Class for representing the system matrix on the SPR-format. More...

#include <SPRMatrix.h>

Inheritance diagram for SPRMatrix:

Collaboration diagram for SPRMatrix:

[legend]

Public Member Functions
	SPRMatrix ()
	Default constructor.

	SPRMatrix (const SPRMatrix &A)
	Copy constructor.

virtual	~SPRMatrix ()
	The destructor frees the dynamically allocated arrays.

virtual LinAlg::MatrixType	getType () const
	Returns the matrix type.

virtual SystemMatrix *	copy () const
	Creates a copy of the system matrix and returns a pointer to it.

SPRMatrix &	operator= (const SPRMatrix &)=delete
	This class is not copyable.

virtual size_t	dim (int idim) const
	Returns the dimension of the system matrix.

virtual void	initAssembly (const SAM &sam, char)
	Initializes the element assembly process. More...

virtual void	init ()
	Initializes the matrix to zero assuming it is properly dimensioned.

virtual bool	assemble (const Matrix &eM, const SAM &sam, int e)
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const SAM &sam, SystemVector &B, int e)
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const SAM &sam, SystemVector &B, const IntVec &meq)
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const IntVec &meq)
	Adds an element matrix into the associated system matrix. More...

virtual void	mult (Real alpha)
	Multiplication with a scalar.

virtual bool	add (const SystemMatrix &B, Real alpha)
	Adds a matrix with similar sparsity pattern to the current matrix. More...

virtual bool	add (Real sigma, int ieq)
	Adds the constant σ to the diagonal of this matrix.

virtual bool	multiply (const SystemVector &B, SystemVector &C) const
	Performs the matrix-vector multiplication C = this B.

virtual bool	solve (SystemVector &B, Real *)
	Solves the linear system of equations for a given right-hand-side. More...

bool	solveEig (SPRMatrix &B, RealArray &val, Matrix &vec, int nev, Real shift=0.0, int iop=1)
	Solves a generalized symmetric-definite eigenproblem. More...

virtual Real	Linfnorm () const
	Returns the L-infinity norm of the matrix.

bool	convert (Matrix &fullMat) const
	Converts to a dense matrix.

virtual void	dump (std::ostream &os, LinAlg::StorageFormat fmt, const char *)
	Dumps the system matrix on a specified format.

virtual bool	load (const char *fileName, bool binary)
	Loads the system matrix from specified file.

virtual bool	assemble (const Matrix &eM, const SAM &sam, int e)=0
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const SAM &sam, SystemVector &B, int e)=0
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const SAM &sam, SystemVector &B, const IntVec &meq)=0
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const IntVec &meq)=0
	Adds an element matrix into the associated system matrix. More...

virtual bool	solve (SystemVector &b, Real *rc=nullptr)=0
	Solves the linear system of equations for a given right-hand-side. More...

virtual bool	solve (const SystemVector &b, SystemVector &x)
	Solves the linear system of equations for a given right-hand-side. More...

Public Member Functions inherited from SystemMatrix
virtual	~SystemMatrix ()
	Empty destructor.

virtual bool	lockPattern (bool)
	Locks or unlocks the sparsity pattern.

virtual bool	empty () const
	Checks if the matrix is empty.

bool	isZero () const
	Checks if the matrix have no non-zero contributions.

virtual void	preAssemble (const std::vector< IntVec > &, size_t=0)
	Initializes the element sparsity pattern based on node connections.

virtual void	compressPattern ()
	Compresses the sparsity pattern.

void	initNonZeroEqs ()
	Initializes the nonZeroEqs flags.

bool	flagNonZeroEqs (const IntVec &meq={})
	Flags the equations meq as pivots with non-zero contributions.

bool	flagNonZeroEqs (const SystemMatrix &B)
	Flags the non-zero equations from B as non-zero pivots in this.

virtual bool	endAssembly ()
	Finalizes the system matrix assembly. More...

virtual bool	augment (const SystemMatrix &, size_t, size_t)
	Augments a similar matrix symmetrically to the current matrix.

virtual bool	truncate (Real=Real(1.0e-16))
	Truncates all small matrix elements to zero.

virtual bool	solve (const SystemVector &b, SystemVector &x)
	Solves the linear system of equations for a given right-hand-side. More...

virtual void	dump (const char *fileName, std::streamsize precision=0, LinAlg::StorageFormat format=LinAlg::FLAT)
	Dumps the system matrix to specified file.

StdVector	operator* (const SystemVector &b) const
	Calculates a matrix-vector product.

StdVector	operator/ (const SystemVector &b)
	Solves a linear equation system.

Protected Member Functions
bool	assemble (int e, const Matrix &eM, const SAM &sam, Real *B=nullptr)
	Adds an element matrix into the associated system matrix. More...

bool	multiply (size_t n, const Real b, Real c)
	Performs the matrix-vector multiplication c = this b.

virtual std::ostream &	write (std::ostream &os) const
	Writes the system matrix to the given output stream.

Protected Member Functions inherited from SystemMatrix
	SystemMatrix ()
	Default constructor.

	SystemMatrix (const SystemMatrix &a)
	Copy constructor.

Private Types
using	SAM64 = SAM
	Convenience alias when using 32-bit int version.

Private Attributes
Int_	ierr
	Internal error flag.

Int_	mpar [NS]
	Matrix of sparse PARameters.

Int_ *	msica
	Matrix of Storage Information for CA.

Int_ *	msifa
	Matrix of Storage Information for FA.

Int_ *	mtrees
	Matrix of elimination assembly TREES.

Int_ *	mvarnc
	Matrix of VARiable to Node Correspondence.

Real *	values
	The actual matrix VALUES.

std::vector< Int_ >	iWork
	Integer work array.

std::vector< Int_ > *	jWork
	Integer work arrays for multi-threaded assembly.

std::vector< Real >	rWork
	Real work array.

SAM64 *	mySam
	Possibly 64-bit integer version of SAM arrays.

Additional Inherited Members
Static Public Member Functions inherited from SystemMatrix
static SystemMatrix *	create (const ProcessAdm *adm, LinAlg::MatrixType mType, int num_thread_SLU=1)
	Static method creating a matrix of the given type.

static SystemMatrix *	create (const ProcessAdm *adm, LinAlg::MatrixType mType, const LinSolParams &spar)
	Static method creating a matrix of the given type.

Detailed Description

Class for representing the system matrix on the SPR-format.

It is an interface to a Fortran module for assembling and solving linear systems of equations.

Member Function Documentation

◆ add()

bool SPRMatrix::add	(	const SystemMatrix &	B,
		Real	alpha
	)

virtual

Adds a matrix with similar sparsity pattern to the current matrix.

Parameters

[in]	B	The matrix to be added
[in]	alpha	Scale factor for matrix B

Reimplemented from SystemMatrix.

References SystemMatrix::flagNonZeroEqs(), SystemMatrix::isZero(), mpar, and values.

◆ assemble() [1/9]

bool SPRMatrix::assemble	(	const Matrix &	eM,
		const IntVec &	meq
	)

virtual

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	meq	Matrix of element equation numbers (0 based)

Returns: true on successful assembly, otherwise false

To be used when there is no underlying SAM

Implements SystemMatrix.

◆ assemble() [2/9]

virtual bool SystemMatrix::assemble

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	meq	Matrix of element equation numbers (0 based)

Returns: true on successful assembly, otherwise false

To be used when there is no underlying SAM

◆ assemble() [3/9]

bool SPRMatrix::assemble	(	const Matrix &	eM,
		const SAM &	sam,
		int	e
	)

virtual

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
[in]	e	Identifier for the element that eM belongs to

Returns: true on successful assembly, otherwise false

Implements SystemMatrix.

References assemble().

◆ assemble() [4/9]

virtual bool SystemMatrix::assemble

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
[in]	e	Identifier for the element that eM belongs to

Returns: true on successful assembly, otherwise false

Referenced by assemble().

◆ assemble() [5/9]

bool SPRMatrix::assemble	(	const Matrix &	eM,
		const SAM &	sam,
		SystemVector &	B,
		const IntVec &	meq
	)

virtual

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
	B	The system right-hand-side vector
[in]	meq	Matrix of element equation numbers

Returns: true on successful assembly, otherwise false

When multi-point constraints are present, contributions from these are also added into the system right-hand-side vector, B.

Implements SystemMatrix.

◆ assemble() [6/9]

virtual bool SystemMatrix::assemble

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
	B	The system right-hand-side vector
[in]	meq	Matrix of element equation numbers

Returns: true on successful assembly, otherwise false

When multi-point constraints are present, contributions from these are also added into the system right-hand-side vector, B.

◆ assemble() [7/9]

bool SPRMatrix::assemble	(	const Matrix &	eM,
		const SAM &	sam,
		SystemVector &	B,
		int	e
	)

virtual

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
	B	The system right-hand-side vector
[in]	e	Identifier for the element that eM belongs to

Returns: true on successful assembly, otherwise false

When multi-point constraints are present, contributions from these are also added into the system right-hand-side vector, B.

Implements SystemMatrix.

References assemble(), LinAlg::DENSE, SystemVector::getPtr(), and SystemVector::getType().

◆ assemble() [8/9]

virtual bool SystemMatrix::assemble

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
	B	The system right-hand-side vector
[in]	e	Identifier for the element that eM belongs to

Returns: true on successful assembly, otherwise false

When multi-point constraints are present, contributions from these are also added into the system right-hand-side vector, B.

◆ assemble() [9/9]

bool SPRMatrix::assemble	(	int	e,
		const Matrix &	eM,
		const SAM &	sam,
		Real *	B = `nullptr`
	)

protected

Adds an element matrix into the associated system matrix.

Parameters

[in]	eM	The element matrix
[in]	sam	Auxiliary data for FE assembly management
	B	Pointer to the system right-hand-side vector
[in]	e	Identifier for the element that eM belongs to

Returns: true on successful assembly, otherwise false

References SystemMatrix::flagNonZeroEqs(), ierr, jWork, SAM::madof, SAM::meqn, SAM::mmceq, SAM::mmnpc, SAM::mpar, mpar, SAM::mpmceq, SAM::mpmnpc, msica, msifa, mtrees, mvarnc, mySam, utl::matrixBase< T >::ptr(), utl::matrix< T >::rows(), rWork, spradm_(), SAM::ttcc, and values.

◆ initAssembly()

void SPRMatrix::initAssembly	(	const SAM &	sam,
		char
	)

virtual

Initializes the element assembly process.

Parameters

[in] sam Auxiliary data describing the FE model topology, etc.

Must be called once before the element assembly loop. The SPR data structures are initialized and the all symbolic operations that are need before the actual assembly can start are performed.

Implements SystemMatrix.

References ierr, iWork, SAM::madof, SAM::meqn, SAM::minex, SAM::mmceq, SAM::mmnpc, SAM::mpar, mpar, SAM::mpmceq, SAM::mpmnpc, SAM::msc, msica, msifa, mtrees, mvarnc, mySam, SAM::ndof, SAM::neq, SAM::nnod, Real, sprpmp_(), sprprp_(), sprrnm_(), sprsas_(), sprsmb_(), sprtrs_(), and values.

◆ solve() [1/3]

virtual bool SystemMatrix::solve

inline

Solves the linear system of equations for a given right-hand-side.

Parameters

[in]	b	Right-hand-side vector
[out]	x	Solution vector

◆ solve() [2/3]

bool SPRMatrix::solve	(	SystemVector &	B,
		Real *
	)

virtual

Solves the linear system of equations for a given right-hand-side.

Parameters

B	Right-hand-side vector on input, solution vector on output

Implements SystemMatrix.

References LinAlg::DENSE, SystemVector::dim(), SAM::getNodeAndLocalDof(), SystemVector::getPtr(), SystemVector::getType(), ierr, iWork, mpar, msifa, mtrees, mySam, Real, rWork, sprsol_(), and values.

◆ solve() [3/3]

virtual bool SystemMatrix::solve

Solves the linear system of equations for a given right-hand-side.

Parameters

	b	Right-hand-side vector on input, solution vector on output
[out]	rc	Reciprocal condition number of the LHS-matrix (optional)

◆ solveEig()

bool SPRMatrix::solveEig	(	SPRMatrix &	B,
		RealArray &	val,
		Matrix &	vec,
		int	nev,
		Real	shift = `0.0`,
		int	iop = `1`
	)

Solves a generalized symmetric-definite eigenproblem.

Parameters

	B	Symmetric and positive definite mass matrix.
[out]	val	Computed eigenvalues
[out]	vec	Computed eigenvectors stored column by column
[in]	nev	The number of eigenvalues and eigenvectors to compute
[in]	shift	Eigenvalue shift
[in]	iop	Option telling whether to factorize matrix A or B.

The eigenproblem is assumed to be on the form A x = λ B x where A ( = *this ) and B both are assumed to be symmetric and B also to be positive definite. The eigenproblem is solved by the SAM library subroutine SPRLAN.

See also: SAM library documentation.

References ierr, iWork, mpar, msifa, mtrees, utl::matrixBase< T >::ptr(), Real, utl::matrix< T >::resize(), rWork, sprlax_(), and values.

Referenced by eig::solve().

The documentation for this class was generated from the following files:

src/LinAlg/SPRMatrix.h
src/LinAlg/SPRMatrix.C

Public Member Functions

Protected Member Functions

Private Types

Private Attributes

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ add()

◆ assemble() [1/9]

◆ assemble() [2/9]

◆ assemble() [3/9]

◆ assemble() [4/9]

◆ assemble() [5/9]

◆ assemble() [6/9]

◆ assemble() [7/9]

◆ assemble() [8/9]

◆ assemble() [9/9]

◆ initAssembly()

◆ solve() [1/3]

◆ solve() [2/3]

◆ solve() [3/3]

◆ solveEig()
