A vector-valued spatial function, defined through a vector field. More...

#include <FieldFunctions.h>

Inheritance diagram for VecFieldFunction:

[legend]

Collaboration diagram for VecFieldFunction:

[legend]

Public Member Functions
	VecFieldFunction (const std::string &fileName, const std::string &basisName, const std::string &fieldName, int level=0)
	The constructor creates a field from the provided HDF5-file. More...

	VecFieldFunction (const std::vector< Fields * > &fields)
	Wrap existing fields. More...

virtual	~VecFieldFunction ()
	Empty destructor.

bool	initPatch (size_t pIdx) override
	Sets the active patch.

Public Member Functions inherited from VecFunc
unsigned char	getType () const override
	Returns the function type flag.

std::vector< Real >	getValue (const Vec3 &X) const override
	Returns the function value as an array.

Real	getScalarValue (const Vec3 &X) const override
	Returns a representative scalar equivalent of the function value.

Tensor	gradient (const Vec3 &X) const
	Evaluates first derivatives of the function.

utl::matrix3d< Real >	hessian (const Vec3 &X) const
	Evaluates second derivatives of the function.

Vec3	timeDerivative (const Vec3 &X) const
	Evaluates time derivatives of the function.

Public Member Functions inherited from utl::SpatialFunction< Vec3 >
virtual Vec3	deriv (const Vec3 &, int) const
	Returns a first-derivative of the function.

virtual Vec3	dderiv (const Vec3 &, int, int) const
	Returns a second-derivative of the function.

Public Member Functions inherited from utl::Function< Arg, Result >
virtual	~Function ()
	Empty destructor.

virtual bool	isZero () const
	Returns whether the function is identically zero or not.

virtual bool	isConstant () const
	Returns whether the function is time-independent or not.

Result	operator() (const Arg &x) const
	Operator returning the function value for the given argument.

Public Member Functions inherited from FunctionBase
virtual	~FunctionBase ()
	Empty destructor.

size_t	dim () const
	Returns the number of components of the return value.

virtual bool	inDomain (const Vec3 &) const
	Checks if a specified point is within the function domain.

virtual void	setParam (const std::string &, Real)
	Sets an additional parameter in the function.

void	setParam (const std::string &name, const Vec3 &value)
	Sets additional parameter values in the function.

Protected Member Functions
Vec3	evaluate (const Vec3 &X) const override
	Evaluates the vectorial field function.

std::vector< Real >	evalGradient (const Vec3 &X) const override
	Returns the gradient of the function as a 1D array.

std::vector< Real >	evalHessian (const Vec3 &X) const override
	Returns the hessian of the function as a 1D array.

Protected Member Functions inherited from VecFunc
	VecFunc (size_t n=3)
	The constructor is protected to allow sub-class instances only.

Protected Member Functions inherited from utl::SpatialFunction< Vec3 >
	SpatialFunction (const Vec3 &val)
	The constructor is protected to allow sub-class instances only.

virtual std::vector< Real >	evalTimeDerivative (const Vec3 &) const
	Returns the time derivatives of the function as a 1D array.

Protected Member Functions inherited from utl::Function< Arg, Result >
	Function ()
	The constructor is protected to allow sub-class instances only.

virtual Result	evaluate (const Arg &x) const =0
	Evaluates the function for the argument x.

Protected Member Functions inherited from FunctionBase
	FunctionBase ()
	The constructor is protected to allow sub-class instances only.

Additional Inherited Members
Public Types inherited from utl::Function< Arg, Result >
typedef Arg	Input
	Input type.

typedef Result	Output
	Output type.

Protected Attributes inherited from utl::SpatialFunction< Vec3 >
Vec3	zero
	Return value for default implementations of derivatives.

Protected Attributes inherited from FunctionBase
size_t	ncmp
	Number of components in the return value.

Private Member Functions inherited from FieldsFuncBase
	FieldsFuncBase (const std::vector< Fields * > &fields)
	Construct from vector of fields. More...

	FieldsFuncBase (const std::string &fileName, const std::string &basisName, const std::string &fieldName, int level)
	The constructor creates a field from the provided HDF5-file. More...

virtual	~FieldsFuncBase ()
	The destructor deletes the vector fields.

virtual void	addPatchField (ASMbase *pch, const std::vector< Real > &coefs, int nf, int basis)
	Adds a patch-wise field with the given coefficient values. More...

virtual void	clearField ()
	Clears the field container.

std::vector< Real >	getValues (const Vec3 &X)
	Evaluates the field at the givent point X.

std::vector< Real >	getGradient (const Vec3 &X) const
	Evaluates the field gradient at the givent point X.

std::vector< Real >	getHessian (const Vec3 &X) const
	Evaluates the field gradient at the givent point X.

Private Member Functions inherited from FieldFuncHDF5
	FieldFuncHDF5 ()
	Default constructor.

	FieldFuncHDF5 (const std::string &fileName)
	The constructor opens the provided HDF5-file. More...

	FieldFuncHDF5 (const FieldFuncHDF5 &)=delete
	No copying of this class.

virtual	~FieldFuncHDF5 ()
	The destructor closes the HDF5-file.

bool	load (const std::vector< std::string > &fieldNames, const std::string &basisName, int level, bool isScalar=false)
	Loads field values for the specified time level. More...

int	findClosestLevel (double time) const
	Finds the level whose time is closest to the specified time.

Private Member Functions inherited from FieldFuncBase
	FieldFuncBase ()
	Default constructor.

	FieldFuncBase (const FieldFuncBase &)=delete
	No copying of this class.

virtual	~FieldFuncBase ()
	The destructor deletes the patches.

bool	setPatch (size_t pIdx)
	Sets the active patch.

Private Attributes inherited from FieldsFuncBase
std::vector< std::string >	fName
	Name of field components.

std::string	bName
	Name of basis.

std::vector< Fields * >	field
	The vector field to be evaluated.

Private Attributes inherited from FieldFuncHDF5
bool	hasMultipleLevels
	True if we have multiple time levels.

int	lastLevel
	The last time level read from.

Private Attributes inherited from FieldFuncBase
std::vector< ASMbase * >	patch
	The patches on which the field is defined.

size_t	pidx
	Current patch index.

size_t	npch
	Number of patches in the field.

Static Private Attributes inherited from FieldFuncBase
static constexpr int	FIXED_LEVEL = 1 << 24
	Bit flag in level for using fixed.

Detailed Description

A vector-valued spatial function, defined through a vector field.

Constructor & Destructor Documentation

◆ VecFieldFunction() [1/2]

VecFieldFunction::VecFieldFunction	(	const std::string &	fileName,
		const std::string &	basisName,
		const std::string &	fieldName,
		int	level = `0`
	)

The constructor creates a field from the provided HDF5-file.

Parameters

[in]	fileName	Name of the HDF5-file
[in]	basisName	Name of the basis which the field values refer to
[in]	fieldName	Name of the field in the HDF5-file
[in]	level	Time level to read for

References FieldsFuncBase::field, and FunctionBase::ncmp.

◆ VecFieldFunction() [2/2]

VecFieldFunction::VecFieldFunction ( const std::vector< Fields * > & fields )

Wrap existing fields.

Parameters

fields Fields to evaluate

Takes ownership of given fields.

References FunctionBase::ncmp, and FieldFuncBase::npch.

The documentation for this class was generated from the following files:

src/Utility/FieldFunctions.h
src/Utility/FieldFunctions.C
