GlbForceVec Class Reference

Class for storage of a global nodal force vector with assembly methods. More...

#include <GlbForceVec.h>

Inheritance diagram for GlbForceVec:

Collaboration diagram for GlbForceVec:

Public Member Functions
	GlbForceVec (const SAM &_sam)
	The constructor only sets its reference to the SAM object.
virtual	~GlbForceVec ()
	Empty destructor.
bool	initNodeMap (const std::vector< int > &globalNodes, size_t nfc)
	Initializes the global node map and allocates the force vector. More...
virtual void	initialize (char=0)
	Initializes the global nodal force vector to zero.
virtual bool	finalize (bool=false)
	Finalizes the global nodal force vector after element assembly.
virtual bool	assemble (const LocalIntegral *elmObj, int elmId)
	Adds a set of element nodal forces into the global nodal forces. More...
Vec3	getForce (int node) const
	Returns the global nodal force vector for a specified node. More...
Vec3	getTotalForce () const
	Returns the sum of the nodal forces, i.e. total force.
int	getForce (size_t indx, Vec3 &force) const
	Returns the global nodal force vector for a specified node. More...
size_t	size () const
	Returns the size in terms of number of nodes with nodal forces.
Public Member Functions inherited from GlobalIntegral
	GlobalIntegral ()
	The default constructor.
virtual	~GlobalIntegral ()
	Empty destructor.
virtual bool	threadSafe () const
	Returns true if all elements can be assembled in parallel.
virtual bool	haveContributions (size_t, const std::vector< Property > &) const
	Returns false if no contributions from a specified patch.

Private Attributes
const SAM &	sam
	Data for FE assembly management.
Matrix	F
	Global nodal forces.
std::vector< int >	nodeNum
	Global node numbers with forces.
std::map< int, size_t >	nodeMap
	Maps from global node number to force index.

Detailed Description

Class for storage of a global nodal force vector with assembly methods.

Member Function Documentation

assemble()

bool GlbForceVec::assemble ( const LocalIntegral *  elmObj, int  elmId  )

virtual

Adds a set of element nodal forces into the global nodal forces.

Parameters

[in]	elmObj	Pointer to the element nodal forces to add into *this
[in]	elmId	Global number of the element associated with *elmObj

Reimplemented from GlobalIntegral.

References ElmMats::b, F, SAM::getElmNodes(), SAM::getNodeDOFs(), ElmMats::getRHSVector(), nodeMap, utl::matrix< T >::rows(), and sam.

getForce() [1/2]

Vec3 GlbForceVec::getForce

(

int

node

)

const

Returns the global nodal force vector for a specified node.

Parameters

[in]

node

1-based global node number to return the forces for

References F, utl::matrix< T >::getColumn(), and nodeMap.

Referenced by HDF5Writer::writeNodalForces().

getForce() [2/2]

int GlbForceVec::getForce	(	size_t	indx,
		Vec3 &	force
	)		const

Returns the global nodal force vector for a specified node.

Parameters

[in]	indx	0-based node index to return the forces for
[out]	force	The force at the sepcified node

Returns

Global node number of the specified node, or zero if out-of-range

References utl::matrix< T >::cols(), F, utl::matrix< T >::getColumn(), and nodeNum.

initNodeMap()

bool GlbForceVec::initNodeMap	(	const std::vector< int > &	globalNodes,
		size_t	nfc
	)

Initializes the global node map and allocates the force vector.

Parameters

[in]	globalNodes	The global node numbers that will have force terms
[in]	nfc	Number of force components

References F, SAM::getNoNodes(), nodeMap, nodeNum, utl::matrix< T >::resize(), and sam.

Referenced by SIM::initBoundaryNodeMap().

---

The documentation for this class was generated from the following files:

• src/ASM/GlbForceVec.h
• src/ASM/GlbForceVec.C
