Solver >

TimeIntegration::SIMExplicitRK< Solver >::SIMExplicitRK	(	Solver &	solv,
		Method	type,
		bool	standalone = `true`
	)

inline

Constructor.

Parameters

solv	The simulator to do time stepping for
type	The Runge-Kutta scheme to use
standalone	If true, this is a standalone solver

References TimeIntegration::RKTableaux::A, TimeIntegration::RKTableaux::b, TimeIntegration::RKTableaux::c, TimeIntegration::EULER, TimeIntegration::HEUN, TimeIntegration::RKTableaux::order, utl::matrix< T >::resize(), TimeIntegration::SIMExplicitRK< Solver >::RK, TimeIntegration::RK3, and TimeIntegration::RK4.

Member Function Documentation

◆ advanceStep()

template<class Solver >

bool TimeIntegration::SIMExplicitRK< Solver >::advanceStep ( TimeStep & tp )

inline

Advances the time step one step forward.

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ deSerialize()

template<class Solver >

bool TimeIntegration::SIMExplicitRK< Solver >::deSerialize ( const std::map< std::string, std::string > & data )

inline

Set internal state from a serialized state.

Parameters

[in] data Container for serialized data

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ getProcessAdm()

template<class Solver >

const ProcessAdm& TimeIntegration::SIMExplicitRK< Solver >::getProcessAdm ( ) const

inline

Returns the parallel process administrator.

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ registerFields()

template<class Solver >

void TimeIntegration::SIMExplicitRK< Solver >::registerFields ( DataExporter & exporter )

inline

Registers fields for output to a data exporter.

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ saveModel()

template<class Solver >

bool TimeIntegration::SIMExplicitRK< Solver >::saveModel	(	char *	fileName,
		int &	geoBlk,
		int &	nBlock
	)

inline

Opens a new VTF-file and writes the model geometry to it.

Parameters

[in]	fileName	File name used to construct the VTF-file name from
[out]	geoBlk	Running geometry block counter
[out]	nBlock	Running result block counter

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ saveStep()

template<class Solver >

bool TimeIntegration::SIMExplicitRK< Solver >::saveStep	(	const TimeStep &	tp,
		int &	nBlock
	)

inline

Saves the converged results of a given time step to VTF file.

Parameters

[in]	tp	Time stepping parameters
[in]	nBlock	Running VTF block counter

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ serialize()

template<class Solver >

bool TimeIntegration::SIMExplicitRK< Solver >::serialize ( std::map< std::string, std::string > & data )

inline

Serialize internal state for restarting purposes.

Parameters

data	Container for serialized data

References TimeIntegration::SIMExplicitRK< Solver >::solver.

◆ solveRK()

template<class Solver >

bool TimeIntegration::SIMExplicitRK< Solver >::solveRK	(	Vectors &	stages,
		const TimeStep &	tp
	)

inline

Applies the Runge-Kutta scheme.

Parameters

	stages	Vector of stage vectors
[in]	tp	Time stepping information

References TimeIntegration::RKTableaux::A, utl::vector< T >::add(), TimeIntegration::SIMExplicitRK< Solver >::alone, TimeIntegration::RKTableaux::b, TimeIntegration::RKTableaux::c, TimeDomain::dt, TimeIntegration::SIMExplicitRK< Solver >::linear, utl::vector< T >::resize(), TimeIntegration::SIMExplicitRK< Solver >::RK, TimeIntegration::SIMExplicitRK< Solver >::solver, TimeStep::step, TimeDomain::t, and TimeStep::time.

Referenced by TimeIntegration::SIMExplicitRK< Solver >::solveStep(), and TimeIntegration::SIMExplicitRKE< Solver >::solveStep().

◆ solveStep()

template<class Solver >

virtual bool TimeIntegration::SIMExplicitRK< Solver >::solveStep ( TimeStep & tp )

inlinevirtual

Computes the solution for the current time step.

Reimplemented in TimeIntegration::SIMExplicitRKE< Solver >.

References TimeIntegration::SIMExplicitRK< Solver >::alone, TimeIntegration::SIMExplicitRK< Solver >::solver, TimeIntegration::SIMExplicitRK< Solver >::solveRK(), TimeStep::step, TimeDomain::t, and TimeStep::time.

The documentation for this class was generated from the following file:

Apps/Common/SIMExplicitRK.h
