Class representing a dual field for goal-oriented error estimation. More...

#include <DualField.h>

Inheritance diagram for DualRealFunc:

[legend]

Collaboration diagram for DualRealFunc:

[legend]

Public Member Functions
	DualRealFunc (const Vec3 &o, const Vec3 &n, const Vec3 &XZp, double d, double w=0.0, ASMbase *p=nullptr, int c=0)
	Constructor for 3D problems. More...

	DualRealFunc (const Vec3 &o, const Vec3 &n, double d, double w=0.0, ASMbase *p=nullptr, int c=0)
	Constructor for 2D problems (in XY-plane). More...

	DualRealFunc (const utl::Point &o, const Vec3Pair &d, ASMbase *p=nullptr, double eps=0.0, int c=0)
	Constructor for point extraction. More...

virtual	~DualRealFunc ()
	Empty destructor.

virtual unsigned char	getType () const
	Returns the function type flag.

const Vec3 &	x () const
	Returns the local X (normal) direction of the cross section.

const Vec3 &	y () const
	Returns the local Y (tangent) direction of the cross section.

Vec3	z () const
	Returns the local Z (2nd tangent) direction of the cross section.

double	ecc (const Vec3 &X, int i) const
	Returns the offset from the cross section origin \ b X0.

double	value (const Vec3 &X, bool ignoreDomain=false) const
	Returns the function value at the given point. More...

bool	isPointExtraction () const
	Returns true, if the dual field is for extracting point values.

virtual bool	inDomain (const Vec3 &X) const
	Checks if the point X is within the function domain.

virtual bool	initPatch (size_t idx)
	Returns true if current patch is affected by this function.

Public Member Functions inherited from RealFunc
unsigned char	getType () const override
	Returns the function type flag.

std::vector< Real >	getValue (const Vec3 &X) const override
	Returns the function value as an array.

virtual Vec3	gradient (const Vec3 &X) const
	Evaluates first derivatives of the function.

virtual SymmTensor	hessian (const Vec3 &X) const
	Evaluates second derivatives of the function.

Real	getScalarValue (const Vec3 &X) const override
	Returns a representative scalar equivalent of the function value.

Real	timeDerivative (const Vec3 &X) const
	Returns the time derivative of the function.

Public Member Functions inherited from utl::SpatialFunction< Real >
virtual Real	deriv (const Vec3 &, int) const
	Returns a first-derivative of the function.

virtual Real	dderiv (const Vec3 &, int, int) const
	Returns a second-derivative of the function.

Public Member Functions inherited from utl::Function< Arg, Result >
virtual	~Function ()
	Empty destructor.

virtual bool	isZero () const
	Returns whether the function is identically zero or not.

virtual bool	isConstant () const
	Returns whether the function is time-independent or not.

Result	operator() (const Arg &x) const
	Operator returning the function value for the given argument.

Public Member Functions inherited from FunctionBase
virtual	~FunctionBase ()
	Empty destructor.

size_t	dim () const
	Returns the number of components of the return value.

virtual void	setParam (const std::string &, Real)
	Sets an additional parameter in the function.

void	setParam (const std::string &name, const Vec3 &value)
	Sets additional parameter values in the function.

Protected Member Functions
virtual double	evaluate (const Vec3 &X) const
	Evaluates the dual field function.

Protected Member Functions inherited from RealFunc
	RealFunc ()
	The constructor is protected to allow sub-class instances only.

Protected Member Functions inherited from utl::SpatialFunction< Real >
	SpatialFunction (const Real &val)
	The constructor is protected to allow sub-class instances only.

virtual std::vector< Real >	evalGradient (const Vec3 &) const
	Returns the gradient of the function as a 1D array.

virtual std::vector< Real >	evalHessian (const Vec3 &) const
	Returns the hessian of the function as a 1D array.

virtual std::vector< Real >	evalTimeDerivative (const Vec3 &) const
	Returns the time derivatives of the function as a 1D array.

Protected Member Functions inherited from utl::Function< Arg, Result >
	Function ()
	The constructor is protected to allow sub-class instances only.

virtual Result	evaluate (const Arg &x) const =0
	Evaluates the function for the argument x.

Protected Member Functions inherited from FunctionBase
	FunctionBase ()
	The constructor is protected to allow sub-class instances only.

Private Attributes
short int	comp
	Result component to extract for (0 if used as weight)

utl::Point	X0
	Coordinates of cross section origin or reference point.

Vec3	normal
	Outward-directed normal vector of the cross section.

Vec3	tangent
	Vector defining the local y-direction of the cross section.

double	depth
	Depth of the the dual function domain (0=point extraction)

double	width
	Width of the the dual function domain (0=infinite)

Vec3	Xll
	Lower-left corner of box domain for point extraction.

Vec3	Xur
	Upper-right corner of box domain for point extraction.

ASMbase *	patch
	The patch that this field is defined on.

std::set< int >	Delem
	List of elements in domain.

Additional Inherited Members
Public Types inherited from utl::Function< Arg, Result >
typedef Arg	Input
	Input type.

typedef Result	Output
	Output type.

Protected Attributes inherited from utl::SpatialFunction< Real >
Real	zero
	Return value for default implementations of derivatives.

Protected Attributes inherited from FunctionBase
size_t	ncmp
	Number of components in the return value.

Detailed Description

Class representing a dual field for goal-oriented error estimation.

Constructor & Destructor Documentation

◆ DualRealFunc() [1/3]

DualRealFunc::DualRealFunc	(	const Vec3 &	o,
		const Vec3 &	n,
		const Vec3 &	XZp,
		double	d,
		double	w = `0.0`,
		ASMbase *	p = `nullptr`,
		int	c = `0`
	)

Constructor for 3D problems.

Parameters

[in]	o	Origin of local cross section coordinate system
[in]	n	Cross section normal
[in]	XZp	Point in the local XZ-plane
[in]	d	Depth of dual function domain
[in]	w	Width of dual function domain (0=infinite)
[in]	p	The affected patch (null=all)
[in]	c	Component index to do extraction for

References comp, Vec3::cross(), depth, normal, Vec3::normalize(), patch, tangent, width, and X0.

◆ DualRealFunc() [2/3]

DualRealFunc::DualRealFunc	(	const Vec3 &	o,
		const Vec3 &	n,
		double	d,
		double	w = `0.0`,
		ASMbase *	p = `nullptr`,
		int	c = `0`
	)

Constructor for 2D problems (in XY-plane).

Parameters

[in]	o	Origin of local cross section coordinate system
[in]	n	Cross section normal
[in]	d	Depth of dual function domain
[in]	w	Width of dual function domain (0=infinite)
[in]	p	The affected patch (null=all)
[in]	c	Component index to do extraction for

References comp, depth, normal, Vec3::normalize(), patch, tangent, width, Vec3::x, and Vec3::y.

◆ DualRealFunc() [3/3]

DualRealFunc::DualRealFunc	(	const utl::Point &	o,
		const Vec3Pair &	d,
		ASMbase *	p = `nullptr`,
		double	eps = `0.0`,
		int	c = `0`
	)

Constructor for point extraction.

Parameters

[in]	c	Component index to do extraction for
[in]	o	Point to extract the point quantity at
[in]	d	Lower-left and upper-rigth corner of function domain
[in]	p	The affected patch (null=all)
[in]	eps	Parameter tolerance for searching elements around a point

References comp, depth, normal, patch, tangent, width, Vec3::x, and Vec3::y.

Member Function Documentation

◆ value()

double DualRealFunc::value	(	const Vec3 &	X,
		bool	ignoreDomain = `false`
	)		const

Returns the function value at the given point.

Parameters

[in]	X	Spatial evaluation point
[in]	ignoreDomain	If true, the function is evaluated without considering the boundaries of the function domain. Otherwise, it is assumed identically zero outside these boundaries.

References comp, depth, ecc(), inDomain(), normal, and X0.

Referenced by evaluate(), DualVecFunc::evaluate(), and DualVecFunc::getScalarValue().

The documentation for this class was generated from the following files:

src/ASM/DualField.h
src/ASM/DualField.C
