ControlFIFO Class Reference

This class enables simple application control over a FIFO. More...

#include <ControlFIFO.h>

Collaboration diagram for ControlFIFO:

Public Member Functions
	ControlFIFO ()
	Default constructor.
	~ControlFIFO ()
	The destructor tears down the opened fifo and removes the file.
void	registerCallback (ControlCallback &callback)
	Registers a callback handler. More...
bool	open (const char *name="ifem-control")
	Opens the fifo and prepares for receiving. More...
void	poll ()
	Polls for new data in the fifo.

Private Attributes
std::string	fifo_name
	Name of filesystem entry of our fifo.
int	fifo
	fifo handle
std::map< std::string, ControlCallback * >	callbacks
	Registered callbacks.

Detailed Description

This class enables simple application control over a FIFO.

A fifo is opened, and users can write instructions to the fifo in XML format. These are then processed between time steps.

Member Function Documentation

open()

bool ControlFIFO::open

(

const char *

name = "ifem-control"

)

Opens the fifo and prepares for receiving.

Parameters

[in]

name

The name of the filesystem entry for the fifo

References fifo, and fifo_name.

Referenced by IFEM::Init().

registerCallback()

void ControlFIFO::registerCallback

(

ControlCallback &

callback

)

Registers a callback handler.

Parameters

[in]

callback

The callback handler to register

References callbacks, and ControlCallback::GetContext().

Referenced by IFEM::registerCallback().

---

The documentation for this class was generated from the following files:

• src/Utility/ControlFIFO.h
• src/Utility/ControlFIFO.C
