ReactionsOnly Class Reference

Class for assembly of reaction- and interface forces. More...

#include <ReactionsOnly.h>

Inheritance diagram for ReactionsOnly:

Collaboration diagram for ReactionsOnly:

Public Member Functions
	ReactionsOnly (const SAM *sam, const ProcessAdm &adm, RealArray *rf=nullptr, Vector *sf=nullptr)
	The constructor initializes the data members. More...
virtual	~ReactionsOnly ()
	Empty destructor.
virtual void	initialize (char)
	Initializes the integrated quantity to zero.
virtual bool	finalize (bool)
	Finalizes the integrated quantity after element assembly.
virtual bool	assemble (const LocalIntegral *elmObj, int elmId)
	Adds a LocalIntegral object into a corresponding global object. More...
virtual bool	haveContributions (size_t pidx, const std::vector< Property > &pvec) const
	Returns true if the patch pidx have any force contributions. More...
Public Member Functions inherited from GlobalIntegral
	GlobalIntegral ()
	The default constructor.
virtual	~GlobalIntegral ()
	Empty destructor.
virtual bool	threadSafe () const
	Returns true if all elements can be assembled in parallel.

Private Attributes
const SAM *	mySam
	Data for FE assembly management.
const ProcessAdm &	myAdm
	Parallel processing administrator.
StdVector	b
	Internal right-hand-side vector used in the force assembly.
RealArray *	R
	Nodal reaction forces.
Vector *	S
	Nodal internal forces.

Detailed Description

Class for assembly of reaction- and interface forces.

This class can be used for linear problems which normally consists of a single assembly loop. For non-linear problems, the reaction forces for a given solution state is calculated during the subsequent iteration where the solution vector of the previous iteration is used. In linear problems we therefore need a separate assembly loop where only the reaction forces are calculated. This class is provided to facilitate such calculations.

The class can also be used to calculate interface force resultants, for boundaries not associated with dirichlet conditions.

Constructor & Destructor Documentation

ReactionsOnly()

ReactionsOnly::ReactionsOnly	(	const SAM *	sam,
		const ProcessAdm &	adm,
		RealArray *	rf = nullptr,
		Vector *	sf = nullptr
	)

The constructor initializes the data members.

Parameters

[in]	sam	Data for FE assembly management
[in]	adm	Parallell processing administrator
[in]	rf	Reaction forces to be assembled
[in]	sf	Internal force vector to be assembled

References b, SAM::getNoEquations(), SAM::getNoSpecifiedDOFs(), R, and StdVector::redim().

Member Function Documentation

assemble()

bool ReactionsOnly::assemble ( const LocalIntegral *  elmObj, int  elmId  )

virtual

Adds a LocalIntegral object into a corresponding global object.

Parameters

[in]	elmObj	The local integral object to add into *this.
[in]	elmId	Global number of the element associated with elmObj

Reimplemented from GlobalIntegral.

References SAM::assembleSystem(), b, ElmMats::getRHSVector(), mySam, and R.

haveContributions()

bool ReactionsOnly::haveContributions ( size_t  pidx, const std::vector< Property > &  pvec  ) const

virtual

Returns true if the patch pidx have any force contributions.

Parameters

[in]	pidx	1-based patch index
[in]	pvec	Physical property mapping

Reimplemented from GlobalIntegral.

References R, and S.

---

The documentation for this class was generated from the following files:

• src/ASM/ReactionsOnly.h
• src/ASM/ReactionsOnly.C
