Class for representing the system matrix in ISTL format. More...

#include <ISTLMatrix.h>

Inheritance diagram for ISTLMatrix:

Collaboration diagram for ISTLMatrix:

[legend]

Public Member Functions
	ISTLMatrix (const ProcessAdm &padm, const LinSolParams &spar)
	Constructor.

	ISTLMatrix (const ISTLMatrix &A)
	Copy constructor.

	~ISTLMatrix () override
	The destructor frees the dynamically allocated arrays.

LinAlg::MatrixType	getType () const override
	Returns the matrix type.

size_t	dim (int=1) const override
	Returns the dimension of the system matrix.

SystemMatrix *	copy () const override
	Creates a copy of the system matrix and returns a pointer to it.

void	initAssembly (const SAM &sam, char) override
	Initializes the element assembly process. that are needed before the actual assembly can start are performed. More...

void	init () override
	Initializes the matrix to zero assuming it is properly dimensioned.

bool	endAssembly () override
	Copies the assembled matrix into iA.

bool	solve (SystemVector &B, Real *) override
	Solves the linear system of equations for a given right-hand-side. More...

bool	solve (const SystemVector &B, SystemVector &x) override
	Solves the linear system of equations for a given right-hand-side. More...

Real	Linfnorm () const override
	Returns the L-infinity norm of the matrix.

ISTL::Mat &	getMatrix ()
	Returns the ISTL matrix (for assignment).

const ISTL::Mat &	getMatrix () const
	Returns the ISTL matrix (for read access).

Public Member Functions inherited from SparseMatrix
	SparseMatrix (SparseSolver eqSolver=NONE, int nt=1)
	Default constructor creating an empty matrix.

	SparseMatrix (size_t m, size_t n=0, SparseSolver eqsolver=NONE)
	Constructor creating a \(m \times n\) matrix.

	SparseMatrix (const SparseMatrix &B)
	Copy constructor.

virtual	~SparseMatrix ()
	The destructor frees the dynamically allocated arrays.

virtual bool	lockPattern (bool doLock)
	Locks or unlocks the sparsity pattern. More...

void	resize (size_t r, size_t c=0, bool forceEditable=false)
	Resizes the matrix to dimension \(r \times c\). More...

bool	redim (size_t r, size_t c)
	Resizes the matrix to dimension \(r \times c\). More...

size_t	rows () const
	Query number of matrix rows.

size_t	cols () const
	Query number of matrix columns.

size_t	size () const
	Query total matrix size in terms of number of non-zero elements.

Real &	operator() (size_t r, size_t c)
	Index-1 based element access.

const Real &	operator() (size_t r, size_t c) const
	Index-1 based element reference.

const ValueMap &	getValues () const
	For traversal of the non-zero elements of an editable matrix.

void	printSparsity (std::ostream &os) const
	Print sparsity pattern - for inspection purposes.

void	printFull (std::ostream &os) const
	Print the matrix in full rectangular form. More...

virtual void	dump (std::ostream &os, LinAlg::StorageFormat format, const char *label)
	Dumps the system matrix on a specified format.

void	preAssemble (const SAM &sam, bool delayLocking)
	Initializes the element sparsity pattern based on node connections. More...

virtual void	preAssemble (const std::vector< IntVec > &MMNPC, size_t nel=0)
	Initializes the element sparsity pattern based on node connections. More...

virtual void	compressPattern ()
	Compresses the sparsity pattern.

virtual bool	assemble (const Matrix &eM, const SAM &sam, int e)
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const SAM &sam, SystemVector &B, int e)
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const SAM &sam, SystemVector &B, const IntVec &meq)
	Adds an element matrix into the associated system matrix. More...

virtual bool	assemble (const Matrix &eM, const IntVec &meq)
	Adds an element matrix into the associated system matrix. More...

bool	assembleCol (const RealArray &V, const SAM &sam, int n, size_t col)
	Adds a nodal vector into columns of a non-symmetric sparse matrix. More...

bool	assembleCol (Real val, const SAM &sam, int n, size_t col)
	Adds a scalar value into columns of a non-symmetric sparse matrix. More...

virtual bool	augment (const SystemMatrix &B, size_t r0, size_t c0)
	Augments a similar matrix symmetrically to the current matrix. More...

virtual bool	truncate (Real threshold=Real(1.0e-16))
	Truncates all small matrix elements to zero. More...

virtual void	mult (Real alpha)
	Multiplication with a scalar.

virtual bool	add (const SystemMatrix &B, Real alpha)
	Adds a matrix with similar sparsity pattern to the current matrix. More...

virtual bool	add (Real sigma, int ieq)
	Adds the constant σ to the diagonal of this matrix.

virtual bool	multiply (const SystemVector &B, SystemVector &C) const
	Performs the matrix-vector multiplication C = this B.

void	calcCSR (IntVec &iA, IntVec &jA) const
	Calculates compressed-sparse-row arrays from the element map. More...

bool	split (std::array< SparseMatrix, 4 > &Asub, const IntVec &meqn2) const
	Splits the matrix into four sub-matrices, A11, A12, A21, A22. More...

bool	getColumn (size_t c, Vector &col) const
	Extracts a specified column from the matrix. More...

bool	isFactored () const
	Returns whether the matrix has been factored or not.

virtual bool	solve (SystemVector &b, Real *rc=nullptr)=0
	Solves the linear system of equations for a given right-hand-side. More...

virtual bool	solve (const SystemVector &b, SystemVector &x)
	Solves the linear system of equations for a given right-hand-side. More...

Public Member Functions inherited from SystemMatrix
virtual	~SystemMatrix ()
	Empty destructor.

virtual bool	empty () const
	Checks if the matrix is empty.

bool	isZero () const
	Checks if the matrix have no non-zero contributions.

void	initNonZeroEqs ()
	Initializes the nonZeroEqs flags.

bool	flagNonZeroEqs (const IntVec &meq={})
	Flags the equations meq as pivots with non-zero contributions.

bool	flagNonZeroEqs (const SystemMatrix &B)
	Flags the non-zero equations from B as non-zero pivots in this.

virtual void	dump (const char *fileName, std::streamsize precision=0, LinAlg::StorageFormat format=LinAlg::FLAT)
	Dumps the system matrix to specified file.

virtual bool	load (const char *, bool=false)
	Loads the system matrix from specified file.

StdVector	operator* (const SystemVector &b) const
	Calculates a matrix-vector product.

StdVector	operator/ (const SystemVector &b)
	Solves a linear equation system.

Protected Member Functions
void	handleSolverReset ()
	Handles solver resets.

Protected Member Functions inherited from SparseMatrix
bool	optimiseRows (bool transposed=false)
	Converts the matrix to an optimized row-oriented format.

bool	optimiseCols ()
	Converts the matrix to an optimized column-oriented format. More...

bool	optimiseCols (const std::vector< std::set< int > > &dofc)
	Converts the matrix to an optimized column-oriented format. More...

bool	solveSAMG (Vector &B)
	Invokes the SAMG equation solver for a given right-hand-side. More...

bool	solveSLU (Vector &B)
	Invokes the SuperLU equation solver for a given right-hand-side. More...

bool	solveSLUx (Vector &B, Real *rcond)
	Invokes the SuperLU equation solver for a given right-hand-side. More...

bool	solveUMF (Vector &B, Real *rcond)
	Invokes the UMFPACK equation solver for a given right-hand-side. More...

virtual std::ostream &	write (std::ostream &os) const
	Writes the system matrix to the given output stream.

Protected Member Functions inherited from SystemMatrix
	SystemMatrix ()
	Default constructor.

	SystemMatrix (const SystemMatrix &a)
	Copy constructor.

Protected Attributes
std::unique_ptr< ISTL::Operator >	op
	The matrix adapter.

std::unique_ptr< ISTL::InverseOperator >	solver
	Solver to use.

std::unique_ptr< ISTL::Preconditioner >	pre
	Preconditioner to use.

ISTL::Mat	iA
	The actual ISTL matrix.

const ProcessAdm &	adm
	Process administrator.

ISTLSolParams	solParams
	Linear solver parameters.

int	nLinSolves = 0
	Number of linear solves.

Protected Attributes inherited from SparseMatrix
bool	factored
	Set to true when the matrix is factorized.

IntVec	IA
	Identifies the beginning of each row or column.

IntVec	JA
	Specifies column/row index of each nonzero element.

Vector	A
	Stores the nonzero matrix elements.

Additional Inherited Members
Public Types inherited from SparseMatrix
enum	SparseSolver { NONE , SUPERLU , S_A_M_G , UMFPACK }
	Available equation solvers for this matrix type.

Static Public Member Functions inherited from SystemMatrix
static SystemMatrix *	create (const ProcessAdm *adm, LinAlg::MatrixType mType, int num_thread_SLU=1)
	Static method creating a matrix of the given type.

static SystemMatrix *	create (const ProcessAdm *adm, LinAlg::MatrixType mType, const LinSolParams &spar)
	Static method creating a matrix of the given type.

Static Public Attributes inherited from SparseMatrix
static bool	printSLUstat = false
	Print solution statistics for SuperLU?

Detailed Description

Class for representing the system matrix in ISTL format.

Member Function Documentation

◆ initAssembly()

void ISTLMatrix::initAssembly	(	const SAM &	sam,
		char
	)

overridevirtual

Initializes the element assembly process. that are needed before the actual assembly can start are performed.

Parameters

[in] sam Auxiliary data describing the FE model topology, etc.

Reimplemented from SparseMatrix.

References SparseMatrix::cols(), SAM::getDofCouplings(), SAM::getNoEquations(), iA, SparseMatrix::preAssemble(), SparseMatrix::resize(), and SparseMatrix::rows().

◆ solve() [1/2]

bool ISTLMatrix::solve	(	const SystemVector &	B,
		SystemVector &	x
	)

overridevirtual

Solves the linear system of equations for a given right-hand-side.

Parameters

[in]	B	Right-hand-side vector
[out]	x	Solution vector

Reimplemented from SystemMatrix.

References ISTLVector::getVector(), handleSolverReset(), iA, nLinSolves, op, pre, SparseMatrix::rows(), ISTLSolParams::setupPC(), solParams, and solver.

◆ solve() [2/2]

bool ISTLMatrix::solve	(	SystemVector &	B,
		Real *
	)

overridevirtual

Solves the linear system of equations for a given right-hand-side.

Parameters

B	Right-hand-side vector on input, solution vector on output

Reimplemented from SparseMatrix.

References ISTLVector::getVector(), handleSolverReset(), iA, nLinSolves, op, pre, SparseMatrix::rows(), ISTLSolParams::setupPC(), solParams, and solver.

The documentation for this class was generated from the following files:

src/LinAlg/ISTLMatrix.h
src/LinAlg/ISTLMatrix.C
