Class that checks if an element has interface contributions. More...
Inheritance diagram for ASMs2DIB::Intersected:
Collaboration diagram for ASMs2DIB::Intersected:
Public Member Functions | |
| Intersected (const ASMs2DIB &pch, bool all=false, bool sw=false) | |
| The constructor initialises the reference to current patch. | |
| virtual | ~Intersected () |
| Empty destructor. | |
| virtual short int | hasContribution (int, int I, int J, int=-1) const |
| Returns non-zero if the specified element have contributions. More... | |
 Public Member Functions inherited from ASMs2D::InterfaceChecker | |
| InterfaceChecker (const ASMs2D &pch) | |
| The constructor initialises the reference to current patch. | |
| virtual | ~InterfaceChecker () |
| Empty destructor. | |
| Public Member Functions inherited from ASM::InterfaceChecker | |
| virtual short int | elmBorderMask (double u0, double u1, double v0, double v1, double w0=0.0, double w1=1.0) const |
| Returns a status mask based on the element boundary parameters. More... | |
Private Attributes | |
| bool | myAll |
| If true, consider all element interfaces. | |
| bool | alsoSW |
| If true, consider south/west neighbors too. | |
Additional Inherited Members | |
| Protected Attributes inherited from ASMs2D::InterfaceChecker | |
| const ASMs2D & | myPatch |
| Reference to the patch being integrated. | |
Detailed Description
Class that checks if an element has interface contributions.
The class has one member function that checks if the specified element is intersected by the immersed boundary, or if it is neighbor to an element that is intersected.
Member Function Documentation
◆ hasContribution()
|
virtual |
Returns non-zero if the specified element have contributions.
- Parameters
-
[in] I Index in first parameter direction of the element [in] J Index in second parameter direction of the element
Reimplemented from ASMs2D::InterfaceChecker.
References alsoSW, ASMs2DIB::isIntersected(), myAll, ASMs2D::InterfaceChecker::myPatch, ASMs2DIB::quadPoints, and ASMs2D::surf.
The documentation for this class was generated from the following files:
- src/ASM/ASMs2DIB.h
- src/ASM/ASMs2DIB.C
