Class representing the block element matrices for a FEM problem. More...

#include <BlockElmMats.h>

Inheritance diagram for BlockElmMats:

Collaboration diagram for BlockElmMats:

[legend]

Classes
struct	Basis
	A struct with some key parameters for each basis. More...

struct	Block
	A struct with some key parameters for each block. More...

Public Member Functions
	BlockElmMats (size_t nBlk, size_t nBas)
	The constructor initializes the block information arrays. More...

virtual	~BlockElmMats ()
	Empty destructor.

bool	redim (size_t blkIndex, size_t nen, size_t ncmp=1, char basis=1)
	Sets the dimension of a diagonal block sub-matrix. More...

bool	redimOffDiag (size_t blkIndex, char symmetric=1)
	Sets the dimension of an off-diagonal block sub-matrix. More...

bool	finalize ()
	Calculates the dimension of the Newton matrix. More...

virtual const Matrix &	getNewtonMatrix () const
	Returns the element-level Newton matrix.

virtual const Vector &	getRHSVector () const
	Returns the element-level right-hand-side vector.

void	redim (size_t ndim)
	Sets the dimension of the element matrices and vectors. More...

Public Member Functions inherited from ElmMats
	ElmMats (bool lhs=true)
	Default constructor.

virtual	~ElmMats ()
	Empty destructor.

void	resize (size_t nA, size_t nB, size_t nC=0)
	Defines the number of element matrices and vectors. More...

void	redim (size_t ndim)
	Sets the dimension of the element matrices and vectors. More...

virtual bool	empty () const
	Checks if the element matrices are empty.

virtual void	setStepSize (double, int)
	Updates the time step size.

void	printMat (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const
	Prints element matrix idx to output stream os.

void	printVec (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const
	Prints element vector idx to output stream os.

void	printScl (std::ostream &os, size_t idx=0, const char *prefix=nullptr) const
	Prints element scalar idx to output stream os.

Public Member Functions inherited from LocalIntegral
virtual	~LocalIntegral ()
	Empty destructor.

virtual void	destruct ()
	Virtual destruction method to clean up after numerical integration.

virtual const LocalIntegral *	ref () const
	Returns the LocalIntegral object to assemble into the global one.

void	getSolution (size_t nsd, size_t nen, Matrix u=nullptr, Matrix v=nullptr, Matrix *a=nullptr, bool forceCurrent=false) const
	Extracts element solution vectors as nsd by nen matrices. More...

Private Attributes
size_t	neldof
	Size of newton matrix.

std::vector< Block >	blockInfo
	Block information.

std::vector< Basis >	basisInfo
	Basis information.

std::vector< char >	symmFlag
	Symmetry flag for off-diagonal blocks.

Additional Inherited Members
Public Attributes inherited from ElmMats
std::vector< Matrix >	A
	The element coefficient matrices.

std::vector< Vector >	b
	The element right-hand-side vectors.

std::vector< double >	c
	The scalar quantities.

std::vector< const char * >	Aname
	Matrix names (for debug print)

std::vector< const char * >	Bname
	Vector names (for debug print)

std::vector< const char * >	Cname
	Scalar names (for debug print)

bool	rhsOnly
	If true, only the right-hand-sides are assembled.

bool	withLHS
	If true, left-hand-side element matrices are present.

Public Attributes inherited from LocalIntegral
Vectors	vec
	Element-level primary solution vectors.

Protected Member Functions inherited from LocalIntegral
	LocalIntegral ()
	The default constructor is protected to allow sub-classes only.

Detailed Description

Class representing the block element matrices for a FEM problem.

This class can be used for multi-integrand FEM problems with strong coupling, where the element matrices typically consist of blocks resulting from the various integrands. The block sub-matrices are stitched together into an element-level Newton matrix corresponding to all DOFs of the element by the getNewtonMatrix() method.

Constructor & Destructor Documentation

◆ BlockElmMats()

BlockElmMats::BlockElmMats	(	size_t	nBlk,
		size_t	nBas
	)

inline

The constructor initializes the block information arrays.

Parameters

[in]	nBlk	Number of matrix blocks (in each direction, row & column)
[in]	nBas	Number of bases (> 1 for mixed problems)

Member Function Documentation

◆ finalize()

bool BlockElmMats::finalize ( )

Calculates the dimension of the Newton matrix.

This method must not be invoked until the redim method has been invoked for all the diagonal blocks.

References basisInfo, blockInfo, and neldof.

◆ redim() [1/2]

bool BlockElmMats::redim	(	size_t	blkIndex,
		size_t	nen,
		size_t	ncmp = `1`,
		char	basis = `1`
	)

Sets the dimension of a diagonal block sub-matrix.

Parameters

[in]	blkIndex	Sub-matrix block index
[in]	nen	Number of element nodes for this matrix block
[in]	ncmp	Number of nodal components for this matrix block
[in]	basis	Basis index associated with this block. If negative, this diagonal block is identically zero, but the dimension parameters are used for the associated off-diagonal blocks later.

References ElmMats::A, ElmMats::b, basisInfo, and blockInfo.

◆ redim() [2/2]

void ElmMats::redim

Sets the dimension of the element matrices and vectors.

Parameters

[in] ndim Number of rows and columns in the matrices/vectors

◆ redimOffDiag()

bool BlockElmMats::redimOffDiag	(	size_t	blkIndex,
		char	symmetric = `1`
	)

Sets the dimension of an off-diagonal block sub-matrix.

Parameters

[in]	blkIndex	Sub-matrix block index
[in]	symmetric	Symmetry flag (0: not, 1: yes, -1: skew-symmetric)

This method must not be invoked until the redim method has been invoked for all the diagonal blocks.

References ElmMats::A, basisInfo, blockInfo, and symmFlag.

The documentation for this class was generated from the following files:

src/ASM/BlockElmMats.h
src/ASM/BlockElmMats.C
