DataExporter Class Reference

Administer and write data using DataWriters. More...

#include <DataExporter.h>

Inheritance diagram for DataExporter:

Collaboration diagram for DataExporter:

Classes
struct	FileEntry
	A structure holding information about registered fields. More...

Public Types
enum	FieldType {   VECTOR , INTVECTOR , KNOTSPAN , SIM ,   NODALFORCES , BASIS }
	Supported field types.
enum	Results {   PRIMARY = 1 , DISPLACEMENT = 2 , SECONDARY = 4 , NORMS = 8 ,   EIGENMODES = 16 , ONCE = 32 , GRID = 128 , REDUNDANT = 256 ,   L2G_NODE = 512 , ELEMENT_MASK = 1024 }
	An enum used to describe the results to write from a SIM. More...

Public Member Functions
	DataExporter (bool dynWriters=false, int ndump=1, int level0=0)
	Default constructor. More...
virtual	~DataExporter ()
	The destructor deletes the writers if dynWriters was true.
void	registerWriter (DataWriter *writer)
	Adds the data writer to the list of registered writers.
bool	registerField (const std::string &name, const std::string &description, FieldType field, int results=PRIMARY, const std::string &prefix="", int ncmps=0)
	Registers an entry for storage. More...
bool	setFieldValue (const std::string &name, const void *data, const void *data2=nullptr, const void *data3=nullptr, const void *data4=nullptr)
	Sets the data values for a registered field. More...
bool	dumpTimeLevel (const TimeStep *tp=nullptr, bool geoUpd=false, bool doLog=false)
	Dumps all registered fields using the registered writers. More...
virtual void	OnControl (const tinyxml2::XMLElement *context)
	Callback on receiving a XML control block from external controller.
virtual std::string	GetContext () const
	Returns context name for callback for external controller.
std::string	getName () const
	Returns name from (first) data writer.
int	getTimeLevel () const
	Returns current time level of the exporter.
int	getStride () const
	Returns the data dump stride.

Protected Attributes
std::map< std::string, FileEntry >	m_entry
	A map of field names -> field info structures.
std::vector< DataWriter * >	m_writers
	A vector of registered data writers.
bool	m_delete
	If true, we are in charge of freeing up datawriters.
int	m_ndump
	Time level stride for dumping.
int	m_level
	Current time level.
int	m_last_step
	Last time step we dumped for.

Detailed Description

Administer and write data using DataWriters.

This class holds a list of data writers, and the SIM classes or vectors to write.

Member Enumeration Documentation

Results

enum DataExporter::Results

An enum used to describe the results to write from a SIM.

Enumerator
PRIMARY	Storage of primary solutions.
DISPLACEMENT	Storage of vector fields as displacements.
SECONDARY	Storage of secondary field.
NORMS	Storage of norms.
EIGENMODES	Storage of eigenmodes.
ONCE	Only write field once.
GRID	Always store an updated grid.
REDUNDANT	Field is redundantly calculated on all processes.
L2G_NODE	Storage of local-to-global node mapping.
ELEMENT_MASK	Storage of element activation flags.

Constructor & Destructor Documentation

DataExporter()

DataExporter::DataExporter ( bool  dynWriters = false, int  ndump = 1, int  level0 = 0  )

inline

Default constructor.

Parameters

[in]	dynWriters	If true, delete the writers on destruction
[in]	ndump	Interval between dumps
[in]	level0	Time level to start dumping from (in case of restart)

Member Function Documentation

dumpTimeLevel()

bool DataExporter::dumpTimeLevel	(	const TimeStep *	tp = nullptr,
		bool	geoUpd = false,
		bool	doLog = false
	)

Dumps all registered fields using the registered writers.

Parameters

[in]	tp	Current time stepping info
[in]	geoUpd	If true, write updated geometry as well
[in]	doLog	If true, write a log message when dumping data

References IFEM::cout, m_entry, m_last_step, m_level, m_ndump, m_writers, TimeStep::multiSteps(), ONCE, PROFILE1, TimeStep::step, TimeDomain::t, and TimeStep::time.

Referenced by SIMSolver< T1 >::saveState(), SIMSolverAdapInternal< T1 >::saveState(), and SIMSolverStat< T1 >::solveProblem().

registerField()

bool DataExporter::registerField	(	const std::string &	name,
		const std::string &	description,
		FieldType	field,
		int	results = PRIMARY,
		const std::string &	prefix = "",
		int	ncmps = 0
	)

Registers an entry for storage.

Parameters

[in]	name	Name of entry
[in]	description	Description of entry
[in]	field	Type of entry
[in]	results	Which results to store
[in]	prefix	Field name prefix
[in]	ncmps	Number of field components

References DataExporter::FileEntry::description, DataExporter::FileEntry::enabled, DataExporter::FileEntry::field, m_entry, DataExporter::FileEntry::ncmps, DataExporter::FileEntry::prefix, and DataExporter::FileEntry::results.

setFieldValue()

bool DataExporter::setFieldValue	(	const std::string &	name,
		const void *	data,
		const void *	data2 = nullptr,
		const void *	data3 = nullptr,
		const void *	data4 = nullptr
	)

Sets the data values for a registered field.

Parameters

[in]	name	Name the field is registered with
[in]	data	The value to set the field to
[in]	data2	(optional) The secondary data of the field
[in]	data3	(optional) The third data of the field
[in]	data4	(optional) The fourth data of the field

References m_entry.

---

The documentation for this class was generated from the following files:

• src/Utility/DataExporter.h
• src/Utility/DataExporter.C
